Kidde i9010CA User manual

Manual P/N 21008406 Rev. B 08/12
ATTENTION: Plea e take a few minute to thoroughly read thi
u er’ guide, which hould be aved for future reference and
pa ed on to any ub equent owner.
Smoke Alarm
User’s Guide
i9010CA
SINGLE STATION
SMOKE ALARM
10 Year Sealed Lithium Batter Operated
i9010CA

Inroducion ........................1
Insallaion..........................2-9
Operaion...........................10-12
Mainenance.........................13-14
FireSafey...........................15-18
Warrany............................19
Cont nts
Introduction
Thank you for purchasing this smoke alarm. It is an
important part of your family’s home safety plan. You can
trust this product to provide the highest quality safety
protection. We know you expect nothing less when the
lives of your family are at stake.
Please take a few minutes to thoroughly read this alarm
manual, and save it for future reference. Teach children
how to respond to the alarms, and that they should never
play with the unit.
If you have any questions about the operation or
installation of your alarm, please call our toll free
Consumer Hotline at 1-800-880-6788.
Image 1C will help you determine the correct location of
safety products that will help make your home a safer place.
IMPORTANT: Read all instructions before installation and keep this
manual near the alarm for future reference.
Do not try to repair the smoke alarm yourself. Refer to the instructions in
arranty section for service.
1
Made in China. Patent Pending
Kidde Canada Inc.
P.O. Box 40, Apsley, ON K0L 1A0
www.kiddecanada.co

R comm nd d Locations
• Locate the first alarm in the immediate area of the
bedrooms. Try to protect the exit path, as the
bedrooms are usually farthest from the exit. If more
than one sleeping area exists, locate additional alarms
in each sleeping area (Image 1A).
• Locate additional alarms to protect any stairway as
stairways act like chimneys for smoke and heat.
• Locate at least one alarm on every floor level (Image
1B).
• Locate an alarm in every bedroom.
• Locate an alarm in every room where electrical
appliances are operated (i.e. portable heaters or
humidifiers).
• Locate an alarm in every room where someone sleeps
with the door closed. The closed door may prevent the
alarm from waking the sleeper.
• Smoke, heat, and combustion products rise to the
ceiling and spread horizontally. Mounting the smoke
alarm on the ceiling in the center of the room places it
closest to all points in the room. Ceiling mounting is
preferred in ordinary residential construction.
• When mounting an alarm on the ceiling, locate it at a
minimum of 10 cm (4") from the side wall (Image 2A).
• When mounting the alarm on the wall, use an inside
wall with the top edge of the alarm at a minimum of
10 cm (4") and a maximum of 30.5 cm (12") below the
ceiling (Image 2A).
• Put smoke alarms at both ends of a bedroom hallway
or large room if the hallway or room is more than 9.1
m (30') long.
• For mobile home installation, select locations carefully
to avoid thermal barriers that may form at the ceiling.
For more details, see Mobile Homes.
Installation
2

3
Installation
• Install smoke alarms on sloped, peaked or cathedral
ceilings following the mounting guidelines outlined in
Image 2A and 2B. NFPA Standard 72 states: “Smoke
alarms in rooms with ceiling slopes greater than 0.3 m in
2.4 m (1 foot in 8 feet) horizontally shall be located on
the high side of the room” (Images 2B and 2C).
DINING
ROOM
LIVING
ROOM
Required Smoke Alarms
Ionization Type Smoke Alarm with
Hush®Control or Photoelectric Type
Smoke Alarms for Additional Protection
KITCHEN BEDROOM
BEDROOM
BEDROOM
LIVING
ROOM KITCHEN
BEDROOMBEDROOM HALL
BASEMENT
IMAGE 1A
IMAGE 1C
IMAGE 1B
SINGLE FLOOR PLAN MULTIPLE FLOOR PLAN
BEDROOM
FAMILY ROOM
WORKSHOPBASEMENT
KITCHEN
HALL
GARAGE
MASTER
BEDROOM
FIRE
EXTINGUISHERS
SMOKE
ALARMS
CARBON
MONOXIDE
ALARMS
TALKING
SMOKE/CO
ALARM
TOTAL HOME PROTECTION

4
Installation
Locations to Avoid
• Do not install within 0.9 m (3') of the following: The
door to a kitchen, or a bathroom that contains a tub or
shower, forced air ducts used for heating or cooling,
ceiling or whole house ventilating fans, or other high
air-flow areas.
• Do not place the alarm where drapes or other objects
will block the sensor. Smoke must be able to reach the
sensor to accurately detect conditions.
• Do not install in peaks of vaulted ceilings, “A” frame
ceilings or gabled roofs.
• Install at least 30.5 cm (12") away from fluorescent
lights as electronic noise may cause nuisance alarms.
• eep out of insect infested areas. Avoid excessively
dusty, dirty or greasy areas. Dust particles may cause
nuisance alarms or failure to alarm.
• Extreme temperatures may effect the sensitivity of the
alarm. Do not install in areas where the temperature is
colder than 4.4°C (40°F) or hotter than 37.8°C (100°F),
such as garages and unfinished attics.
• Do not install in areas where the relative humidity (RH)
is greater than 85%. Very humid areas, with moisture or
steam, can cause nuisance alarms.
• Avoid placing ionization smoke alarms in kitchen areas.
Normal cooking may cause nuisance alarms. If a
kitchen alarm is desired, it should have an alarm silence
feature or be a photoelectric type.
• Do not place in the garage. Particles of combustion are
present when you start your automobile.
• Smoke alarms are not to be used with detector guards
unless the combination (alarm and guard) has been
evaluated and found suitable for that purpose.

Installation
5
IMAGE 2A
IMAGE 2C
IMAGE 2B
HORIZONTAL DISTANCE FROM PEAK
CEILING
10 cm (4”)
MINIMUM
10 cm (4”)
MINIMUM
30.5 cm (12”)
MAXIMUM
SIDE WALL
BEST
PLACEMENT
ACCEPTABLE
PLACEMENT
NE ER HERE
STAGNANT
AIR
0.9 m (3’) 0.9 m (3’)
NOT IN
THIS AREA
ANYWHERE IN THIS
AREA
NOT IN
THIS AREA
ANYWHERE IN
THIS AREA
0.9 m (3’)

Installation
6
Mounting
CAUTION: This unit is sealed (including the battery). The cover is not
removable!
• After selecting the proper smoke alarm location as
described previously, attach the mounting plate to the
ceiling (Image 3B).
• To ensure aesthetic alignment of the alarm with the
hallway, or wall, the “A” line on the mounting plate
must be parallel with the hallway when ceiling
mounted, or horizontal when wall mounted (Image 3A).
• Secure the mounting plate to the wall or ceiling with
the anchors and screws provided (Image 3B). Use a
3/16" drill bit for anchors.
• For aesthetic reasons, the suggested position for wall
mounting is as shown in Image 3C.
NOTE: This alarm has a battery permanently sealed inside the alarm. No
battery installation is necessary.
Activation
This model is equipped with a feature that automatically
activates the alarm when the alarm is attached to the
mounting plate for the first time. Once activated, the battery
will supply power to the alarm for the life of the alarm (10
years). Be sure that the mounting plate is installed correctly
before attaching the alarm to it.
• Install the alarm on the mounting plate and rotate the
alarm in the direction of the “ON” arrow on the cover
until the alarm ratchets into place (Image 3D). This
ratcheting function allows for aesthetic alignment. Note:
The alarm will attach to the mounting plate in 4 positions
(every 90 degrees). The alarm is now a tivated!
ANYWHERE IN THIS
AREA
30 cm (12")
IMAGE 2D

CAUTION: Due to the loudness (85 decibels) of the alarm, always stand an
arms-length away from the unit when testing.
• After installation, test your alarm by depressing and
holding down the Test button for a minimum of 5
seconds (or until the alarm sounds). This will sound the
alarm if the electronic circuitry, horn, and battery are
working. If the alarm does not sound, the unit has a
defective battery or another failure.
Mobil Hom s
Mobile homes built in the past five to seven years have
been designed to be energy efficient. Install smoke alarms
as recommended in Re ommended Lo ations and Image 2A.
In mobile homes that are not well insulated compared to
present standards, extreme heat or cold can be transferred
from the outside to the inside through poorly insulated
walls and roof. This may create a thermal barrier that can
prevent the smoke from reaching an alarm mounted on
the ceiling. In such units, install the smoke alarm on an
inside wall with the top edge of the alarm at a minimum
of 10 cm (4") and a maximum of 30.5 cm (12") below the
ceiling (Image 2A).
If you are not sure about the insulation in your mobile
home, or if you notice that the outer walls and ceiling are
either hot or cold, install the alarm on an inside wall. For
minimum protection, install at least one alarm close to the
bedrooms. For additional protection, see Image 1A.
ARNING: Test your smoke alarm operation after mobile home vehicle
has been in storage, before each trip and at least once a week during use.
Installation
7

Installation
8
A A
IMAGE 3A IMAGE 3B
IMAGE 3C IMAGE 3D
“A” LINE
ALIGNMENT MARKS
SUGGESTED WALL
MOUNTING POSITION
ROTATE TO MOUNT OR
TO REMOVE

Installation
9
Alarm Tamp r R sist F atur
This alarm is equipped with an automatic tamper resist
feature that prevents someone from removing the unit
from the mounting plate. The feature engages when the
alarm is rotated onto the mounting plate.
Rotate the alarm onto the mounting plate until you hear
the tamper resist tab snap into place, locking the alarm.
To remove the alarm, press on the tamper resist tab, and
rotate the alarm off of the mounting plate (Image 4).
IMAGE 4

This product is designed to detect products of combustion
using the ionization technique. It contains 0.9 microcurie
of Americium 241, a radioactive material. Distributed under
U.S. NRC License No. 32-23858-01E. Manufactured in
compliance with U.S. NRC safety criteria in 10 CFR 32.27.
The purchaser is exempt from any regulatory
requirements.
This smoke alarm uses an extremely small amount of
radioactive element in the ionization sensor chamber. Do
not try to repair the smoke alarm yourself. Refer to the
instructions in Warranty for service.
The smoke alarm is operating once the alarm is activated
(see A tivation) and testing is complete. When the smoke
alarm ionization sensor chamber senses products of
combustion, the horn will sound a loud (85db) alarm until
the sensing chamber is cleared of smoke particles.
Fals Alarms
Smoke alarms are designed to minimize false alarms.
Cigarette smoke will not normally set off the alarm, unless
the smoke is blown directly into the alarm.
Combustion particles from cooking may set off the alarm if
the alarm is located close to the cooking area. Large
quantities of combustible particles are generated from
spills or when broiling. Using the fan on a range hood
that vents to the outside (non-recirculating type) will also
help remove these combustible particles from the kitchen.
Op ration
10

HUSH®Control F atur
CAUTION: This feature should only be used to silence an alarm that was
activated by a readily known non-hazardous condition, such as smoke
from cooking.
Combustion particles from cooking may set off the alarm if
the alarm is located close to the cooking area. Large
quantities of combustible particles are generated from
spills or when broiling. Using the fan on a range hood
that vents to the outside (non-recirculating type) will also
help remove these combustible particles from the kitchen.
The Hush®button is extremely useful in a kitchen area or
other areas prone to nuisance alarms.
The Hush®feature, activated by pushing the Test/Hush®
button on the smoke alarm cover, temporarily desensitizes
the alarm. If the smoke is not too dense, the alarm will
silence, the Red LED will flash every 10 seconds for up to
8 minutes.
The smoke alarm will automatically reset to normal
sensitivity after approximately 8 minutes. If after this
period, particles of combustion are still present, the alarm
will sound again.
The Hush®feature can be used repeatedly until the air has
been cleared of the condition causing the alarm.
NOTE: Dense smoke will override the Hush®control feature and sound a
continuous alarm.
Op ration
11

LED Indicator
This alarm is equipped with a red LED indicator, with four
modes of operation.
Red LED - Flashing every 40-45 se onds: Indicates that the
smoke alarm is receiving power and operating properly.
Red LED - Flashing (1 se ond on - 1 se ond off): When the
smoke alarm senses particles of combustion and goes into
alarm (constant pulsating sound), the red LED will flash
(approximately one flash per second). The flashing LED
and pulsating alarm will continue until the air is cleared.
Red LED - Flashing slowly (1 se ond on - 8 se onds off):
Indicates that the unit is in the Hush®mode.
Red LED - Flashing rapidly when the Test button is pressed:
This unit features an “alarm memory” to inform you if the
alarm has sounded since the Test button was last pressed.
The alarm memory will cause the red LED to flash rapidly
when the Test button is pressed. The alarm memory is
reset when the Test button is released.
Op ration
12

T sting
NOTE: REGULAR EEKLY TESTING IS REQUIRED!
CAUTION: Due to the loudness (85 decibels) of the alarm, always stand an
arms length away from the unit when testing.
Test by pushing the Test button on the cover and hold it
for a minimum of 5 seconds (or until the alarm sounds).
This will sound the alarm if all the electronic circuitry,
horn and battery are working. If the alarm does not
sound, the unit has a defective battery or some other
failure. DO NOT use an open flame to test your alarm,
you could damage the alarm or ignite combustible
materials and start a fire.
Test the alarm weekly to ensure proper operation. Erratic
or low sound coming from your alarm may indicate a
defective alarm, and it should be returned for service (see
Warranty section).
Alarms failing an alarm test, or not operating normally,
must be replaced with a new alarm. Similarly, alarms more
than 10 years old must be replaced.
Cl aning th Alarm
The alarm should be leaned at least on e a year.
• To clean your alarm, remove it from the mounting plate
(see Alarm Tamper Resist Feature and Alarm Removal
sections). You can clean the alarm by using compressed
air or a vacuum cleaner hose with a soft brush
attachment. Blow or vacuum around the perimeter of the
alarm to remove dust and dirt. The outside of the alarm
can be wiped with a damp cloth (do not use a wet cloth
to avoid water entering the unit).
• After cleaning, reinstall your alarm and test your alarm
by using the Test button. If cleaning does not restore
the alarm to normal operation, the alarm should be
replaced.
• Do not paint the unit. Paint will seal the vents and
interfere with the sensor’s ability to detect smoke. Never
attempt to disassemble the unit or clean inside. This
action will void your warranty.
Maint nanc
13

Maint nanc
14
Alarm R moval
Refer to the Alarm Tamper Resist Feature section for
removal instructions.
To remove the alarm from the mounting plate, rotate the
alarm in the direction of the “OFF” arrow on the cover.
ARNING: Do not attempt to open the alarm for any reason!
Batt ry
A Lithium-ion battery, permanently sealed inside the alarm,
powers this unit. No battery installation or replacement is
necessary for the life of the alarm.
This alarm has a low battery monitor circuit which will
cause the alarm to “chirp” approximately every 40-45
seconds for a minimum of thirty (30) days at the end of the
life of the alarm. Replace the alarm when this condition
occurs.
D activation
ARNING: Do not deactivate the alarm until the end of the alarm life,
when a "chirp" is heard every 40-45 seconds. Once the alarm is
deactivated, the battery will be drained and the alarm will no longer
function.
ARNING: Once the alarm has been deactivated, it cannot be reactivated
and it cannot be reattached onto the mounting plate!
To deactivate the alarm remove the alarm from the
mounting plate and locate the black square on the back
label.
Puncture the black square area with a screwdriver or
similar tool then slide the exposed piece towards the
center of the alarm. This will deactivate the alarm, stop the
low battery “chirp” and render the alarm safe for disposal
by draining the battery.

WARNING: Please read arefully and thoroughly.
• NFPA Standard 72 states: Life safety from fire in
residential occupancies is based primarily on early
notification to occupants of the need to escape, followed
by the appropriate egress actions by those occupants.
Fire warning systems for dwelling units are capable of
protecting about half of the occupants in potentially fatal
fires. Victims are often intimate with the fire, too old or
young, or physically or mentally impaired such that they
cannot escape even when warned early enough that
escape should be possible. For these people, other
strategies such as protection-in-place or assisted escape
or rescue are necessary.
• Smoke alarms are devices that can provide early warning
of possible fires at a reasonable cost; however, alarms
have sensing limitations. Ionization sensing alarms may
detect invisible fire particles (associated with fast flaming
fires) sooner than photoelectric alarms. Photoelectric
sensing alarms may detect visible fire particles
(associated with slow, smouldering fires) sooner than
ionization alarms. Home fires develop in different ways
and are often unpredictable. For maximum protection,
idde recommends that both ionization and
photoelectric alarms be installed.
• A battery powered alarm must have a battery of the
specified type, in good condition and installed properly.
• AC powered alarms (without battery backup) will not
operate if the AC power has been cut off, such as by an
electrical fire or an open fuse.
• Smoke alarms must be tested regularly to make sure the
batteries and the alarm circuits are in good operating
condition.
• Smoke alarms cannot provide an alarm if smoke does not
reach the alarm. Therefore, smoke alarms may not sense
fires starting in chimneys, walls, on roofs, on the other side
of a closed door or on a different floor.
• If the alarm is located outside the bedroom or on a different
floor, it may not wake up a sound sleeper.
Fir Saf ty
15

16
Fir Saf ty
• The use of alcohol or drugs may also impair one’s ability to
hear the smoke alarm. For maximum protection, a smoke
alarm should be installed in each sleeping area on every
level of a home.
• Although smoke alarms can help save lives by providing an
early warning of a fire, they are not a substitute for an
insurance policy. Home owners, landlords and tenants should
have adequate insurance to protect their lives and property.
Good Saf ty Habits
Develop and pra ti e a plan of es ape!
• Install and maintain Fire extinguishers on every level of the
home and in the kitchen, basement and garage. now how
to use a fire extinguisher prior to an emergency.
• Make a floor plan indicating all doors and windows and at
least two (2) escape routes from each room. Second story
windows may need an escape ladder.
• Have a family meeting and discuss your escape plan,
showing everyone what to do in case of fire.
• Determine a place outside your home where you all can
meet if a fire occurs.
• Familiarize everyone with the sound of the smoke alarm and
train them to leave your home when they hear it.
• Practice a fire drill at least every six months, including fire
drills at night. Ensure that small children hear the alarm and
wake when it sounds. They must wake up in order to
execute the escape plan. Practice allows all occupants to test
your plan before an emergency. You may not be able to
reach your children. It is important they know what to do.
• Current studies have shown smoke alarms may not awaken
all sleeping individuals, and that it is the responsibility of
individuals in the household that are capable of assisting
others to provide assistance to those who may not be
awakened by the alarm sound, or to those who may be
incapable of safely evacuating the area unassisted.

Alarm Exit Proc dur
• Alert small children in the home.
• Leave immediately by your escape plan. Every second
counts, so don’t waste time getting dressed or picking up
valuables.
• In leaving, don’t open any inside door without first
feeling its surface. If hot, or if you see smoke seeping
through cracks, don’t open that door! Instead, use your
alternate exit. If the inside of the door is cool, place
your shoulder against it, open it slightly and be ready to
slam it shut if heat and smoke rush in.
• Stay close to the floor if the air is smokey. If possible
do not breathe too deeply to avoid smoke inhalation.
Breathe through a cloth (preferably wet) if possible.
• Once outside, go to your selected meeting place and
make sure everyone is there.
• Call the fire department from your neighbor’s home -
not from yours!
• Don’t return to your home until the fire officials say that
it is all right to do so.
There are situations where a smoke alarm may not be
effective to protect against fire as noted by the NFPA and
UL. For instance:
a) smoking in bed
b) leaving children home alone
c) cleaning with flammable liquids, such as gasoline
d) fires where the victim is intimate with a flaming
initiated fire; for example, when a person’s clothes
catch fire while cooking
e) fires where the smoke is prevented from reaching the
detector due to a closed door or other obstruction
f) incendiary fires where the fire grows so rapidly that an
occupant’s egress is blocked even with properly
located detectors
Fir Saf ty
17

NRC Information
Ionization type smoke alarms use a very small amount of
a radioactive element in the sensing chamber to enable
detection of visible and invisible combustion products. The
radioactive element is safely contained in the chamber and
requires no adjustments or maintenance. This smoke alarm
meets or exceeds all government standards. It is
manufactured and distributed under license from the U.S.
Nuclear Regulatory Commission.
Additional R comm ndations
The National Fire Protection Association’s Standard 72
provides the following information:
Smoke Detection. Where required by applicable laws,
codes, or standards for the specified occupancy, approved
single- and multiple-station smoke alarms shall be installed
as follows: (1) In all sleeping rooms. (2) Outside of each
separate sleeping area, in immediate vicinity of the
sleeping rooms. (3) On each level of the dwelling unit,
including basements Exception: In existing one- and two-
family dwelling units, approved smoke alarms powered by
batteries are permitted.
Smoke Dete tion - Are More Smoke Alarms Desirable?
Required number of smoke alarms (as shown in Image 1A and
Image 1B): The required number of smoke alarms might not
provide reliable early warning protection for those areas
separated by a door from the areas protected by the
required smoke alarms. For this reason, it is recommended
that the householder consider the use of additional smoke
alarms for those areas for increased protection.
The additional areas include the basement, bedrooms,
dining room, furnace room, utility room, and hallways not
protected by the required smoke alarms. The installation
of the smoke alarms in the kitchen, attic (finished or
unfinished), or garage is normally not recommended, as
these locations occasionally experience conditions that can
result in improper operation.
Alarms should be installed in accordance with the National
Fire Protection Association’s Standard 72 (NFPA,
Batterymarch Park, Quincy, MA 02269). Notify your local
fire department and insurance company of your smoke
alarm installation.
Fir Saf ty
18

If after reviewing this manual you feel that your smoke
alarm is defective in any way, do not tamper with the unit.
In many cases, the quickest way to exchange your alarm
is to return it to the original place of purchase.
Alternatively, you may return it for servicing to idde. If
you have questions, call idde Customer Service at
1-800-880-6788.
10 Y ar Limit d Warranty
idde warrants to the original purchaser that the enclosed
smoke alarm will be free from defects in material and
workmanship or design under normal use and service for a
period of ten years from the date of purchase.
The obligation of idde under this warranty is limited to
repairing or replacing this smoke alarm or any part which we
find to be defective in material, workmanship or design, free of
charge to the customer, upon sending this smoke alarm with
proof of date of purchase, postage and return postage prepaid,
to idde Canada Inc., P.O. Box 40, Apsley, ON 0L 1A0.
1-800-880-6788.
This warranty shall not apply to this smoke alarm if it has
been damaged, modified, abused or altered after the date of
purchase or if it fails to operate due to improper maintenance
or inadequate AC or DC electrical power.
The liability of idde or any of its parent or subsidiary corporations
arising from the sale of this smoke alarm or under the terms of this
limited warranty shall not in any case exceed the cost of
replacement of smoke alarm and, in no case shall idde or any of
its parent or subsidiary corporations be liable for consequential loss
or damages resulting from the failure of the smoke alarm or for
breach of this or any other warranty, express or implied, even if
the loss or damage is caused by the company’s negligence or fault.
Since some provinces do not allow limitations on the duration
of an implied warranty or do not allow the exclusion or
limitation of incidental or consequential damages, the above
limitations or exclusions may not apply to you. While this
warranty gives you specific legal rights, you may also have
other rights which vary from province to province.
The above warranty may not be altered except in writing
signed by both parties hereto.
Warranty
19
