KINGZO GMD120-D User manual

KINGZO
GMD120-D
Electric Film Reeler Manual

11
24V120W
（
GMD120-D
）
Installation Distance
Control Mode
30m 50m 75m 100m 150m
Each circuit controls 1 set
2*1.5mm²
2*2.5mm²
2*4mm²
2*4mm²
2*6mm²
Each circuit controls 2 sets
2*4mm²
2*4mm²
2*6mm²
2*10mm²
2*16mm²
Each circuit controls 3 sets
2*4mm²
2*6mm²
2*10mm²
2*16mm²
2*16mm²
Each circuit controls 4 sets
2*6mm²
2*10mm²
2*16mm²
2*16mm²
2*25mm²
Notice: Wire is the standard copper one.
8.Wiring Distribution Table
10

CONTENTS：
1.Safey tips-----------------------------------------------------1
2.Product features ＆performance data -------------2
3.Installation Instructions -----------------------------------4
4.Limit range adjusting---------------------------------------7
5.Maintenance ------------------------------------------------8
6.Common problems ＆solutions ------------------------9
7.Packing list -------------------------------------------------9
8.Wiring distribution table--------------------------------10
9. Certificate of product quality--------------------------11
The product is subject to design and performance modification,
it could be a little different from this Manual. But it will not affect
your usage. This Manual is also subject to modification without
further notice. Please read this Manual carefully before using the
product.
9
7.GMD120-D Packing list
No.
Problem
Analysis
1Motor
doesn’t rotate
No power connection
The left and the right knob
touch the micro switch at the
same time.
2Limit not
accurate
Lock bolts loose
Inner parts damage
3
Noise
Incorrect installation
Overload
1.The packing list only contain the standard accessories and
documents, it doesn’t include the other accessories you
choose. If you have ordered other accessories, please check
it when youreceive the order. The production date is on this
packing list.
2.To insure your interest and rights please keep this packing
list for future service.
1
No
PART NAME
QTY
MARK
1
Electric Film Reeler body
1
2
Coupling
2
3
Suit
2
4
Plugs
2
5
Self-locking nut M8
2
6
Hexagon bolt M8×12
4
7
Hexagon bolt M8×45
2
8
Assemble instruction
1

4.2.4 When the motor is rolling up the plastics, the pipe arrives
at the required position, at this time rotate the knob which
controls the rolling status and make the gear pin touch the
micro switch( with click sound), hold on and fasten the lock
bolt by a cross head screw-driver.
4.2.5 When the motor is rolling down the plastics, the pipe arrives
at the required position, at this time rotate the knob which
controls the rolling status and make the gear pin touch the
micro switch( with click sound) , hold on and fasten the lock
bolt by a cross head screw-driver.
4.2.6 The above steps would set up the motor’s limit range. Turn
on the power and check if the range setup is correct. If it is
not correct, please review the manual carefully and do the
setup again.
5. Maintenance
5.1 Check the bolts on each connection regularly. Replace the
bolts which is deformed or snapped.
5.2 No need to refill the gear oil during the life duration of this
product.
5.3 This product could be used for greenhouse rolling ventilation
and curtaining system. For other usage, please consult our
company first.
6. Common problems and solutions
1、Safty tips
1.1 The life of this roll-up would be extended by proper operation
and maintenance, please kindly operate according to this
manual strictly.
1.2 This product needs DC24V input currency. Specialist or
electrician is needed to connect the power. Please don’t
connect 、AC220V or any other unspecified power, or there
would be damage or fires.
1.3 When the rolling pipe is rolling to high position with the plastics,
please don’t loosen this product with the pipe. Or the rolling
pipe will fall down fast and there would be possibility to hit
person or to cause damage to the product.
1.4 Cut off the electricity when there is lightning or the motor
could be damaged.
1.5 The rolling pipe could be at the same line with the motor
shaft. The curve of the pipe should not be too big, or the
motor could be damaged by overload.
1.6 Please check and fasten the bolts connecting the electric
winch and its accessories; loose bolts will cause danger.
1.7 If the product didn’t work，please don’t uninstall the part
inside; you should stop operating and contact the distributors
or the company.
1.8 Please don’t put the product into water and store it in moist
environment; the product could be damaged or cause danger
to operators. If the products have water leaking inside, please
stop operating and send it back to the factory for repair.
1.9 Please don’t toss or throw the products, it should be prevented
from outside force.

7
4.2 Limit switch adjusting
4.2.1 Loosen the left and right lock bolts by a cross head screw
-driver, at the same make sure the gear pins don’t touch
the micro switch.
4.2.2 Turn on the power, and make the motor run, confirm the
status of the rolling pipe, is it rolling up or rolling down.
4.2.3 When the motor is rolling up the plastics, rotate any of the
knobs slowly, and make the gear pin touch the micro switch
( with click sound) , if the motor stops running, it means this
knob is used for the rolling you need; if the motor doesn’t
stop running, then the other knob is used to control the
required rolling.
4、Limit range adjusting
4.1 Limit illustration
Before limit adjust, please loosen“left or right fasten bolts”
After limit adjust, please fasteb“left or right fasten bolts”
CAUTION: After the limit adjust is finished, please fasten the bolts. Or the
limit will not be accurate and there would be dange of power shock.
2
1.10 The user should keep the site clean and swipe the leaves
or snow on the plastics to avoid overload damage.
1.11 After the adjust is finished, the user should fasten the bolts
or there might be damage or accidents.
1.12 Don’t use the product over the maximum currency.
1.13 In the transportation or in installation please prevent the
products from falling; tossing the cable is prohibited.
1.14 We are not responsible for the damage due to ignorance
of our instruction manual.
2、Product Features and Performance data
2.1 Product Features
This product is compact in structure, reliable in performance,
convenient in installation and operation, adjustable reversing
switch，with reversing-lock function;
2.2 Outside Drawing
Left gear pin
Left lock bolt
Left knob
Right gear pin
Right lock bolt
Right knob
Micro switch

3
2.3. Circuit principles
5
3.4.1 Please operate this product according to the “correct
installation diagram”.
3.4.2 Correct installation could guarantee the performance of
the products.
3.4.3 After the installation, the motor should be above the limit
switch at any position of the rolling.
3.4 Installation diagram.
Figure 1
Figure 2

4
2.4 Performance data
3、Installation instructions
3.1 First please fasten the pipe and this product with the bolts.
Then fix the film into the pipe by the film hoop, please keep
the pipe and the output shaft of this product on the same line;
then start the motor and operate the opening and closing the
films.
3.2 Two types of pipe could be used for this motor, the diameter
is φ27, φ33.5. When the φ27 pipe is used, the suit is needed,
the φ33.5 pipe doesn’t need it.
3.3 The pipe for top opening is φ27.
3.4.4 After the installation, the cable should be connect into the
control box, then turn on the power, adjust the limit switch
the proper position, and then fasten the lock bolts.
3.4.5 If there is power failure during the operation of the products,
and you would like to lower down the rolling pipe urgently,
you could hold the pipe first and loosen the connection
between the pipe and the motor, then lower the pipe slowly.
3.5 Installation dimension
6
Model GMD120-D
Power 120W
Torque 140N·m
Current ≤7.5A
Voltage
DC24V±3V
Speed 70N·m 3.2 r/min
140N·m 2.7 r/min
Rolling tube 3/4″（OD:Φ27）or 1″（OD:Φ33.5）
Recommended
Load
Rotating ability Screening
180m(L)x1.5m(H) 700 ㎡
Maximum range
(output shaft) 38 Rounds
Protection degree IP55
