kincrome K10201 User manual

Thank you for purchasing a Kincrome product. Manufactured to a high standard this product will, if used according to these
instructions and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS,
WARNINGS & CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS
INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE
WARRANTY. PLEASE KEEP INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. GENERAL
Ensure the lamp is fully charged before initial use.
 DO NOT turn the lamp on when it is being charged.
 DO NOT shine directly into your, other person’s or
animal’s eyes.
 DO NOT allow children to use the lamp.
 DO NOT handle or move the lamp whilst it is being
charged.
 DO NOT use the lamp if you suspect that the battery
or the lamp casing is damaged.
DO NOT leave battery in a discharged state, recharge
battery immediately. Before storage, fully recharge the
battery, subsequently recharge the battery at least
once every six months of non-use.
1.2. ELECTRICAL SAFETY FOR USE OF CHARGER.
USE ONLY THE SUPPLIED CHARGER PLUG FOR
CONNECTING LAMP TO THE POWER SUPPLY.
 WARNING! It is the user’s responsibility to read,
understand and comply with the following electrical
instructions:
You must ensure the risk of electric shock is minimised
by the installation of appropriate safety devices.
An RCCB (Residual Current Circuit Breaker) should be
incorporated in the main distribution board. We also
recommend that an RCD (Residual Current Device) is
used with all electrical products, particularly portable
equipment which is plugged into an electrical supply
not protected by an RCCB.
You must also read and understand the following
instructions concerning electrical safety:
If in any doubt about electrical safety, contact a
qualified electrician.
1.2.1. You must ensure that you:
Inspect the charger plug, cable and connector for wear
and damage to ensure items are safe before connecting
to the mains power supply. If worn or damaged DO NOT
use.
Important: Check that the voltage marked on the
charger plug is the same as the lamp.
Uncoil the cable between charger and the lamp.
 DO NOT pull the charger plug from the mains socket by
the lead.
 WARNING! DO NOT use any other type of charger with
this product, other than the supplied mains or car
charger. Failure to observe this warning could result in
injury and or fire and will invalidate the warranty.
 DO NOT try to take the charger plug apart.
 DO NOT use the charger plug to charge or power any
other electrical item.
 DO NOT get the charger wet, or use in wet, damp
conditions (for indoor use only).
1.3. BATTERY SAFETY
 WARNING! To reduce the risk of burns or fire:
 DO NOT attempt to open, disassemble, modify or
service the battery pack.
 DO NOT crush, puncture, short external contacts or
dispose of in fire or water.
 DO NOT expose to temperatures above 60°C (140°F).
 Replace only with the battery pack designated for this
product.
Recycle or dispose of used battery as stipulated by local
regulation.
If the electrolyte in the cells gets on your skin,
thoroughly wash with soap and water. If it gets in your
eyes, rinse thoroughly with cool water and seek
immediate medical attention.
Unique and innovative 360° swivel and tilt function enables the light source to be positioned in any direction. The work light
houses a singular bright COB (Chip on Board) LED providing up to 250 lumens output with two selectable modes of brightness
and 120° spread of light, illuminating the whole work area. Includes an additional high power 3W LED in the end for use as a
directional torch. Features two swivel hooks and three concealed magnets, two on the rear and one on the end, which allow
hands free operation. High quality 2.2Ah Lithium-ion battery for longer life, no memory effect and a much slower discharge than
traditional Ni-MH batteries. Supplied with mains and in car charger.
2. INTRODUCTION / SPECIFICATION
INSTRUCTION MANUAL FOR:
LED WORK LIGHT
LITHIUM-ION
BLUE
Part No: K10201 (BLUE)
Part No: .......................................................................... K10201
Battery:............................................................LI-ion 3.7V-2.2Ah
Main LED Type: .....................................................3W COB LED
Lumen Output High:.......................................................... 250lm
Lumen Output Low: .......................................................... 100lm
Top Torch........................................................................3W LED
Lumen Output High:.......................................................... 120lm
Minimum Length: ............................................................250mm
Maximum Length: ...........................................................275mm
Operating Time:............................................ 3hrs high /6hrs low
Top Torch Operating Time:...................................................8hrs
Charging Time: ..................................................................... 4hrs
Ingress Protection Rating:....................................................IP54

3. CHARGING
4. OPERATION
4.1. Direct the lens away from your eyes before switching on. Toggle the
lamp between 3W top torch LED, high power COB, low power COB
and OFF using the push switch on the handle (Fig.1B).
4.2. Suspend the lamp by the hooks. When the light is hanging from one
hook it can be rotated through 360° for more precise positioning.
4.3. Alternatively use the integral magnets to attach the lamp to any
ferrous metal surface.
IMPORTANT WARRANTY INFORMATION:
The battery fitted to this cordless tool is considered to be a
consumable item and its ability to accept charge will reduce over time.
We will warranty it against mechanical and electrical defect for a
period of one year - this does not cover fair wear and tear. If the
battery is not properly charged before first use, or regularly
conditioned, its capacity will diminish. Under these circumstances we
will not replace the battery even if it is less than one year old.
Note: Fully charge the lamp before first use.
Note: The Lithium battery does not suffer from memory effect and once fully
charged may be stored for up to six months without another charge.
3.1. Connect the charger into the charge socket on back of the lamp
(Fig.2A). Plug into power supply and turn on, the charging LED
(Fig.1A) on the lamp will light RED to show charging has commenced.
3.2. When the battery has fully charged the LED will turn GREEN.
Environmental Protection.
Recycle unwanted materials instead of disposing of them as
waste. All tools, accessories and packaging should be sorted,
taken to a recycle centre and disposed of in a manner which is
compatible with the environment.
WEEE Regulations
Dispose of this product at the end of its working life.
When the product is no longer required, it must be disposed
off in an environmentally protective way. Contact your local
solid waste authority for recycling information.
Battery Removal
Remove the 6 screws on the back of the lamp. Remove the
back casing, and disconnect the wiring to the circuit board.
Remove the two battery mounting screws. Dispose of battery
according to local government guidelines.
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
INFORMATION: For a copy of our latest catalogue and promotions call us on 1300 657 528 and leave your full name and address, including postcode.
g.1
g.2
Li-ion
Warranty given by Kincrome Australia Pty Ltd of 3 Lakeview Drive, Carib-
bean Park, Scoresby, Victoria (Tel [phone]). If this product has ma-
terials or workmanship defects (other than defects caused by abnormal
or non warranted use) you can, at your cost, send the product to place of
purchase, an authorised Kincrome service agent or one of Kincromes ad-
dresses for repair or replacement. Your rights under this warranty are in addition to any
other rights you have under the Australian Consumer Law or other applicable laws. Our
goods come with guarantees that cannot be excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a major failure and compensation for any
other reasonably foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure does not
amount to a major failure. For further details please visit www.kincrome.com.au or call us.
Lamp Charge
Indicator
(A)
360º
rotating
hook
Charging
socket
(A)
Vertical
Magnet
Horizontal
Magnet
On/Off
switch
(B)
