KingsBox Foldable Flat Bench User manual

Foldable
Flat Bench
EN

2
Table of content
Manufacturer information....................................3
Equipment Identification..........................................3
Field of application......................................................4
Equipment positioning..............................................5
Correct use of the equipment.............................6
Exercise instructions...............................................7
Technical information...............................................8
Care and maintenance..............................................10
List of tools required................................................11
Assembly elements....................................................12
Assembly instructions.............................................13

3
Manufacturer information
Equipment identification
TNG oprema d.o.o.
Bazoviška cesta 7a, 6210 Sežana
Slovenia
Costumer service
Telephone: [phone]
Email: [e-mail]
Address: Bazoviška cesta 7a, 6210 Sežana
Slovenia

4
Field of application
Product classification:
EN ISO 20957-1:2013 Class S
The free area shall not be less than 0,6 m
greater han the training area in the
directions from which the equipment is
accessed. The free area must also include the
area for emergency dimount. Where
equipment is positioned adjacent to each
other the value of the free area may be
shared.
The possibility of users not being able to exist
the equipment when using it according to this
manual shall be avoided.

5
Equipment positioning
Total surface area (foot print):
600
600 600
600
Training area
Free area

6
Correct use of the equipment
unsupervised children should be kept
away from the equipment!

7
Exercise instructions
injuries to health may result from
incorrect or excessive training!
start
end

8
Technical information
Total mass: 16 KG
Maximum user body weight: 100 KG
Maximum loading mass: 250 KG
warning!
if any of the adjustment
devices are left projecting, they could
interfere with the user’smovement!
warning!
free standing equipment shall be in-
stalled on astable and levelled base!

9
warning!
If the structure is not secured to the ground
and / or to the wall, it may overturn and / or
cause damage to person or
object in the immediate vicinity.
The fixing bolts for wall and/or floor are not
included in the pack-age, since different types
of anchor bolts must be used for differ-ent
wall/floor types.
Dimensions

10
Care and maintenance
warning!
The safety of the equipment is assured only
on condition that it is carefully inspected
for signs of damage and/or wear every two
weeks.
Replace defective and worn components im-
medeately, or alteranively remove the equip-
ment from service.
warning!
Be careful not to rub with excessive force on
the drawings and instructions shown on the
labels.
The equipment should always be kept clean
and free of dust, in compliance with good
hygiene practice, especially if it is used in a
gym or by more than one person.
To clean the padded parts, use a moist cloth
or a sponge and mild soap.
Every week, clean the outer parts of the
equipment using a damp sponge.

11
List of tools required
2x 1x
19 mm Wrench 13 mm Wrench

12
Assembly elements
QTY.
1x
2x2x
position
position 3
name
Bench Profile I.
FFB Bracket
FFB Leg
position 2position 1
SAMPLE
2x1x
Locking Pin 12x80Bench Pillow
position 5position 4
6x
position 6
M12 x 100
12x
M12 Washer
position 7 6x
M12 Nuts
position 8

13
Assembly elements
4x
2x
2x2x
position 9
position 12
Rubber Leg
60x60
M8x70
M8 Washer
Plug 60x60
position 11position 10

14
Assembly instructions
10
12
11
3
4
11
12
10
STEP 1
8
8
7
7
3
2
7
66
8
7
7
6
1
9
9
STEP 2

15
Assembly instructions
5
STEP 3

Foldable
Flat Bench
IT

17
Indice contenuti
Dati produttore............................................................18
Identificazione articolo.............................................18
Utilità...................................................................................19
Collocamento articolo...............................................20
Utilizzo corretto dell’articolo...............................21
Istruzioni per l’esecuzione degli
esercizi..............................................................................22
Informazioni tecniche................................................23
Cura e manutenzione...............................................25
Elenco attrezzi necessari......................................26
Elenco componenti.....................................................27
Istruzioni per l’assemblaggio................................29

18
Dati produttore
Identificazione articolo
TNG oprema d.o.o.
Bazoviška cesta 7a, 6210 Sežana
Slovenia
Servizio clienti
Telefono: [phone]
E-mail: [e-mail]
Indirizzo: Bazoviška cesta 7a, 6210 Sežana
Slovenia

19
Utilità
Classificazione articolo:
EN ISO 20957-1:2013 Class S
L’area libera attorno all’area d’allenamento
dovrebbe essere di almeno 0,6m tutt’attorno
all’area di utilizzo. L’area libera deve includere
anche un’area per l’evacuazione o altre emer-
genze. Nel caso di più attrezzi posizionati uno
accanto all’altro, questi possono condividere
l’area libera.

20
600
600 600
600
Training area
Free area
Collocamento articolo
Planimetria articolo (foot print):
