KIBI KPW102 User manual

LIMITED LIFETIME WARRANTY
KIBI provides its customers with an extensive warranty as a result of our excellent workmanship and
high quality components used in our products.
Mechanical warranty: A limited lifetime warranty is provided on all mechanical parts to be free from
manufacturing defects in materials and workmanship under normal use for as long as the original
purchaser owns their home.
Finish warranty: A 5-year warranty is provided on all KIBI faucet finishes to the original purchaser
against manufacturing defects in materials and workmanship.
At its sole discretion, KIBI will repair or replace any part or finish that proves to be defective in ma-
terial and/or workmanship under normal installation, use and service.
This warranty is extended to the original consumer owner, but does not cover installation or any
other labor charges. In no event shall KIBI be liable for any incidental, consequential or special dam-
ages, installation cost, labor, travel time, freight costs incurred, lost profits, or contingent liabilities.
KIBI makes no representation that its products comply with any or all local building or plumbing
codes. It is the consumer’s responsibility to determine local code compliance.
We recommend that this product is installed by a qualified professional plumber
contractor.
Please check this product immediately to ensure that it has not been damaged
and is complete. Before installation, please make sure this product is the correct
model and you have all the parts required for installation and using.
Please read these instructions carefully and keep it for future reference.
We DO NOT recommend using any household cleaners to clean the product. The
product should be cleaned only with soapy water. Rinsed with clean water and dry
with a soft cloth.
Installation Guide
www.kibiusa.com
KPW103KPW102
IMPORTANT
MAINTENANCE
KPW101KPW100

DIMENSIONS
PARTS
21
3 4
Install waste system (not included) and check
for leakage.
Screw tail piece onto drain using the tail
washer.
Insert thick silicone washer and hard
washer over the exposed mail threaded
area and screw drain nut onto drain. Do not
overtighten.
Remove all components from drain piece
including: thin and thick silicone washer, hard
washer, drain nut and tail piece.
Insert drain and thin silicone washer into basin.
Apply Teflon to the exposed male threading
area of drain piece.
INSTALLATION
1 Drain
2 Thin Rubber Washer
3 Thick Rubber Washer
4 Hard Washer
5 Drain Nut
6 Tail piece
1
2
4
3
5
6
1-4/16”
(Φ32 mm)
2-7/16
(max 62 mm)
G1-1/4
2-10/16”
(Φ66 mm)
3-4/16”
(83 mm)
4-11/16”
(119 mm)
1-4/16”
(Φ32 mm)
2-7/16
(max 62 mm)
G1-1/4
2-7/16”
(Φ62 mm)
3-4/16”
(83 mm)
4-11/16”
(119 mm)
