Kia PICANTO 2017 Technical manual

INDEX - VICS(VEHICLE INSTRUCTION CARD)
KIA VEHICLES
Page Vehicle Details
1Index n/a
2Supplement (Electronic Parking Brake, etc) n/a
3Picanto 5 seats / 5 door hatchback
4Rio 5 seats / 5 door hatchback
5Cee’d 5 seats / 5 door hatchback / estate
6Venga 5 seats / 5 door hatchback
7Optima 5 seats / 4 door saloon
8Niro 5 seats / 5 door hybrid SUV
9Sportage 5 seats / 3 door hatchback
10 Carens 7 seats / 5 door MPV
11 Stonic 5 seats / 5 door SUV
12
13
INDEX PAGE 1

LOCATION
The diagrams above indicate example locations of the electronic parking brake (A) which is labelled with the universal icon symbol:
ACTIVATION
The EPB will normally auto activate. If will also activate if seat belts are not being worn, or when luggage placed on top of seats activates the system. To
enable the system to function correctly, fasten seatbelts, and remove luggage from the seats and store it securely in the boot. Pull the switch labelled A to
manually apply the parking brake. The warning lamps on both the switch and instrument panel will light up to confirm its activation.
DEACTIVATION
The EPB will normally auto release. Depress the brake or accelerator pedal to auto release it, or press the switch (A) to manually release it. The
associated warning lamps on both the switch and dashboard instrument panel will go out to confirm its deactivation. Note: seatbelts should be fastened,
and luggage should not be placed on seats.
WHEN DRIVING AWAY
The parking brake will deactivate automatically when driving away, and it also prevents the vehicle from rolling back unintentionally for a few seconds
when starting on a gradient. This works by driving off in a normal way, the parking brake will automatically release and the vehicle will start moving in the
desired direction.
On vehicles fitted with an automatic gear box, you can apply the parking brake when stopping briefly at traffic lights etc., to avoid the vehicle creeping
forward. When you drive off the parking brake will be automatically released.
INFORMATION
Vehicle specifications are subject to change. This vehicle does not include any manufacturer handbooks or manuals.
VEHICLE INSTRUCTION CARD SUPPLEMENT
No responsibility is accepted for inaccuracies or misunderstanding caused by the wording of this guide. If in any doubt ask a member of staff for assistance.
KIA VEHICLES
Where fitted, the electronic parking brake replaces the mechanical handbrake and is designed to prevent the vehicle from accidently rolling away. This
system offers convenience and safety features in addition to those normally associated with a mechanical handbrake. Please refer to the primary Vehicle
Instruction Guide for information about other operational instructions.
05-02-2017
ELECTRONIC PARKING BRAKE (EPB)
Don’t panic! Despite seeing a new light pop-up on your instrument panel, unless it is red it is likely the car is still running fine, and while there may be a
problem to attend to, proceed with confidence and patience.
RED indicates a potentially serious problem or safety issue. Attend to it! Red may also indicate an important reminder.
YELLOW or orange means something needs to be serviced or repaired soon. If it is flashing, it is important that you contact your rental agent for advice.
GREEN or blue is only telling you that a system is on or operating normally.
WARNING LIGHTS AND WHAT THEY MEAN
Deadlock / safelock messages shown on the instrument display when the engine is turned off simply indicate that once you exit the vehicle and lock the
doors, they’re effectively deadlocked and anyone left in the car wouldn’t be able to get out in the event of an emergency. The warning is nothing to worry
about and is just a standard advisory message.
DEADLOCKS
A seatbelt warning light may illuminate when the engine is turned on. This may mean that the electronic parking brake (EPB) becomes auto activated to
prevent vehicle movement. To deactivate these warning lights, and turn off the auto activation of the EPB in this instance, ensure all passengers fasten
their seatbelts, and remove any luggage from on top of the seats. For safety secure all luggage inside the boot.
SEATBELT WARNING LIGHTS
Unless indicated otherwise by road traffic signs and/or local road regulations and/or dictated by weather conditions, the Highway Code states that
provided always it is safe to do so, a passenger vehicle may be driven at the following MAXIMUM speeds (MPH):
DRIVING RESTRICTIONS AND/OR CONDITIONS
Drivers are reminded that they are responsible for the consequences arising out of their failure
to comply at all times with the requirements of any applicable Road Traffic Regulations, the
Highway Code and/or to the road conditions prevailing at the time and in the locality through
which they are driving the vehicle.
Europcar accepts no responsibility or liability for any costs, claims, penalties, fines or any other
circumstances arising out of or in connection with the driver’s failure to comply with all and any
road restrictions and/or conditions.

USEFUL INFORMATION ABOUT YOUR VEHICLE
design and production by : Drake Enterprises Limited - Phone : [phone]
CHILD SEATS
FUEL IN CASE OF BREAKDOWN DRIVER’S SEAT
Vehicle specifications are subject to change. When the engine is turned off, ensure that the starter switch is in position II when operating electrical items such
as door mirrors and windows, etc. This vehicle does not include any manufacturer handbooks or manuals.
No responsibility is accepted for inaccuracies or misunderstanding caused by the wording of this guide. If in any doubt ask a member of staff for assistance.
Use hazard lights. Attempt to park
in a safe position.
Use an emergency phone rather
than a mobile as emergency
services will then know the location
of the vehicle.
Never use a child seat in a front
passenger seat which is fitted with
an active airbag (SRS). Follow all
fitting instructions carefully.
Check seat positioning and security
before use.
VEHICLE INSTRUCTION CARD
TYRE PRESSURES (COLD)
CONTROLS
When parked, the handbrake should be fully
applied with the vehicle left in first or reverse
gear for vehicles equipped with manual
transmission or P (Park) for vehicles with
automatic transmission.
CAUTION!
For assistance after an accident/incident, please call 0800 0280 999
For assistance after a breakdown or help with tyres or windscreens please refer to the numbers on the tax disc holder.
TYRE HELPLINE
In the event of having a punctured tyre
please call the Europcar Tyre Helpline
0800 0280 999 for ANY assistance.
NOTE: Vehicles are not usually supplied
with a tyre repair kit (for vehicles that use
this in lieu of a spare wheel).
KIA PICANTO 5 DOOR HATCH
5 SEATS
Key / remote control operated central dead locking. Depress the button on the centre console to lock from inside or depress
the door locking knobs.
Passive arming of electronic engine immobiliser after removal of the key from the starter switch. Visible VIN plate.
Centrally locked. Use the key or remote control to unlock / open.
Electric adjustment operated by the control pad on the driver’s door (or manual adjustment on entry models).
Electric front and rear operated via control buttons on the driver’s door. Or manually operated rear windows.
If fitted - electric sunroof operated by roof mounted switches.
Press the centre console central locking button to lock them. Check from inside that the doors are securely locked.
Ensure gear selector is in neutral (or P if automatic) and handbrake is on. Place ignition key in starter switch next to steering
wheel. Use a normal starting routine. Select desired gear. Release handbrake and brake pedal and gently press the
accelerator to move the vehicle.
Located under flap on rear nearside. Centrally locked. A remote release button may be present on right hand side of driver’s
seat. Press the edge of the flap to open it, and twist off the cap anticlockwise. Press the flap closed.
Pull bonnet release lever located on the right of the driver’s footwell. Unhook catch under bonnet.
The rear seat is divided into 60:40 sections which can be separately folded. To release the seat press the seat unlocking
catch and fold the seat down. To return the seat to normal use, raise the seat and push it firmly to engage the seat lock.
Check it is locked before using the seat.
Lift the carpet cover to access the storage area housing the tools. Move the vehicle to firm / level ground. Turn the engine
off, select first gear (manual) or P (automatic). Apply the handbrake or parking brake. Loosen the wheel nuts (do not remove
them). Only use the specific reinforced jack points on the underside of the vehicle. Crank the jack to lift the vehicle. Undo
wheel nuts and change the wheel. Lower the vehicle. Tighten the wheel nuts. For any assistance in the event of having a
punctured tyre, or should the vehicle not be supplied with a spare wheel and tyre or a tyre repair kit, please call the
Europcar Tyre Helpline 0800 0280 999.
Select Nfor neutral, Pwhen leaving the vehicle, Rfor reversing (the vehicle must be at a complete standstill before this
gear can be selected). For normal driving select Dwhere the transmission will use all available forward gears automatically
(a ‘kickdown ‘ facility is provided when the accelerator is pressed all the way to the floor past the normal acceleration point
forcing the transmission to select a lower gear to obtain maximum acceleration. Release pressure on the accelerator to
return to normal accelerator use). Use low gear 1and 2at low speed only. Whenever the vehicle is at a standstill apply the
handbrake or parking brake.
VIC-KIA-01 / 30-09-2017
Check tyre pressure regularly
Legal minimum tread depth is 1.6 mm
175/65 R14
185/55 R15
195/45 R16
Check the tyre pressure table found on
the inside of driver’s door B-pillar (or fuel
filler cap).
Note: driving speeds and travel distances
are restricted when using spacesaver
spare tyres.
1Heating & Ventilation
2Hazard Lights
3Starter Switch
4Headlights
5Sidelights
6Indicators
7Wipers
8Rear Screen Wipers
9Horn
10 Bonnet Release (not shown)
11 Heated Rear Screen
12 Rear Fog Lamp
13 Front Fog Lamp 10
3
1
11
4 / 5 / 6 / 12 / 13
9
7 / 8
2
Ensure you use the correct fuel
type. Only use unleaded petrol
in petrol vehicles (see inside of
filler flap).
Fuel Tank Capacity:
35.0 litres
Tilt
Lumbar
Legroom
Height
Locking the doors?
Anti-theft system?
Opening the boot?
Adjusting door mirrors?
Opening the windows?
Operating the sunroof?
Using child door locks?
Starting the engine?
Opening fuel filler cap?
Releasing the bonnet?
Folding the rear seats?
How to change a tyre?
How to drive an
automatic?
9
P
R
N
D
2
1
or +
_
1 3 5
2 4 R

USEFUL INFORMATION ABOUT YOUR VEHICLE
design and production by : Drake Enterprises Limited - Phone : [phone]
CHILD SEATS
FUEL IN CASE OF BREAKDOWN DRIVER’S SEAT
Vehicle specifications are subject to change. When the engine is turned off, ensure that the starter switch is in position II when operating electrical items such
as door mirrors and windows, etc. This vehicle does not include any manufacturer handbooks or manuals.
No responsibility is accepted for inaccuracies or misunderstanding caused by the wording of this guide. If in any doubt ask a member of staff for assistance.
Use hazard lights. Attempt to park
in a safe position.
Use an emergency phone rather
than a mobile as emergency
services will then know the location
of the vehicle.
Never use a child seat in a front
passenger seat which is fitted with
an active airbag (SRS). Follow all
fitting instructions carefully.
Check seat positioning and security
before use.
VEHICLE INSTRUCTION CARD
TYRE PRESSURES (COLD)
CONTROLS
When parked, the handbrake should be fully
applied with the vehicle left in first or reverse
gear for vehicles equipped with manual
transmission or P (Park) for vehicles with
automatic transmission.
CAUTION!
For assistance after an accident/incident, please call 0800 0280 999
For assistance after a breakdown or help with tyres or windscreens please refer to the numbers on the tax disc holder.
TYRE HELPLINE
In the event of having a punctured tyre
please call the Europcar Tyre Helpline
0800 0280 999 for ANY assistance.
NOTE: Vehicles are not usually supplied
with a tyre repair kit (for vehicles that use
this in lieu of a spare wheel).
KIA RIO 5-5 DOOR HATCH
5 SEATS
Key / remote control operated central dead locking. Depress the central locking buttons on the driver’s door to lock the
doors from the inside.
Passive arming of electronic engine immobiliser after removal of the key from the starter switch.
Centrally locked. Use the key or remote control to unlock / open.
Electric adjustment operated by the control pad on the driver’s door. Or manual internal adjustment.
.
Electric front and rear operated via control buttons on the driver’s door. Or manually operated rear windows.
If fitted, roof mounted switchgear is used to control the electric tilt / slide sunroof.
Located on the edge of the rear doors, twist the slot to activate it, or lock the doors by pressing the central locking button on
the driver’s door. Check from inside that the doors are securely locked.
Ensure gear selector is in neutral (or P if automatic) and handbrake is on. Place ignition key in starter switch next to steering
wheel. Use a normal starting routine. Select desired gear. Release handbrake and brake pedal and gently press the
accelerator to move the vehicle. Some vehicles feature auto engine start/stop technology where the engine switches off at
standstill or when idling - just depress the clutch to instantly restart the engine.
Located under flap on rear nearside. Centrally locked. Pull the remote release button. Lift the edge of the flap to open it, and
twist off the cap anticlockwise.
Pull bonnet release lever located on the right of the driver’s footwell. Unhook catch under bonnet.
The rear seat is divided into sections which can be separately folded. To release the seat press the seat unlocking catch
and fold the seat down. To return the seat to normal use, raise the seat and push it firmly to engage the seat lock. Check it is
locked before using the seat.
Lift the carpet cover to access the storage area housing some of the tools. Move the vehicle to firm / level ground. Turn the
engine off, select first gear (manual) or P (automatic). Apply the handbrake or parking brake. Loosen the wheel nuts (do not
remove them). Only use the specific reinforced jack points on the underside of the vehicle. Crank the jack to lift the vehicle.
Undo wheel nuts and change the wheel. Lower the vehicle. Tighten the wheel nuts. For any assistance in the event of
having a punctured tyre, or should the vehicle not be supplied with a spare wheel and tyre or a tyre repair kit, please
call the Europcar Tyre Helpline 0800 0280 999.
Select Nfor neutral, Pwhen leaving the vehicle, Rfor reversing (the vehicle must be at a complete standstill before this
gear can be selected). For normal driving select Dwhere the transmission will use all available forward gears automatically
(a ‘kickdown ‘ facility is provided when the accelerator is pressed all the way to the floor past the normal acceleration point
forcing the transmission to select a lower gear to obtain maximum acceleration. Release pressure on the accelerator to
return to normal accelerator use). Whenever the vehicle is at a standstill apply the handbrake or parking brake.
VIC-KIA-02 / 23-06-2012
Check tyre pressure regularly
Legal minimum tread depth is 1.6 mm
185/65 R15
195/55 R16
205/45 R17
Check the tyre pressure table found on
the inside of driver’s door B-pillar (or fuel
filler cap).
Some models may be fitted with an
electronic tyre pressure monitor.
Note: driving speeds and travel distances
are restricted when using spacesaver
spare tyres.
1Heating & Ventilation
2Hazard Lights
3Starter Switch
4Headlights
5Sidelights
6Indicators
7Wipers
8Rear Screen Wipers
9Horn
10 Bonnet Release (not shown)
11 Heated Rear Screen
12 Rear Fog Lamp
13 Front Fog Lamp
10
3
1
11
12 / 13
9
7 / 8
2
Ensure you use the correct fuel
type. Only use unleaded petrol
in petrol vehicles (see inside of
filler flap).
Fuel Tank Capacity:
43.0 litres
Tilt
Lumbar
Legroom
Height
Locking the doors?
Anti-theft system?
Opening the boot?
Adjusting door mirrors?
Opening the windows?
Operating the sunroof?
Using child door locks?
Starting the engine?
Opening fuel filler cap?
Releasing the bonnet?
Folding the rear seats?
How to change a tyre?
How to drive an
automatic?
9
4 / 5 / 6
P
R
N
D
or
R 1 3
246
5
+
_

USEFUL INFORMATION ABOUT YOUR VEHICLE
design and production by : Drake Enterprises Limited - Phone : [phone]
CHILD SEATS
FUEL IN CASE OF BREAKDOWN DRIVER’S SEAT
Vehicle specifications are subject to change. When the engine is turned off, ensure that the starter switch is in position II when operating electrical items such
as door mirrors and windows, etc. This vehicle does not include any manufacturer handbooks or manuals.
No responsibility is accepted for inaccuracies or misunderstanding caused by the wording of this guide. If in any doubt ask a member of staff for assistance.
Use hazard lights. Attempt to park
in a safe position.
Use an emergency phone rather
than a mobile as emergency
services will then know the location
of the vehicle.
Never use a child seat in a front
passenger seat which is fitted with
an active airbag (SRS). Follow all
fitting instructions carefully.
Check seat positioning and security
before use.
VEHICLE INSTRUCTION CARD
TYRE PRESSURES (COLD)
CONTROLS
When parked, the handbrake should be fully
applied with the vehicle left in first or reverse
gear for vehicles equipped with manual
transmission or P (Park) for vehicles with
automatic transmission.
CAUTION!
For assistance after an accident/incident, please call 0800 0280 999
For assistance after a breakdown or help with tyres or windscreens please refer to the numbers on the tax disc holder.
TYRE HELPLINE
In the event of having a punctured tyre
please call the Europcar Tyre Helpline
0800 0280 999 for ANY assistance.
NOTE: Vehicles are not usually supplied
with a tyre repair kit (for vehicles that use
this in lieu of a spare wheel).
5 DOOR HATCH / ESTATE
5 SEATS
Key / remote control operated central dead locking. Depress the central locking switch to lock the doors from the inside.
Auto locking of doors on pulling away. Some vehicles feature a keyless entry system.
Passive arming of electronic engine immobiliser after removal of the key from the starter switch. Visible VIN plate.
Centrally locked. Use the key or remote control to unlock / open.
Electric adjustment operated by the control pad on the driver’s door.
Electric front and rear operated via control buttons on the driver’s door.
If fitted, roof mounted switchgear is used to control the electric tilt / slide panoramic sunroof.
Located on the edge of the rear doors, twist the slot to activate it (or press the central locking switch). Check from inside that
the doors are securely locked.
Ensure gear selector is in neutral (or P if automatic) and electronic parking brake is on. Place ignition key in starter switch
next to steering wheel / press the engine start/stop button on the dashboard to start or stop the engine. Select desired gear.
Release electronic parking brake and brake pedal and gently press the accelerator to move the vehicle. Vehicles feature
auto engine start/stop technology where the engine switches off when at standstill, gears are in neutral and foot pedals are
not depressed - just depress the clutch or accelerator to instantly restart the engine.
Located under flap on rear nearside. Centrally locked. Remote release. Lightly press the edge of the flap to open it, and
twist off the fuel cap anticlockwise.
Pull bonnet release lever located on the right of the driver’s footwell. Unhook catch under bonnet.
The rear seat is divided into 40:20:40 sections which can be separately flat-folded. To release the seat press the seat
unlocking catch and fold the seat down. To return the seat to normal use, raise the seat and push it firmly to engage the seat
lock. Check it is locked before using the seat.
Vehicles are not normally supplied with a spare wheel or tyre repair kit. For any assistance in the event of having a
punctured tyre, or should the vehicle not be supplied with a spare wheel and tyre or a tyre repair kit, please call the
Europcar Tyre Helpline 0800 0280 999. Lift the carpet cover to access the temporary spare wheel and tools. Move the
vehicle to firm / level ground. Turn the engine off, select first gear (manual) or P (automatic). Apply the electronic parking
brake or parking brake. Loosen the wheel nuts (do not remove them). Only use the specific reinforced jack points on the
underside of the vehicle. Crank the jack to lift the vehicle. Undo wheel nuts and change the wheel. Lower the vehicle.
Tighten the wheel nuts.
Select Nfor neutral, Pwhen leaving the vehicle, Rfor reversing (the vehicle must be at a complete standstill before this
gear can be selected). For normal driving select Dwhere the transmission will use all available forward gears automatically
(a ‘kickdown ‘ facility is provided when the accelerator is pressed all the way to the floor past the normal acceleration point
forcing the transmission to select a lower gear to obtain maximum acceleration. Release pressure on the accelerator to
return to normal accelerator use). For manual selection of gears use the D+ or D- options to select gears. Whenever the
vehicle is at a standstill apply the electronic parking brake.
VIC-KIA-03 / 14-04-2019
Locking the doors?
Anti-theft system?
Opening boot/tailgate?
Adjusting door mirrors?
Opening the windows?
Operating the sunroof?
Using child door locks?
Starting the engine?
Opening fuel filler cap?
Releasing the bonnet?
Folding the rear seats?
How to change a tyre?
Driving an automatic?
Check tyre pressure regularly
Legal minimum tread depth is 1.6 mm
205/55 R16
225/45 R17
225/40 R18
Check the tyre pressure table found on
the inside of driver’s door B-pillar (or fuel
filler cap).
Note: driving speeds and travel distances
are restricted when using spacesaver
spare tyres.
1Heating & Ventilation
2Hazard Lights
3Starter Switch
4Headlights
5Sidelights
6Indicators
7Wipers
8Rear Screen Wipers
9Horn
10 Bonnet Release (not shown)
11 Heated Rear Screen
12 Rear Fog Lamp
13 Front Fog Lamp
14 Electronic Parking Brake
10
3
1
11
P
R
N
D
or
4 / 5 / 6 / 12 / 13
7 / 8
2
Ensure you use the correct fuel
type. Only use unleaded petrol
in petrol vehicles (see inside of
filler flap).
Fuel Tank Capacity:
50 litres
Tilt
Lumbar
Legroom
Height
KIA CEE’D
9
R 1 3
246
5
+
_
14

USEFUL INFORMATION ABOUT YOUR VEHICLE
design and production by : Drake Enterprises Limited - Phone : [phone]
CHILD SEATS
FUEL IN CASE OF BREAKDOWN DRIVER’S SEAT
Vehicle specifications are subject to change. When the engine is turned off, ensure that the starter switch is in position II when operating electrical items such
as door mirrors and windows, etc. This vehicle does not include any manufacturer handbooks or manuals.
No responsibility is accepted for inaccuracies or misunderstanding caused by the wording of this guide. If in any doubt ask a member of staff for assistance.
Use hazard lights. Attempt to park
in a safe position.
Use an emergency phone rather
than a mobile as emergency
services will then know the location
of the vehicle.
Never use a child seat in a front
passenger seat which is fitted with
an active airbag (SRS). Follow all
fitting instructions carefully.
Check seat positioning and security
before use.
VEHICLE INSTRUCTION CARD
TYRE PRESSURES (COLD)
CONTROLS
When parked, the handbrake should be fully
applied with the vehicle left in first or reverse
gear for vehicles equipped with manual
transmission or P (Park) for vehicles with
automatic transmission.
CAUTION!
For assistance after an accident/incident, please call 0800 0280 999
For assistance after a breakdown or help with tyres or windscreens please refer to the numbers on the tax disc holder.
TYRE HELPLINE
In the event of having a punctured tyre
please call the Europcar Tyre Helpline
0800 0280 999 for ANY assistance.
NOTE: Vehicles are not usually supplied
with a tyre repair kit (for vehicles that use
this in lieu of a spare wheel).
KIA VENGA 5 DOOR HATCHBACK
5 SEATS
Key / remote control operated central dead locking. Depress the central locking switch on the driver’s door to lock doors
from the inside. Doors will also auto-lock on vehicle motion.
Passive arming of electronic engine immobiliser after removal of the key from the starter switch. Vehicles may be fitted with
an alarm. Visible VIN plate.
Centrally locked. Use the key or remote control to unlock / open. Boot is fitted with luggage net hooks.
Electric adjustment operated by the control pad on the driver’s door. Some models feature an electric folding facility.
Electric front and rear operated via control buttons on the driver’s door.
If fitted: Electric panoramic sunroof operated by roof mounted switchgear.
Located on the edge of the rear doors, twist the slot to activate it. Or press the central locking switch on the driver’s door.
Doors also auto-lock on vehicle motion. Check from inside that the doors are securely locked.
Ensure gear selector is in neutral (or P if automatic) and handrake is on. Place ignition key in starter key slot to right of
steering wheel. Turn the key to start / stop. Select desired gear. Release handbrake and brake pedal and gently press the
accelerator to move the vehicle. Some models may feature automatic start / stop technology, whereby the engine auto shuts
off when stationary, simply depress the clutch to restart the engine. (To activate start / stop when stopping - put the gear
selector into neutral and remove your foot from the clutch, the engine will then auto-stop).
Located under flap on rear offside. Centrally locked. Press the remote release button on the driver’s door. Lift the edge of
the flap to open it, and twist off the cap anticlockwise.
Pull bonnet release lever located on the right of the driver’s footwell. Unhook catch under bonnet.
The rear seats are divided into sections which can be separately flat-folded. To release the seat press the seat unlocking
catch and fold the seat down. The seats feature a slide and recline option. To return the seat to normal use, raise the seat
and push it firmly to engage the seat lock. Check it is locked before using the seat.
Lift the carpet cover to access the tools and jack. Move the vehicle to firm / level ground. Turn the engine off, select first gear
(manual) or P (automatic). Apply the handbrake or parking brake. Loosen the wheel nuts (do not remove them). Only use
the specific reinforced jack points on the underside of the vehicle. Crank the jack to lift the vehicle. Undo wheel nuts and
change the wheel. Lower the vehicle. Tighten the wheel nuts. For any assistance in the event of having a punctured tyre,
or should the vehicle not be supplied with a spare wheel and tyre or a tyre repair kit, please call the Europcar Tyre
Helpline 0800 0280 999.
Select Nfor neutral, Pwhen leaving the vehicle, Rfor reversing (the vehicle must be at a complete standstill before this
gear can be selected). For normal driving select Dwhere the transmission will use all available forward gears automatically
(a ‘kickdown ‘ facility is provided when the accelerator is pressed all the way to the floor past the normal acceleration point
forcing the transmission to select a lower gear to obtain maximum acceleration. Use D+ or D- to manually select gears.
Release pressure on the accelerator to return to normal accelerator use). Whenever the vehicle is at a standstill apply the
handbrake.
VIC-KIA-04 / 23-06-2012
Ensure you use the correct fuel
type. Only use unleaded petrol
in petrol vehicles (see inside of
filler flap).
Fuel Tank Capacity:
48.0 litres
Check tyre pressure regularly
Legal minimum tread depth is 1.6 mm
Check the tyre pressure table found on
the inside of driver’s door B-pillar (or fuel
filler cap).
195/65 R15
205/50 R16
Some models may be fitted with an
electronic tyre pressure monitor.
1Heating & Ventilation
2Hazard Lights
3Starter Switch
4Headlights
5Sidelights
6Indicators
7Wipers
8Rear Screen Wipers
9Horn
10 Bonnet Release
11 Heated Rear Screen
12 Rear Fog Lamp
13 Front Fog Lamp
Tilt
Lumbar
Legroom
Height
10
3
2
1
11
4 / 5 / 6 / 12 / 13
9
7 / 8
9
Locking the doors?
Anti-theft system?
Opening the boot?
Adjusting door mirrors?
Opening the windows?
Operating the sunroof?
Using child door locks?
Starting the engine?
Opening fuel filler cap?
Releasing the bonnet?
Folding the rear seats?
How to change a tyre?
How to drive an
automatic?
or
1 3 5
2 4 6
R
9
P
R
N
D+
_

USEFUL INFORMATION ABOUT YOUR VEHICLE
design and production by : Drake Enterprises Limited - Phone : [phone]
CHILD SEATS
FUEL IN CASE OF BREAKDOWN DRIVER’S SEAT
Vehicle specifications are subject to change. When the engine is turned off, ensure that the starter switch is in position II when operating electrical items such
as door mirrors and windows, etc. This vehicle does not include any manufacturer handbooks or manuals.
No responsibility is accepted for inaccuracies or misunderstanding caused by the wording of this guide. If in any doubt ask a member of staff for assistance.
Use hazard lights. Attempt to park
in a safe position.
Use an emergency phone rather
than a mobile as emergency
services will then know the location
of the vehicle.
Never use a child seat in a front
passenger seat which is fitted with
an active airbag (SRS). Follow all
fitting instructions carefully.
Check seat positioning and security
before use.
VEHICLE INSTRUCTION CARD
TYRE PRESSURES (COLD)
CONTROLS
When parked, the handbrake should be fully
applied with the vehicle left in first or reverse
gear for vehicles equipped with manual
transmission or P (Park) for vehicles with
automatic transmission.
CAUTION!
For assistance after an accident/incident, please call 0800 0280 999
For assistance after a breakdown or help with tyres or windscreens please refer to the numbers on the tax disc holder.
TYRE HELPLINE
In the event of having a punctured tyre
please call the Europcar Tyre Helpline
0800 0280 999 for ANY assistance.
NOTE: Vehicles are not usually supplied
with a tyre repair kit (for vehicles that use
this in lieu of a spare wheel).
When parked, the parking brake should be
fully applied with the vehicle left in first or
reverse gear for vehicles equipped with manual
transmission or P (Park) for vehicles with
automatic transmission.
CAUTION!
4 DOOR SALOON
5 SEATS
Passive arming of electronic engine immobiliser after removal of the key from the starter switch. Visible VIN plate.
Key / remote control operated central dead locking. Depress the centre console central locking switch to lock the doors
from the inside. Auto locking of doors on vehicle motion. Some vehicles feature a keyless entry system.
Centrally locked. Use the key or remote control to unlock / open.
Electric adjustment operated by the control pad on the driver’s door.
Electric front operated via control buttons on the driver’s door.
If fitted, roof mounted switchgear is used to control the electric tilt / slide panoramic sunroof.
Located on the edge of the rear doors. Press the central locking switch to activate. Check from inside that the doors are
securely locked.
Ensure gear selector is in neutral (or P if automatic) and electric parking brake is on. Use a normal ignition key start/stop
procedure, or some vehicles are fitted with an engine start/stop button (simply carry the key in your pocket or handbag,
and press the button to start or stop the engine). Select desired gear. Release electric parking brake and brake pedal and
gently press the accelerator to move the vehicle. Some vehicles feature auto engine start/stop technology where the engine
switches off at standstill or when idling - just depress the clutch to instantly restart the engine.
Located under flap on rear offside. Centrally locked. Remote release. Lift the edge of the flap to open it, and twist off the
cap anticlockwise.
Pull bonnet release lever located on the right of the driver’s footwell. Unhook catch under bonnet.
The rear seat is divided into sections which can be separately folded. To release the seat press the seat unlocking catch
and fold the seat down. To return the seat to normal use, raise the seat and push it firmly to engage the seat lock. Check it is
locked before using the seat.
Lift the carpet cover to access the temporary spare wheel and tools. Move the vehicle to firm / level ground. Turn the engine
off, select first gear (manual) or P (automatic). Apply the handbrake or parking brake. Loosen the wheel nuts (do not remove
them). Only use the specific reinforced jack points on the underside of the vehicle. Crank the jack to lift the vehicle. Undo
wheel nuts and change the wheel. Lower the vehicle. Tighten the wheel nuts. For any assistance in the event of having a
punctured tyre, or should the vehicle not be supplied with a spare wheel and tyre or a tyre repair kit, please call the
Europcar Tyre Helpline 0800 0280 999.
Select Nfor neutral, Pwhen leaving the vehicle, Rfor reversing (the vehicle must be at a complete standstill before this
gear can be selected). For normal driving select Dwhere the transmission will use all available forward gears automatically
(a ‘kickdown ‘ facility is provided when the accelerator is pressed all the way to the floor past the normal acceleration point
forcing the transmission to select a lower gear to obtain maximum acceleration. Release pressure on the accelerator to
return to normal accelerator use). For manual selection of gears use the D+ or D- options to select gears. Whenever the
vehicle is at a standstill apply the electric parking brake.
VIC-KIA-05 / 28-01-2015
Anti-theft system?
Locking the doors?
Opening boot/tailgate?
Adjusting door mirrors?
Opening the windows?
Operating the sunroof?
Using child door locks?
Starting the engine?
Opening fuel filler cap?
Releasing the bonnet?
Folding the rear seats?
How to change a tyre?
Driving an automatic?
Check tyre pressure regularly
Legal minimum tread depth is 1.6 mm
205/65 R16
215/55 R17
225/45 R18
Check the tyre pressure table found on
the inside of driver’s door B-pillar (or fuel
filler cap).
Note: driving speeds and travel distances
are restricted when using spacesaver
spare tyres.
1Heating & Ventilation
2Hazard Lights
3Starter Switch
4Headlights
5Sidelights
6Indicators
7Wipers
8Rear Screen Wipers
9Horn
10 Bonnet Release (not shown)
11 Heated Rear Screen
12 Rear Fog Lamp
13 Front Fog Lamp
10
3
1
11
P
R
N
D
or
4 / 5 / 6 / 12 / 13
7 / 8
2
Ensure you use the correct fuel
type. Only use unleaded petrol
in petrol vehicles (see inside of
filler flap).
Fuel Tank Capacity:
70.0 litres
Tilt
Lumbar
Legroom
Height
KIA OPTIMA
9
R 1 3
246
5
+
_
9

USEFUL INFORMATION ABOUT YOUR VEHICLE
design and production by : Drake Enterprises Limited - Phone : [phone]
CHILD SEATS
FUEL IN CASE OF BREAKDOWN DRIVER’S SEAT
Vehicle specifications are subject to change. When the engine is turned off, ensure that the starter switch is in position II when operating electrical items such
as door mirrors and windows, etc. This vehicle does not include any manufacturer handbooks or manuals.
No responsibility is accepted for inaccuracies or misunderstanding caused by the wording of this guide. If in any doubt ask a member of staff for assistance.
Use hazard lights. Attempt to park
in a safe position.
Use an emergency phone rather
than a mobile as emergency
services will then know the location
of the vehicle.
Never use a child seat in a front
passenger seat which is fitted with
an active airbag (SRS). Follow all
fitting instructions carefully.
Check seat positioning and security
before use.
VEHICLE INSTRUCTION CARD
TYRE PRESSURES (COLD)
CONTROLS
When parked, the handbrake should be fully
applied with the vehicle left in first or reverse
gear for vehicles equipped with manual
transmission or P (Park) for vehicles with
automatic transmission.
CAUTION!
For assistance after an accident/incident, please call 0800 0280 999
For assistance after a breakdown or help with tyres or windscreens please refer to the numbers on the tax disc holder.
TYRE HELPLINE
In the event of having a punctured tyre
please call the Europcar Tyre Helpline
0800 0280 999 for ANY assistance.
NOTE: Vehicles are not usually supplied
with a tyre repair kit (for vehicles that use
this in lieu of a spare wheel).
KIA NIRO
VIC-KIA-06 / 11-02-2018
HYBRID SUV
5 DOOR / 5 SEATS
Key / remote control operated central dead locking. Depress the central locking switch on the driver’s door to lock doors
from the inside. Doors will also auto-lock on vehicle motion.
Passive arming of electronic engine immobiliser after removal of the key from the starter switch. Anti-theft alarm.
Centrally locked. Use the key or remote control to unlock / open. Press lower right dashboard switch for remote release.
Electric adjustment operated by the control pad on the driver’s door.
Electric front and rear operated via control buttons on the driver’s door.
If fitted: Electric tilt / slide panoramic sunroof operated by roof mounted switchgear.
Located on the edge of the rear doors, twist the slot to activate it. Or press the central locking switch on the driver’s door.
Doors also auto-lock on vehicle motion. Check from inside that the doors are securely locked.
Ensure gear selector is in neutral (or P if automatic) and parking brake is on. Place ignition key in starter key slot to right
of steering wheel. Press the engine start/stop button to start or stop the engine or turn the key for models not fitted with a
smart key. Select desired gear. Release parking brake and brake pedal and gently press the accelerator to move the vehicle.
Located under flap on rear offside. Centrally locked. Press the remote release button on the driver’s door. Press the edge of
the flap to open it, and twist off the cap anticlockwise. Press the flap closed.
Pull bonnet release lever located on the right of the driver’s footwell. Unhook catch under bonnet.
The rear seats are divided into 60:40 sections which can be separately flat-folded. To release the seat press the seat
unlocking catch and fold the seat down. To remove it, release the seat lock and slide / lift it out. To return the seat to normal
use, raise the seat and push it firmly to engage the seat lock. Check it is locked before using the seat.
The vehicle is not normally supplied with a spare wheel or tyre repair kit. For any assistance in the event of having a
punctured tyre, or should the vehicle not be supplied with a spare wheel and tyre or a tyre repair kit, please call
the Europcar Tyre Helpline 0800 0280 999. Lift the carpet cover to access the storage area housing the standard spare
wheel, tools and jack. Move the vehicle to firm / level ground. Turn the engine off, select first gear (manual) or P (automatic).
Apply the parking brake. Loosen the wheel nuts (do not remove them). Only use the specific reinforced jack points on
the underside of the vehicle. Crank the jack to lift the vehicle. Undo wheel nuts and change the wheel. Lower the vehicle.
Tighten the wheel nuts.
Select Nfor neutral, Pwhen leaving the vehicle, Rfor reversing (the vehicle must be at a complete standstill before this
gear can be selected). For normal driving select Dwhere the transmission will use all available forward gears automatically
(a ‘kickdown ‘ facility is provided when the accelerator is pressed all the way to the floor past the normal acceleration point
forcing the transmission to select a lower gear to obtain maximum acceleration. Use D+ or D- to manually select gears.
Release pressure on the accelerator to return to normal accelerator use). Whenever the vehicle is at a standstill apply the
parking brake.
Hybrid power: electric power is used when starting from a stop; mid-acceleration uses electric power; full acceleration
uses electric motor and petrol engine; cruising uses hybrid power assisting the main petrol power; during deceleration and
braking the electric hybrid battery energy regenerates.
Ensure you use the correct fuel
type. Only use unleaded petrol
in petrol vehicles (see inside of
filler flap).
Fuel Tank Capacity:
45.0 litres
Check tyre pressure regularly
Legal minimum tread depth is 1.6 mm
Check the tyre pressure table found on
the inside of driver’s door B-pillar (or fuel
filler cap).
205/60 R16
225/45 R18
Some models may be fitted with an
electronic tyre pressure monitor.
1Heating & Ventilation
2Hazard Lights
3Starter Switch
4Headlights
5Sidelights
6Indicators
7Wipers
8Rear Screen Wipers
9Horn
10 Bonnet Release
11 Heated Rear Screen
12 Rear Fog Lamp
13 Front Fog Lamp
14 Electronic Parking Brake
15 Engine Start / Stop
Tilt
Lumbar
Legroom
Height
10
3
2
1
11
4 / 5 / 6 / 12 / 13
9
7 / 8
9
Locking the doors?
Anti-theft system?
Opening the boot?
Adjusting door mirrors?
Opening the windows?
Operating the sunroof?
Using child door locks?
Starting the engine?
Opening fuel filler cap?
Releasing the bonnet?
Folding the rear seats?
How to change a tyre?
How to drive an
automatic?
Using the hybrid mode?
or
1 3 5
2 4 6
RP
R
N
D+
_
14
15

USEFUL INFORMATION ABOUT YOUR VEHICLE
design and production by : Drake Enterprises Limited - Phone : [phone]
CHILD SEATS
FUEL IN CASE OF BREAKDOWN DRIVER’S SEAT
Vehicle specifications are subject to change. When the engine is turned off, ensure that the starter switch is in position II when operating electrical items such
as door mirrors and windows, etc. This vehicle does not include any manufacturer handbooks or manuals.
No responsibility is accepted for inaccuracies or misunderstanding caused by the wording of this guide. If in any doubt ask a member of staff for assistance.
Use hazard lights. Attempt to park
in a safe position.
Use an emergency phone rather
than a mobile as emergency
services will then know the location
of the vehicle.
Never use a child seat in a front
passenger seat which is fitted with
an active airbag (SRS). Follow all
fitting instructions carefully.
Check seat positioning and security
before use.
VEHICLE INSTRUCTION CARD
TYRE PRESSURES (COLD)
CONTROLS
When parked, the handbrake should be fully
applied with the vehicle left in first or reverse
gear for vehicles equipped with manual
transmission or P (Park) for vehicles with
automatic transmission.
CAUTION!
For assistance after an accident/incident, please call 0800 0280 999
For assistance after a breakdown or help with tyres or windscreens please refer to the numbers on the tax disc holder.
TYRE HELPLINE
In the event of having a punctured tyre
please call the Europcar Tyre Helpline
0800 0280 999 for ANY assistance.
NOTE: Vehicles are not usually supplied
with a tyre repair kit (for vehicles that use
this in lieu of a spare wheel).
KIA SPORTAGE SUV 2X4 OR 4X4
5 DOOR / 5 SEATS
Key / remote control operated central dead locking. Depress the central locking switch on the driver’s door to lock doors
from the inside. Doors will also auto-lock on vehicle motion.
Passive arming of electronic engine immobiliser after removal of the key from the starter switch. Anti-theft alarm.
Centrally locked. Use the key or remote control to unlock / open. Press lower right dashboard switch for remote release.
Electric adjustment operated by the control pad on the driver’s door.
Electric front and rear operated via control buttons on the driver’s door.
If fitted: Electric tilt / slide panoramic sunroof operated by roof mounted switchgear.
Located on the edge of the rear doors, twist the slot to activate it. Or press the central locking switch on the driver’s door.
Doors also auto-lock on vehicle motion. Check from inside that the doors are securely locked.
Ensure gear selector is in neutral (or P if automatic) and parking brake is on. Place ignition key in starter key slot to left of
steering wheel. Press the engine start/stop button to start or stop the engine or turn the key for models not fitted with a
smart key. Select desired gear. Release parking brake and brake pedal and gently press the accelerator to move the vehicle.
Located under flap on rear offside. Centrally locked. Press the remote release button on the driver’s door. Press the edge of
the flap to open it, and twist off the cap anticlockwise. Press the flap closed.
Pull bonnet release lever located on the right of the driver’s footwell. Unhook catch under bonnet.
The rear seats are divided into 60:40 sections which can be separately flat-folded. To release the seat press the seat
unlocking catch and fold the seat down. To remove it, release the seat lock and slide / lift it out. To return the seat to normal
use, raise the seat and push it firmly to engage the seat lock. Check it is locked before using the seat.
Lift the carpet cover to access the storage area housing the standard spare wheel, tools and jack. Move the vehicle to
firm / level ground. Turn the engine off, select first gear (manual) or P (automatic). Apply the handbrake or parking brake.
Loosen the wheel nuts (do not remove them). Only use the specific reinforced jack points on the underside of the vehicle.
Crank the jack to lift the vehicle. Undo wheel nuts and change the wheel. Lower the vehicle. Tighten the wheel nuts. For any
assistance in the event of having a punctured tyre, or should the vehicle not be supplied with a spare wheel and tyre
or a tyre repair kit, please call the Europcar Tyre Helpline 0800 0280 999.
Select Nfor neutral, Pwhen leaving the vehicle, Rfor reversing (the vehicle must be at a complete standstill before this
gear can be selected). For normal driving select Dwhere the transmission will use all available forward gears automatically
(a ‘kickdown ‘ facility is provided when the accelerator is pressed all the way to the floor past the normal acceleration point
forcing the transmission to select a lower gear to obtain maximum acceleration. Use D+ or D- to manually select gears.
Release pressure on the accelerator to return to normal accelerator use). Whenever the vehicle is at a standstill apply the
parking brake.
VIC-KIA-07 / 30-09-2017
Ensure you use the correct fuel
type. Only use unleaded petrol
in petrol vehicles (see inside of
filler flap).
Fuel Tank Capacity:
62.0 litres
Check tyre pressure regularly
Legal minimum tread depth is 1.6 mm
Check the tyre pressure table found on
the inside of driver’s door B-pillar (or fuel
filler cap).
215/70 R16
225/60 R17
245/45 R19
Some models may be fitted with an
electronic tyre pressure monitor.
1Heating & Ventilation
2Hazard Lights
3Starter Switch
4Headlights
5Sidelights
6Indicators
7Wipers
8Rear Screen Wipers
9Horn
10 Bonnet Release
11 Heated Rear Screen
12 Rear Fog Lamp
13 Front Fog Lamp
Tilt
Lumbar
Legroom
Height
10
3
2
1
11
4 / 5 / 6 / 12 / 13
9
7 / 8
9
Locking the doors?
Anti-theft system?
Opening the boot?
Adjusting door mirrors?
Opening the windows?
Operating the sunroof?
Using child door locks?
Starting the engine?
Opening fuel filler cap?
Releasing the bonnet?
Folding the rear seats?
How to change a tyre?
How to drive an
automatic?
or
1 3 5
2 4 6
RP
R
N
D+
_

USEFUL INFORMATION ABOUT YOUR VEHICLE
design and production by : Drake Enterprises Limited - Phone : [phone]
CHILD SEATS
FUEL IN CASE OF BREAKDOWN DRIVER’S SEAT
Vehicle specifications are subject to change. When the engine is turned off, ensure that the starter switch is in position II when operating electrical items such
as door mirrors and windows, etc. This vehicle does not include any manufacturer handbooks or manuals.
No responsibility is accepted for inaccuracies or misunderstanding caused by the wording of this guide. If in any doubt ask a member of staff for assistance.
Use hazard lights. Attempt to park
in a safe position.
Use an emergency phone rather
than a mobile as emergency
services will then know the location
of the vehicle.
Never use a child seat in a front
passenger seat which is fitted with
an active airbag (SRS). Follow all
fitting instructions carefully.
Check seat positioning and security
before use.
VEHICLE INSTRUCTION CARD
TYRE PRESSURES (COLD)
CONTROLS
When parked, the handbrake should be fully
applied with the vehicle left in first or reverse
gear for vehicles equipped with manual
transmission or P (Park) for vehicles with
automatic transmission.
CAUTION!
For assistance after an accident/incident, please call 0800 0280 999
For assistance after a breakdown or help with tyres or windscreens please refer to the numbers on the tax disc holder.
TYRE HELPLINE
In the event of having a punctured tyre
please call the Europcar Tyre Helpline
0800 0280 999 for ANY assistance.
NOTE: Vehicles are not usually supplied
with a tyre repair kit (for vehicles that use
this in lieu of a spare wheel).
KIA CARENS 5 DOOR MPV
7 SEATS
Key / remote control operated central dead locking. Depress the central locking button to lock the doors from the inside.
Passive arming of electronic engine immobiliser after removal of the key from the starter switch. Vehicles are fitted with an
alarm. Visible VIN plate.
Centrally locked. Use the key or remote control to unlock / open.
Electric adjustment operated by the control pad on the driver’s door.
Electric front and rear operated via control buttons on the driver’s door.
If fitted: Electric tilt / slide panoramic sunroof operated by roof mounted switchgear.
Press the centre console central locking button to lock them. Check from inside that the doors are securely locked.
Ensure gear selector is in neutral (or P if automatic) and parking brake is on. Press the engine start/stop button to start or
stop the engine. Select desired gear. Release parking brake and brake pedal and gently press the accelerator to move
the vehicle. Vehicles feature engine start/stop whereby the engine auto shuts off when stationary, gears are in neutral, and
pedals are not depressed - the engine instantly restarts when the clutch (or accelerator in auto) is depressed.
Located under flap on rear nearside. Centrally locked. Lightly press the edge of the flap to open it, and twist off the fuel
cap anticlockwise.
Pull bonnet release lever located on the right of the driver’s footwell. Unhook catch under bonnet.
The second and third rear seat rows are divided into sections which can be separately flat-folded. To release the seat press
the seat unlocking catch and fold the seat down. To return the seat to normal use, raise the seat and push it firmly to engage
the seat lock. Check it is locked before using the seat.
Vehicle is not normally supplied with a spare wheel or tyre repair kit. For any assistance in the event of having a
punctured tyre, or should the vehicle not be supplied with a spare wheel and tyre or a tyre repair kit, please call
the Europcar Tyre Helpline 0800 0280 999. Lift the carpet cover to access the storage area housing the standard (or
temporary) spare wheel, tools and jack. Move the vehicle to firm / level ground. Turn the engine off, select first gear (manual)
or P (automatic). Apply the handbrake or parking brake. Loosen the wheel nuts (do not remove them). Only use the specific
reinforced jack points on the underside of the vehicle. Crank the jack to lift the vehicle. Undo wheel nuts and change the
wheel. Lower the vehicle. Tighten the wheel nuts.
Select Nfor neutral, Pwhen leaving the vehicle, Rfor reversing (the vehicle must be at a complete standstill before this
gear can be selected). For normal driving select Dwhere the transmission will use all available forward gears automatically
(a ‘kickdown ‘ facility is provided when the accelerator is pressed all the way to the floor past the normal acceleration point
forcing the transmission to select a lower gear to obtain maximum acceleration. Use D+ or D- to manually select gears.
Release pressure on the accelerator to return to normal accelerator use). Whenever the vehicle is at a standstill apply the
electronic parking brake.
VIC-KIA-08 / 14-04-2019
Ensure you use the correct fuel
type. Only use unleaded petrol
in petrol vehicles (see inside of
filler flap).
Fuel Tank Capacity:
58.0 litres
Check tyre pressure regularly
Legal minimum tread depth is 1.6 mm
Check the tyre pressure table found on
the inside of driver’s door B-pillar (or fuel
filler cap).
205/55 R16
225/45 R17
Some models may be fitted with an
electronic tyre pressure monitor.
Note: driving speeds and travel distances
are restricted when using spacesaver
spare tyres.
1Heating & Ventilation
2Hazard Lights
3Engine Start/Stop
4Headlights
5Sidelights
6Indicators
7Wipers
8Rear Screen Wipers
9Horn
10 Bonnet Release
11 Heated Rear Screen
12 Rear Fog Lamp
13 Front Fog Lamp
14 Electronic Parking Brake
Tilt
Lumbar
Legroom
Height
10
3
2
1
11
4 / 5 / 6 / 12 / 13
7 / 8
9
Locking the doors?
Anti-theft system?
Opening the boot?
Adjusting door mirrors?
Opening the windows?
Operating the sunroof?
Using child door locks?
Starting the engine?
Opening fuel filler cap?
Releasing the bonnet?
Folding the rear seats?
How to change a tyre?
How to drive an
automatic?
P
R
N
D
or
R 1 3
246
5
+
_
9
14

USEFUL INFORMATION ABOUT YOUR VEHICLE
design and production by : Drake Enterprises Limited - Phone : [phone]
CHILD SEATS
FUEL IN CASE OF BREAKDOWN DRIVER’S SEAT
Vehicle specifications are subject to change. When the engine is turned off, ensure that the starter switch is in position II when operating electrical items such
as door mirrors and windows, etc. This vehicle does not include any manufacturer handbooks or manuals.
No responsibility is accepted for inaccuracies or misunderstanding caused by the wording of this guide. If in any doubt ask a member of staff for assistance.
Use hazard lights. Attempt to park
in a safe position.
Use an emergency phone rather
than a mobile as emergency
services will then know the location
of the vehicle.
Never use a child seat in a front
passenger seat which is fitted with
an active airbag (SRS). Follow all
fitting instructions carefully.
Check seat positioning and security
before use.
VEHICLE INSTRUCTION CARD
TYRE PRESSURES (COLD)
CONTROLS
When parked, the handbrake should be fully
applied with the vehicle left in first or reverse
gear for vehicles equipped with manual
transmission or P (Park) for vehicles with
automatic transmission.
CAUTION!
For assistance after an accident/incident, please call 0800 0280 999
For assistance after a breakdown or help with tyres or windscreens please refer to the numbers on the tax disc holder.
TYRE HELPLINE
In the event of having a punctured tyre
please call the Europcar Tyre Helpline
0800 0280 999 for ANY assistance.
NOTE: Vehicles are not usually supplied
with a tyre repair kit (for vehicles that use
this in lieu of a spare wheel).
KIA STONIC 5 DOOR MPV
5 SEATS
Key / remote control operated central dead locking. Depress the central locking button on centre consoleto lock the doors
from the inside.
Passive arming of electronic engine immobiliser after removal of the key from the starter switch. Vehicles are fitted with an
alarm. Visible VIN plate.
Centrally locked. Use the key or remote control to unlock / open.
Electric adjustment operated by the control pad on the driver’s door.
Electric front and rear operated via control buttons on the driver’s door.
If fitted: Electric tilt / slide panoramic sunroof operated by roof mounted switchgear.
Press the centre console central locking button to lock them. Check from inside that the doors are securely locked.
Ensure gear selector is in neutral (or P if automatic) and handbrake is on. Press the engine start/stop button to start or stop
the engine. Select desired gear. Release handbrake and brake pedal and gently press the accelerator to move the vehicle.
Vehicles feature engine start/stop whereby the engine auto shuts off when stationary, gears are in neutral, and pedals are
not depressed - the engine instantly restarts when the clutch (or accelerator in auto) is depressed.
Located under flap on rear nearside. Centrally locked. Lightly press the edge of the flap to open it, and twist off the fuel
cap anticlockwise.
Pull bonnet release lever located on the right of the driver’s footwell. Unhook catch under bonnet.
The second and third rear seat rows are divided into 60:40 sections which can be separately flat-folded. Cargo floor can be
flush or lowered to increase load space. To release the seat press the seat unlocking catch and fold the seat down. To return
the seat to normal use, raise the seat and push it firmly to engage the seat lock. Check it is locked before using the seat.
Vehicle is not normally supplied with a spare wheel or tyre repair kit. For any assistance in the event of having a
punctured tyre, or should the vehicle not be supplied with a spare wheel and tyre or a tyre repair kit, please call
the Europcar Tyre Helpline 0800 0280 999. Lift the carpet cover to access the storage area housing the standard (or
temporary) spare wheel, tools and jack. Move the vehicle to firm / level ground. Turn the engine off, select first gear (manual)
or P (automatic). Apply the handbrake. Loosen the wheel nuts (do not remove them). Only use the specific reinforced jack
points on the underside of the vehicle. Crank the jack to lift the vehicle. Undo wheel nuts and change the wheel. Lower the
vehicle. Tighten the wheel nuts.
Select Nfor neutral, Pwhen leaving the vehicle, Rfor reversing (the vehicle must be at a complete standstill before this
gear can be selected). For normal driving select Dwhere the transmission will use all available forward gears automatically
(a ‘kickdown ‘ facility is provided when the accelerator is pressed all the way to the floor past the normal acceleration point
forcing the transmission to select a lower gear to obtain maximum acceleration. Use D+ or D- to manually select gears.
Release pressure on the accelerator to return to normal accelerator use). Whenever the vehicle is at a standstill apply
the handbrake.
VIC-KIA-09 / 19-09-2019
Ensure you use the correct fuel
type. Only use unleaded petrol
in petrol vehicles (see inside of
filler flap).
Fuel Tank Capacity:
50.0 litres
Check tyre pressure regularly
Legal minimum tread depth is 1.6 mm
Check the tyre pressure table found on
the inside of driver’s door B-pillar (or fuel
filler cap).
205/55 R17
Some models may be fitted with an
electronic tyre pressure monitor.
Note: driving speeds and travel distances
are restricted when using spacesaver
spare tyres.
1Heating & Ventilation
2Hazard Lights
3Engine Start/Stop
4Headlights
5Sidelights
6Indicators
7Wipers
8Rear Screen Wipers
9Horn
10 Bonnet Release
11 Heated Rear Screen
12 Rear Fog Lamp
13 Front Fog Lamp
Tilt
Lumbar
Legroom
Height
10
3
2
1
11
4 / 5 / 6 / 12 / 13
7 / 8
9
Locking the doors?
Anti-theft system?
Opening the boot?
Adjusting door mirrors?
Opening the windows?
Operating the sunroof?
Using child door locks?
Starting the engine?
Opening fuel filler cap?
Releasing the bonnet?
Folding the rear seats?
How to change a tyre?
How to drive an
automatic?
P
R
N
D
or
R 1 3
246
5
+
_
9
