Instruction Manual
ETLus Electric Fan
KSTFA12AAG
For Household Use Only
IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
This fan has a polarized plug (one blade is wider than the other). To reduce the
risk of electric shock, this plug is intended to fit in a polarized outlet only one way.
If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit,
contact a qualified electrician. Do not attempt to defeat this safety feature.
This product employs overload protection (fuse). A blown fuse indicates an
overload or short-circuit situation. If the fuse blows, unplug the product from the
outlet. Replace the fuse as per the user servicing instructions (follow product
marking for proper fuse rating) and check the product, If the replacement fuse
blows, a short-circuit may be present and the product should be discarded or
returned to an authorized service facility for examination and/or repair.
WARNING – To Reduce The Risk Of Fire Or Electric Shock, Do Not Use This
Fan With Any Solid-State Speed Control Device.
WARNING – To Reduce The Risk Of Electric Shock, Do Not Expose to Water
or Rain.
WARNING – This is a fan – not a toy! To reduce the risk of personal injury
and electric shock, it should not be played with or placed where small children can
reach it.
When using electric appliances, basic safety precautions should always be
followed, including the following:
1. Do unplug or disconnect the appliance from the power supply before servicing.
2. Do not use gasoline, thinners, solvents, ammonias or other chemicals for
cleaning.
3. Do not operate any fan with a damaged cord or plug. Discard fan or return to
an authorized service facility for examination and/or repair.
4. Do not run cord under carpeting. Do not cover cord with throw rugs, runners,
or similar coverings. Do not route cord under furniture or appliances. Arrange
cord away from traffic area and where it will not be tripped over.
5. Do not use this product outdoors.
6. Do not use this product on wet surfaces.
7. Do not use this product in a bathtub or shower.
8. Do not use near furnaces, fireplaces, stove or other high-temperature heat
sources.
9. Do not immerse this product in water or allow water to drip into the motor
housing.
SAVE THESE INSTRUCTIONS
P1-14606
P2-14606

User Servicing Instructions
Grasp plug and remove from the receptacle or other outlet device. Do not unplug
by pulling on cord. Open fuse cover (A.) by sliding access cover on top of
attachment plug towards blades. Remove fuse carefully (B.) by gently prying out
the ends of the fuse from the receptacle.
Risk of fire. Replace fuse only with 2.5 Amp, 125 Volt fuse.
Install replacement fuse (C.) by first placing the end of the fuse into the fuse
receptacle which is opposite of the blades of the plug, then carefully push in the
other end. Only push against the metal end of the fuse, not the glass center
portion. Close the fuse access cover (D.) by sliding the cover back into the plug
until it is completely closed, latches and is flush with the face of the plug.
Risk of fire. Do not replace attachment plug.
Contains a safety device (fuse, AFCI, LCDI) that should not be removed.
Discard product if the attachment plug is damaged.
Know Your Fan
PartsandFeatures
HeightAdjustButton
Use only when higher position required.
Pressing the height adjust button, pull the slide
pipe upwards.
When lower position required, just push the slide
pipe downwards.
You can adjust the height in 2 steps.
Caution:
Be careful not to pinch fingers.
Before moving this electric fan, make sure
Height Adjust Button is properly fixed.
P3-14606
P4-14606

SwingControlandTiltingAdjustment
Press down…Swivel starts.
Pull up…Swivel stops.
Always switch the fan off
before making a tilt adjustment.
The air flow can be adjusted
upward or downward simply by
moving the guard up or down.
How to Assemble
WARNING!
Do not insert the plug into the power point before assembly is complete.
(May cause electric shock or injury)
Do not press height adjustment button while fan and fan guard are
detached.
(The motor section (slide pipe) may jump out of stand, causing injury.)
Fixthestandontothebase
Remove the motor shaft
cover.
Check the stand direction
by the indication of front
and back of the base and
stand, then push the whole
stand part down onto the
base until it is fitted in firmly.
Placing the motor shaft
upward, then fix the stand and
base by turning the base
fixing ring provided clockwise.
Fixing Rear Guard and Fixing Fan Blade
Fixing Rear Guard
Couple protrusions (three) on the motor
section to concaves (three) on the rear
guard.
Fix them firmly by turning the guard
fixing ring toward [fasten].
Fixing Fan Blade
Couple the pin on the motor shaft and the
concave on the fan blade and insert the
fan part into the motor part. Then pressing
the fan part towards the motor part turn the
fan blade cap toward [fasten] to fix them
firmly.
CAUTION
If the fan blade cap is not fastened firmly
enough, fan blade may come off, causing injury.
Be careful not to be injured by motor shaft or pin when assembling or
P5-14606
P6-14606

disassembling.
FixingFrontGuardandFeatures
Use tool to lock the screw and nut of the
guard, turn counter clockwise fixation the
front guard.
How to Take off Front Guard
Use tool to unlock the screw and nut of
the guard, turn counter clockwise remove the front guard.
After cleaning, turn clockwise to
assemble the front guard, and use tool
to lock the screw of the guard.
Features
The middle part in the front guard can
rotate, promote air consistency and
comfort.
CAUTION
How to Operate
OFF/ ON Operation STOP/ LOW - MID - HIGH
ON TIMER Select TIMER ON
(30min, 60min, 90min, 120min, 150min, 180min)
OFF TIMER Select TIMER OFF
Ready
Insert the power plug into power point.
Start
Switch on by pushing [LOW - MID - HIGT] button.
Timer Setting
Turn timer on, select at your desired time (30min, 60min, 90min, 120min, 150min,
180min).
(After the time you set, the fan will stop automatically)
When the timer is set [TIMER OFF], will stop timer function.
P7-14606

Maintenance and Storage
WARNING
When cleaning, the plug must be removed from the power point. Do not
handle plug with wet hands.
[May cause electric shock or injury.]
Do not press the height adjustment button while the fan and fan guard are
detached.
[The motor section (slide pipe) may jump out of the stand part, causing injury.]
When disassembling the base or stand, unplug plug from the power point.
[May cause electric shock or injury.]
How to Clean
Disassemble the fan and guard in the inverse order of assembling. Wash off dirt
and dust with well squeezed wet soft cloth with water or neutral detergent, then
wipe off the detergent.
CAUTION:
Do not use volatile solvents such as gasoline, thinner, benzene, wax,
kerosene, alcohol, polishing powder, or alkaline detergent. These may
discolour or damage the machine, causing injury.
If using a chemical dust cloth, follow those instruction.
Do not oil plastic. May cause discoloration or injury from damaged parts.
How to Store
Disassemble fan, guard, stand and base in the inverse order of assembling.
Clean the motor shaft and oil put the motor shaft cover back to the motor shaft.
Store three parts in the box provided at purchase and keep in a dry place.
CAUTION:
When the fan is not facing front, do not force the fan to turn. Use the swivel
function.
Clean the fan and guard referrring to [ How to Clean], then store it.
How to Disassemble the Base
1. Put the motor shaft upward, then unscrew fixing ring by turning anticlockwise.
(Refer to the drawing at below)
Holding the base firmly, press the stand hook.
Then pull the base and remove the stand hook.
CAUTION:
If the motor shaft is facing downward, the will become unstable and may
damage the product or floor.
When putting the motor shaft down, the fan is unstable. May cause machine
failure and damage to floor.
2. Hold the stand firmly and gently lift and remove the base.
Technical Specifications
V
oltage 120V~60Hz Power Consumption ?A or ?W
Fan Speed STOP/ LOW - MID - HIGT
Time
r
1min ~ 180min
Product Holde
r
Join-One Electric (Shenzhen) Co.,Ltd
Subject to technical modification
