KingShield AC3000 User manual

Installation Instructions
For t e KingS ield Air Curtain
Model No: AC3000
IMPORTANT
This produc should be ins alled by a compe en
person and in accordance wi h he curren IEE
Wiring Regula ions. If in doub , consul a qualified
elec rician.
• This produc is no in ended o be used by
children and persons wi h sensory, physical
and/or men al impairmen s ha would preven
hem from using i safely.
•Ex reme cau ion is necessary where children or
persons wi h reduced physical, sensory or men al
capabili ies may come in o con ac wi h he
hea er when in use.
The Air Curtain unit is designed for easy
installation and can e wall or ceiling mounted.
The unit has a fan and two heat settings and its
angle can e adjusted. This unit is ideal for
providing a heated air curtain if mounted over
doorways and reduces draughts and the
discomfort of cold air when doors are opened.
It is also an ideal choice for heating general
areas.
Swi ch off mains supply and remove he
appropria e circui fuse or MCB before
commencing ins alla ion or main enance.
1. Remove the four screws securing the ack
mounting racket.
2. Using the racket as a template, mark the
fixing holes position.
3. Drill and secure the racket with suita le
fixings.
4. Re-position the heater ack on the racket
with the four screws, ensuring the serrated
lock washer is in the correct place. Position
the angle of heater as required.
• In order to avoid overheating do not cover or
o struct grilles or air intake openings when
in use.
• The heater must not e located immediately
adjacent to or under/against an electrical
socket outlet.
• Do not operate the heater with a damaged
cord/plug or if heater malfunctions. If the
supply cord is damaged it must e replaced
y a qualified electrician
• Before making any fixing holes make sure
there are no pipes or ca les elow the
surface.
• Make sure the heater is anchored to a solid
surface which can take the weight of the
heater.
• This heater is for indoor use only.
• This heater must e connected to earth.
• Position the heater ensuring that hot air
cannot low directly onto flamma le surfaces.
• This heater is not equipped with a device to
control the room temperature. Do not use
this heater in small rooms when they are
occupied y persons not capa le of leaving
the room on their own, unless constant
supervision is provided.
INTRODUCTION
INSTALLATION
WARNING
AC3000 Product Instructions:Layout 1 14/11/13 15:27 Page 1

TECHNICAL DATA
Rating: 230-240V 50Hz
Power: 1.5 -3kw (two heat settings)
Class: I (requires earth)
Colour: White
Dimensions: L585 x W185 x H100mm
Prewired: 1.3M ca le
Conforms To: EN60335-2-30, EN 60335-1
& EN62233
INSTALLER - Please pass instruction manual
onto the owner of the unit
Please keep t ese instructions for future reference.
GUARANTEE
Issue no: 703414
WEST ROAD . HARLOW
ESSEX . CM20 2BG . UK
sales@green rook.co.uk
W W W. G R E E N B R O O K . C O . U K
Your KingShield Air Curtain is guaranteed
for 12 months from the date of purchase.
This does not affect your statutory rights.
5. Connect heater to mains supply using a
switched 13A fused spur to the
corresponding sym ols.
Live - Brown or Red
Neutral - Blue or Black
Earth - Green and Yellow
6. Restore power and switch on the main switch
(red illuminated). Heating levels are
controlled y two switches (2) for half and
full load.
3
2
1
1- Illuminated mains switch and fan lower
2- Heater control switch
3- Fixing racket
Mains switch - Fan only
Mains switch and I or II - heated warm air 1500W
Main switch and I and II - heated warm air 3000W
Note: Non resetting thermal fuse
- requires electrical technician for repair.
