System Sensor RTS151 User manual

NOTE: RTS151 replaces RTS451.
NOTICE: This manual shall be left with the owner/user of this equipment.
NOTE: A test coil is required only for use with D2/DNR/DH400/DH500 mod-
els. For D2 models order part #DCoil. For the DH400/500 models order part
is #Coil.
GENERAL INFORMATION
System Sensor’s RTS151 is an automatic fire detector accessory designed to
test a remotely located detector. Consult detector installation instructions for
additional information.
The National Fire Protection Association has published codes, standards, and
recommended practices for the installation and use of the above product. It is
recommended that the installer be familiar with these requirements, with local
codes, and any special requirements of the local authority having jurisdiction.
RTS151 CONTENTS
1 RTS151 remote test station
1 screw pack (2 mounting screws)
1 M02-04 test magnet
WIRING OF RTS151
Consult the appropriate detector installation instructions for the applicable
wiring diagram. The RTS151 mounts to a single gang box (2 1/2” minimum
depth), or directly to the wall or ceiling.
See Figure 8 for wiring diagram of RTS151 with Duct Smoke Detectors.
In Canadian applications, the RTS151 is intended to be located in the same
room as the smoke detector and within 60 feet of the unit.
OPERATION
Test Function
Place and hold the painted side of the magnet to the test location RTS151.
Alarm Indication
With the magnet in place some time will elapse (40 sec. maximum) depend-
ing on the detector type, before the alarm indicating LED will light.
Reset Function
Gently insert a 1/8˝ maximum diameter tool into the hole until it stops and
LED turns off. The RTS151 is capable of resetting only certain System Sensor
models of detectors. Refer to detector installation instructions for additional
information.
SPECIFICATIONS
Dimensions: 4.8˝ H × 2.90˝ W × 1.4˝ D
Weight: .16 lbs.
Power Requirements
Alarm LED: 2.8 – 32 VDC, 10 mA max.
Coil Current: 95 mA max.
Test Switch: 10 VA @ 32 VDC
Reset Switch: 10 VA @ 32 VDC
Alarm Response Time: 40 sec. max.
Temperature: –10°C to 60°C (14°F to 140°F)
Humidity: 95% RH Non-condensing Max
Listing: UL, FM, CE
FIGURE 1. RTS151 REMOTE TEST STATION:
FIGURE 2. WIRING DIAGRAM FOR RTS151 TO D4120 4-WIRE DUCT
SMOKE DETECTOR:
RTS151
Remote Test Station
INSTALLATION AND MAINTENANCE INSTRUCTIONS
3825 Ohio Avenue, St. Charles, Illinois 60174
1-800-SENSOR2, FAX: [phone]
www.systemsensor.com
H0196-01
H0582-20
I56-0469-015
19
20
15
2
1
5
4
3
D4120
RTS151
(RED LED)
ALARM
FIELD
INSTALLED
JUMPER
11
2
AUX OUT +
AUX OUT –
ALARM
R TEST
R RESET
RTS451/RTS451KEY
RTS151/RTS151KEY
JUMPER
4
5
3
2
1
TEST COIL +
TEST COIL –
COMM +
OUT
(CONV ONLY) +
COMM –
RA/RTS –
RA +
RTS +
H0633-00
FIGURE 3. WIRING DIAGRAM FOR RTS151 TO DNR 2-WIRE DUCT
SMOKE DETECTOR WITH REMOTE TEST CAPABLE HEAD:
1 I56-0469-015
06-10

THREE-YEAR LIMITED WARRANTY
System Sensor warrants its enclosed product to be free from defects in materials and
workmanship under normal use and service for a period of three years from date of
manufacture. System Sensor makes no other express warranty for the enclosed product.
No agent, representative, dealer, or employee of the Company has the authority to in-
crease or alter the obligations or limitations of this Warranty. The Company’s obligation
of this Warranty shall be limited to the replacement of any part of the product which is
found to be defective in materials or workmanship under normal use and service during
the three year period commencing with the date of manufacture. After phoning System
Sensor’s toll free number 800-SENSOR2 (736-7672) for a Return Authorization number,
send defective units postage prepaid to: Honeywell, 12220 Rojas Drive, Suite 700, El Paso
TX 79936, USA. Please include a note describing the malfunction and suspected cause
of failure. The Company shall not be obligated to replace units which are found to be
defective because of damage, unreasonable use, modifications, or alterations occurring
after the date of manufacture. In no case shall the Company be liable for any consequen-
tial or incidental damages for breach of this or any other Warranty, expressed or implied
whatsoever, even if the loss or damage is caused by the Company’s negligence or fault.
Some states do not allow the exclusion or limitation of incidental or consequential dam-
ages, so the above limitation or exclusion may not apply to you. This Warranty gives you
specific legal rights, and you may also have other rights which vary from state to state.
FIGURE 5. WIRING DIAGRAM FOR RTS151 TO DH100ACDC 4-WIRE
DUCT SMOKE DETECTOR:
FIGURE 6. WIRING DIAGRAM FOR RTS151 TO DH100 2-WIRE DUCT
SMOKE DETECTOR:
15
20
2
11
2
1
Alarm Signal +
Aux. Power –
Reset
Test
(Red LED) Alarm
DH100ACDC RTS151
5
4
3Reset
Test
Field
Installed
Jumper
1
2
3
4
5
6
3
4
5
Test +
Test / Reset –
Reset +
Test
Reset
RA +
RA –
V Out +
DH100 RTS151
6
2
1Alarm
LED
No Connection
H0198-04
H0612-11
H0197-01
FIGURE 7. WIRING DIAGRAM FOR RTS151 TO DH400ACDC DUCT
SMOKE DETECTOR:
ALARM SIGNAL (+)
AUX POWER (–)
5
6
1
2
R
E
D
5
3
4
3RESET
TEST
4
FIELD
INSTALLED
JUMPER
RESET (–)
TEST (–)
DH400ACDC RTS151
H0149-02
FIGURE 8. WIRING DIAGRAM FOR RTS151 TO BEAM1224/BEAM1224S
SMOKE DETECTOR:
1
2
3
4
5
3
2
1
5
4
RTS151BEAM1224/BEAM1224S
REMOTE ALARM OUT
AUX (–)
TEST INPUT
REMOTE TROUBLE OUTPUT
RESET INPUT
TEST
RESET
T2-3
T3-3
T2-4
T2-2
T2-1
OPTIONAL YELLOW LED
(RED LED) ALARM
H0586-03
24 VAC (+10%, –15%)
FULL WAVE RECTIFIED,
UNFILTERED POWER
MAY BE USED
RTS151
(OPTIONAL) REMOTE
TEST STATION
MAGNET
TEST
SWITCH
ALARM
LED (RED)
4
5
2
1(+)
(–)
+ RA
+ RTS
– RA
+ TEST COIL
– TEST COIL
+ IN
+ OUT
–
(–)
(+)
D2
24 VDC
AUX POWER
SUPPLIED
BY USER
(100mA
SUPPLY)
RTS151
(OPTIONAL) REMOTE
TEST STATION
24 VAC (+10%, –15%)
FULL WAVE RECTIFIED,
UNFILTERED POWER
MAY BE USED
MAGNET
TEST
SWITCH
ALARM
LED (RED)
4
5
2
1(+)
(–)
+ RA
+ RTS
– RA
+ TEST COIL
– TEST COIL
+ IN
+ OUT
–
24 VDC
AUX POWER
SUPPLIED
BY USER
(100mA
SUPPLY)
D2
NOTE: THE USE OF THE RTS151 REQUIRES THE INSTALLATION OF
AN ACCESSORY COIL, DCOIL, SOLD SEPARATELY.
METHOD #1 - AUX POWER LOCATED
AT DUCT DETECTOR
METHOD #2 - AUX POWER LOCATED
AT TEST STATION
FIGURE 4. WIRING DIAGRAM FOR RTS151 TO D2-2WIRE DUCT SMOKE DETECTOR:
2 I56-0469-015
