Kidde IG-55 User manual

P/N 06-237619-001
April 2020, Rev. AA
EXPORT INFORMATION (USA)
Jurisdiction: EAR
US ECCN: EAR99
This document contains technical
data subject to the EAR
Inert Gas Engineered
Fire Suppression System
Design, Installation, Operation, and
Maintenance Manual with FM Approval

06-237619-001 i April 2020
FOREWORD
This manual is written for those who design, install, operate, or maintain the Kidde Fire Systems Inert Gas
Engineered Fire Suppression System (Kidde®IGS) using IG-55 or IG-100 (herein refer to collectively as
the “Agent”) manufactured after June 2018. For Kidde®Argonite®Engineered Fire Systems manufactured
prior to July 2018, see DIOM P/N: 06-236432-001. For Kidde Nitrogen Engineered Fire Systems
manufactured prior to July 2018, see DIOM P/N: 06-237459-001.
IMPORTANT
Kidde Fire Systems assumes no responsibility for the application of any systems other than those addressed
in this manual. The technical data contained herein is limited strictly for information purposes only.
Kidde Fire Systems believes this data to be accurate, but it is published and presented without any
guarantee or warranty whatsoever. Kidde Fire Systems disclaims any liability for any use that may be made
of the data and information contained herein by any and all other parties.
Kidde IGS is to be designed, installed, inspected, maintained, tested and recharged by authorized, trained
personnel in accordance with the following:
• Standard of the National Fire Protection Association No. 2001, Edition 2015 titled Clean Agent Fire
Extinguishing Systems.
• ISO 14520, BS EN 15004 and any other applicable national standards
• All instructions, limitations, cautions, and warnings, contained in this manual, 06-237619-001.
• All information contained on the system container nameplate(s).
Storage, handling, transportation, service, maintenance, recharge, and test of Agent storage containers
shall be performed only by qualified and trained personnel in accordance with the information in this
manual and Compressed Gas Association pamphlets C-1, C-6 and P-1:
• C-1, Methods for Hydrostatic Testing of Compressed Gas Cylinders.
• C-6, Standards for Visual Inspection of Compressed Gas Cylinders.
• P-1, Safe Handling of Compressed Gases In Containers.
CGA pamphlets are published by the Compressed Gas Association: http://www.cganet.com
All personnel should be trained by Kidde Fire Systems and should have attended a Cylinder
Handling/Installation training session provided by Kidde Fire Systems.
For additional reference information refer to:
• National Fire Protection Association (USA): www.nfpa.org
• Fire Industry Association (UK): www.fia.uk.com
The design concentration for Class A and C fires applies to systems designed to meet and comply with
FM5600, and NFPA 2001, Edition 2015 requirements. As such, our customers are reminded and advised:
• In accordance with 4.3.1.2 and 4.3.1.3 of NFPA 2001, Edition 2015, automatic detection and
automatic actuation shall be used. Manual actuation is permitted only if acceptable by the authority
having jurisdiction.
• Designers should also take note of 4.3.5.6 in NFPA 2001, Edition 2015 with regard to discharge
delays.
• The designer should also review A.5.4.2.4 in NFPA 2001, Edition 2015 and confirm that a protected
Class A hazard does not include any Class B materials (flammable or combustible liquids or gases)
which would classify the protected space as a Class B hazard.
• In addition, the designer should refer to section A.5.6 in NFPA 2001, Edition 2015 and confirm that
the protected space does not include electrical equipment that will not be de-energized prior to or at
the time of Agent discharge. Such energized electrical equipment has the potential to act as a
persistent re-ignition source. If electrical equipment cannot be de-energized, the design Agent
concentration shall be at least that required by 5.4.2.5 in NFPA 2001, Edition 2015. In some cases
consideration should be given to the use of extended Agent discharge or higher design Agent
concentration. When exploring these options, keep in mind the possibility of the formation of
combustion and decomposition products. Please contact applications engineering for design guidance
in such instances.

April 2020 ii 06-237619-001
Questions concerning the information presented in this manual should be addressed to:
SAFETY DATA SHEETS
The Safety Data Sheets (SDS) can be found in Appendix A. The latest version of the SDS can also be found
online at the Kidde Fire Systems website (www.kiddefiresystems.com). Use the built-in navigation links to
view the desired sheet.
SAFETY SUMMARY
Kidde IGS uses pressurized equipment; therefore, personnel responsible for fire suppression systems must
be aware of the dangers associated with the improper handling, installation or maintenance of this
equipment.
Fire suppression system service personnel must be trained in the proper handling, installation and service
of Kidde IGS equipment and follow the instructions used in this manual and in the Safety Bulletin and
cylinder nameplate.
Kidde has provided warnings and cautions at appropriate locations throughout the text of this manual.
These warnings and cautions are to be adhered to at all times. Failure to do so may result in serious injury
to personnel.
DEFINITIONS
Kidde Fire Systems
400 Main Street
Ashland, MA 01721
Phone: [phone]
Fax: [phone]
www.kiddefiresystems.com
Email: [email protected]
WARNING
Indicates an imminently hazardous situation which, if not avoided, could result in death,
serious bodily injury and/or property damage.
CAUTION
Indicates a potentiality hazardous situation which, if not avoided, could result in
property or equipment damage.

06-237619-001 iii April 2020
SAFE CYLINDER HANDLING PROCEDURES
Before handling Kidde IGS products, all personnel must be trained in the safe handling of the containers
as well as in the proper procedures for installation, removal, filling, and connection of other critical devices,
such as flex hoses; actuation devices; pressure monitoring devices; transportation safety caps, guards, or
shrouds; and anti-recoil devices.
READ, UNDERSTAND and ALWAYS FOLLOW the design, installation, operation and maintenance manuals,
owners manuals, service manuals, etc., that are provided with the individual systems.
The following safety procedures must be observed at all times:
TRANSPORTING CONTAINER
Containers must be shipped securely either upright in steel stillages or horizontally on pallets using a
minimum of 3 bands to secure the container/s to the pallet.
On site, containers must not be rolled, dragged, or slid, nor allowed to be slid from tailgates of vehicles. A
suitable hand truck, fork truck, single cylinder trolley, roll platform, or similar device must be used.
ROUGH HANDLING
Containers must not be dropped or permitted to strike violently against each other or other surfaces.
STORAGE
Containers must be stored standing upright where they are not likely to be knocked over and the containers
must be secured.
For additional information on safe handling of compressed gas cylinders, see CGA Pamphlet PI titled
“Standard for Safe Handling of Compressed Gases in Containers”. CGA pamphlets may be purchased from
The Compressed Gas Association: http://www.cganet.com
ANTI-RECOIL SAFETY CAP
• Each Agent cylinder is factory equipped with an anti-recoil safety cap installed on the valve discharge
outlet, and securely fixed to the valve via a stainless steel, PVC coated cable to prevent loss. This
device is a safety feature, and will prevent discharge when installed if the cylinder is actuated
accidentally.
• The anti-recoil safety cap must be installed on the valve outlet AT ALL TIMES except when the
cylinders are connected into the system piping.
WARNING
Any area in which inert gas agent is used or stored must be properly ventilated.
A person working in an area where air has become enriched with agent can
become unconscious without sensing the lack of oxygen. Remove the victim to
fresh air. Administer artificial respiration if necessary and summon a physician.
Never dispose of liquefied agent in an indoor work or storage area.
WARNING
Pressurized (charged) cylinders are capable of violent discharge and, as such, are
extremely hazardous. Pressurized cylinders must be handled safely to avoid accidents
that could cause bodily injury, death, or property damage.
WARNING
The instructions contained in this foreword and throughout the manual must be
followed in the exact sequence as written to prevent serious injury, death, or
property damage.

April 2020 iv 06-237619-001
SAFETY TRANSPORTATION CAP, GUARD, OR SHROUD
The Safety Transportation cap, guard, or shroud is factory installed on the cylinder. The safety
transportation cap, guard, or shroud covers the cylinder valve to protect it during transportation and
handling. No attachments (release unit or slave gauge assemblies) are to be connected to the cylinder
valve during shipment, storage, or handling.
INSTALLATION
THIS SEQUENCE FOR CYLINDER INSTALLATION MUST BE FOLLOWED AT ALL TIMES:
1. Install cylinder into bracketing.
2. Remove the Transport cap.
3. Remove the anti-recoil safety cap and connect all cylinder valves into system piping using
appropriately sized discharge hose.
4. Install all pilot hoses, Pilot Line Bleed Valves etc. leaving the release unit available for installation by
the commissioning engineer only.
REMOVAL FROM SERVICE
THIS SEQUENCE FOR CYLINDER REMOVAL MUST BE FOLLOWED AT ALL TIMES:
1. Remove all release units, slave cylinder pressure gauge units, and pilot lines from cylinder valve.
2. Disconnect discharge hose at the valve outlet.
3. Immediately install anti-recoil safety cap on valve outlet.
4. Attach the transport cap to the cylinder/valve assembly.
5. Remove cylinder from bracketing.
WARNING
In order to prevent injury in the event of accidental cylinder discharge, the discharge
hose must be connected to the system piping before attaching to the cylinder valve
outlet.
WARNING
The safety pin for the manual release must be fully inserted and secured using anti-
tamper seal before attempting to fit the release unit to the valve actuation port
WARNING
The cylinder valve anti-recoil safety cap must be immediately available for installation
on the cylinder valve outlet before disconnecting the cylinder discharge hose from
system piping. If the safety cap is missing obtain a new safety cap from Kidde Fire
Systems.
WARNING
Failure to follow all instructions in this manual on the use and handling of system
components could result in serious bodily injury, death, and property damage in the
event of inadvertent and unexpected cylinder discharge.

06-237619-001 v April 2020
Foreword ....................................................................................................... i
Safety Summary............................................................................................. ii
Safe Cylinder Handling Procedures .................................................................... iii
Table of Contents............................................................................................ v
List of Figures ................................................................................................ xiii
List of Tables.................................................................................................. xvii
CHAPTER 1 GENERAL INFORMATION
1-1 Introduction ........................................................................................ 1-1
1-1.1 Use .................................................................................................... 1-1
1-1.2 Unsuitable Risks .................................................................................. 1-2
1-1.3 Fire Class Table ................................................................................... 1-2
1-1.4 Agent Cylinder Quantity ........................................................................ 1-2
1-2 Fire Extinguishment Methods ................................................................. 1-3
1-3 Safety ................................................................................................ 1-3
1-3.1 Personal Safety ................................................................................... 1-3
1-3.2 Agent Safety Concentrations ................................................................. 1-4
1-3.2.1 Oxygen Concentration Above or Below Sea Level ..................................... 1-5
1-4 System Description .............................................................................. 1-6
1-4.1 Central Cylinder Bank ........................................................................... 1-6
1-4.2 Selector Valve System .......................................................................... 1-7
1-4.3 Release Time....................................................................................... 1-7
1-4.4 Pressure Monitoring.............................................................................. 1-7
1-4.5 Placement Supervision.......................................................................... 1-7
1-5 Extinguishing Agent....................................................................... 1-8
1-5.1 Design Concentration Safety Factor ........................................................1-8
1-5.2 IG-100 (Nitrogen) ................................................................................ 1-9
1-5.3 IG-55 (Nitrogen and Argon) .................................................................. 1-11
1-5.3.1 Purity of Argon and Nitrogen ................................................................. 1-11
1-5.4 Agent Pressure verse Temperature Formulas ........................................... 1-14
1-5.5 Operating Temperature Range Limitations ............................................... 1-14
1-5.6 Agent Storage Container Temperature Range Limitations.......................... 1-14
1-5.6.1 Balanced System Agent Storage Container Temperature Range.................. 1-14
1-5.6.2 Unbalanced System Agent Storage Container Temperature Range.............. 1-14
1-5.6.3 Storage .............................................................................................. 1-14
1-6 Noise Consideration.............................................................................. 1-15
1-7 System Detection and Control................................................................ 1-15
1-8 Release Modes..................................................................................... 1-16
1-8.1 Automatic Release ............................................................................... 1-16
1-8.2 Manual Remote Release ........................................................................ 1-16
1-8.3 Manual Emergency Release ................................................................... 1-16
1-9 Flow Calculations ................................................................................. 1-16
1-10 Pressure Relief/Vent ............................................................................. 1-17
1-11 Service and Maintenance ...................................................................... 1-17
1-12 Retrofitability ...................................................................................... 1-17
1-13 References.......................................................................................... 1-18
1-14 Approvals ........................................................................................... 1-18
TABLE OF CONTENTS

April 2020 vi 06-237619-001
TABLE OF CONTENTS (CONT.)
CHAPTER 2 COMPONENT DESCRIPTIONS
2-1 Introduction ........................................................................................ 2-1
2-2 Functional Description .......................................................................... 2-1
2-3 Kidde IGS Agent Cylinders and Release Units........................................... 2-2
2-3.1 Cylinder and Valve Assemblies............................................................... 2-2
2-3.1.1 Spare Parts for Cylinders ...................................................................... 2-3
2-3.2 Cylinder Valves.................................................................................... 2-4
2-3.3 Release Units ...................................................................................... 2-5
2-3.4 Slave Cylinder Gauge Assemblies ........................................................... 2-6
2-3.5 Actuation Hoses................................................................................... 2-7
2-3.6 Pilot Line Bleed Valve ........................................................................... 2-8
2-3.7 Quick Connect Cables ........................................................................... 2-9
2-4 Discharge Accessories .......................................................................... 2-10
2-4.1 Discharge Hoses .................................................................................. 2-10
2-4.2 Manifold Safety Device ......................................................................... 2-11
2-4.3 Manifold Pressure Gauge....................................................................... 2-11
2-4.4 Discharge Indicator (Optional) ............................................................... 2-12
2-4.5 3/4” Manifold Check Valves ................................................................... 2-12
2-4.6 Pressure Operated Switches .................................................................. 2-13
2-4.7 Pressure Operated Trip ......................................................................... 2-14
2-4.8 Main to Reserve Transfer Switch ............................................................ 2-15
2-4.9 Odorizer Assembly ............................................................................... 2-16
2-4.10 Main and Reserve Nameplates ............................................................... 2-17
2-4.11 Caution Signs ...................................................................................... 2-17
2-5 Selector Valves.................................................................................... 2-18
2-5.1 Back-Plate Manifold.............................................................................. 2-19
2-5.1.1 Pressure Regulator............................................................................... 2-19
2-5.1.2 Back-Plate Manifold Hose ...................................................................... 2-20
2-5.1.3 Back-Plate Manifold Spare Solenoids....................................................... 2-20
2-6 Lockout Valves .................................................................................... 2-21
2-7 Discharge Nozzles ................................................................................ 2-23
2-8 Nitrogen Pilot System and Pressure Driven Accessories ............................. 2-24
2-8.1 Nitrogen Discharge Delay Kits, P/N 38-401140-030
and P/N 38-401140-060 ....................................................................... 2-24
2-8.2 Pressure Operated Siren ....................................................................... 2-25
2-8.3 Nitrogen Pilot Cylinders......................................................................... 2-26
2-8.3.1 108 cu. in. Nitrogen Pilot Cylinder .......................................................... 2-26
2-8.3.1.1 5/16” Flare x 1/8” NPT Male Connector ................................................... 2-26
2-8.3.1.2 108 cu. in. Nitrogen Pilot Cylinder Mounting Bracket, ................................ 2-26
2-8.3.1.3 30” Actuation Hose .............................................................................. 2-26
2-8.3.2 1040 cu. in. Nitrogen Pilot Cylinder ........................................................ 2-27
2-8.3.2.1 1040 cu. in. Nitrogen Pilot Cylinder Strap ................................................ 2-27
2-8.3.2.2 3/4 in. Nitrogen Discharge Hose............................................................. 2-27
2-8.3.2.3 Plain-nut Discharge Head ...................................................................... 2-28
2-8.4 Electric Control Heads Kit, P/N 85-890181-000 ........................................ 2-29
2-8.4.1 Lever Operated Control Head (P/N WK-870652-000) ................................ 2-30
2-8.4.1.1 Lever/Pressure Operated Control Head, P/N 82-878751-000...................... 2-31

06-237619-001 vii April 2020
TABLE OF CONTENTS (CONT.)
2-8.4.2 Control Head Monitor with Hazloc Assembly,
P/N 85-100000-100 ............................................................................. 2-32
2-8.4.2.1 Standards for US Hazloc Approval .......................................................... 2-33
2-8.4.2.2 Standards for Canadian Hazloc Approval ................................................. 2-33
2-9 Fill Adapter ......................................................................................... 2-34
2-10 Manifold Equipment.............................................................................. 2-35
2-10.1 Manifold Bracket .................................................................................. 2-36
2-10.2 Manifold Clamp.................................................................................... 2-36
2-10.3 2" Adapter, BSPT (F) to NPT (F) .............................................................2-36
2-11 Racking Components ............................................................................ 2-37
2-11.1 Unistrut®Wall Rail ............................................................................... 2-37
2-11.2 Front Clamping Bar .............................................................................. 2-38
2-11.3 Rear Wooden Spacer ............................................................................ 2-38
2-11.4 Center Wooden Spacer ......................................................................... 2-39
2-11.5 Single Cylinder Clamping Bracket ........................................................... 2-39
2-11.6 Clamping Bolt...................................................................................... 2-40
2-11.7 Endcover ............................................................................................ 2-40
2-11.8 Distance Pipe ...................................................................................... 2-41
CHAPTER 3 SYSTEM DESIGN
3-1 Introduction ........................................................................................ 3-1
3-2 Evaluation of Risk/Hazard ..................................................................... 3-1
3-2.1 Requirements for a Cylinder Storage Room.............................................. 3-3
3-2.2 Extended Discharge ............................................................................. 3-3
3-3 Extinguishing Values ............................................................................ 3-4
3-4 Discharge Time.................................................................................... 3-4
3-5 Minimum Design Concentrations (MDC’s) ................................................ 3-4
3-6 IG-55 Total Flooding Concentration Factor Tables ..................................... 3-5
3-7 IG-100 Total Flooding Concentration Factor Tables ................................... 3-7
3-8 Design Factors..................................................................................... 3-9
3-8.1 Electrical Clearance .............................................................................. 3-9
3-8.2 Hold Time ........................................................................................... 3-10
3-8.3 Temperature Considerations .................................................................. 3-10
3-8.4 Flow Calculation................................................................................... 3-10
3-8.4.1 Required Input Information ................................................................... 3-10
3-8.4.2 Program Outputs ................................................................................. 3-11
3-8.5 Calculation of Room Volume .................................................................. 3-11
3-8.6 Calculation of the Quantity of Extinguishant............................................. 3-11
3-8.7 Ventilation Considerations ..................................................................... 3-11
3-8.8 Atmospheric Correction Factors.............................................................. 3-12
3-9 Cylinder Content .................................................................................. 3-13
3-10 Cylinder Bank Installation ..................................................................... 3-14
3-10.1 Location ............................................................................................. 3-14
3-10.2 Typical Foot Print ................................................................................. 3-14
3-11 Typical Floor Load ................................................................................ 3-15
3-12 Vibrations ........................................................................................... 3-15
3-13 Agent Cylinder Release Constraints ........................................................ 3-15
3-14 Selector Valves.................................................................................... 3-16

April 2020 viii 06-237619-001
TABLE OF CONTENTS (CONT.)
3-14.1 Back-Plate Manifold for Selector Valves................................................... 3-17
3-15 Selecting Number of Nozzles ................................................................. 3-17
3-15.1 Nozzle Coverage .................................................................................. 3-18
3-15.2 Nozzle Selection and Placement ............................................................. 3-18
3-15.2.1 Nozzle Placement................................................................................. 3-19
3-15.3 Tee Split Limitations............................................................................. 3-20
3-15.4 Pipe Sizing .......................................................................................... 3-21
3-15.5 Temperature Limitations ....................................................................... 3-21
3-15.5.1 Operating/Storage Temperature Range................................................... 3-21
3-15.5.2 Storage Temperature ........................................................................... 3-21
3-15.6 Cylinder Actuation Limitations................................................................ 3-21
3-15.7 Pressure Actuation Limitations ............................................................... 3-22
3-15.7.1 Pressure Trip Limitations....................................................................... 3-22
3-15.7.2 Pressure Operated Sirens...................................................................... 3-22
CHAPTER 4 INSTALLATION
4-1 General Equipment Installation .............................................................. 4-1
4-1.1 Personal Safety ................................................................................... 4-1
4-1.2 General Installation Requirements.......................................................... 4-1
4-1.3 Electrical Clearance .............................................................................. 4-1
4-2 Installation Process .............................................................................. 4-2
4-3 Technical Description............................................................................ 4-2
4-4 Functional Description .......................................................................... 4-2
4-4.1 System Overview................................................................................. 4-3
4-4.2 Selector Valve System.......................................................................... 4-4
4-4.3 Systems Using Discharge Delays............................................................ 4-6
4-5 Cylinder Bank Installation ..................................................................... 4-7
4-5.1 Typical Floor Load ................................................................................ 4-7
4-5.2 Racking Install Diagrams ...................................................................... 4-8
4-5.2.1 Clamp Racking Layouts......................................................................... 4-8
4-5.2.2 2 Row Wooden Racking Layouts............................................................. 4-9
4-5.2.3 Distance Pipe Installation ...................................................................... 4-10
4-5.2.4 Cylinder and Valve Installation Diagrams ................................................ 4-11
4-6 Cylinder Bank Assembly........................................................................ 4-12
4-6.1 Securing Manifold ................................................................................ 4-12
4-6.2 Manifold Safety Device ......................................................................... 4-13
4-6.3 Install Discharge Hoses to Manifold Check Valves ..................................... 4-14
4-6.4 Securing Single-Row Cylinders............................................................... 4-14
4-6.5 Securing Multi-Row Cylinders ................................................................ 4-14
4-6.6 Positioning Cylinders ............................................................................ 4-15
4-6.6.1 Installing Back-Plate Manifold for Selector Valve Systems.......................... 4-16
4-6.7 Installing Release Units......................................................................... 4-17
4-6.7.1 Aligning the Release Unit after Pressurization........................................... 4-18
4-6.8 Installing Slave Cylinder Gauge Assembly ............................................... 4-19
4-6.9 Locations for Leak Testing the Valve and Cylinder .................................... 4-20
4-6.10 Locations for Leak Testing the Release Unit ............................................. 4-20
4-6.11 Venting Pressure from the Manifold Burst Discs........................................ 4-21
4-7 Installation of Hoses............................................................................. 4-22
4-8 Distribution Pipe & Fittings .................................................................... 4-23

06-237619-001 ix April 2020
TABLE OF CONTENTS (CONT.)
4-8.1 Pipe ................................................................................................... 4-23
4-8.2 Ferrous Piping ..................................................................................... 4-23
4-8.3 Fittings ............................................................................................... 4-25
4-8.4 Support of Pipes/Manifolds .................................................................... 4-26
4-8.4.1 Pipe Spans .......................................................................................... 4-26
4-8.4.2 Nozzle Supports................................................................................... 4-26
4-8.4.3 Support Details.................................................................................... 4-27
4-8.5 Installation of Pipes.............................................................................. 4-28
4-8.5.1 Cutting ............................................................................................... 4-28
4-8.5.2 NPT/BSPT – Threading.......................................................................... 4-28
4-8.5.3 Grooved Joining................................................................................... 4-29
4-8.5.4 Installation of Pipes.............................................................................. 4-29
4-8.5.5 Threaded Pipe Assemblies ..................................................................... 4-30
4-9 Test of Pipework .................................................................................. 4-30
4-10 Nozzle Installation................................................................................ 4-30
4-11 Pressure Testing of Pipework ................................................................. 4-31
4-11.1 Precautions ......................................................................................... 4-31
4-11.2 Pressure Testing Using Gas ................................................................... 4-31
4-12 Signs and Labeling ............................................................................... 4-32
4-12.1 Storage Room ..................................................................................... 4-32
4-12.2 Cylinder.............................................................................................. 4-32
4-12.3 Selector Valves.................................................................................... 4-32
4-12.4 Protected Enclosure.............................................................................. 4-32
4-12.4.1 Access Doors....................................................................................... 4-32
4-12.5 Warning Alarms ................................................................................... 4-32
4-12.5.1 Pressure Relief Vents............................................................................ 4-32
4-13 Electrical Installation ............................................................................ 4-33
4-13.1 Release Unit/Slave Cylinder Gauge Assembly Wiring ................................. 4-33
4-13.2 Solenoid Valve, Release And Selection .................................................... 4-34
4-14 Typical Wiring Details ........................................................................... 4-35
4-15 Pressure Operated Switches .................................................................. 4-36
4-16 Pressure Operated Trip ......................................................................... 4-37
4-17 Nitrogen Pilot Cylinder Accessories Installation......................................... 4-38
4-17.1 Installation of Nitrogen Pilot Cylinder, P/N WK-877940-000
and Mounting Bracket, P/N WK-877845-000 ............................................ 4-38
4-17.2 Nitrogen Pilot Cylinder Installation, 1040 cu. in. P/N 90-101040-000 .......... 4-38
4-17.2.1 Installation of Flexible Discharge Hose, P/N WK-251821-000
or WK-264986-000 .............................................................................. 4-39
4-17.2.2 Installation Of Discharge Head, P/N WK-872450-000 ................................ 4-39
4-17.3 Installation of Control Heads to Pilot Cylinders ......................................... 4-40
4-17.3.1 Installation of Electric Control Heads
to N2 1040 cu. in. Pilot Cylinder............................................................. 4-40
4-17.3.2 Installation of Electric Control Head
to 108 cu. in. Nitrogen Pilot Cylinder....................................................... 4-41
4-17.3.3 Installation of Lever/Pressure Operated Control Head,
P/N 82-878751-000 ............................................................................ 4-41
4-17.4 Installation of Discharge Delay, P/Ns 81-871072-001
and 81-871072-002 ............................................................................. 4-42

April 2020 x 06-237619-001
TABLE OF CONTENTS (CONT.)
4-17.4.1 Connecting Discharge Delay to the Pressure Regulator
and Cylinder Valve ............................................................................... 4-43
4-17.5 Pressure Operated Siren ....................................................................... 4-45
4-17.5.1 Sample Siren Setups ............................................................................ 4-46
4-18 Installation of Pressure Trip, P/N 81-874290-000 ..................................... 4-46
4-19 Installation of Discharge Indicator, P/N 81-875553-000 ............................ 4-46
4-20 Odorizer ............................................................................................. 4-47
4-21 Selector Valves.................................................................................... 4-48
4-21.1 1-inch, 1 1/2-inch, and 2-inch Selector Valves ......................................... 4-48
4-21.2 3 and 4 inch Selector Valves.................................................................. 4-48
4-22 Lockout Valves .................................................................................... 4-49
4-23 Main to Reserve Transfer Switch ............................................................ 4-50
4-24 Post-Installation Procedures .................................................................. 4-51
4-24.1 Pilot Line Test...................................................................................... 4-52
CHAPTER 5 OPERATION
5-1 Introduction ........................................................................................ 5-1
5-2 System Controls and Indicators ............................................................. 5-1
5-2.1 General .............................................................................................. 5-1
5-2.2 Operating Procedures ........................................................................... 5-1
5-2.2.1 Automatic Operation ............................................................................ 5-1
5-2.2.2 Local Manual Operation (Single Area) ..................................................... 5-1
5-2.2.3 Local Manual Operation (Multi Area System)............................................ 5-1
5-2.3 Post-Fire Operation .............................................................................. 5-2
5-3 Main and Reserve Systems.................................................................... 5-2
5-4 Lockout Valves .................................................................................... 5-2
5-5 Cylinder Recharge................................................................................ 5-2
CHAPTER 6 MAINTENANCE
6-1 Introduction ........................................................................................ 6-1
6-1.1 Agent Storage Cylinders....................................................................... 6-1
6-2 Maintenance Procedures ....................................................................... 6-2
6-3 Preventative Maintenance Schedule........................................................ 6-2
6-4 Weekly ............................................................................................... 6-4
6-4.1 Check Kidde IGS System Cylinder Pressure ............................................. 6-4
6-4.2 Check Nitrogen Pilot Cylinder Pressure.................................................... 6-4
6-4.3 Hazard and Enclosure Inspection............................................................ 6-4
6-4.4 Pipework and Controls Inspection........................................................... 6-4
6-5 Monthly .............................................................................................. 6-4
6-5.1 Perform General Inspection ................................................................... 6-4
6-5.1.1 Inspect Discharge Nozzles..................................................................... 6-4
6-5.1.2 Inspect Pull Stations............................................................................. 6-4
6-5.1.3 Inspect Pressure Switches..................................................................... 6-4
6-5.1.4 Personnel ........................................................................................... 6-5
6-5.2 Inspect Hazard Access.......................................................................... 6-5
6-5.3 Inspect Hoses ..................................................................................... 6-5
6-5.4 Inspect Release Units and Slave Gauge Assemblies .................................. 6-5
6-5.5 Inspect Cylinder and Valve Assembly...................................................... 6-5

06-237619-001 xi April 2020
TABLE OF CONTENTS (CONT.)
6-5.6 Inspect Electric Control Heads on Nitrogen Pilot Cylinders.......................... 6-5
6-5.6.1 Inspect Brackets, Straps, Cradles and Mounting Hardware.........................6-5
6-6 Semi-Annual Inspection Procedure ......................................................... 6-6
6-6.1 System Lockout Valve (if Fitted) ............................................................ 6-6
6-6.2 Actuator on Selector Valve ....................................................................6-6
6-6.3 Distribution Pipe Work and Nozzles......................................................... 6-6
6-6.4 Protected Room ................................................................................... 6-6
6-6.5 Test Discharge Pressure Switches........................................................... 6-6
6-6.6 Test Release Units................................................................................ 6-7
6-6.7 Control Head Test for Nitrogen Pilot Cylinders .......................................... 6-8
6-6.7.1 Electric Control Head Test for Nitrogen Pilot Cylinders ............................... 6-8
6-6.7.2 Lever Operated Control Head Test for Nitrogen Pilot Cylinders.................... 6-9
6-6.7.3 Lever/Pressure Operated Control Head Test
for Nitrogen Pilot Cylinders....................................................................6-9
6-6.8 Inspect Flexible Hoses .......................................................................... 6-10
6-6.9 Verify Odorizer Assembly ...................................................................... 6-10
6-7 Annual Inspection Procedure ................................................................. 6-11
6-7.1 Check Kidde IGS System Cylinder Pressure Gauges .................................. 6-11
6-8 Inspection Procedures-2 Year ................................................................ 6-11
6-8.1 Distribution Piping Blow Out ..................................................................6-11
6-9 Inspection Procedures- 5 year (CFR)....................................................... 6-12
6-9.1 Inspection and Retest Procedures for Kidde IGS System
UN Specification Cylinders.....................................................................6-12
6-9.1.1 Cylinders Continuously in Service Without Discharge................................. 6-12
6-9.1.2 Discharged Cylinders ............................................................................ 6-12
6-9.1.3 Charged Cylinders Needing to be Transported.......................................... 6-12
6-9.2 Inspection and Retest Procedures for Flexible Hoses ................................. 6-12
6-10 Inspection Procedures- 10 year (EU) ......................................................6-13
6-10.1 Retest Procedures for TPED Specification EU Cylinders .............................. 6-13
6-10.1.1 Cylinders Continuously in Service without Discharge .................................6-13
6-10.1.2 Discharge Cylinders or Charged Cylinders that are Transported .................. 6-13
6-10.1.3 Retest ................................................................................................ 6-13
6-11 Service............................................................................................... 6-14
6-11.1 Cleaning ............................................................................................. 6-14
6-11.2 Nozzle Service ..................................................................................... 6-14
6-11.3 Repairs............................................................................................... 6-14
6-12 Removing a Kidde IGS Cylinder.............................................................. 6-15
6-12.1 Reinstalling a Kidde IGS Cylinder ........................................................... 6-15
CHAPTER 7 POST-DISCHARGE MAINTENANCE
7-1 Introduction ........................................................................................ 7-1
7-2 After System Discharge ........................................................................ 7-1
7-2.1 Cylinder Replacement ........................................................................... 7-1
7-3 Re-Installing Release Units .................................................................... 7-2
7-4 Re-Installing Slave Cylinder Gauge Assemblies......................................... 7-3
7-5 Recharging Kidde IGS System Cylinders.................................................. 7-3
7-6 Nitrogen Pilot Cylinder Service and Maintenance....................................... 7-3
7-6.1 Nitrogen Pilot Cylinder Hydrostatic Pressure Test...................................... 7-3

April 2020 xii 06-237619-001
TABLE OF CONTENTS (CONT.)
7-6.2 Pilot Cylinder Removal .......................................................................... 7-4
7-6.3 Nitrogen Pilot Cylinder Recharge ............................................................ 7-5
7-6.4 Nitrogen Cylinder I-Valve Inspection and Services .................................... 7-7
7-6.4.1 Valve Disassembly ............................................................................... 7-7
7-6.4.2 Nitrogen Cylinder I-Valve Assembly........................................................ 7-8
7-6.4.3 Safety Disc Replacement....................................................................... 7-8
7-6.4.4 Plain Nut Discharge Head Inspection and Service ..................................... 7-9
CHAPTER 8 PARTS LIST
8-1 Introduction and Parts List .................................................................... 8-1
8-2 Agent and Cylinder Part Number ............................................................ 8-2
8-3 Release Units ...................................................................................... 8-3
8-4 Slave Cylinder Gauge Assemblies ........................................................... 8-3
8-5 Quick Connect Cables ........................................................................... 8-3
8-6 Discharge Accessories .......................................................................... 8-4
8-7 Selector Valves.................................................................................... 8-5
8-8 Lockout Valves .................................................................................... 8-5
8-9 Discharge Nozzles ................................................................................ 8-6
8-9.1 Listed 360 Degree Nozzles .................................................................... 8-7
8-9.2 Listed 180 Degree Nozzles .................................................................... 8-10
8-10 Discharge Delay, Siren, and Associated Accessories.................................. 8-13
8-11 Fill Adapters........................................................................................ 8-14
8-12 Manifold Equipment.............................................................................. 8-14
8-13 Cylinder Racking Kits............................................................................ 8-15
APPENDIX A SAFETY DATA SHEETS

06-237619-001 xiii April 2020
Figure Name Page Number
1-1 IG-100 Pressure/Temperature Curve Isometric Diagram for 200 bar,
U.S. Customary Units .......................................................................................... 1-9
1-2 IG-100 Pressure/Temperature Curve Isometric Diagram for 200 bar, SI Units............. 1-9
1-3 IG-100 Pressure/Temperature Curve Isometric Diagram for 300 bar,
U.S. Customary Units .......................................................................................... 1-10
1-4 IG-100 Pressure/Temperature Curve Isometric Diagram for 300 bar, SI Units............. 1-10
1-5 IG-55 Pressure/Temperature Curve Isometric Diagram for 200 bar,
U.S. Customary Units .......................................................................................... 1-11
1-6 IG-55 Pressure/Temperature Curve Isometric Diagram for 200 bar, SI Units............... 1-12
1-7 IG-55 Pressure/Temperature Curve Isometric Diagram for 300 bar,
U.S. Customary Units .......................................................................................... 1-12
1-8 IG-55 Pressure/Temperature Curve Isometric Diagram for 300 bar, SI Units............... 1-13
2-1 Typical Kidde Inert System ..................................................................................2-1
2-2 Typical Cylinder Assembly.................................................................................... 2-2
2-3 Kidde Inert Agent and Cylinder Part Number Breakdown .......................................... 2-3
2-4 Valve General Arrangement, P/N 38-400000-001 .................................................... 2-4
2-5 Release Unit....................................................................................................... 2-5
2-6 Slave Cylinder Gauge Assembly ............................................................................ 2-6
2-7 Flexible Actuation Hose with Straight to Straight Couplings....................................... 2-7
2-8 Flexible Actuation Hose with Straight to 90° Couplings............................................. 2-7
2-9 Pilot Line Bleed Valve .......................................................................................... 2-8
2-10 Quick Connect Cables .......................................................................................... 2-9
2-11 Quick Connect Cabling Example ............................................................................ 2-9
2-12 Discharge Hose with 90° to 90° Couplings.............................................................. 2-10
2-13 Manifold Safety Device ........................................................................................ 2-11
2-14 Discharge Indicator ............................................................................................. 2-12
2-15 Manifold Check Valves ......................................................................................... 2-12
2-16 Pressure Operated Switch .................................................................................... 2-13
2-17 Pressure Operated Switch, Hazloc ......................................................................... 2-14
2-18 Pressure Operated Trip ........................................................................................ 2-14
2-19 Main to Reserve Transfer Switch (84-802398-000) .................................................. 2-15
2-20 Odorizer Assembly .............................................................................................. 2-16
2-21 Main and Reserve Nameplates .............................................................................. 2-17
2-22 Selector Valves................................................................................................... 2-18
2-23 3 Area Back-Plate Manifold................................................................................... 2-19
2-24 Pressure Regulator.............................................................................................. 2-19
2-25 Back-Plate Manifold Hose ..................................................................................... 2-20
2-26 Back-Plate Manifold Spare Solenoid ....................................................................... 2-20
2-27 1”, and 2” Lockout Valves .................................................................................... 2-21
2-28 3”, and 4” Lockout Valves .................................................................................... 2-22
2-29 180 Degree Nozzle.............................................................................................. 2-23
2-30 360 Degree Nozzle.............................................................................................. 2-23
2-31 Discharge Delays (30/60 sec.) .............................................................................. 2-24
2-32 Pressure Operated Siren ...................................................................................... 2-25
2-33 1/4-inch Actuation Hose ......................................................................................2-26
2-34 Discharge Hose, 3/4 in. ....................................................................................... 2-27
2-35 Discharge Head, Plain Nut.................................................................................... 2-28
LIST OF FIGURES

April 2020 xiv 06-237619-001
LIST OF FIGURES (CONT.)
Figure Name Page Number
2-36 Electric Control Head........................................................................................... 2-29
2-37 Lever Operated Control Head ............................................................................... 2-30
2-38 Lever/Pressure Operated Control Head .................................................................. 2-31
2-39 Control Head Monitor with Hazloc Assembly ........................................................... 2-32
2-40 Control Head Monitor Dimensions ......................................................................... 2-32
2-41 Charging Adapter................................................................................................ 2-34
2-42 Manifold Bracket................................................................................................. 2-36
2-43 Manifold Clamp................................................................................................... 2-36
2-44 Unistrut............................................................................................................. 2-37
2-45 2 Cylinder Front Clamping Bar .............................................................................. 2-38
2-46 2 Cylinder Rear Wooden Spacer............................................................................ 2-38
2-47 2x2 Cylinder Center Wooden Spacer...................................................................... 2-39
2-48 2x3 Cylinder Center Wooden Spacer...................................................................... 2-39
2-49 Single Cylinder Clamping Bracket.......................................................................... 2-39
2-50 Clamping Bolt .................................................................................................... 2-40
2-51 End Cover.......................................................................................................... 2-40
2-52 Distance Pipe ..................................................................................................... 2-41
2-53 Installed Distance Pipe ........................................................................................ 2-41
3-1 Hold Time Model................................................................................................. 3-10
3-2 Typical Footprint of a Kidde IGS............................................................................ 3-14
3-3 Typical Distribution Manifold Design ...................................................................... 3-16
3-4 Back-Plate Manifold Arrangement.......................................................................... 3-17
3-5 Nozzle Placement and Coverage ........................................................................... 3-19
3-6 Nozzle Orientation .............................................................................................. 3-19
4-1 Single Area Cylinder Bank Arrangement................................................................. 4-3
4-2 Typical Pilot Line on Selector Valve System (Rear View) ........................................... 4-4
4-3 Typical Detailed Cylinder Bank Selector Valve System.............................................. 4-5
4-4 System with Discharge Delay ............................................................................... 4-6
4-5 Single Row Racking System with Clamps................................................................ 4-8
4-6 Dual Row Racking System with Clamps.................................................................. 4-9
4-7 Installed Distance Pipe ........................................................................................ 4-10
4-8 Cylinder Components .......................................................................................... 4-11
4-9 Typical Primary Cylinder/Valve Assembly (Rear View) .............................................. 4-11
4-10 Typical Slave Cylinder/Valve Assembly (Rear View) ................................................. 4-12
4-11 Manifold Safety Device Installation Example ........................................................... 4-13
4-12 Cylinder Valve Gauge Port.................................................................................... 4-15
4-13 Selector Valve Installation.................................................................................... 4-16
4-14 Back Plate Manifold Installation ............................................................................ 4-16
4-15 Release Unit....................................................................................................... 4-17
4-16 Actuation Hose Install ......................................................................................... 4-18
4-17 Contacts for Pressure Gauge ................................................................................ 4-19
4-18 Valve Leak Test Locations .................................................................................... 4-20
4-19 Release Unit Leak Test Locations .......................................................................... 4-20
4-20 Hose Installation................................................................................................. 4-22
4-21 Pipe Support Details............................................................................................ 4-27
4-22 Nozzle with Dirt Trap........................................................................................... 4-30

06-237619-001 xv April 2020
LIST OF FIGURES (CONT.)
Figure Name Page Number
4-23 Quick Connect Wiring Example ............................................................................. 4-33
4-24 Typical Wiring Details .......................................................................................... 4-35
4-25 Pressure-Operated Switches................................................................................. 4-36
4-26 Pressure Operated Switches, Hazloc ...................................................................... 4-37
4-27 Pressure Operated Trip ........................................................................................ 4-37
4-28 Typical 1040 cu. in. Nitrogen Pilot Cylinder Strap Installation.................................... 4-38
4-29 Control Head and Placements Supervision Component Installation
to Type “I” Valve, Top View..................................................................................4-40
4-30 Control Head and Placements Supervision Component Installation
to Type “I” Valve, Side View................................................................................. 4-40
4-31 Order of Installation ............................................................................................ 4-41
4-32 Discharge Delay Outlet Adapters and Hose ............................................................. 4-43
4-33 Pressure Regulator Outlet Adapters and Hose ......................................................... 4-43
4-34 Discharge Delay and Pressure Regulator with Adapters and Hoses ............................. 4-44
4-35 Pressure Operated Siren ...................................................................................... 4-45
4-36 Siren with Pneumatic Activation ............................................................................ 4-46
4-37 Siren with Electric Control Head Activation ............................................................. 4-46
4-38 Odorizer Installation............................................................................................ 4-47
4-39 Wiring Diagram for Lockout Valve when Ball Valve is in Fully Open Position................. 4-49
4-40 Wiring Diagram with Single Solenoid (Main and Reserve) ......................................... 4-50
4-41 Wiring Diagram with Dual Solenoid (Main and Reserve)............................................4-50
6-1 Typical Primary Cylinder/Valve Assembly (Rear View) .............................................. 6-7
6-2 Spare Pilot Line Bleed Valve Location..................................................................... 6-7
7-1 Actuation Hose Install.......................................................................................... 7-2
7-2 Nitrogen Temperature vs. Pressure Data ................................................................ 7-6
7-3 5/8-inch I-Valve for Nitrogen Driver ...................................................................... 7-7
7-4 Plain Nut Discharge Head..................................................................................... 7-9
8-1 Kidde Inert Agent and Cylinder Part Number Breakdown .......................................... 8-2

April 2020 xvi 06-237619-001
THIS PAGE INTENTIONALLY LEFT BLANK.

06-237619-001 xvii April 2020
Table Name Page Number
1-1 Fire Classifications .............................................................................................. 1-2
1-2 Egress Time Limits for Spaces Flooded with a Kidde IGS Agent ................................. 1-5
1-3 Agent Pressure Verse Temperature Formulas.......................................................... 1-14
2-1 Dimensions. Cylinder and Valve Assemblies............................................................ 2-3
2-2 Filled Cylinder Weights ........................................................................................ 2-3
2-3 Kidde IGS Cylinder Spare Parts............................................................................. 2-3
2-4 Kidde IGS Slave Cylinder Gauge Part Numbers .......................................................2-6
2-5 Dimensions, Flexible Actuation Hose...................................................................... 2-7
2-6 Actuation Hose Usage.......................................................................................... 2-7
2-7 Kidde IGS Quick Connect Cable Part Numbers......................................................... 2-9
2-8 Dimensions, Flexible Discharge Hoses.................................................................... 2-10
2-9 Kidde IGS Discharge Accessories Part Numbers....................................................... 2-11
2-10 Kidde IGS Manifold Check Valve............................................................................ 2-12
2-11 Kidde IGS Discharge Accessories Part Numbers....................................................... 2-17
2-12 Kidde Fire Protection IGS Selector Valve Part Numbers ............................................ 2-18
2-13 Kidde Fire Protection IGS Back-Plate Manifold Part Numbers ..................................... 2-19
2-14 Kidde Fire Protection IGS Pressure Regulator Part Numbers ...................................... 2-19
2-15 Kidde Fire Protection IGS Back-Plate Manifold Hose Part Numbers ............................. 2-20
2-16 Kidde Fire Protection IGS Back-Plate Manifold Spare Solenoid Part Numbers ............... 2-20
2-17 Lockout Valves Dimensions and Part Numbers for 1 1-2” and 2” valves
(U.S. Customary Units)........................................................................................ 2-21
2-18 Lockout Valves Dimensions and Part Numbers for 1” and 2” valves (SI Units) ............. 2-21
2-19 Lockout Valves Dimensions and Part Numbers for 3” and 4” valves
(U.S. Customary Units)........................................................................................ 2-22
2-20 Lockout Valves Dimensions and Part Numbers for 3” and 4” valves (SI Units) ............. 2-22
2-21 Kidde IGS Lockout Valve Part Numbers.................................................................. 2-22
2-22 Kidde IGS Nozzle Part Numbers ............................................................................ 2-23
2-23 Discharge Delays ................................................................................................ 2-24
2-24 Kidde IGS Nitrogen Pilot Cylinder Part Numbers ......................................................2-26
2-25 Electric Control Head Specifications ....................................................................... 2-29
2-26 Kidde IGS Fill Adapter Part Numbers ..................................................................... 2-34
2-27 Kidde IGS Manifold Equipment Part Numbers.......................................................... 2-35
2-28 Kidde IGS Manifold Bracket Part Numbers .............................................................. 2-36
2-29 Kidde IGS Manifold Clamp Part Numbers ................................................................2-36
2-30 Kidde IGS Unistrut Part Numbers .......................................................................... 2-37
2-31 Kidde IGS Front Clamping Bar Part Numbers .......................................................... 2-38
2-32 Kidde IGS Rear Wooden Spacer Part Numbers ........................................................ 2-38
2-33 Kidde IGS Center Wooden Spacer Part Numbers ..................................................... 2-39
2-34 Kidde IGS Single Cylinder Clamping Bracket Part Numbers ....................................... 2-39
2-35 Kidde IGS Clamping Bolt Part Numbers.................................................................. 2-40
2-36 Kidde IGS End Cover Part Numbers ....................................................................... 2-40
2-37 Kidde IGS Distance Pipe Part Numbers................................................................... 2-41
3-1 Design Concentrations for IG-01 and IG-55 ............................................................ 3-4
3-2 IG-55 US Customary Units Total Flooding Quantity.................................................. 3-5
3-3 IG-55 SI Units Total Flooding Quantity................................................................... 3-6
3-4 IG-100 US Customary Units Total Flooding Quantity ................................................ 3-7
LIST OF TABLES

April 2020 xviii 06-237619-001
LIST OF TABLES (CONT.)
Table Name Page Number
3-5 IG-100 SI Units Total Flooding Quantity................................................................. 3-8
3-6 Electrical Clearance............................................................................................. 3-9
3-7 Atmospheric Correction Factors ............................................................................ 3-12
3-8 Kidde IGS IG-100 ............................................................................................... 3-13
3-9 Kidde IGS IG-55 ................................................................................................. 3-13
3-10 Approximate Weight per Foot of 80.0 Liter Cylinders ............................................... 3-15
3-11 Tee Split Limitations............................................................................................ 3-20
3-12 Pipe Size Estimating Table ................................................................................... 3-21
3-13 Maximum Number of Cylinders that can Be Actuated per Actuation Device ................. 3-21
3-14 Nitrogen Pilot Cylinder Actuation Cylinder, Driver and Ancillary Limits ........................ 3-22
3-15 Siren Driver Cylinder Actuation Limits.................................................................... 3-22
4-1 Single Area Cylinder Bank Arrangement Components............................................... 4-3
4-2 Components for Typical Pilot Line.......................................................................... 4-4
4-3 Selector Valve System Cylinder Bank Arrangement Components ............................... 4-5
4-4 Discharge Delay System Components.................................................................... 4-6
4-5 Approximate Weight per Foot of 80.0 Liter Cylinders ............................................... 4-7
4-6 Dimensions for Racking Systems with Clamps......................................................... 4-8
4-7 Dimensions for Racking Systems with Clamps......................................................... 4-9
4-8 Components for Manifold Safety Device Installation Example .................................... 4-13
4-9 Actuation Hose Usage.......................................................................................... 4-17
4-10 Minimum Hose Bend Radius ................................................................................. 4-22
4-11 Allowable Pipe Grade and Size for Use with Kidde IGS Manifold
to Selector valves for Sch 40 THDF Per FSSA.......................................................... 4-24
4-12 Allowable Pipe Grade and Size for Use with Kidde IGS Manifold
to Selector valves for Sch. 40 Rolled Groove Fittings ............................................... 4-24
4-13 Allowable Pipe Grade and Size for Use with Kidde IGS Manifold
to Selector valves for Sch. 80 Threaded Fitting ....................................................... 4-25
4-14 Pipe Support Distances........................................................................................ 4-26
4-15 NPT Thread Length ............................................................................................. 4-28
4-16 BSPT Thread Length............................................................................................ 4-28
4-17 1040 cu. in. Nitrogen Pilot Cylinder Strap Installation Dimensions ............................. 4-39
4-18 Nitrogen Discharge Delay Rating........................................................................... 4-42
4-19 Siren Driver Cylinder Actuation Limits.................................................................... 4-45
6-1 Owner Preventive Maintenance Schedule ............................................................... 6-2
6-2 Authorized Kidde Fire Systems Distributor Preventive Maintenance Schedule .............. 6-3
6-3 Retest Schedule EU Specification Cylinders............................................................. 6-13
7-1 Nitrogen Fill Weights ........................................................................................... 7-5
7-2 I-Valve Components............................................................................................ 7-7
7-3 Safety Disc Replacements for the I-Valve............................................................... 7-8
7-4 Discharge Head Replacement Part Numbers ........................................................... 7-9
7-5 Recommended Lubricants .................................................................................... 7-9
8-1 Kidde Fire Systems Branded Cylinders ................................................................... 8-2
8-2 Kidde IGS Cylinder Spare Parts............................................................................. 8-2
8-3 Kidde IGS Release Unit Part Numbers.................................................................... 8-3
8-4 Kidde IGS Slave Cylinder Gauge Part Numbers ....................................................... 8-3
8-5 Kidde IGS Quick Connect Cable Part Numbers ........................................................ 8-3
