Keysight 81150A User manual

User’s Guide
Keysight 81150A and
81160A Pulse Function
Arbitrary Noise Generator
Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 - TestEquipmentDepot.com

Keysight
Pulse Function Arbitrary
Noise Generator
81150A and 81160A
User’s Guide

Notices
© Keysight Technologies 2011, 2014
No part of this manual may be reproduced in any
form or by any means (including electronic
storage and retrieval or translation into a foreign
language) without prior agreement and written
consent from Keysight Technologies as governed
by United States and international copyright laws.
Manual Part Number
81160-91020
Edition
Edition 2.0, August 2014
Printed in Germany
Keysight Technologies, Deutschland GmbH
Herrenberger Str. 130
71034 Böblingen, Germany
For Assistance and Support
Warranty
The material contained in this document is
provided “as is,” and is subject to being
changed, without notice, in future editions.
Further, to the maximum extent permitted by
applicable law, Keysight disclaims all
warranties, either express or implied, with
regard to this manual and any information
contained herein, including but not limited to the
implied warranties of merchantability and
fitness for a particular purpose. Keysight shall
not be liable for errors or for incidental or
consequential damages in connection with the
furnishing, use, or performance of this document
or of any information contained herein. Should
Keysight and the user have a separate written
agreement with warranty terms covering the
material in this document that conflict with
these terms, the warranty terms in the separate
agreement shall control.
Technology Licenses
The hardware and/or software described in this
document are furnished under a license and may
be used or copied only in accordance with the
terms of such license.
Restricted Rights Legend
If software is for use in the performance of a U.S.
Government prime contract or subcontract,
Software is delivered and licensed as
“Commercial computer software” as defined in
DFAR 252.227-7014 (June 1995), or as a
“commercial item” as defined in FAR 2.101(a) or
as “Restricted computer software” as defined in
FAR 52.227-19 (June 1987) or any equivalent
agency regulation or contract clause. Use,
duplication or disclosure of Software is subject to
Keysight Technologies’ standard commercial
license terms, and non-DOD Departments and
Agencies of the U.S. Government will receive no
greater than Restricted Rights as defined in FAR
52.227-19(c)(1-2) (June 1987). U.S. Government
users will receive no greater than Limited Rights
as defined in FAR 52.227-14 (June 1987) or DFAR
252.227-7015 (b)(2) (November 1995), as
applicable in any technical data.
Safety Notices
A CAUTION notice denotes a hazard. It
calls attention to an operating
procedure, practice, or the like that, if
not correctly performed or adhered to,
could result in damage to the product
or loss of important data. Do not
proceed beyond a CAUTION notice until
the indicated conditions are fully
understood and met.
A WARNING notice denotes a hazard.
It calls attention to an operating
procedure, practice, or the like that, if
not correctly performed or adhered to,
could result in personal injury or
death. Do not proceed beyond a
WARNING notice until the indicated
conditions are fully understood and
met.
CAUTION
WARNING

4
The following general safety precautions
must be observed during all phases of
operation of this instrument. Failure to
comply with these precautions or with
specific warnings elsewhere in this manual
violates safety standards of design,
manufacture, and intended use of the
instrument.
Keysight Technologies assumes no liability
for the customer's failure to comply with
these requirements.
Before operation, review the instrument and
manual for safety markings and instructions.
You must follow these to ensure safe
operation and to maintain the instrument in
safe condition.
This product is a Safety Class 1 instrument
(provided with a protective earth terminal).
The protective features of this product may
be impaired if it is used in a manner not
specified in the operation instructions.
All Light Emitting Diodes (LEDs) used in this
product are Class 1 LEDs as per IEC 60825-1.
This instrument is intended for indoor use in
an installation category II, pollution degree 2
environment. It is designed to operate at a
maximum relative humidity of 95% and at
altitudes of up to 2000 meters.
Refer to the specifications tables for the ac
mains voltage requirements and ambient
operating temperature range.
Verify that all safety precautions are taken.
The power cable inlet of the instrument
serves as a device to disconnect from the
mains in case of hazard. The instrument
must be positioned so that the operator can
easily access the power cable inlet. When
the instrument is rack mounted the rack
must be provided with an easily accessible
mains switch.
To minimize shock hazard, the instrument
chassis and cover must be connected to an
electrical protective earth ground. The
instrument must be connected to the ac
power mains through a grounded power
cable, with the ground wire firmly connected
to an electrical ground (safety ground) at the
power outlet. Any interruption of the
protective (grounding) conductor or
disconnection of the protective earth
terminal will cause a potential shock hazard
that could result in personal injury.
Do not operate the instrument in the
presence of flammable gases or fumes.
Operating personnel must not remove
instrument covers. Component replacement
and internal adjustments must be made only
by qualified personnel.
Instruments that appear damaged or
defective should be made inoperative and
secured against unintended operation until
they can be repaired by qualified service
personnel.

Indicates warning or caution. If you see this
symbol on a product, you must refer to the
manuals for specific Warning or Caution
information to avoid personal injury or damage to
the product.
Safety requirements for electrical equipment for
measurement, control, and laboratory use
CAN/CSA C22.2 No. 1010.1 (1993) UL 3101, 3111
(First Editions). This equipment has also been
evaluated to IEC 61010 edition 1 including
amendments 1 and 2.
Notice for European Community: This product
complies with the relevant European legal
Directives: EMC Directive 89/336/EEC and Low
Voltage Directive 73/23/EEC.
Conformity Mark of the Australian ACA for EMC
compliance.
General Recycling Mark for plastic parts used in
the product.
This product complies with the WEEE
Directive (2002/96/EC) marketing
requirements. The affixed label indicates
that you must not discard this
electrical/electronic product in domestic
household waste.
Product category: With reference to the
equipment types in the WEEE Directive
Annexure I, this product is classed as a
“Monitoring and Control instrumentation”
product.
Do not dispose in domestic household
waste.

Appendix
6
Contents
Contents................................................................................................................................................................ 6
1Introduction.......................................................................................................................................... 13
2Front-Panel Menu Operation............................................................................................................. 17
2.1 The Front Panel...................................................................................................................... 19
2.2 Help is Available .................................................................................................................... 24
2.3 The Front-Panel Display at a Glance.................................................................................... 25
2.3.1 Menu Mode................................................................................................................ 25
2.3.2 Graph Mode................................................................................................................ 26
2.4 The Front-Panel Number Entry............................................................................................. 27
2.5 The Rear Panel....................................................................................................................... 28
2.6 Preparing the 81150A / 81160A for Use.............................................................................. 30
2.7 Using the Built-in Help System............................................................................................. 31
2.8 Selecting the Mode of Operation ......................................................................................... 32
2.9 Selecting Trigger Mode and Source..................................................................................... 33
2.10 Selecting the Waveform........................................................................................................ 37
2.11 Selecting the Advanced Mode.............................................................................................. 40
2.11.1 Modulation............................................................................................................... 40
2.11.2 Burst ......................................................................................................................... 41
2.11.3 Sweep....................................................................................................................... 42
2.12 Setting the Output Frequency............................................................................................... 43
2.13 Setting the Output Amplitude............................................................................................... 45
2.13.1 Converting the amplitude from one unit to another............................................. 47
2.14 Selecting Delay....................................................................................................................... 48
2.15 Selecting DC Volts ................................................................................................................. 50
2.16 Setting a DC Offset Voltage.................................................................................................. 51
2.17 Setting the Duty Cycle of a Square Wave ........................................................................... 53
2.18 Setting the High-Level and Low-Level Values .................................................................... 54
2.19 Configuring a Pulse Waveform............................................................................................. 55
2.20 Setting up a Pattern............................................................................................................... 57

Introduction
81150A and 81160A User’s Guide 7
2.21 Viewing a Waveform Graph.................................................................................................. 59
2.22 Outputting a Stored Arbitrary Waveform............................................................................. 60
2.23 Selecting the Output Termination ........................................................................................ 62
2.24 Outputting a Modulated Waveform...................................................................................... 64
2.25 Outputting an FSK Waveform ............................................................................................... 67
2.26 Outputting a PWM Waveform .............................................................................................. 70
2.27 Outputting a Frequency Sweep ............................................................................................ 72
2.28 Outputting a Burst Waveform............................................................................................... 75
2.29 Triggering a Sweep or Burst................................................................................................. 78
2.30 Storing the Instrument State ................................................................................................ 79
2.31 Configuring the Remote Interface ........................................................................................ 82
2.31.1 GPIB Configuration.................................................................................................. 82
2.31.2 USB Configuration................................................................................................... 83
2.31.3 LAN Configuration................................................................................................... 84
2.32 Resetting the 81150A / 81160A........................................................................................... 89
3Features and Functions ...................................................................................................................... 90
3.1 Trigger Mode.......................................................................................................................... 92
3.1.1 Arming Source ........................................................................................................... 94
3.1.2 Arming Slope.............................................................................................................. 96
3.1.3 Internal Trigger Period/Frequency........................................................................... 97
3.2 Output Configuration ............................................................................................................. 99
3.2.1 Output Function......................................................................................................... 99
3.2.2 Output Frequency ....................................................................................................101
3.2.3 Output Amplitude ....................................................................................................104
3.2.4 DC Offset Voltage ....................................................................................................107
3.2.5 Output Units .............................................................................................................109
3.2.6 Load Impedance.......................................................................................................110
3.2.7 Output Source Impedance ......................................................................................111
3.2.8 Voltage Autoranging................................................................................................112
3.2.9 Amplifier Type Selection.........................................................................................113
3.2.10 Digital Channel Addition.......................................................................................114
3.2.11 Voltage Limits ........................................................................................................115
3.2.12 Duty Cycle (Square Waves)..................................................................................116
3.2.13 Symmetry (Ramp Waves) .....................................................................................118

Appendix
8
3.2.14 Output Control .......................................................................................................119
3.2.15 Parameter Coupling...............................................................................................120
3.2.16 Polarity....................................................................................................................124
3.2.17 Strobe Output.........................................................................................................125
3.2.18 Trigger Output........................................................................................................126
3.2.19 Sync Output............................................................................................................127
3.3 Input Configuration..............................................................................................................129
3.3.1 External In Parameters............................................................................................130
3.3.2 Modulation In Parameters......................................................................................134
3.3.3 Reference Clock.......................................................................................................139
3.4 Pulse Waveforms.................................................................................................................141
3.4.1 Pulse Period .............................................................................................................142
3.4.2 Pulse Width..............................................................................................................143
3.4.3 Leading Edge/Trailing Edge ...................................................................................145
3.5 Pattern Capabilities..............................................................................................................148
3.5.1 Pattern Mode ...........................................................................................................149
3.5.2 Pattern Source .........................................................................................................150
3.5.3 Configuring the External Pattern Source...............................................................152
3.5.4 Selecting a Pattern..................................................................................................159
3.5.5 Creating, Editing and Storing a Pattern.................................................................161
3.5.6 Bitshape Selection...................................................................................................168
3.5.7 Creating, Editing and Storing a Bitshape...............................................................170
3.5.8 Triggered and Gated Patterns.................................................................................176
3.6 Noise.....................................................................................................................................178
3.7 Amplitude Modulation (AM)...............................................................................................180
3.7.1 Selecting AM Modulation.......................................................................................181
3.7.2 Carrier Waveform Shape.........................................................................................182
3.7.3 Carrier Frequency.....................................................................................................183
3.7.4 Modulating Waveform Shape.................................................................................184
3.7.5 Modulating Waveform Frequency..........................................................................185
3.7.6 Modulating Depth....................................................................................................186
3.7.7 DSSC (Double Sideband Suppressed Carrier Mode) ............................................188
3.7.8 Modulating Source ..................................................................................................190
3.8 Frequency Modulation (FM)................................................................................................191
3.8.1 Selecting FM Modulation........................................................................................192
3.8.2 Carrier Waveform Shape.........................................................................................193

Introduction
81150A and 81160A User’s Guide 9
3.8.3 Carrier Frequency.....................................................................................................194
3.8.4 Modulating Waveform Shape.................................................................................195
3.8.5 Modulating Waveform Frequency..........................................................................196
3.8.6 Peak Frequency Deviation.......................................................................................197
3.8.7 Modulating Source ..................................................................................................198
3.9 Phase Modulation (PM) ......................................................................................................199
3.9.1 Selecting PM Modulation .......................................................................................200
3.9.2 Carrier Waveform Shape.........................................................................................201
3.9.3 Carrier Frequency.....................................................................................................202
3.9.4 Modulating Waveform Shape.................................................................................203
3.9.5 Modulating Waveform Frequency..........................................................................204
3.9.6 Phase Deviation.......................................................................................................205
3.9.7 Modulating Source ..................................................................................................206
3.10 Frequency-Shift Keying (FSK) Modulation.........................................................................207
3.10.1 Selecting FSK Modulation ....................................................................................208
3.10.2 Carrier Waveform Shape.......................................................................................209
3.10.3 FSK Carrier Frequency...........................................................................................210
3.10.4 FSK “Hop” Frequency............................................................................................211
3.10.5 FSK Rate.................................................................................................................212
3.10.6 FSK Source.............................................................................................................213
3.11 Pulse Width Modulation (PWM)........................................................................................214
3.11.1 Selecting PWM Modulation .................................................................................215
3.11.2 Pulse Waveform ....................................................................................................216
3.11.3 Pulse Period ...........................................................................................................217
3.11.4 Modulating Waveform Shape...............................................................................218
3.11.5 Modulating Waveform Frequency........................................................................219
3.11.6 Width Deviation.....................................................................................................220
3.11.7 Duty Cycle Deviation.............................................................................................221
3.11.8 Modulating Source ................................................................................................224
3.12 Frequency Sweep.................................................................................................................225
3.12.1 Selecting a Sweep.................................................................................................227
3.12.2 Start Frequency and Stop Frequency...................................................................228
3.12.3 Center Frequency and Frequency Span...............................................................229
3.12.4 Idle Frequency........................................................................................................231
3.12.5 Sweep Type............................................................................................................232
3.12.6 Sweep Time............................................................................................................234
3.12.7 Marker Frequency..................................................................................................235

Appendix
10
3.12.8 Triggered/Gated Sweep........................................................................................236
3.13 Burst Mode...........................................................................................................................238
3.13.1 Selecting a Burst...................................................................................................239
3.13.2 Continuous Burst Mode........................................................................................240
3.13.3 Triggered Burst Mode...........................................................................................241
3.13.4 Gated Burst Mode ................................................................................................. 242
3.13.5 Burst Count............................................................................................................243
3.13.6 Burst Phase............................................................................................................244
3.14 Arbitrary Waveforms............................................................................................................245
3.14.1 Creating and Storing an Arbitrary Waveform......................................................246
3.14.2 Managing Stored Waveforms...............................................................................253
3.14.3 Additional Information on Arbitrary Waveforms ................................................256
3.15 System-Related Operations.................................................................................................257
3.15.1 Instrument State Storage......................................................................................258
3.15.2 Export/Import State ..............................................................................................261
3.15.3 Error Conditions.....................................................................................................263
3.15.4 Beeper Control.......................................................................................................265
3.15.5 Display Brightness.................................................................................................266
3.15.6 Display Control.......................................................................................................267
3.15.7 Time........................................................................................................................269
3.15.8 Date.........................................................................................................................270
3.15.9 Firmware Revision Query......................................................................................271
3.15.10 SCPI Language Version Query............................................................................272
3.16 Remote Interface Configuration .........................................................................................273
3.16.1 GPIB Address.........................................................................................................274
3.16.2 DHCP/Auto-IP On/Off (LAN)...............................................................................275
3.16.3 IP Address (LAN)...................................................................................................276
3.16.4 Subnet Mask (LAN)...............................................................................................277
3.16.5 Default Gateway (LAN).........................................................................................278
3.16.6 Host Name .............................................................................................................279
3.16.7 Domain Name (LAN).............................................................................................280
3.16.8 DNS Server (LAN)..................................................................................................281
3.16.9 WINS Server (LAN) ...............................................................................................282
3.16.10 Current Configuration (LAN)...............................................................................284
3.17 Software Update ..................................................................................................................286
3.18 Installing Licenses ...............................................................................................................288

Introduction
81150A and 81160A User’s Guide 11
3.19 Diagnostics/Calibration Overview......................................................................................290
3.20 Security.................................................................................................................................293
3.21 Factory Default Settings......................................................................................................294
4Remote Programming Reference ....................................................................................................299
4.1 Keysight 81150A / 81160A Remote Control......................................................................299
4.1.1 Programming Recommendations...........................................................................300
4.2 81150A / 81160A SCPI Command Summary ....................................................................302
4.3 Common Command Summary ............................................................................................315
4.4 81150A / 81160A SCPI Instrument Command List Format..............................................317
4.5 81150A / 81160A SCPI Instrument Elements Name........................................................318
4.5.1 APPLy Commands ...................................................................................................319
4.5.2 Arbitrary Waveform Commands.............................................................................329
4.5.3 Burst Commands .....................................................................................................352
4.5.4 Level Commands......................................................................................................361
4.5.5 Modulation Commands...........................................................................................371
4.5.6 Channel Command ..................................................................................................414
4.5.7 Output Commands...................................................................................................416
4.5.8 Output Function Commands...................................................................................431
4.5.9 Reference Clock Commands...................................................................................465
4.5.10 Non-Volatile Storage Commands.........................................................................468
4.5.11 Status Reporting Commands................................................................................482
4.5.12 Sweep Commands.................................................................................................488
4.5.13 System-Related Commands..................................................................................499
4.5.14 Display Commands................................................................................................520
4.5.15 Triggering Commands ...........................................................................................524
4.5.16 Pattern Related Commands..................................................................................536
4.6 Common Command List ......................................................................................................573
4.7 Status Model........................................................................................................................576
4.7.1 Status register structure.........................................................................................578
4.7.2 Status Byte Register................................................................................................579
4.7.3 STATus Commands.................................................................................................580
4.7.4 STATus Questionable Data Register command subsystem ................................580
4.8 Programming Basics............................................................................................................583
4.8.1 Before you begin......................................................................................................583
4.8.2 Application Programs..............................................................................................587

Appendix
12
5Error Messages..................................................................................................................................595
6Application Programs.......................................................................................................................597
7Tutorial................................................................................................................................................599
7.1 Direct Digital Synthesis.......................................................................................................600
7.2 Creating Arbitrary Waveforms ............................................................................................604
7.3 Pulse Waveform Generation...............................................................................................607
7.4 Pattern Generation...............................................................................................................609
7.4.1 Multi-Level Pattern Definitions ..............................................................................610
7.4.2 Pattern Types and Sequencing Capabilities..........................................................612
7.4.3 Trigger Modes..........................................................................................................613
7.4.4 Defining the Shape of a Bit.....................................................................................614
7.4.5 External Patterns .....................................................................................................618
7.5 Noise Generation.................................................................................................................620
7.5.1 Limitations of User-defined Noise Distributions ..................................................622
7.6 Trigger Modes......................................................................................................................624
7.7 External In to Trigger Out Timing .......................................................................................627
7.8 Signal Imperfections............................................................................................................629
7.9 Output Amplitude Control ...................................................................................................631
7.10 Attributes of AC Signals......................................................................................................634
7.11 Modulation ...........................................................................................................................637
7.12 Frequency Sweep.................................................................................................................644
7.13 Burst......................................................................................................................................647
7.14 Channel Addition..................................................................................................................649
7.15 Coupling between Channels ...............................................................................................651
AAppendix.............................................................................................................................................653
A.1 Coupled Parameters when channel coupling is on ..........................................................653
A.2 Pulse Parameter Definitions ...............................................................................................656
A.3 Keysight 81150A / 81160A in comparison with other Keysight instruments................663
A.3.1 Keysight 81110A/81104A/81101A instrument family.........................................663
A.3.2 Keysight 33220A .....................................................................................................665
A.4 Preparing a USB Flash Drive using Windows Vista®.......................................................668

Introduction
81150A and 81160A User’s Guide 13
1 Introduction
Keysight
Technologies’
81150A / 81160A
Pulse Function
Arbitrary Noise
Generator
The Keysight Technologies 81150A and 81160A is a Pulse Pattern and
Function Arbitrary Noise Generator with built-in arbitrary waveform and
pulse capabilities
Its combination of bench-top and system features makes this Pulse Function
Arbitrary Noise Generator a versatile solution for your testing requirements
now and in the future.
Features and
Benefits
 81150A: 1 Hz-120 MHz pulse generation with variable rise/fall time
 81150A: 1 Hz-240 MHz sine waveform outputs
 81160A: 1 Hz-330 MHz pulse generation with variable rise/fall time
 81160A: 1 Hz-500 MHz sine waveform outputs
 Pulse, sine, square, ramp, noise and arbitrary waveforms
 FM, AM, PM, FSK, PWM modulation capability
 One or two channels
 81150A: 14-bit, 2GSa/s, 512 KSa deep arbitrary waveform memory
per channel
 81160A: 14-bit, 2.5GSa/s, up to 256 KSa deep arbitrary waveform
memory per channel
 USB, GPIB and LAN connectivity.
 Glitch free change of timing parameters delay, frequency, transition
time, width, duty cycle
 LXI class C compliant
Benchtop Testing
The 81150A / 81160A features a graphic display showing all pulse
parameters at a glance. The cursor keys and the modify knob allow fast and
simple operation.
The user interface is designed to minimize the time invested in getting
familiar with the instrument. After familiarization, the instrument supports
quick setups of signals. This leaves you free to concentrate on the
measurement task and testing of the DUT.

Appendix
14
What’s inside this
Manual
This manual provides detailed information about the following:
 Front-Panel Menu Operation
 Features and Functions
 Remote Programming Reference
 Error Messages
 Application Programs
 Tutorial
Purpose of this
Manual
The purpose of this manual is to enable you to install, initialize, and start the
81150A / 81160A and to understand the front-panel menu features of the
81150A / 81160A.
Who should read
this Manual
This manual is intended for testers and Engineers who will be using the
81150A / 81160A to test other devices.
How this document
is organized
This section provides information on the chapters, and their content.
Navigating this manual
Topic
What information does it contain?
Introduction
Introduces the 81150A / 81160A, defines the purpose and
intended audience of this manual; explains how information is
organized in this manual.
Front-Panel Menu Operation
Introduces you to the Front-Panel Menu and describes some of
the menu features of the 81150A / 81160A Pulse Pattern and
Function Arbitrary Noise Generator.
Features and Functions
Gives a detailed description of the 81150A / 81160A’s
capabilities and operation. You will find this section useful when
you are operating the 81150A / 81160A from the front panel or
over the remote interface.

Introduction
81150A and 81160A User’s Guide 15
Topic
What information does it contain?
Remote Programming Reference
Contains reference information to help you program the 81150A
/ 81160A over the remote interface.
Error Messages
Describes the error reporting model that is used by the 81150A /
81160A.
Application Programs
Describes the various types of programming examples available
for the 81150A / 81160A and where to find them.
Tutorial
Gives an overview of the internal operations of the 81150A /
81160A.
Terms and
conventions used in
this manual
The following table lists the terms and conventions used in this manual:
Conventions
The icon...
Indicates…
A note or important information.
A tip
A caution or warning

Notes within a table
Acronyms used in
this manual
The following table lists the acronyms and abbreviations used in this manual:
Acronyms used in this Document
Acronym
Explanation
DHCP
Dynamic Host Configuration Protocol
DNS
Domain Name Service
DUT
Device Under Test

Appendix
16
References
The Getting Started Guide along with this manual forms a part of the 81150A
and 81160A product documentation suite.

Front-Panel Menu Operation
81150A and 81160A User’s Guide 17
2 Front-Panel Menu Operation
Introduction
This section introduces the front-panel menu and describes the menu
features of the 81150A / 81160A Pulse Pattern and Function Arbitrary Noise
Generator.

Appendix
18
What’s inside this
Chapter
The following topics are discussed in this section:
 The Front Panel
 Help is Available
 The Front-Panel Display at a Glance
 Menu Mode
 Graph Mode
 The Front-Panel Number Entry
 The Rear Panel
 Preparing the 81150A / 81160A for Use
 Using the Built-in Help System
 Selecting the Mode of Operation
 Selecting Trigger Mode
 Selecting the Waveform
 Selecting the Advanced Mode
 Setting the Output Frequency
 Setting the Output Amplitude
 Selecting Delay
 Selecting DC Volts
 Setting a DC Offset Voltage
 Setting the Duty Cycle of a Square Wave
 Setting the High-Level and Low-Level Values
 Configuring a Pulse Waveform
 Setting up a Pattern
 Viewing a Waveform Graph
 Outputting a Stored Arbitrary Waveform
 Selecting the Output Termination
 Outputting a Modulated Waveform
 Outputting an FSK Waveform
 Outputting a PWM Waveform
 Outputting a Frequency Sweep
 Outputting a Burst Waveform
 Triggering a Sweep or Burst
 Storing the Instrument State
 Configuring the Remote Interface
 Resetting the 81150A / 81160A

Front-Panel Menu Operation
81150A and 81160A User’s Guide 19
2.1 The Front Panel
Introduction
The instrument is mainly operated from the front panel, when used for
benchtop testing.
This section explains the Keys, Functions, Inputs/Outputs and Controls,
seen on the Front Panel of the 81150A / 81160A.
Ch 1
Ch 2
Coupling
Graph
Cancel
7 8 9
45 6
1 2 3
0 . +/-
Out 2 Out 2 Out 1 Out 1
Man Cont Pulse Square Mod Store/
Recall
Utility
Help
Sweep
BurstArb
Ramp
Noise
SineTrig
Gated
max. ±15V
Trigger Out 2 Strobe Out 2External In Trigger Out 1 Strobe Out 1
81150A
Pulse Function Arbitrary Generator
120 MHz
L ocal
Power Switch Menu Softkeys Cancel
Graph / Local
Numeric Keypad Inputs / Outputs
USB Host
Channel 1 Selection
Channel Coupling
Channel 2 Selection
Navigation
Keys
Rotary Knob
Cursor Keys
Trigger
Modes
Waveform
Type
Advanced
Modes
Special
Function Keys
Front Panel of the 81150A
Ch 1
Ch 2
Coupli ng
Gr aph
Ca nc e l
L o c a l m a x . ± 1 0 V
E x t e r n a l I n Sy n c Ou t A Sy n c Ou t B
789
4 5 6
1 2 3
0 . +/-
Out 2 Out 2 Out 1 Out 1
Man Cont Pulse Square Mod Store/
Recall
Utility
Help
Sweep
BurstArb
Ramp
Noise
SineTrig
Gated
Channel 1 Selection
Channel Coupling
Channel 2 Selection
USB Host
Power Switch Menu Softkeys Cancel
Graph / Local
Numeric Keypad Inputs / Outputs
Special
Function Keys
Advanced
Modes
Waveform
Type
Trigger
Modes
Rotary Knob
Cursor Keys
Navigation
Keys
Front Panel of the 81160A

Appendix
20
Power Switch
The front panel switch is used to switch on and off the instrument.
When the front panel switch is off, the instrument is in standby mode. The
instrument is disconnected from the AC line power only by disconnecting
the power cord.
USB
The Front Panel contains a USB host connector. It is intended to connect
USB drives to store instrument states and waveforms on an external
memory.
Menu Softkeys
The five keys below the main display screen are called softkeys (software-
controlled keys). The current function of each softkey is indicated in the
corresponding box on the display.
Some softkeys hold additional symbols to indicate that they provide
extended functionality.
 Yellow Triangles: These are visible on the five softkeys on the
Front Panel. The yellow triangles indicate that there are more choices
further, and keep pressing to view the available options.
 White Rectangles: Indicate that by pressing them, you can
enter into another screen.
The following examples explain the above-mentioned points:
Pressing this softkey will toggle between
Frequency and Period representation.
Pressing this softkey will open the output
configuration screen.
More Key
Pressing the MORE key switches to the next layer of softkeys on the current
screen.
