KING CANOPY Hercules HC1820PC User manual

Hercules™18ft X 20ft
17ft9in Wide x 20ft Deep x 6ft8in Side Height /
11ft6in Center Height
King Canopy Item #: HC1820PC
With 8 Legs, White Drawstring Cover,
Elastic Ball Straps & Foot Pads.
WARNING:
Keep all ame and heat sources
away from this tent fabric. Meets
the ammability requirements of
CPAI-84 Sec 6 and NFPA 701. It is not
re proof. The fabric will burn if left in
continuous contact with any ame source.
www.northlineexpress.com
1-877-734-2458

PARTS LIST
6X6-2PC 25 pc 78” Pipe
3X2-2PC 8 pc 38” Swedge Pipe
3W2PC 6 pc 3-Way Connectors
4W2PC 6 pc 4-Way Connectors
BALL75W 75 pc Elastic Ball Straps
FOOT2PC 8 pc Metal Foot Pads
TDS1820-5 1 pc White Drawstring Cover
CCLIP2 4 pc Curtain Clips
www.northlineexpress.com
1-877-734-2458

FRAME ASSEMBLY
Step 1
Separate all pieces according to size and shape and arrange per the illustration shown below.
Please note:
• The 38in (8) and 78” (8) pipes are used to form the roof rafters
• The remaining 78in pipes are used to form the roof perimeter and for the legs
Step 2
Start with the center and complete the center frame rst. Then assemble each side.
NOTE: Attach the cover before inserting the legs.
DO NOT CONNECT LEG POLES AT THIS POINT!
78’’
78’’
Set aside eight 78”
pipes to use for legs.
78’’
Start Here
78’’ 78’’ 78’’
78’’ 78’’ 78’’
78’’ 78’’ 78’’
78’’
78’’
78’’
78’’
78’’
78’’
78’’
78’’38’’
38’’
38’’
38’’
38’’
38’’
38’’
38’’
38’’
www.northlineexpress.com
1-877-734-2458

COVER ASSEMBLY
Step 1
Unfold the cover with the grommets toward the cover’s bottom and place over the frame. The ared edges
should be located at each of the 4 corners of the frame.
Step 2
Begin attaching the cover with the elastic ball straps by inserting the elastic cord of the ball strap underneath
the cover and through the grommet. Then pull cord taut until ball stops. Wrap the cord around the pole and
under the ball. This will hide the ball under the cover and provide a more nished look to your unit.
• Start by attaching 2 elastic ball straps at each of the four corners
• Continue attaching straps from left to right in a zigzag pattern down both sides of the canopy
• Attach straps at the front and back of the unit, again using a zigzag pattern until all straps are secured
Note:
The ball straps are long enough to accommodate various cover lengths. If your straps need a tighter t, they
can be shortened by making an additional knot in the cord strap. Slide the ball upward to reveal the tied knot.
Tie a new knot above the old one. The size of the knot will determine how short the strap becomes.
Slip the ball down over the new knot and secure.
Inside View Outside View
Start at Corners Go Left to Right
Go Front to Back End Here
www.northlineexpress.com
1-877-734-2458

LEGS ASSEMBLY
NOW, CONNECT THE LEG POLES TO THE ROOF ASSEMBLY WITH THE COVER ALREADY POSITIONED ON
TOP OF THE UNIT.
Step A: First insert the pipes for the middle poles into the 3- and 4-way connectors, and then connect the end
leg pipes in the same way. (See illustration)
Step B: Push the eight foot pads onto the bottom of each leg.
NOTE: the foot pads are NOT for anchoring the canopy!
Step C: Connect the hook & loop fastening strips down the length of each leg.
Step D:
Slip one clip onto each of the corner legs.
To secure the clips on the corner legs use the drawstring sewn into each end of the cover. Adjust the drawstring
evenly on each side of the canopy by pulling the drawstrings on each end of the cover at the same time. Insert
the ball on the drawstring into the slot on the curtain clip. Pull the clip down until tight. Pressure from the
drawstring will cause the clip to wedge onto the pipe.
Curtain clips may have to be re-tightened occaisonally due to strong wind gusts.
IMPORTANT! Once the legs and cover are assembled, your canopy will act like a kite in the wind. It is
imperative that the canopy anchors be installed NOW!
Insert Second
Insert First
www.northlineexpress.com
1-877-734-2458

ANCHORING YOUR UNIT
This canopy is designed for use as a temporary structure. After assembly, the canopy MUST BE securely
anchored to the ground to prevent damage from winds. Your canopy will act like a kite in the wind if not
properly and securely anchored to the ground. Severe winds will cause the frame to twist and unanchored
legs will fall, thereby collapsing the canopy. If severe winds are expected, you must remove the cover from
the frame to prevent damage.
Step 1
Measure out at least 36in from each leg. Screw each anchor into the ground leaving 2in between the ground
and the eye of each anchor. We strongly recommend that your unit be anchored 36in from each leg
although this may not be possible in all cases. DO install anchors as close to 36in away from legs as possible.
Step 2
Tie anchor cable or rope around the connector at the top of each leg of the canopy.
Step 3
Securely tie the other end of the cable or rope through the eye of the anchor and pull tight.
Step 4
Now, continue to screw each anchor into the ground until the eye of the anchor is ush with the ground. This
will secure the anchor rope even tighter.
NOTE: You should check and tighten the rope frequently to ensure maximum stability of your canopy and to
protect against wind damage.
ANCHOR KIT NOT INCLUDED
WITH THIS CANOPY
www.northlineexpress.com
1-877-734-2458

IMPORTANT NOTICE: PLEASE READ CAREFULLY
We are condent that you will be completely satised with your King Canopy unit. Please take a moment
to read the very important information below, and call us with any questions you may have.
King Canopy/PIC America, LTD. has no control over wind, snow, ice, rain or any other weather condition and
we are in no way responsible for any damage caused by the canopy or to the canopy.
We suggest you contact your insurance carrier just as you would for any other outside structure.
OTHER PRECAUTIONS WHICH MUST BE FOLLOWED:
Keep all ame and heat sources away from this tent fabric. The tent fabric will burn if left in continuous
contact with any ame source.
DO NOT cook underneath or near canopy.
DO NOT store or use ammable liquids underneath or near canopy.
DO NOT ignite or store reworks underneath or near canopy.
DO NOT use bleach to clean cover.
DO NOT dry clean cover.
DO NOT wash cover in washing machine or dry in dryer. Hand wash with mild soap and water only.
DO NOT allow rain water, snow or ice to accumulate on top of cover.
DO NOT hang or suspend anything from the frame, grommets, truss system or ball straps of the unit.
REMOVE canopy cover before a storm, or disassemble entire canopy unit if possible.
REMOVE rain water, snow and ice from canopy cover.
This is a temporary structure and is not recommended for use as a permanent structure.
