Kingfisher PHP650C User manual

PHP650C
EAN 3663602796367
ORIGINAL INSTRUCTIONS
V60910 BX220IM

Safety instructions 7
Product description 14
Assembly 16
Use 18
Care & maintenance 21
Guarantee 27
Declaration of conformity 28
Product description 4
Safety instructions 7
Product description 14
Assembly 16
Use 18
Care & maintenance 21
Guarantee 27
Declaration of conformity 28
2

1
x1
WARNING! Please read all safety warnings carefully and be
sure that they are fully understood before handling the tool.
3

Product description
1 2 3
4
5
6
7
8
9
10
11
12
13
15
16
17
18
14
19
20
21
A
10
19
B
10
4

C D
2.
1.
+
-
9
8
E F
2
2.
1. 1
G H
11
5

I
12
15 J
11
16
+
-
6

Safety instructions
GENERAL POWER TOOL SAFETY WARNING
WARNING Read all safety warnings, instructions, illustrations and
specications provided with this power tool. Failure to follow all
instructions listed below may result in electric shock, re and/or serious
injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated
(corded) power tool or battery-operated (cordless) power tool.
1) WORK AREA SAFETY
a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the
presence of ammable liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
2) ELECTRICAL SAFETY
a) Power tool plugs must match the outlet. Never modify the plug in any
way. Do not use any adapter plugs with earthed (grounded) power tools.
Unmodied plugs and matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a
power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled cords increase the risk of electric
shock.
e) When operating a power tool outdoors, use an extension cord suitable
for outdoor use. Use of a cord suitable for outdoor use reduces the risk of
electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual
current device (RCD) protected supply. Use of an RCD reduces the risk of
electric shock.
3) PERSONAL SAFETY
a) Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired
or under the inuence of drugs, alcohol or medication. A moment of
inattention while operating power tools may result in serious personal injury.
7

b) Use personal protective equipment. Always wear eye protection.
Protective equipment such as dust mask, non-skid safety shoes, hard hat, or
hearing protection used for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position
before connecting to power source and/or battery pack, picking up or
carrying the tool. Carrying power tools with your nger on the switch or
energising power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A
wrench or a key left attached to a rotating part of the power tool may result in
personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair,
clothing and gloves away from moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly used. Use
of dust collection can reduce dust-related hazards.
h) Do not let familiarity gained from frequent use of tools allow you to
become complacent and ignore tool safety principles. A careless action
can cause severe injury within a fraction of a second.
4) POWER TOOL USE AND CARE
a) Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at the rate
for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any
power tool that cannot be controlled with the switch is dangerous and must be
repaired.
c) Disconnect the plug from the power source and/or the battery pack from
the power tool before making any adjustments, changing accessories,
or storing power tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow
persons unfamiliar with the power tool or these instructions to operate
the power tool. Power tools are dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of moving
parts, breakage of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power tool repaired before
use. Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with
sharp cutting edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with
these instructions, taking into account the working conditions and the
work to be performed. Use of the power tool for operations different from
those intended could result in a hazardous situation.
h) Keep handles and grasping surfaces dry, clean and free from oil and
grease. Slippery handles and grasping surfaces do not allow for safe handling
and control of the tool in unexpected situations.
8

5) SERVICE
a) Have your power tool serviced by a qualied repair person using only
identical replacement parts. This will ensure that the safety of the power tool
is maintained.
SAFETY WARNINGS FOR PLANERS
a) Wait for the cutter to stop before setting the tool down. An exposed
rotating cutter may engage the surface leading to possible loss of control and
serious injury.
b) Hold the power tool by insulated gripping surfaces, because the cutter
may contact its own cord. Cutting a “live” wire may make exposed metal
parts of the power tool “live” and could give the operator an electric shock.
c) Use clamps or another practical way to secure and support the workpiece
to a stable platform. Holding the workpiece by your hand or against the body
leaves it unstable and may lead to loss of control.
d) The power tool shall not be wet or applied in wet environment.
e) The voltage of the power source must agree with the voltage specied on the
nameplate of the machine.
f) Check the product, its power cord and plug as well as accessories for damage
before each use. Do not use the product if it is damaged or shows wear.
g) Be aware of kickback.
h) Turn the product off immediately, if the cutting blade gets jammed.
i) Never touch the workpiece with your hand when you are working on it.
j) Do not work overhead.
k) Ensure that the workpiece is free of foreign objects such as screws or nails.
l) Keep the handles dry to ensure safe control. Grip the product securely with
two hands so you have full control at all times.
m) Ensure that the air vents are always unobstructed and clear. Clean them if
necessary with a soft brush. Blocked air vents may lead to overheating and
damage the product.
n) Switch the product off immediately if you are disturbed while working by other
people entering the working area. Always let the product come to complete
stop before putting it down.
o) Do not overwork yourself. Take regular breaks to ensure you can concentrate
on the work and have full control over the product.
p) Always keep the power cord behind the power tool.
The following information applies to professional users only but is good practice for all
users:
ADDITIONAL SAFETY WARNINGS FOR CONSTRUCTION DUST
The updated Control of Substances Hazardous to Health Regulations 1st October
2012 now also targets to reduce the risks associated with silica, wood and gypsum
dusts.
Construction workers are one of the at-risk groups within this because of the dust that
they breathe: silica dust is not just a nuisance; it is a real risk to your lungs!
9

Silica is a natural mineral present in large amounts in things like sand, sandstone and
granite. It is also commonly found in many construction materials such as concrete and
mortar. The silica is broken into very ne dust (also known as Respirable Crystalline
Silica or RCS) during many common tasks such as cutting, drilling and grinding.
Breathing in very ne particles of crystalline silica can lead to the development of:
• lung cancer
• Silicosis
• Chronic obstructive pulmonary disease (COPD).
And breathing in ne particles of wood dust can lead to the development of Asthma.
The risk of lung disease is linked to people who regularly breathe construction dust
over a period of time, not on the odd occasion.
To protect the lung, the COSHH Regulations sets a limit on the amount of these dusts
that you can breathe (called a Workplace Exposure Limit or WEL) when averaged over
a normal working day. These limits are not a large amount of dust: when compared to
a penny it is tiny – like a small pinch of salt:
This limit is the legal maximum; the most you can breathe after the right controls have
been used.
How to reduce the amount of dust?
1. Reduce the amount of cutting by using the best sizes of building products.
2. Use a less powerful tool e.g. a block cutter instead of angle grinder.
3. Using a different method of work altogether – e.g. using a nail gun to direct fasten
cable trays instead of drilling holes rst.
Please always work with approved safety equipment, such as those dust masks that
specially designed to lter out microscopic particles and use the dust extraction facility
at all time.
For more information please see the HSE website:
http://www.hse.gov.uk/construction or http://www.hse.gov.uk/pubns/cis69.pdf
10

WARNING! Some dust particles created by power sanding, sawing,
grinding, drill and other construction jobs contain chemicals known
to cause cancer, birth defects or other reproductive harm. Some
examples of these chemicals are:
• Lead from lead-based paints.
• Crystalline silica from bricks and cement and other masonry products.
• Arsenic and chromium from chemically treated timber.
Your risk from these exposures varies, depending upon how often you do
this type of work. To reduce your exposure to these dusts:
• Work in a well-ventilated.
• Work with approved protective equipment, such as those dust masks
that are specially designed to lter microscopic particles.
VIBRATION
The European Physical Agents (Vibration) Directive has been brought in to help reduce
hand arm vibration syndrome injuries to power tool users. The directive requires power
tool manufacturers and suppliers to provide indicative vibration test results to enable
users to make informed decisions as to the period of time a power tool can be used
safely on a daily basis and the choice of tool.
SEE TECHNICAL SPECIFICATIONS IN THE INSTRUCTION MANUAL FOR THE
VIBRATION LEVELS OF YOUR TOOL.
The declared vibration emission value should be used as a minimum level and should
be used with the current guidance on vibration.
Calculating the actual period of use can be difcult and the HSE website has further
information.
The declared vibration total value has been measured in accordance with EN 62841-1
and EN 62841-2-14 and may be used for compare one tool with another.
The declared vibration total value may also be used in a preliminary assessment of
exposure.
11

WARNING! The vibration emission during actual use of the power tool
can differ from the declared total value depending on the ways in which
the tool is used:
• How the materials are grinded, cut or drilled.
• If the tool is in good condition and well maintained.
• Use correct accessory for the tool and ensure it is sharp and in good
condition.
• The tightness of the gripping handles.
• The tool is being used as intended by its design and these instructions.
While working with this power tool, hand/arm vibrations occur.
Adopt the correct working practices in order to reduce the exposure
to vibration. This tool may cause hand-arm vibration syndrome if its
use is not adequately managed.
WARNING! Identify safety measures to protect the operator that are
based on an estimation of exposure in the actual conditions of use (taking
account of all parts of the operating cycle such as the times when the tool
is switched off and when it is running idle in addition to the trigger time).
Note:
• The use of other tools will reduce the users’ total working period on
this tool.
• Helping to minimise your vibration exposure risk. ALWAYS use sharp
chisels, drills and blades.
• Maintain this tool in accordance with these instructions and keep well
lubricated (where appropriate).
• Avoid using tools in temperatures of 10ºC or less. Plan your work
schedule to spread any high vibration tool use across a number of
days.
Health surveillance
All employees should be part of an employer’s health surveillance scheme to help
identity any vibration related diseases at an early stage, prevent disease progression
and help employees stay in work.
12

VIBRATION AND NOISE REDUCTION
To reduce the impact of noise and vibration emission, limit the time of operation,
use low-vibration and low-noise operating modes as well as wear personal
protective equipment.
Take the following points into account to minimise the vibration and noise exposure
risks:
1. Only use the product as intended by its design and these instructions.
2. Ensure that the product is in good condition and well maintained.
3. Use correct attachments for the product and ensure they are in good condition.
4. Keep tight grip on the handles/grip surface.
5. Maintain this product in accordance with these instructions and keep it well lubri-
cated (where appropriate).
6. Plan your work schedule to spread any high vibration tool use across a longer pe-
riod of time.
7. Prolonged use of the product exposes the user to vibrations that can cause a
range of conditions collectively known as hand-arm vibration syndrome (HAVS)
e.g. ngers going white; as well as specic diseases such as carpal tunnel syn-
drome. To reduce this risk when using the product, always wear protective gloves
and keep your hands warm.
RESIDUAL RISKS
Even if you are operating this product in accordance with all the safety
requirements, potential risks of injury and damage remain. The following
dangers can arise in connection with the structure and design of this product:
1. Health defects resulting from vibration emission if the product is being used over
long periods of time or not adequately managed and properly maintained.
2. Injuries and damage to property due to broken attachments or the sudden impact
of hidden objects during use.
3. Danger of injury and property damage caused by ying objects or poor power tool
accessories.
WARNING! This product produces an electromagnetic eld during
operation! This eld may under some circumstances interfere with active
or passive medical implants! To reduce the risk of serious or fatal injury,
we recommend persons with medical implants to consult their doctor and
the medical implant manufacturer before operating this product!
13

Product description
Part index
The index below refers to Fig. 1 on page 4.
1. On/Off switch
2. Lock-off button
3. Main handle
4. Belt cover
5. Parallel guide
6. Mounting hole (parallel guide)
7. Wing nut
8. Cutting depth Scale
9. Cutting depth adjustment knob
10. Dust extraction outlet
11. Hex bolts
12. Blade
13. Rear plate
14. Roller
15. Blade holder
16. Grub screws
17. V-groove
18. Front plate
19. Dust bag
20. Wrench
21. Hex key
Symbols
On the product, the rating label and within these instructions you will nd among others
the following symbols and abbreviations. Familiarize yourself with them to reduce
hazards like personal injuries and damage to property.
Always wear eye protection. Always wear ear protection.
Wear a dust mask. Wear protective gloves.
Lock / to tighten or secure. Unlock / to loosen.
Note / Remark. Caution / Warning.
dB(A) Decibel (A-rated) n0No-load speed
To reduce the risk of injury, user must read instruction manual.
Switch the product off and disconnect it from the power supply
before assembly, cleaning, adjustments, maintenance, storage and
transportation.
This product is of protection class II. That means it is equipped with
enhanced or double insulation.
The product complies with the applicable European directives and an
evaluation method of conformity for these directives was done.
Rated voltage, frequency : 220 – 240 V~ ,50 Hz
Rated power input : 500 W
Rated speed n : 11000 min-1
Max. grinding wheel diameter : Ø 115 mm
Max. thickness of grinding wheel : 6 mm
Diameter of wheel bore : 22.23 mm
Spindle thread size : M 14
Protection class : ||
Weight : 1.43 kg
Sound pressure level LpA :87.2 dB (A)
Sound power level LWA :98.2 dB (A)
Uncertainty KpA, KWA :3 dB (A)
Vibration total value:ah, AG : 6.1 m/s2
Uncertainty K : 1.5 m/s2
14

WEEE symbol. Waste electrical products should not be disposed of with
household waste. Please recycle where facilities exist. Check with your
Local Authority or local store for recycling advice.
yyWxx Manufacturing date code; year of manufacturing (20yy) and week of
manufacturing (Wxx)
Technical data
Rated voltage, frequency : 220 – 240 V~, 50 Hz
Rated power input : 650 W
Rated no load speed n0: 16000 min-1
Planing width : 82 mm
Cutting depth : 0-2 mm
Protection class : II
Weight :approx. 2.58 kg
Sound pressure level LpA 89.0 dB(A)
Sound power level LWA :100.0 dB(A)
Uncertainty KpA, KWA :3 dB(A)
Vibration total value: ah: 3.4 m/s2
Uncertainty K : 1.5 m/s2
The sound emission values have been obtained according to the noise test code given
in EN 62841-1 and EN 62841-2-14. The noise for the operator may exceed 80 dB(A)
and ear protection measures are necessary.
Rating label explanation
PHP650C = Model number
P = Brand name
HP = Hand Planer
650C = Power (Watts)
15

Assembly
01 Unpacking
1. Unpack all parts and lay them on a at, stable surface.
2. Remove all packing materials and shipping devices, if applicable.
3. Make sure the delivery contents are complete and free of any damage. If you nd
that parts are missing or show damage do not use the product but contact your
dealer. Using an incomplete or damaged product represents a hazard to people
and property.
4. Ensure that you have all the accessories and tools needed for assembly and oper-
ation. This also includes suitable personal protective equipment.
WARNING! The product must be fully assembled before operation!
Do not use a product that is only partly assembled or assembled with
damaged parts!
Wear protective gloves for this assembly work and always lay the product
on a at and stable surface while assembling.
Follow the assembly instructions step-by-step and use the pictures
provided as a visual guide to easily assemble the product!
Do not connect the product to power supply before it is completely
assembled!
WARNING! The product and the packaging are not children’s toys!
Children must not play with plastic bags, sheets and small parts! There is
a danger of choking and suffocation!
16

02 Dust extraction (Fig. A and B)
WARNING! Always attach a dust extraction device or the dust bag when
using this product to keep the working area clean! Wear a dust mask
when operating this product! Dust can be harmful to health!
Especially dust and chips of wood that has been treated, e.g.
with wood preservative or a stain!
Dust bag
1. Align the connector of the dust bag (19) to the dust extraction outlet (10) and insert
it completely (Fig. A).
2. Pull the connector out in a twisting motion to remove the dust bag (19).
Emptying
1. Remove the dust bag (19) from the product as described above.
2. Open the zip and empty chippings into a suitable rubbish bag.
3. Close the zip and re-attach the dust bag (19) to the product.
NOTE: Empty the dust bag when it is half full. An overlled dust
bag lowers the performance of the product.
Dust extraction
Attach a proper dust extraction device, e.g. a suitable vacuum cleaner attachment
(Ø35mm) to the dust extraction outlet (10) (Fig. B).
03 Parallel guide (Fig. C)
Attach the parallel guide to perform straight cuts along a workpiece edge.
1. Loosen the wing nut (7) and insert the parallel guide (5) into the mounting hole (6).
2. Adjust the parallel guide (5) to the desired width.
3. Tighten the wing nut (7).
NOTE: The parallel guide can only be applied for planing a thickness less
than 2mm. Otherwise the housing will touch the workpiece surface.
17

Use
Intended use
This product is intended for planing of rmly supported wooden materials, such as
beams and boards. It is also suitable for bevelling edges.
The product must be used in an upright position only with the front plate lying at on
the workpiece. It may not be used upside down or as stationary product on a work
bench.
Before you start
01 Protection
Controls
01 Planing depth adjustment (Fig. D)
WARNING! Always switch the product off and disconnect it from power
supply before making any adjustments!
Adjust the desired planing depth by turning the cutting depth adjustment knob (9). The
depth can be adjusted from 0 to 2 mm. The number on the scale (8) next to the point-
er indicates the depth of cut in millimetres.
02 Switching on/off (Fig. E)
1. Press the lock-off button (2) and hold it in position.
2. Press the on/off switch (1) to switch on the product.
3. Release the on/off switch (1) to switch the product off.
18

Operation
01 General planing (Fig. F)
WARNING! During operation ne dust will be generated!
These dusts are highly inammable and explosive! Do not smoke during
operation, keep heat sources and open ames out of the working area!
Always wear a dust mask to protect yourself against hazards resulting
from ne dust!
1. Adjust the desired planing depth.
2. Hold the product with one hand on the main handle (3), and with the other hand on
the cutting depth adjustment knob (9).
3. Switch the product on and wait until it runs at full speed before placing it on the
workpiece.
WARNING! Danger of kickback! Apply the product to the workpiece
only when switched on!
4. Place the front plate (18) at on the workpiece and push the product forward at an
even speed. Apply light consistent pressure against the workpiece to achieve an
even result.
5. Turn the cutting depth adjustment knob (9) anticlockwise to retract the blades after
nishing your work.
• Always make a trial cut before working on the actual workpiece,
especially after replacing or adjusting the planing depth.
• To achieve high-grade surfaces: work only with low feed with slight
consistent pressure on the centre of the planer base plate. Use small
depths of cut and repeat the planing process.
• When machining hard materials (e.g. hardwood) as well as when
utilising the maximum planer width, set only low planing depths and
reduce planer feed, as required.
• Excessive feed reduces the surface quality and can lead to rapid
clogging of the chip ejector.
• Only sharp blades achieve good cutting capacity and give the
machine longer life.
19

02 Bevel planing (Fig. G)
With the V-groove (17) bevel angles of 45° can be cut on the edge of a workpiece.
1. Place the V-groove (17) onto the edge of the workpiece. Apply slight consistent
pressure against the workpiece to achieve an even result.
2. Guide the product along the edge.
After use
1. Switch the product off, wait for complete stop, disconnect it from the power supply
and let it cool down.
2. Check, clean and store the product as described below.
20
