Keysight Technologies E8267D Installation and operation manual

Notice: This document contains references to Agilent.
Please note that Agilent’s Test and Measurement busi-
ness has become Keysight Technologies. For more in-
formation, go to www.keysight.com.
Keysight E8267D PSG Signal Generators
Add Option 005 (Internal Hard Drive)
Kit Part Number: E8251-60387
Installation Note
Part Number: E8251-90387
Printed in USA August 2014

Notice
The information contained in this document is subject to change without notice.
Keysight Technologies makes no warranty of any kind with regard to this material, including but
not limited to, the implied warranties ofmerchantability andfitness for a particular purpose.
Keysight Technologies shall not be liable for errors contained herein orfor incidental or
consequential damages in connection with the furnishing, performance, or use of this material.
©Copyright 2004-2014 Keysight Technologies Inc.

3
Add Option 005 (Internal Hard Drive)
Kit Part Number: E8251-60387
Introduction
This upgrade kit adds Option 005 (Internal Hard Drive) to the E8267D (Vector) PSG Signal Generators.
Installation includes the following major steps, starting on page 5:
1. Check signal generator functionality.
2. Remove the outer and inner signal generator covers.
3. Install A34 Internal Hard Drive.
4. Activate Option 005.
5. Verify proper installation of Option 005.
6. Re-assemble the signal generator.
Product Affected: . . . . . . . . . . . . . . . . . . . . . . . . . E8267D
Serial Numbers: . . . . . . . . . . . . . . . . . . . . . . . . . . All
Options: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
To Be Performed By: . . . . . . . . . . . . . . . . . . . . . . (X) Agilent Technologies Service Center
(X) Personnel Qualified by Agilent Technologies
(X) Customer
Estimated Installation Time: . . . . . . . . . . . . . . . 1.0 hours
Estimated Verification Time: . . . . . . . . . . . . . . . 0.5 hours

4
Installation Kit Parts List
Tools Required
• TORX T-10 driver
• TORX T-15 driver
• TORX T-20 driver
• 5/16” open-ended wrench
• Needle-nose pliers
Item Quantity Description Part Number
11Installation Note E8251-90387
2 1 Screw M3x0.5 8mm-LG 0515-1521
3 1 Internal Hard Drive (Option 005) E8251-60115
4 1 Entitlement Certificate 5964-5143
5 1 Entitlement Certificate Envelope 5967-7169

5
Safety Considerations
WARNING Before you disassemble the signal generator, turn the power switch off
and unplug the power cord. Failure to unplug the signal generator can
result in personal injury.
CAUTION Electrostatic discharge (ESD) can damage or destroy electronic components. All
work on electronic assemblies should be performed at a static-safe workstation.
Check Signal Generator Functionality
Use the following procedure to confirm that the signal generator powers up and the internal check
identifies no errors. The internal check evaluates the operation of the signal generator and returns an error
message if it detects a problem.
NOTE When the signal generator is first connected to ac line power, the error message
ERROR 514, Reference Oven Cold occurs which causes both the OVEN COLD annunciator
and the ERR annunciator to turn on.
After approximately five minutes, the OVEN COLD annunciator automatically clears, but the
ERR annunciator remains on until all errors are cleared from the error queue.
1. Turn on the signal generator and let it warm up for at least five minutes.
2. Run the signal generator self-test by pressing Utility > Instrument Info/Help Mode > Self Test >
Run Complete Self Test. Upon completion a summary of the self-test will be displayed. Use the
E8257D/67D PSG Service Guide to troubleshoot any failures detected by the test.
NOTE Some circuits may require up to 50 minutes to warm up before passing the self-test. If
self-tests continue to fail after 50 minutes of warm up, troubleshoot the instrument.
3. Check to see if the ERR annunciator is on.
•IftheERR annunciator is on, review the error messages in the error queue by pressing
Utility > Error Info. The first page of error messages in the error queue appears in the display text
area. (Refer to the signal generator error messages document for information about each error
message.)
After resolving all problems causing errors, press Clear Error Queue(s).
•IftheERR annunciator is off, the signal generator functionality check has passed.

6
Remove the Outer and Inner Signal Generator Covers
Remove the Outer Cover
Refer to Figure 1.
1. Disconnect the power cord.
2. Using a T-20 driver, loosen the two screws (1) and remove the strap handle (2).
3. Using a T-15 driver, remove the center screws (3) on the four rear-panel feet (4).
4. Remove the four bottom feet (5) from the cover by lifting the tab and sliding the foot toward the tab.
5. Place the signal generator on its side.
6. Tilt the signal generator forward and slide the outer cover (6) back to remove it from the frame.
Remove the Inner Top Cover
Refer to Figure 2.
1. Using a T-10 driver, remove the screws (1) from the inner-top cover (2). There eleven screws for E8267D.
2. Remove the inner-top cover.

7
Figure 1 Outer Cover Removal

8
Figure 2 Inner Top Cover Removal

9
Install the A34 Internal Hard Drive
Refer to Figure 3.
1. Position the signal generator with the RF deck on top and the rear panel facing you.
2. Using the T-10 drive, install the screw (1) to attach the A34 Internal Hard Drive to the A19 Power
Supply.
3. Connect the W66 ribbon cable (provided in kit with one end connected to the A34 Internal Hard Drive)
to the A18 CPU P2.
Figure 3 A34 Internal Hard Drive
Activate Option 005
1. Follow the instructions on the Entitlement Certificate.
Verify Proper Installation of Option 005
1. Press: Utility > Instrument Info > Help Info > Options Info.
2. Make sure Option 005 is listed.
NOTE If you enable an option that does not have the required hardware installed, the menus for
that option will be activated but the option cannot operate.
A34
W66 A18 A19
1

10
Re-Assemble the Signal Generator
Refer to Figure 1 and Figure 2.
1. Reinstall the inner and outer instrument covers by reversing the order for removal.
2. Torque all T-10 screws to 9 in-lbs.
3. Torque all T-15 and T-20 screws to 21 in-lbs.
