KING CANOPY KMK1PCS User manual

KMK1PCS 10ft X 20ft
10ft8in Wide x 20ft Deep x 5ft8in Side Height x
9ft9in Center Height
King Canopy Item #: KMK1PCS
With 6 Legs, Cover, Elastic Ball Straps & Foot Pads
WARNING:
Keep all ame and heat sources
away from this tent fabric. Meets
the ammability requirements of
CPAI-84 It is not re proof. The fabric
will burn if left in continuous contact
with any ame source.
Distributed by:
PIC America, LTD.
1730 Five Points Lane • Fuquay-Varina, NC 27526
1-800-800-6296 • www.kingcanopy.com

PARTS LIST
5X8PCS 18 pc 1 3/8” diameter 68” Pipe
4X6PCS 6 pc 1 3/8” diameter 52” Swaged Pipe
3WPCS 6 pc 3-way connectors
4WPCS 3 pc 4-way connectors
BALL50 50 pc Elastic ball straps
T10203 1 pc Cover
PFOOT 6 pc Foot pads

FRAME ASSEMBLY
Step 1
Place all corners and pipe on the ground as shown. The swaged pipes are used to form the length of the
canopy.
Step 2
Start with the center and complete the center frame rst. Then assemble each side.
NOTE: Attach the cover before inserting the legs.

COVER ASSEMBLY
Step 1
Unfold the cover with the grommets toward the cover’s bottom and place over the frame.
Step 2
Begin attaching the cover with the elastic ball straps by inserting the elastic cord of the ball strap under-
neath the cover and through the grommet. Then pull cord taut until ball stops. Wrap the cord around the
pole and under the ball. This will hide the ball under the cover and provide a more nished look to your unit.
• Start by attaching 2 elastic ball straps at each of the four corners
• Continue attaching straps from left to right in a zigzag pattern down both sides of the canopy
• Attach straps at the front and back of the unit, again using a zigzag pattern until all straps are secured
Note:
The ball straps are long enough to accommodate various cover lengths. If your straps need a tighter t, they
can be shortened by making an additional knot in the cord strap. Slide the ball upward to reveal the tied
knot. Tie a new knot above the old one. The size of the knot will determine how short the strap becomes.
Slip the ball down over the new knot and secure.
start at corners
go left to right
1
2
go front to back
3end here

LEGS ASSEMBLY
NOW, CONNECT THE LEG POLES TO THE ROOF ASSEMBLY WITH THE COVER ALREADY POSITIONED ON
TOP OF THE UNIT.
Step A: First insert the pipes for the middle poles into the 3- and 4-way connectors, and then connect the
end leg pipes in the same way. (See illustration)
Step B: Push the foot pads onto the bottom of each leg.
NOTE: The foot pads are NOT for anchoring the canopy!
IMPORTANT! Once the legs and cover are assembled, your canopy will act like a kite in the wind. It is
imperative that the canopy anchors be installed NOW!
insert rst
insert second

ANCHORING YOUR UNIT
This canopy is designed for use as a temporary structure. After assembly, the canopy MUST BE securely
anchored to the ground to prevent damage from winds. Your canopy will act like a kite in the wind if not
properly and securely anchored to the ground. Severe winds will cause the frame to twist and unanchored
legs will fall, thereby collapsing the canopy. If severe winds are expected, you must remove the cover from
the frame to prevent damage.
Step 1
Measure out at least 36in from each leg. Screw each anchor into the ground leaving 2in between the ground
and the eye of each anchor. We strongly recommend that your unit be anchored 36in from each leg
although this may not be possible in all cases. DO install anchors as close to 36in away from legs as possible.
Step 2
Tie anchor cable or rope around the connector at the top of each leg of the canopy.
Step 3
Securely tie the other end of the cable or rope through the eye of the anchor and pull tight.
Step 4
Now, continue to screw each anchor into the ground until the eye of the anchor is ush with the ground.
This will secure the anchor rope even tighter.
NOTE: You should check and tighten the rope frequently to ensure maximum stability of your canopy and
to protect against wind damage.
ANCHOR KIT NOT INCLUDED
WITH THIS CANOPY

IMPORTANT NOTICE: PLEASE READ CAREFULLY
We are condent that you will be completely satised with your King Canopy unit. Please take a
moment to read the very important information below, and call us with any questions you may have.
King Canopy/PIC America, LTD. has no control over wind, snow, ice, rain or any other weather condition and
we are in no way responsible for any damage caused by the canopy or to the canopy.
We suggest you contact your insurance carrier just as you would for any other outside structure.
OTHER PRECAUTIONS WHICH MUST BE FOLLOWED:
Keep all ame and heat sources away from this tent fabric. The tent fabric will burn if left in continuous
contact with any ame source.
DO NOT cook underneath or near canopy.
DO NOT store or use ammable liquids underneath or near canopy.
DO NOT ignite or store reworks underneath or near canopy.
DO NOT use bleach to clean cover.
DO NOT dry clean cover.
DO NOT wash cover in washing machine or dry in dryer. Hand wash with mild soap and water only.
DO NOT allow rain water, snow or ice to accumulate on top of cover.
DO NOT hang or suspend anything from the frame, grommets, truss system or ball straps of the unit.
REMOVE canopy cover before a storm, or disassemble entire canopy unit if possible.
REMOVE rain water, snow and ice from canopy cover.
This is a temporary structure and is not recommended for use as a permanent structure.

PRODUCT INFORMATION
Defective Parts
We try our best to eliminate any defective parts that are shipped with our products. If, however, you should
nd a defective part, we will replace – free of charge – any part which is defective. You will need to provide
proof of purchase showing date of purchase and provide us with detailed description of the defective
component. Your replacement will be shipped by ground shipping, freight prepaid. Next day or express
shipping will require freight collect and paid for by you, the consumer. Damages from improper anchoring,
strong winds, snow, ice or rain are not considered defects.
Improper Anchoring, Strong Winds, Rain Snow, or Ice
King Canopy/PIC America, LTD. does not guarantee these canopies under strong weather conditions.
These canopies are designed to protect against damages caused by sun, rain, tree sap, birds, etc. They are
not designed to hold roof loads that accompany snow, ice or heavy rains. If your canopy is not anchored
securely, it can be lifted by the wind and will y away. If your canopy takes ight, we are not responsible for
any replacement. If you know strong weather is predicted, remove the cover or take down the canopy unit
completely. The cover is designed to be quickly and easily removed.
Warranty
All components of this canopy feature a 1-year limited warranty and are warranted to be free from defects
in material and workmanship for a period of 1-year. You must complete and return the enclosed warranty
card promptly after purchase. Please retain your proof of purchase receipt; you will be asked to provide this
receipt in order to obtain warranty service.
Non-Warranty Replacement Parts
If after expiration of the warranty period, you require replacement parts please contact us at
1-800-800-6296. We stock replacement parts and make them available to you at discounted prices.
Our customer service department will be pleased to assist you in any way possible.
Certain regions of the country are extremely hard on covers of any kind. Normal wear and tear is not
covered under the warranty, and should be expected.
In order to receive a discounted or free replacement part, you may be asked to return the part, freight
prepaid, to our warehouse for inspection before we will send a replacement. You must, in all cases, provide a
copy of your receipt showing the date of purchase, model number and price.
For missing parts, replacement parts or any questions:
Please Call 8:00am – 5:00pm EST, Monday – Friday
1-800-800-6296 or 1-919-552-2977
Or you can fax us at: 1-919-552-5069
Replacement parts and customer service is also available through our website.
Please visit us at www.kingcanopy.com
