KIDYWOLF KIDYBIKE User manual

ENGLISH
User/ Product Manual
PRODUCT USE AND CARE INSTRUCTIONS
KIDYBIKE
Scan me to look at the the tuto
English

2
Thank you for choosing KIDYBIKE
l KIDYBIKE is an electric balance bike for children using
l Before riding, please read this Product Manual carefully, learn Security Warnings and Precautions.
l This manual can help you understand, use and maintain KIDYBIKE.
l In order to avoid dangers that are caused by collisions, falls and loss of control, please learn how to ride electric balance
bike safely.
l You can learn riding skills by reading this product manual.
l This manual includes all operating instructions and precautions, users must read carefully and follow the instructions.
All users are responsible for any consequences that are caused by violating warning contents or prompt operations. We
shall not be liable for incidental and consequential damages.
Content&
1. BEFORE USING ...................................................................................................................................................................... 3
1.1 Riding Risk ................................................................................................................................................................... 3
1.2 Preparation Before Riding ........................................................................................................................................... 3
1.2.1 Prepare install the electric balance bike .......................................................................................................... 3
1.2.2 Product specification ........................................................................................................................................ 4
1.2.3 Description of parts .......................................................................................................................................... 5
1.2.4 How to assemble the KIDYBIKE ........................................................................................................................ 5
2. Safe-using of electric balance bike ........................................................................................................................................ 8
2.1 Weight Limit ................................................................................................................................................................ 9
2.2 Maximum Riding Range .............................................................................................................................................. 9
2.3 Speed Limited .............................................................................................................................................................. 9
3. Usage of Battery .................................................................................................................................................................... 9
3.1 Battery power ............................................................................................................................................................. 9
3.2 Charging process ....................................................................................................................................................... 10
3.3 Temperature .............................................................................................................................................................. 11
3.4 Description of battery ............................................................................................................................................... 11
3.5 Shipping Notes .......................................................................................................................................................... 11
4. Maintenance ....................................................................................................................................................................... 11
4.1 Cleaning Electric balance bike ................................................................................................................................... 11
4.2 Storing Electric balance bike ..................................................................................................................................... 12
5. Service ................................................................................................................................................................................. 12
6. Troubleshooting and guide ................................................................................................................................................. 13
English

3
1. BEFORE USING
1.1#Riding#Risk#
Electric balance bike is a personal electric vehicle toy, our technology and production processes have strict testing for every
pair of electric balance bike. Riding without attention to contents of this manual may cause injury.
Falling, losing control, collision, or failure to follow e-balance bike manual, may cause injury even
death. In order to minimize the risk of riding, ensure that you read manual.
1.2#Preparation#Before#Riding#
When first open the carton box, the following items can be founded in carton box.
1.2.1 Prepare install the electric balance bike
Main product
Charger with tool
Battery
Manuel
English
English

4
1.2.2 Product specification
E-balance bike
Net weight
Approx. 10kgs
Size
980*510*568mm
Running time
6-10km
Operating temperature range
0℃-40℃
Max climbing angle
6~9°
Max weight capacity
50KG
Battery
Capacity
2.0Ah
Types
18650 high rate discharge battery
Charging duration
3~4 hours
Charging times
300 times
Motor
Type
Brush motor
Highest speed
12-15KM/H
Size
104*98*100mm
Power
100W
Charger
Input
AC 100V-240V
Charging temperature range
0℃-40℃
DC output
29.4V/0.6A

5
1.2.3 Description of parts
1.2.4 How to assemble the KIDYBIKE
STEP 1: Assemble the handle bar
Brake bar
Battery
Saddle
Rear wheel
Brake
Motor cover
Foot pedal
Chain cover
Charging pot
Front rim
Handle grip
Front fork
Front tire
Handle bar
Throttle bar
Handlebar stem
A: Size: M5X20 Socket head bolt
B: Upper block
C: Handle bar
D: Down block
1. Put（C）in to location（D），then
cover（B）
2. Put（A）into（B），then use the tools
screw to（D）
English

6
STEP 2: Assemble the front wheel
Loosen the screws
and nuts.
Put the front wheel
into the front fork and
hooked.
Tighten the screws and nuts,
finished as left photo, make
sure the front the wheel is in
the middle of the front fork.
English

7
STEP 3: Install the battery
a. Install the battery：Take the battery out, find the female plug in the battery and the male plug in the bike. Match the
female plug to the male plug, then press the battery case until the two plugs are completely locked. (Move the battery
slowly, if it is a movable battery, it means the plugs are not locked completely. Should press the front part of battery case
heavily to make sure the battery is installed. )
b. remove the battery out: Left hand hold the bike, put the index finger of right hand into the battery handle, thumb and
middle finger hold the battery case, then pull the whole battery case out.
Step 4: Adjust the saddle
Release the lock, adjust the saddle into the right position, then lock it.
female plug
male plug
battery handle
Quick release
Locker
Saddle
English

8
Step 5: Check the battery capacity
Battery capacity display
After install all the above steps, check press the red bottom check the battery capacity.
• Full battery capacity： Green，Yellow，Red light on
• Half battery capacity： Yellow, Red light on; Green light off
• Low battery capacity: Red light on, green and yellow light off
2. Safe-using of electric balance bike
We hope every user can ride electric balance bike safely and enjoy the fun. You can recall the memories of learning how to
ride a balance bike, electric toy car, bicycle; all these experiences can be applied.
1. Please follow the related content in "product Manual" before riding electric balance bike at the first time. Check whether
battery power is enough, tires are damaged or parts are loose before driving. If there is any abnormal situation, please
contact local dealer for repair.
2. Please carefully read the "Product Manual", this will help you to get a lot of important safety information such as speed
limited, vibration alert and safety shutdown, etc.
3. Do not use the ebalance bike incorrectly to endanger the safety of persons or property.
4. Do not modify the parts of electric balance bike, it will affect the performance, and can cause serious injury.
5. The children is not allowed to ride the electric balance bike on his/her own. Children can only ride it when they have been
given supervision or instruction concerning use of the appliance by a person responsible for their safety
6. When the user is riding, make sure to wear protectors, such as: helmet, knee pads, elbow pads and other protective gear.
7. It is prohibited to use on road.
8. Please be alert to things in front or far away from children, keeping good vision will keep children safe.
9. Do not ride on slippery and wet surfaces or on rainy days. Do not ride in dark place.
10. Do not ride on obstacles, such as twigs, litter or small stones, etc. Avoid riding in narrow spaces. Avoid riding on a steep
slope.
11. To avoid degradation of battery performance by heat, electric balance bike should store in cool dry place out of sunlight.
#
English

9
2.1#Weight#Limit#
To ensure safety and reduce damage, us er must follow minimum and maxi mum load:
Minimum Load: 20kgs
Maximum Load: 50kgs
Overweight may increase possibility of injury
2.2#Maximum#Riding#Range#
There are a lot of factors that will affect riding range& performance, such as:
Grade: A smooth, flat surface will increase the riding speed, while an incline or hilly terrain will reduce the speed.
Weight: The weight of the user can affect riding speed and riding range.
Ambient temperature: Please ride and store ebalance bike under recommended temperature, which will increase product
lifetime.
Maintenance: Reasonable battery charging and maintenance will increase the product lifetime.
Speed and riding style: Maintaining a moderate speed will increase distance, on the contrary, frequent starting, stopping,
acceleration will reduce the product life time
2.3#Speed#Limited#
Electric balance bike top speed is 12-15KM/H.
When it is close to the max speed, the electric balance bike will ensure that the speed does not continue to increase. When
the user feel discomfort or loss control with the speed, they must hit the brake bar to slow the speed.
3. Usage of Battery
This section mainly describes the charging method of electric balance bike, how to maintain the battery, some security issues,
and battery specifications. For users' safety, maximum extent of prolonging the battery life, and improve battery
performance, please follow the instructions.
3.1#Battery#power#
You must stop riding if electric balance bike displays low power, or it may affect battery lifetime.
l Don't use the battery if it emits odor or overheats.
l If the electric balance bike is not used for long time, the battery must be charged every 2-3 months.
l Don't touch any leaking material if any.
l keep battery away from children when not riding.
l The charger must be unplugged from the charging port before riding.
l Battery contains dangerous substances, do not open the battery, do not insert anything into battery.
l The battery must be removed from the appliance before it is scrapped.
l The appliance must be disconnected from the supply mains when removing the battery.
l Please use the charger provided with electric balance bike original.
l Don't over charge the battery
l The battery is to be disposed of safety
l This appliance must only be supplied at the seller.
English

10
For the purposes of recharging the battery, only use the detachable charger provided with this appliance
3.2#Charging#process#
Ensure the charging port is dry
When the Led light turn red, it means low power, then the battery need to be charged
Switch off the electric balance bike in "off " position
Plug the charger cable into the electric balance bike, connect the cable with power supply. Please refer to power supply for
charging state.
The Red light of charger indicates that it has begun to charge, otherwise check whether the cable is connected. When the
charger indicates light goes from red to green, it indicates the battery is fully charged.
The charging time is about 2-3 hours.
Keep the charging environment clean and dry.
#
English

11
3.3#Temperature#
The best charging temperature is 10 degree to -40 degree. Over cold and over hot will not completely charge the battery
3.4#Description#of#battery#
Contents
Parameters
Battery
Lithium battery
Charging time
2~3h
Voltage
24V
Initial Capacity
2.0Ah
Working Temperature
-15℃~50℃
Charging Temperature
10℃~40℃
Storage Time(-20℃~ 35℃)
12 months(Charge every 2~3 months)
Storage Humidity
~65%
3.5#Shipping#Notes#
Lithium battery contains dangerous articles. Ship lithium only according to local law.
4. Maintenance
Electric balance bike requires the user to do routine maintenance.
This chapter describes maintenance steps and important operating tips.
Before you perform the following operations, ensure the power and charging cable are disconnected. If the battery is
charging, the operation is not allowed.
4.1#Cleaning#Electric#balance#bike#
Disconnect the charger and turn off Electric balance bike
Wipe the cover
Avoid using water or other liquids on the Electric balance bike for cleaning. If water or other liquids seep into Electric balance
bike, it will cause permanent damage to the internal electronics.
#
English

12
4.2#Storing#Electric#balance#bike#
l fully charge your battery before storing
l Charge products at least every two to three months.
l If the storage ambient temperature is below 0 degree, please do not charge. You can bring the Electric balance bike into
a warm environment (about 10 degree) for charging.
l To prevent dust from entering , you should cover Electric balance bike. Do not connect the power.
l Store Electric balance bike indoors in a dry and suitable temperature. If you do not use it for a long time, please do not
connect the power.
Do not disassemble Electric balance bike. Users who try to disassemble Electric balance bike lose their right for guaranty.
5. Service
Thank you again for your purchasing KIDYBIKE, we would like to provide you good after-sale services since your
purchasing date.
The warranty period is consistent with the national and local warranty policy.
The warranty period is calculated from original date of purchase by the user.
A proof of purchase must be given when claiming this warranty; the original sales receipt is considered such proof.
EXCLUSIONS:
This warranty does not apply to:
Damage caused by misuse, accident or abuse.
Damage caused by service performed by any third part.
A product or part that has been modified without the written permission.
WARRANTY DOES NOT COVER:
Product repair and/or part replacement because of improper installation, connections to improper voltage supply
abuse, neglect, accident, unauthorized repair or other cause not within control of our company.
Damage or claims for products not being available for use, or for lost data or lost software.
Damage occurring to product during shipping.
Failure to operate per Owner's Manual
English

13
6. Troubleshooting and guide
Problem
Possible Cause
Solution
Scooter does not run
Battery needs a charge
Charge the battery until the charger's indicate light turns red into
green.
Check all connectors. Make sure the charger connector is tightly
plugged into the charging port, and that the charger is plugged into
the wall.
Charger is not working
Make sure power flow to the wall outlet is on.
Scooter is overloaded
An excessive overload, such as too heavy a rider or too steep a hill,
could cause the scooter doesn't run.
Scooter suddenly
stopped working while
in use
Tripped circuit breaker
Check all wires and connectors to make sure they are tight.
Scooter runs sluggishly
Riding conditions are too
stressful
Use only on solid, flat, clean and dry surfaces such as pavement or
level ground.
Tire is not properly inflated
The tire is inflated when shipped, but it invariably will lose some
pressure between the point of manufacturing and your purchase.
Scooter is overloaded
Make sure you do not overload the scooter by allowing more than
one rider at a time, exceeding the electric scooters 100kgs maximum
weight limit, going up a hill or towing objects behind the scooter. If
the scooter is overloaded, the scooter runs sluggishly.
Brake dragging
Use your finger to twist the adjuster in either direction until front
wheel is centered between pads.
Brakes are not adjusted properly
Adjust the brakes.
Short run time(less
than 15 minutes per
charge)
Undercharged battery
Charge the battery until the charger's indicate light turns red into
green.
Check all wires and connectors. Make sure the battery connector is
tightly plugged into the charger connector, and that the charger is
plugged into the wall.
Battery is old and will not accept
full charge
Make sure power flow to the wall outlet is on.
Even with proper care, a rechargeable battery does not last forever.
Average battery life is 1 to 2 years depending on scooter use and
conditions. Replace only with a replacement battery.
Brakes are not adjusted properly
Adjust the brakes.
Sometimes the scooter
doesn't run, but other
times it does
Loose wires or connectors
Check all wires around the motors and all connectors to make sure
they are tight.
Motor or electrical switch
damage
Contact your local authorized service center for diagnosis and repair.
Scooter makes loud
noises / grinding
sounds
Chain is too dry
Apply a lubricant to the chain.
English

14
MULTILINGAL INSTRUCTION MANUAL
English

FRANCAIS
Manuel d’utilisation
INSTRUCTIONS D'UTILISATION ET D'ENTRETIEN DU PRODUIT
KIDYBIKE
Scannez moi pour voir le tutoriel
Français

16
MERCI D’AVOIR CHOISI KIDYBIKE
l KIDYBIKE est un vélo d'équilibre électrique pour les enfants
l Avant de rouler, veuillez lire attentivement ce manuel du produit, apprendre les avertissements et les
précautions de sécurité.
l Ce manuel peut vous aider à comprendre, utiliser et entretenir votre KIDYBIKE.
l Afin d'éviter les dangers causés par les collisions, les chutes et la perte de contrôle, veuillez
apprendre à conduire le vélo d'équilibre électrique en toute sécurité.
l Vous pouvez acquérir des compétences de conduite en lisant ce manuel du produit.
l Ce manuel comprend toutes les instructions de fonctionnement et les précautions, les utilisateurs
doivent lire attentivement et suivre les instructions. Tous les utilisateurs sont responsables des
conséquences causées par la violation du contenu des avertissements ou des opérations rapides.
Nous ne serons pas responsables des dommages accessoires et indirects.
Content
1. AVANT L’UTILISATION ................................................................................................................................ 17
1.1 Risque de rouler .............................................................................................................................. 17
1.2 Préparation avant de rouler ............................................................................................................ 17
1.2.1 Préparez l'installation du vélo d'équilibre électrique ........................................................... 17
1.2.2 Spécificités produit ............................................................................................................... 18
1.2.3 Description des pièces ......................................................................................................... 19
1.2.4 Comment assembler le KIDYBIKE ......................................................................................... 19
2. Utilisation sûre du vélo d'équilibre électrique .......................................................................................... 22
2.1 Limite de poids ................................................................................................................................ 23
2.2 Plage de conduite maximale ........................................................................................................... 23
2.3 Vitesse Limitée ................................................................................................................................ 23
3. Utilisation de la batterie ........................................................................................................................... 23
3.1 Puissance de la batterie .................................................................................................................. 23
3.2 Processus de chargement ............................................................................................................... 24
3.3 Température .................................................................................................................................... 25
3.4 Description de la batterie ................................................................................................................ 25
3.5 Notes d'expédition .......................................................................................................................... 25
4. Entretien ................................................................................................................................................... 25
4.1 Nettoyage du vélo d'équilibre électrique ........................................................................................ 25
4.2 Rangement du vélo d'équilibre électrique ...................................................................................... 25
5. Service ....................................................................................................................................................... 26
6. Dépannage et guide .................................................................................................................................. 27
Français

17
1. AVANT L’UTILISATION
1.1 Risque de rouler
Le vélo d'équilibre électrique est un jouet, véhicule électrique personnel, notre technologie et nos processus
de production ont des tests stricts pour chaque unité de production. Conduire sans tenir compte du contenu
de ce manuel peut provoquer des blessures.
Une chute, une perte de contrôle, une collision ou le non-respect du contenu de ce manuel peut entraîner
des blessures, voire la mort. Afin de minimiser le risque de rouler, assurez-vous de lire le manuel.
1.2 Préparation avant de rouler
Lors de la première ouverture de la boîte en carton, vous trouverez les éléments suivants dans la boîte en
carton.
1.2.1 Préparez l'installation du vélo d'équilibre électrique
Français

18
1.2.2 Spécificités produit
KIDYBIKE
Poids net
10 KG
Dimensions
980 x 510 x 568 mm
Durée d'utilisation
6-10 km
Plage de température de fonctionnement
0 - 40℃
Angle de montée maximum
6 ~ 9°
Capacité de poids maximum
50 KG
Batterie
Capacité
2.0 Ah
Types
18650 batterie à décharge à haut débit
Temps de charge
3 - 4 heures
Nombre de charges
300 utilisations
Moteur
Type
Moteur Brosse
Puissance maximum
12-15 Km/h
Taille
104 x 98 x 100 mm
Puissance
100W
Chargeur
Entrée
AC 100V-240V
Plage de température de charge
0 - 40℃
Sortie DC
29.4 V / 0.6 A
Français

19
1.2.3 Description des pièces
1.2.4 Comment assembler le KIDYBIKE
ÉTAPE 1: Assemblez le guidon
Barre de frein
Batterie
Selle
Pneu arrière
Frein
Couverture moteur
Pédale /
Pose pied
Couvre chaine
Port de chargement
Jante avant
Poignée
Fourche avant
Pneu avant
Barre de soutien
Accélérateur
Potence de guidon
A: Taille: M5X20 Boulon à tête
creuse
B: Bloc supérieur
C: Guidon
D: Bloc inférieur
1. Mettez (C) à l'emplacement
(D), puis couvrez (B)
2. Mettez (A) dans (B),puis
utilisez le tourne-vis sur (D)
Français

20
ÉTAPE 2: Assemblez la roue avant
Desserrez les vis et
les écrous.
Mettez la roue avant
dans la fourche avant
et accrocher
Serrez les vis et les écrous,
terminé comme sur la photo
de gauche, assurez-vous que
l'avant de la roue est au
milieu de la fourche avant.
Français
