Keysight E4982A
LCR Meter
Installation Guide
Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 - TestEquipmentDepot.com

Notices
© Keysight Technologies 2012, 2015
No part of this manual may be reproduced
in any form or by any means (including
electronic storage and retrieval or transla-
tion into a foreign language) without prior
agreement and written consent from Key-
sight Technologies as governed by United
States and international copyright laws.
Manual Printing History
The manual’s printing date and part num-
ber indicate its current edition. The printing
date changes when a new edition is printed
(minor corrections and updates that are
incorporated at reprint do not cause the
date to change). The manual part number
changes when extensive technical
changes are incorporated.
February 2012 Edition 1
February 2015 Edition 2
.
Manual Part Number
E4982-90000
Edition
Edition 2, February 2015
Printed in Malaysia
Keysight Technologies
1400 Fountaingrove Parkway
Santa Rosa, CA 95403 USA
Warranty
The material contained in this docu-
ment is provided “as is,” and is sub-
ject to being changed, without notice,
in future editions. Further, to the max-
imum extent permitted by applicable
law, Keysight disclaims all warran-
ties, either express or implied, with
regard to this manual and any infor-
mation contained herein, including
but not limited to the implied warran-
ties of merchantability and fitness for
a particular purpose. Keysight shall
not be liable for errors or for inciden-
tal or consequential damages in con-
nection with the furnishing, use, or
performance of this document or of
any information contained herein.
Should Keysight and the user have a
separate written agreement with
warranty terms covering the material
in this document that conflict with
these terms, the warranty terms in
the separate agreement shall control.
Technology Licenses
The hardware and/or software described in
this document are furnished under a
license and may be used or copied only in
accordance with the terms of such license
Restricted Rights Legend
If software is for use in the performance of
a U.S. Government prime contract or sub-
contract, Software is delivered and
licensed as “Commercial computer soft-
ware” as defined in DFAR 252.227-7014
(June 1995), or as a “commercial item” as
defined in FAR 2.101(a) or as “Restricted
computer software” as defined in FAR
52.227-19 (June 1987) or any equivalent
agency regulation or contract clause. Use,
duplication or disclosure of Software is
subject to Keysight Technologies’ standard
commercial license terms, and non-DOD
Departments and Agencies of the U.S. Gov-
ernment will receive no greater than
Restricted Rights as defined in FAR
52.227-19(c)(1-2) (June 1987). U.S. Govern-
ment users will receive no greater than
Limited Rights as defined in FAR 52.227-14
(June 1987) or DFAR 252.227-7015 (b)(2)
(November 1995), as applicable in any
technical data.
Safety Notices
CAUTION
A CAUTION notice denotes a haz-
ard. It calls attention to an operat-
ing procedure, practice, or the like
that, if not correctly performed or
adhered to, could result in damage
to the product or loss of important
data. Do not proceed beyond a
CAUTION notice until the indicated
conditions are fully understood and
met.
WARNING
A WARNING notice denotes a
hazard. It calls attention to an
operating procedure, practice, or
the like that, if not correctly per-
formed or adhered to, could result
in personal injury or death. Do not
proceed beyond a WARNING
notice until the indicated condi-
tions are fully understood and met.

LCR Meter 3
Caution
Do not exceed the operating input power, voltage,
and current level and signal type appropriate for the
instrument being used, refer to your instrument's Function
Reference.
Electrostatic discharge (ESD) can damage the highly
sensitive microcircuits in your instrument. ESD damage is
most likely to occur as the test fixtures are being connected
or disconnected. Protect them from ESD damage by wearing
a grounding strap that provides a high resistance path to
ground. Alternatively, ground yourself to discharge any static
charge built- up by touching the outer shell of any grounded
instrument chassis before touching the test port connectors.

4LCR Meter
Safety Summary
When you notice any of the unusual conditions listed below,
immediately terminate operation and disconnect the power
cable.
Contact your local Keysight Technologies sales representative
or authorized service company for repair of the instrument.
If you continue to operate without repairing the instrument,
there is a potential fire or shock hazard to the operator.
•Instrument operates abnormally.
•Instrument emits abnormal noise, smell, smoke or a
spark- like light during operation.
•Instrument generates high temperature or electrical shock
during operation.
•Power cable, plug, or receptacle on instrument is
damaged.
•Foreign substance or liquid has fallen into the instrument.

LCR Meter 5
Manufacturer’s Declaration
Herstellerbescheinigung
GERA- USCHEMISSION
LpA < 70 dB
am Arbeitsplatz
normaler Betrieb
nach DIN 45635 T. 19
Manufacturer's Declaration
ACOUSTIC NOISE EMISSION
LpA < 70 dB
operator position
normal operation
per ISO 7779

6LCR Meter
Regulatory Compliance Information
This product complies with the essential requirements of the
following applicable European Directives, and carries the CE
marking accordingly:
•The Low Voltage Directive 2006/95/EC
•The EMC Directive 2004/108/EEC
To obtain Declaration of Conformity, please contact your
local Keysight Technologies sales office, agent or distributor.

LCR Meter 7
Safety Notice Supplement
•This equipment complies with EN/IEC61010- 1:2001.
•This equipment is of MEASUREMENT CATEGORY I (CAT
I). Do not use for CAT II, III, or IV.
•Do not connect the measuring terminals to mains.
•This equipment is a POLLUTION DEGREE 2, INDOOR
USE product.
•This equipment is tested in stand- alone condition and in
combination with the accessories supplied by Keysight
Technologies against the requirement of the standards
described in the Declaration of Conformity. If it is used
as a system component, compliance of related regulations
and safety requirements are to be confirmed by the
builder of the system.

8LCR Meter
General Safety Precautions
The following general safety precautions must be observed
during all phases of operation, service, and repair of this
instrument. Failure to comply with these precautions or with
specific WARNINGS elsewhere in this manual may impair the
protection provided by the equipment. Such noncompliance
would also violate safety standards of design, manufacture,
and intended use of the instrument. Keysight Technologies
assumes no liability for the customer’s failure to comply
with these precautions.
•Ground the Instrument
To avoid electric shock, the instrument chassis and
cabinet must be grounded with the supplied power cable’s
grounding prong.
•DO NOT Operate in an Explosive Atmosphere
Do not operate the instrument in the presence of
inflammable gasses or fumes. Operation of any electrical
instrument in such an environment clearly constitutes a
safety hazard.
•Keep Away from Live Circuits
Operators must not remove instrument covers. Component
replacement and internal adjustments must be made by
qualified maintenance personnel. Do not replace
components with the power cable connected. Under
certain conditions, dangerous voltage levels may remain
even after the power cable has been disconnected. To
avoid injuries, always disconnect the power and discharge
circuits before touching them.
•DO NOT Service or Adjust the Instrument Alone
Do not attempt internal service or adjustment unless
another person, capable of rendering first aid and
resuscitation, is present.
•DO NOT Substitute Parts or Modify the Instrument
NOTE
The E4982A complies with INSTALLATION CATEGORY II as well as
POLLUTION DEGREE 2 in IEC61010-1. The E4982A is an INDOOR USE
product.
NOTE
The LEDs in the E4982A are Class 1 in accordance with IEC60825-1,
CLASS 1 LED PRODUCT.

LCR Meter 9
To avoid the danger of introducing additional hazards, do
not install substitute parts or perform unauthorized
modifications to the instrument. Return the instrument to
a Keysight Technologies Sales and Service Office for
service and repair to ensure that safety features are
maintained in operational condition.
•Dangerous Procedure Warnings
Warnings, such as the example below, precede potentially
dangerous procedures throughout this manual.
Instructions contained in the warnings must be followed.
WARNING
Dangerous voltage levels, capable of causing death, are present in
this instrument. Use extreme caution when handling, testing, and
adjusting this instrument.

10 LCR Meter
Safety Symbols
General definitions of safety symbols used on the instrument
or in manuals are listed below.
Instruction Manual symbol: the product is marked
with this symbol when it is necessary for the user
to refer to the instrument manual.
Alternating current.
Direct current.
On (Supply).
Off (Supply).
In- position of push- button switch.
Out- position of push- button switch.
A chassis terminal; a connection to the
instrument’s chassis, which includes all exposed
metal structure.
Standby.
WARNING
This warning sign denotes a hazard. It calls attention to a
procedure, practice, or condition that, if not correctly performed or
adhered to, could result in injury or death to personnel.
CAUTION
This Caution sign denotes a hazard. It calls attention to a procedure,
practice, or condition that, if not correctly performed or adhered to,
could result in damage to or destruction of part or all of the
instrument.
NOTE
This Note sign denotes important information. It calls attention to a
procedure, practice, or condition that is essential for the user to
understand.

LCR Meter 11
Certification
Keysight Technologies certifies that this product met its
published specifications at the time of shipment from the
factory. Keysight Technologies further certifies that its
calibration measurements are traceable to the United States
National Institute of Standards and Technology, to the extent
allowed by the Institution’s calibration facility or by the
calibration facilities of other International Standards
Organization members.
Documentation Warranty
The material contained in this document is provided "as is,"
and is subject to being changed, without notice, in future
editions. Further, to the maximum extent permitted by
applicable law, Keysight disclaims all warranties, either
express or implied with regard to this manual and any
information contained herein, including but not limited to
the implied warranties of merchantability and fitness for a
particular purpose. Keysight shall not be liable for errors or
for incidental or consequential damages in connection with
the furnishing, use, or performance of this document or any
information contained herein. Should Keysight and the user
have a separate written agreement with warranty terms
covering the material in this document that conflict with
these terms, the warranty terms in the separate agreement
will control.
Exclusive Remedies
The remedies provided herein are Buyer’s sole and exclusive
remedies. Keysight Technologies shall not be liable for any
direct, indirect, special, incidental, or consequential damages,
whether based on contract, tort, or any other legal theory.
Assistance
Product maintenance agreements and other customer
assistance agreements are available for Keysight Technologies
products.
For any assistance, contact your nearest Keysight
Technologies Sales and Service Office. Addresses are
provided at the back of this manual.

12 LCR Meter
Manuals for E4982A
Keysight provides the following three manuals for E4982A.
Installation Guide
The installation guide (this manual) provides start up setup
information when you use the E4982A for the first time and
troubleshooting information when the Windows cannot be
boot up. See this manual first when you use the E4982A for
the first time.
Online Help
The online help provides the information about the quick
start, measurement operation, programming, handler
interface. This is pre- installed in the E4982A. Press [Help]
hard key on the front panel to open. Quick Start helps in
understanding the E4982A operation quickly.
The latest version of online help is available at:
http://ena.support.keysight.com/e4982a/manuals/webhelp/eng
The online help has context sensitive help, which is a great
feature of the E4982A help. It allows you to get information
about the selected softkey by pressing the Help key in the
E4982A or by pressing F1 in a keyboard attached to the
E4982A or by clicking the help button in a dialog box. With

LCR Meter 13
context sensitive help, users can receive information quickly
about the area the user is working in the firmware of the
E4982A. It provides information relevant to the task that
needs to be accomplished and reduces the time to search
relevant information required to complete a task.
Service Guide
The service manual provides information about the parts,
troubleshooting, performance test, adjustment and service
menu.

14 LCR Meter
In This Guide...
The following shows the contents of this manual.
Chapter 1, "Installation"
This chapter provides information about how to set up the
Keysight E4982A.
Chapter 2, "Troubleshooting"
This chapter describes the troubleshooting during start up
and the procedure of the operating system (OS) recovery
when the Windows XP OS has been damaged.

Network Analyzer 15
Contents
Regulatory Compliance Information 6
Safety Notice Supplement 7
Checking the Shipment 18
Environmental Requirements 20
Operating Environments 20
Ventilation Requirement 20
Protection Against Electrostatic Discharge (ESD) 21
Ensuring Adequate Free Space around Meter for Immediate
Disconnection of Power Cable in Case of Emergency 22
Installing Front Handles/Rack Mounting Flanges 23
How to Install the Handle Kit (Option 1CN) 24
How to Install the Rack-mount Kit (Option 1CM) 25
How to Install the Rack-mount and Handle Kit (Option 1CP) 25
Connecting Test Head 27
Connecting the DUT when using a special test fixture 27
When using the test head fixed on a handler, etc. 29
Caution for connecting the SMA connector to the test head
connector 30
Connecting Mouse and Keyboard 32
Power Supply 33
Verification of the Power Supply 33
Verification and Connection of Power Cable 33
Blown Fuses 34
Starting the E4982A 35
Turning the Power ON and OFF 35
Disconnection from Supply Source 36
Initial Registration of E4982A 38
Calibration of the Touch Screen 44
Troubleshooting during Startup 48
System Recovery 49

16 Network Analyzer
Notes on executing the factory recovery function 49
Procedure to execute the factory recovery 49

Keysight E4982A LCR Meter
Installation Guide
1
Installation
Checking the Shipment 18
Environmental Requirements 20
Installing Front Handles/Rack Mounting Flanges 23
Connecting Mouse and Keyboard 32
Power Supply 33
Blown Fuses 34
Starting the E4982A 35
Initial Registration of E4982A 38
Calibration of the Touch Screen 44
This chapter provides information about how to set up the
Keysight E4982A.

18 LCR Meter
1Installation
Checking the Shipment
After you receive the meter, carry out checks during
unpacking according to the following procedure.
Step 1. Check that the packing box or shock- absorbing
material used to package the meter has not been damaged.
Step 2. Check the packaged items supplied with the meter
for any damage or defects.
Step 3. By referring to the furnished contents list, check
that all packaged items supplied with the meter have been
received as per the specified options.
Step 4. After checking, if one of the following applies,
contact your nearest Keysight Technologies sales and service
office.
1The packing box or shock- absorbing material used to
package the meter has been damaged or the
shock- absorbing material has traces where extreme force
has been applied.
2A packaged item supplied with the meter has mechanical
damage or defects.
3A packaged item supplied with the meter is missing.
4A fault has been detected in the subsequent operation
check of the meter.
If an abnormality is detected in step 1, contact the
company that transported the meter as well as your
nearest Keysight Technologies sales and service office. For
WARNING
When unpacking the meter, if the exterior of the meter (such as
the cover, front/rear panel, LCD screen, power switch, and port
connectors) appear to be damaged during transport, do not turn
on the power switch. Otherwise, you may get an electric shock.
NOTE
If the packing box or shock-absorbing material has been damaged, leave the
packing box and shock-absorbing material as is until other inspection items
are checked as follows.
