KINGDOM KFE2204 User manual

Kingdom New 20 Cue Wireless Firing System
KFE2204
Instruction Manual
Contents
Disclaimer----------------------------------------------------------P2
Warning-------------------------------------------------------------P2
Description---------------------------------------------------------P2
Technical date------------------------------------------------------P3
What is included---------------------------------------------------P3
What is not included----------------------------------------------P3
Charging the system --------------------------------------------P3
Firing Mode Definitions------------------------------------------P4
Receiver control description ----------------------------------P4
Deprogramming Module and Re-Programming---------------P5
Step 1…………………Step 2…………………Step 3…………………
Setting the receiver operating mode -------------------------P5
Expanding the system---------------------------------------------P6
Over-loading protection-------------------------------------------P7
Optional Upgrade--------------------------------------------------P7
Disclaimer:
The manufacturer(s), distributor(s) and / or seller(s) accept no responsibility
whatsoever for any damage, injury or loss, financial or otherwise, resulting directly or
indirectly from the use, misuse, function or malfunction of this device. By purchasing
and using this device you understand and accept this disclaimer.
Warning:
1. Only the person who has fireworks license is allowed to purchase the product, or
the person of whom there isn’t fireworks purchase limit in his/her country or district is
allowed to purchase the products. Kingdom is not with responsibility for any illegal
usage.
2. Safety is the user’s responsibility. All pyrotechnic effect and firework safety
guidelines should be followed completely.
3, You must deprogram the system prior to trying to re-program the module to prevent
accidental code storage thereby creating a secure firing environment
Description:
It is a 20 cue advanced wireless firing system for pyrotechnics and fireworks. This
system is not only powerful, compact , and reliable, it also is expandable. With the
supplied handheld transmitter it is expandable up to 60cues using up to 3 receivers.
Each receiver can be controlled by the transmitter (1-3 channel ) independently in
Single Firing, Step Firing, Sequence Firing and All Firing. You can also program
multiple receivers to the same channel to infinity if you need simultaneous ignition
from multiple firing locations.
As with all our products, this one can be used safely and securely with our other
systems. Additionally, it can be combined with our advanced control desk
(KFE2209/18/2 ) offering you the ability to take control of all the operating systems in
your show in one convenient location.
Battery Status Light Description
RED (flashing) Battery Low.
RED (steady) Battery Charging.
RED / GREEN (flashing) Battery Almost Full.
GREEN (steady) Battery Full.
Page 2 of 8
Page 1of 8

It is also expandable up to 320 cues in Sequencer Firing modes up to 16 receiver
modules controlled by S channel on the radio control desk KFE2209/18/2 .
Each mode needs to be set on the receiver module before it is used. The operator can
not switch between modes without returning to the receiver modules. This is a safety
feature to prevent the operator activating a mode accidentally.
The new version with advanced over-loading protection function, it can ensure the
firing systems for long time use.
With the advanced interface and musical fireworks show software, it can be used for
creating a professional musical fireworks show.
Technical date sheet:
Module Size (cm) 22.8 x 14.5 x 6.8 Built-in power (V) 12V Ah Lead Acid
Battery
Unit weight (kg) 1.47 Charging power DC 15V-250mA
Range (meter) 300-350 Output power DC 24V
Over-loading
protection New version- Yes Test current (mA) 0.8MA
What is included:
1 Piece of individual 20 cue receiver module
2 Pieces of safety keys.
1 Piece of 3x20 channel transmitter.
1 Instruction manual.
1 Piece of charger with DC15V 250mA output power.
What is not included:
Battery for Transmitter.
Charging the system:
The Battery Status Light will only operate when the unit is switched ON and in Fire
mode. However the system will charge even when switched off.
Lead Acid Batteries naturally discharge over time. To keep the battery in good
condition it is recommended the system is charged every 2-3months. Storing the
system in extremely low or high temperatures will shorten the life of the battery.
Firing mode definitions:
Button Description
1-20 Single Fire Mode: 1-20 Fire individual cues.
CONT Sequence Fire Mode: Fire the cues in sequence with a set delay
between each cue.
STEP Step Fire Mode: Fire the cues sequentially with each successive
button press. Holding STEP down continuously will cause multiple
cues to fire.
ALL All Fire Mode: Fire all the cues.
Slide
Switch(1,2,3,4)
Transmitter Address:
Position 1, 2, 3: Select which receiver(s) to control when more
than 1 receiver is used.
Position 4: Should only be set in position 4 when the system is
configured with receivers operating together automatically in
series(one after the other)
Page 3 of 8
Page 3 of 8
Receiver control description:
Button Description
Function Selection
(FIRE, OFF, TEST)
Controls the mode of the receiver. TEST mode tests the cues for
continuity. OFF mode turns the receiver off. Fire mode allows
the system to be programmed and cues to be fried.
Safety Switch (ON,
OFF) This arms and disarms the system.
Program Programs the receiver with a new transmitter.
Up-Arrow Increments the selected delay digit.
Right-Arrow Sets which delay digit to change AND changes the receiver
operating mode.
Ok / Delete Enters the current time and operating mode setting / Deletes the
current time setting and resets the operating mode.
Add Sets 1 of 16 possible receiver address for expansion up to 16
receivers, giving 320cues available in CONT firing modes.
T / M Different time delay mode: Allow a different time delay to be
set between each cue.
Page 3 of 8 Page 4 of 8

Deprogramming module and re-programming
You must deprogram the system prior to trying to re-program the module. This
system has a fail-safe for digital rectifying that will prevent accidental code storage
thereby creating a secure firing environment..
Step 1. Put the rocket switch to the ( F ) fire position. Turn the key on the receiver
module to “ON” position. Extend the antenna on the module. Ensure that the
transmitter is on.
Step 2. Press and hold the program button. The red LED above the button will
illuminate for about 10 seconds. This LED light will go out when the code is deleted.
It has deleted the previous program. No remote transmitter can control it anymore.
Step 3. Press and release the program button again. Immediately press any channel
button on the remote transmitter. Keep your fingers on the button until you see the
firing LED lights. Which indicates the receiver module has locked onto the signal.
(Warning: Never program the receiver when another transmitter is transmitting. This
may cause the receiver to be programmed with the wrong transmitter.)
Setting the receiver operating mode:
The receiver must be set to the correct mode before using the system. This ensures
that accidentally pressing a button on the transmitter will not have an unwanted
effect.
Mode Display Screen Description
Continuous (Same
time Sequencer) 0.01- 9.99second Sequencer with same time or different time delay between each cue,
All Fire ALL Fires all cues when the ALL button on
transmitter is pressed.
Single Fire SIN Fires the correct cue when the button 1-20 is
pressed on the transmitter.
Step STE
Fires the next cue when STEP is pressed on
the transmitter.
To set the receiver operation mode follow the steps below:
1. Hold down OK/DELETE button until the display reads 0.00
2. Press Right-Arrow button to cycle through the digits and operating modes.
3. Press OK/DELETE button to set the correct receiver operating mode.
Expanding the system:
More receivers can be added to expand the system. By programming the receivers
with different transmitter identities, the receivers can be controlled in parallel (at the
same time), individually or a mixture of both.
Example 1. The receivers are programmed with the same transmitter identity so
they are controlled in parallel(at the same time)
1. Program receiverA,B and C with the transmitter slide switch in the same position.
Example 2. The receivers are programmed with same transmitter identity, but
the slide switch not in same position so that they are controlled separately.
1. Program receiver A with the transmitter slide switch in 1 position.
2. Program receiver B with the transmitter slide switch in 2 position.
3. Program receiver C with the transmitter slide switch in 3 position.
Example 3. The receivers can be controlled separately by using the professional
radio control desk KFE2209/18/2.
1. Program receiverAwith the control desk rotary switch in 1 position.
2. Program receiver B with the control desk rotary switch in 2 position.
3. Program receiver C with the control desk rotary switch in 3 position.
Example 3. 16 Receivers (16x20=320cues) are programmed with same
transmitter identity in sequence fire mode with different addresses.(Transmitter
slide switch in position 4. Control desk rotary switch in position S)
1. Set the address numbers on each receiver. 1-16.
2. Set the same time delay on each receiver. Example: 0.10 second.
3. Set the communication between the transmitter (or control desk) and the receivers.
Page 5 of 8 Page 6 of 8

When CONT button is pressed to start the sequence, all receivers receive the signal
at the same time. Every cue will fire at a time delay of 0.1second from 1-20 on 1st
recei
time use.
mber: 1820A. For more details,
ver, then it will automatically transfer to 2nd receiver and fire cue 21-40, then it
will transfer to next one till the 16th receiver up to 320cues.
This function is good for making the special effects like round-shaped sequence
firing of the mines or comets in stadium.
Over-loading Protection:
New version firing systems will have overload protection function. It is a advanced
technology can ensure the system for long
Optional upgrade:
1.This system also can be used for doing the musical show. There is the special
software and interface for this firing systems. Item nu
please read the instructio
n of this device.
2. Optional Components:
KFE2201C
Receiver Module
KFE2209/18/2
Radio Control Desk
KFE2204E
Receiver Module
KFE2203E
Receiver Module
KFE2204D
Receiver Module
KFE2202B
Receiver Module
KFE2204
Receiver Module
KFE3000
LED Table
Teleconformity No: 2014RNB051R0
KFE2201C/60
Transmitter 1820A Interface for music show KFE2209/18/2 KFE2210
Control Desk Antenna
USB
Computer 1820A KFE2204 Fireworks
Audio
Amplifier Sound
