Keysight E5061B User manual

CONFIGURATION
GUIDE
Keysight E5061B
ENA Vector Network Analyzer

Page 2
Find us at www.keysight.com
Ordering guide
Standard furnished item 1
Description Additional information
Installation guide Contains the information necessary to start up with the E5061B.
CD ROM IO libraries
Power cable
Certificate of calibration
Step 1. Choose test set option (must choose one of the nine test set options.)
Option No. Description
50 Ω RF NA options
E5061B-115 Transmission/Reflection test set, 100 kHz to 1.5 GHz, 50 Ω system impedance
E5061B-215 S-parameter test set, 100 kHz to 1.5 GHz, 50 Ω system impedance
E5061B-135 Transmission/Reflection test set, 100 kHz to 3 GHz, 50 Ω system impedance
E5061B-235 S-parameter test set, 100 kHz to 3GHz, 50 Ω system impedance
75 Ω RF NA options
E5061B-117 Transmission/Reflection test set, 100 kHz to 1.5 GHz, 75 Ω system impedance
E5061B-217 S-parameter test set, 100 kHz to 1.5 GHz, 75 Ω system impedance
E5061B-137 Transmission/Reflection test set, 100 kHz to 3 GHz, 75 Ω system impedance
E5061B-237 S-parameter test set, 100 kHz to 3GHz, 75 Ω system impedance
LF-RF NA option 2
E5061B-3L3 LF-RF network analyzer with DC bias source, 5 Hz to 500 MHz
E5061B-3L4 LF-RF network analyzer with DC bias source, 5 Hz to 1.5 GHz
E5061B-3L5 LF-RF network analyzer with DC bias source, 5 Hz to 3 GHz
Step 2. Choose impedance analysis option
(for E5061B-3L5 LF-RF network analyzer. If not required, go to step 3.)
Option No. Description
Software option
E5061B-005 3, 4 Impedance analysis for E5061B-3L3/3L4/3L5 LF-RF network analyzer
Accessory
E5061B-720 4, 5 Add 50 Ω resistor set
The following steps will guide you through configuring your E5061B.
1. Keyboard and mouse are not furnished as standard. Refer to “Step 6. accessory option” for the selection of these items.
2. The E5061B-3L3/3L4/3L5 includes the 50 ohm S-parameter test set (5 Hz to 500 M/1.5 G/3 GHz), and the gain-phase test port (5 Hz to 30 MHz)
3. This option is not applicable for the E5061B RF NA options 1x5/2x5/1x7/2x7.
4. Refer to “Upgrade Kit” section for retrofit information on the above option.
5. For calibration at test fixtures. Required for the gain-phase series-thru method.

Page 3
Find us at www.keysight.com
Step 3. Choose hardware option (If not required, go to step 4)
Option No. Description
E5061B-1E5 1Add High stability time base
E5061B-721 Add GPIB interface (must choose either Option 721 or 722)
E5061B-722 Without GPIB interface (must choose either Option 721 or 722)
E5061B-731 Add handler I/O interface (must choose either Option 731 or 732)
E5061B-732 Without handler I/O Interface (must choose either Option 731 or 732)
Step 4. Choose storage option 2
Option No. Description
E5061B-020 Standard hard disk drive
Step 5. Choose software option (If not required, go to step 6)
Option No. Description
E5061B-010 3Time domain/fault location analysis
E5061B-006 4Wireless power transfer analysis
Step 6. Choose accessory option (If not required, go to step 7)
Option No. Description
E5061B-810 Add keyboard
E5061B-820 Add mouse
E5061B-1CM Rack mount Kit
E5061B-1CN Front Handle Kit
E5061B-1CP Rack mount and front handle kit
Step 7. Choose calibration option (if not required, go to step 8)
Option No. Description
E5061B-1A7 Calibration + Uncertainties + Guardbanding
E5061B-A6J ANSI Z540-1-1994 Calibration
1. Refer to “Hardware upgrade” section for retrofit information on the above options.
2. Option 020 is the only storage option for the E5061B. Must choose this option when ordering the E5061B.
3. Refer to “Software upgrade” section for retrofit information on the above option.
4. This option is not applicable for the E5061B 75 ohm test set options 1x7/2x7 and Transmission/Reflection test set options 1x5.

Page 4
Find us at www.keysight.com
Test accessories and calibration kits
Electronic calibration (ECal) modules
A complete list of RF test accessories and calibration kits are available on our Web site:
www.keysight.com/find/mta
ww.keysight.com/find/ecal
Test accessories
Test accessories such as test port cable are necessary for a complete measurement system using the E5061B. Order test
accessories in accordance with the desired measurement system.
Calibration kits
Calibration is an accuracy enhancement procedure that effectively reduces the system errors that cause uncertainty in
network measurement. Calibration kit is necessary to perform the calibration.
–Mechanical calibration kits include standards, such as opens, shorts and loads, which are measured by the network
analyzer. Choose a calibration kit for each connector type to be used.
–Electronic calibration (ECal) modules replace mechanical calibration standards with one solid-state calibration
module that is controlled by the network analyzer via USB. ECal modules provide many different impedances to the
test ports which enables a full two-port calibration to be performed quickly with a single connection. This technique
reduces operator errors and connector wear and abrasion.
Mechanical calibration kits

Page 5
Find us at www.keysight.com
Test accessories (for 50 Ω system)
Model No. Description
Test Port Cable
N6314A 50 Ω type-N (m) to type-N (m) cable, DC to 12.4 GHz, 61 cm (24 in)
N6315A 50 Ω type-N (m) to type-N (f) cable, DC to 12.4 GHz, 61 cm (24 in)
11500E 3.5 mm (m) to 3.5 mm (m) cable, 61 cm (24 in)
11500F 3.5 mm (m) to 3.5 mm (m) cable, 152 cm (60 in)
11857D 50 Ω 7 mm to 7 mm cable, 300 kHz to 6 GHz, 61 cm (24 in)
8120-1838 50 Ω BNC (m) to BNC (m) cable, 30 cm (12 in)
8120-1839 50 Ω BNC (m) to BNC (m) cable, 61 cm (24 in)
Adapter
1250-0780 50 Ω type-N (m) to 50 Ω BNC (f) adapter
1250-1200 50 Ω BNC (f) to SMA (m) adapter
1250-2015 50 Ω BNC (m) to SMA (f) adapter
Accessory Kit
11853A 50 Ω type-N accessory kit. Includes;
- Type-N (f) to type-N (f) adapter (2 qty.)
- Type-N (m) to type-N (m) adapter (2 qty.)
- Type-N (f) short
- Type-N (m) short
11854A 50 Ω BNC accessory kit. Includes;
- BNC (m) to Type-N (m) adapter (2 qty.)
- BNC (f) to Type-N (f) adapter (2 qty.)
- BNC (f) to Type-N (m) adapter (2 qty.)
- BNC (m) to Type-N (f) adapter (2 qty.)
- BNC (m) short
Adapter Kit
11878A 50 Ω type-N to 3.5 mm adapter kit. Includes;
- 3.5 mm (m) to type-N (m) adapter
- 3.5 mm (f) to type-N (f) adapter
- 3.5 mm (f) to type-N (m) adapter
- 3.5 mm (m) to type-N (f) adapter
Power Splitter 1
11667L BNC (f) connectors, DC to 2 GHz
DC Block
N9398C 3.5 mm (m) and 3.5 mm (f) connectors, 50 kHz to 26.5 GHz
N9399C 3.5 mm (m) and 3.5 mm (f) connectors, 700 kHz to 26.5 GHz
116 67L
1. For transmission measurement with the gain-phase test port of the E5061B-3L3/3L4/3L5. Required for milliohm impedance measurements
in the low frequency range.

Page 6
Find us at www.keysight.com
Test accessories (for 50 Ω system, continued)
Model No. Description
Active Probe
41800A 5 Hz to 500 MHz active probe, 100 kΩ (probe alone) / 1 MΩ (with 10:1 or 100:1 divider). Includes;
- Probe to BNC adapter
- Hook tip adapter
- Slip-on tip adapter
- 10:1 and 100:1 divider
41800A-001 Adds a cable to connect the probe with an external power supply. This option is not necessary for the E5061B-
3L3/3L4/3L5 since it is equipped with the probe power.
41800A-UK6 Commercial cal certificate with test data
85024A 300 kHz to 3 GHz active probe. Includes;
- Probe tip to type-N Adapter
- 10:1 divider
- Hook tip adapter
- Slip-on tip adapter
- Leads
Active Probe
85024A DC to 200 MHz differential active probe. The 1142A is required. Includes;
Common mode choke
9170-2549 Core-Toroidal Common Mode Choke 204.2 mm
Probe Control and Power Module
1142A Probe control and power module for the 1141A Differential Active Probe.
Common mode choke (Part number: 9170-2549)
41800A and E5061B
1. The 1142A Probe Control and Power Module is required.

Page 7
Find us at www.keysight.com
Non-Keysight test accessories (for 50 Ω system)
Model No. Description
Injection Transformer
Picotest
J2100A Injection Transformer
1 Hz to 5 MHz (when terminated with 5 Ω), 10 Hz to 5 MHz (when terminated with
50 Ω), Input: BNC(f), Output: Banana jacks, 600 V/CAT II isolation voltage.
Optimized for loop gain measurements of DC-DC converters and switching power supplies.
Picotest
J2101A Injection Transformer
10 Hz to 45 MHz (when terminated with 5 Ω), 60 Hz to 45 MHz (when terminated with 50 Ω), Input: BNC(f),
Output: Banana jacks, 600 V/CAT II isolation voltage.
Optimized for loop gain measurements of DC-DC converters and switching power supplies.
North Hills Signal Processing
0017CC 50 Ω Video Isolation Transformer
10 Hz to 5 MHz (when terminated with 50 Ω), Input: BNC(f), Output: BNC(f).
Applicable to loop gain measurements of DC-DC converters and switching power supplies.
Other Signal Injector
Picotest
J2110A Solid-State Injector
(Bode Box)
DC to 40 MHz, Input and output voltage up to ± 10.5 V,
Signal input: BNC(f), Output: Banana jacks.
Optimized for wide band loop gain measurements of control loop circuits.
Picotest
J2120A Line Injector
15 Hz to 5 MHz, up to 50 Vdc / 5 Adc, Signal input: BNC(f),
DC input & output: Banana jacks.
For PSRR measurements of linear regulators and DC-DC converters.
Picotest
J2111A Current Injector
Input: BNC(f), Output: Banana jacks.
For output impedance measurements of DC-DC converters with high-voltage outputs up to 40 Vdc. The
recommended frequency range with the E5061B is 5 Hz to 1 MHz.
Picotest
J2102A Common Mode Transformer
DC to 200 MHz
Input BNC(f), Output BNC(f)
For output impedance/PSRR measurements; greatly attenuates the effects of low frequency ground loops.
Picotest
J2113A Semi-Floating Differential Amplifier
DC to 500 MHz
Input BNC(f), Output BNC(f)
For output impedance/PSRR measurements; eliminates DC ground loop down to 1 Hz.
Picotest
J2160A Probe Adapter
5 Hz to 30 MHz
Input BNC(f), Output BNC(f)
Easy DUT connection for the output impedance measurements of DC-DC converters with 2-port
shunt-thru method
Banana test lead/adapter
Pomona Electronics 1166 Banana plug to alligator clip
Pomona Electronics 4650 Banana plug to test clip
Pomona Electronics 4650 Banana plugs to test clips
Pomona Electronics 1269 Banana plugs to BNC(f) adapter
BNC breakout
Pomona Electronics 2886 BNC(m) to alligator clips
Pomona Electronics 3789 BNC(m) to test clips
BNC to test clip lead
Pomona Electronics 3787-C-18 Coax. cable with a BNC(m) connector and test clips at the ends,
approx. 60 cm (total length).
For probing the DUT from the gain-phase receiver ports.
50 Ω feed through
Pasternack Enterprises
PE6008-50
DC to 1 GHz, 50 Ω BNC(m) to BNC(f) feed through.
DC Block
Mini-Circuits
BLK-89
100 kHz to 8 GHz, 50 Ω SMA(m) to SMA(f) DC blocking capacitor.

Page 8
Find us at www.keysight.com
Non-Keysight test accessories (for 50 Ω system, continued)
North Hills Signal Processing 0017CC
Pomona 3787-C-18 test lead (connected to gain-phase receiver ports)
Pomona 2886 BNC breakout (connected to 0017CC)
Picotest J2113A Semi-Floating Differential Amplifier
Picotest J2111A Current Injector
Picotest J2120A Line Injector
Picotest J2120A Line Injector
(Banana-to-test clip leads connected to its banana jacks)
Picotest web page: www.picotest.com
North Hills Signal Processing web page: www.northhills-sp.com/index.html
Mini-Circuits web page: www.minicircuits.com/index.html
Pomona Electronics web page: www.pomonaelectronics.com
Pasternack Enterprises web page: www.pasternack.com
Picotest J2160A Probe Adapter

Page 9
Find us at www.keysight.com
Calibration kits (for 50 Ω system)
Model No. Description
Type-N
Mechanical calibration kits
85032E 50 Ω economy calibration kit, DC to 6 GHz. Includes;
- Type-N (m) fixed load
- Type-N (m) combined open/short
85032F 50 Ω standard calibration kit, DC to 9 GHz. Includes;
- Type-N (m) fixed load
- Type-N (f) fixed load
- Type-N (m) Open
- Type-N (f) Open
- Type-N (m) Short
- Type-N (f) Short
85032F-100 Adds 50 Ω type-N (f) to type-N (f) adapter
85032F-200 Adds 50 Ω type-N (m) to type-N (m) adapter
85032F-300 Adds 50 Ω type-N (m) to type-N (f) adapter
85032F-500 Adds;
- 50 Ω type-N (m) to 7 mm adapter (2 qty.)
- 50 Ω type-N (f) to 7 mm adapter (2 qty.)
Electronic calibration kits
85092C 1RF ECal module
2-port (50 Ω type-N), 300 kHz to 9 GHz. The sexes of the connectors depend on the option.
85092C-M0F 2Type-N (f) to Type-N (m) RF ECal module
85092C-00M 2Type-N (m) to Type-N (m) RF ECal module
85092C-00F 2Type-N (f) to Type-N (f) RF ECal module
85092C-00A Adds;
- Type-N (f) to Type-N (f) adapter
- Type-N (m) to Type-N (m) adapter
Electronic calibration (ECal) modules
85092C RF ECal module
2-port (50 Ω type-N), 300 kHz to 9 GHz. The sexes of the connectors depend on the option.
N7550A 3Economy ECal module, DC to 4 GHz, 2-port
N7551A 3Economy ECal module, DC to 6.5 GHz, 2-port
N7552A 3Economy ECal module, DC to 9 GHz, 2-port
N7553A 3Economy ECal module, DC to 14 GHz, 2-port
N7554A 3Economy ECal module, DC to 18 GHz, 2-port
N755xA-NMF Type-N (m) to Type-N (f) ECal module
N755xA-NMM Type-N (m) to Type-N (m) ECal module
N755xA-NFF Type-N (f) to Type-N (f) ECal module
1. This ECal module cannot be used in the low frequency range below 300 kHz.
2. Mixed connector options are also available. Visit our website for more details about the ECal: www.keysight.com/find/ecal
3. The E5061B must have firmware revision B.04.86 or above for the operation with the N755xA series ECal module.

Page 10
Find us at www.keysight.com
Calibration kits (for 50 Ω system, continued)
Model No. Description
3.5mm
Mechanical calibration kits
85033E 50 Ω standard calibration kit, DC to 9 GHz. Includes;
- 3.5 mm (m) Load / 3.5 mm (m) Open / 3.5 mm (m) Short
- 3.5 mm (f) Load / 3.5 mm (f) Open / 3.5 mm (f) Short
- Torque wrench
85033E-100 Adds 3.5mm (f) to 3.5 mm (f) adapter
85033E-200 Adds 3.5mm (m) to 3.5 mm (m) adapter
85033E-300 Adds 3.5mm (f) to 3.5 mm (m) adapter
85033E-400 Adds;
- 3.5 mm (m) to 50 Ω type- N (m) adapter
- 3.5 mm (f) to 50 Ω type- N (f) adapter
- 3.5 mm (f) to 50 Ω type- N (m) adapter
- 3.5 mm (m) to 50 Ω type- N (f) adapter
85033E-500 Adds;
- 3.5 mm (m) to 7 mm adapter (2 qty.)
- 3.5 mm (f) to 7 mm adapter (2 qty.)
Electronic calibration kits
85093C1RF ECal module
2-port (3.5 mm), 300 kHz to 9 GHz
85093C-M0F 23.5 mm (f) to 3.5 mm (m) RF ECal module
85093C-00M 23.5 mm (m) to 3.5 mm (m) RF ECal module
85093C-00F 23.5 mm (f) to 3.5 mm (f) RF ECal module
85093C-00A Adds;
- 3.5 mm (f) to 3.5 mm (f) adapter
- 3.5 mm (m) to 3.5 mm (m) adapter
N7550A3Economy ECal module, DC to 4 GHz, 2-port
N7551A3Economy ECal module, DC to 6.5 GHz, 2-port
N7552A3Economy ECal module, DC to 9 GHz, 2-port
N7553A3Economy ECal module, DC to 14 GHz, 2-port
N7554A3Economy ECal module, DC to 18 GHz, 2-port
N7555A3Economy ECal module, DC to 26.5 GHz, 2-port
N755xA-3MF 3.5 mm (m) to 3.5 mm (f) ECal module
N755xA-3MM 3.5 mm (m) to 3.5 mm (m) ECal module
N755xA-3FF 3.5 mm (f) to 3.5 mm (f) ECal module
Selectable connector type
Electronic calibration kit
N4431B1RF ECal module
4-port, 9 kHz to 13.5 GHz. The connector type depends on the option.
N4431B-010 2 Four 3.5 mm (f) connectors
N4431B-020 2 Four 50 Ωtype-N (f) connectors
1. These ECal modules cannot be used in the low frequency range below 300 kHz or 9 kHz.
2. Mixed connector options are also available. Visit our website for more details about the ECal: www.keysight.com/find/ecal
3. The E5061B must have firmware revision B.04.86 or above for the operation with the N755xA series ECal module.
