OWNER`S MANUAL(GK150)

Owner`sManual Owner`sManual Owner`sManual Owner`sManual
2
Limited Warranty
The warranty policy applies to those cases where the new seller vehicle unloaded from its shipping
container, set up and delivered by authorized dealer and under normal use and service is found to have
defects in parts or workmanship under the following terms and conditions. This warranty covers the engine
and engine related components for a period of 180 days.
This warranty does not apply to any part that in opinion of seller was defective because of improper
maintenance, improper assembly, alterations, abuse, negligence or accident.
Should warranty service be required on your vehicle during the 180 days warranty period, please
contact your nearest authorized KINROAD dealer for repairs.

Owner`sManual Owner`sManual Owner`sManual Owner`sManual
3
What is not covered under this warranty?
This warranty does not cover any seller vehicle that has been subjected to:
a. This warranty does not cover any seller vehicle in any way so as to adversely affect its safety or
reliability.
b. Renting
c. Disassembly, adjusting/ or repairing of the vehicle in any way so as to adversely affects its safety
or reliability.
d. Competition or racing
The warranty does not cover loss of use of the seller vehicle, loss of time, inconvenience, or other
consequential damage which includes, but is not limited to/ loss or damage to persons or property or any
expense of returning any damaged units to the seller distributor or its authorized dealer.
KINROAD has the right to make changes without notice.

Owner`sManual Owner`sManual Owner`sManual Owner`sManual
4
Contents
1. FOREWORD----------------------------------------------------------------------------------------------------5
2. A FEW WORDS ABOUT SAFETY-------------------------------------------------------------------------5
3. IMPORTANT SAFETY INFORMATION------------------------------------------------------------------7
4. SAFETY LABELS---------------------------------------------------------------------------------------------11
5. ARE YOU READY TO DRIVE?--------------------------------------------------------------------------- 11
6. IS YOUR VEHICLE READY TODRIVE?----------------------------------------------------------------16
7. SAFE DRIVING PRECAUTIONS--------------------------------------------------------------------------18
8. SPECIFICATIONS--------------------------------------------------------------------------------------------23
9. OPERATION-------------------------------------------------------------------------------------------------- 26
10. SERVICE INSTRUCTIONS---------------------------------------------------------------------------------36
11. REPAIR---------------------------------------------------------------------------------------------------------44
12. PERIODICAL CHECK AND SERVICE------------------------------------------------------------------46
13. WIRING DIAGRAM -----------------------------------------------------------------------------------------47

Owner`sManual Owner`sManual Owner`sManual Owner`sManual
5
Thank you for choosing our double seat BUGGY. We hope you will have fun with it. Before you start
operate on the BUGGY please read through this Owner's Manual carefully as it contains important safety
and maintenance information. Failure to follow the warnings contained in this manual can result in serious
injuries.
Be sure to follow the recommended maintenance schedule and service your vehicle accordingly.
Preventive maintenance is extremely important to the longevity of your BUGGY.
Beginners should drive this BUGGY in a large open area to practice handle of this BUGGY. Protective
gears should be worn at all time when driving or riding this BUGGY.
We hope you will have a pleasant experience with our products and thanks again for choosing KINROAD.
In order to keep everyone safe, you must take responsibility for the safe operation of your BUGGY.
To help you make informed decisions about safety, we have provided operating procedures and other
information on labels and in this manual. This information alerts you to potential hazards that could hurt

Owner`sManual Owner`sManual Owner`sManual Owner`sManual
6
you or others.
It is not practical or possible to warn you about all hazards associated with operating or maintaining a
BUGGY; you must use your own good judgment.
You will find important safety information in a variety of forms, including;
Safety Labels - On the BUGGY.
Safety Messages - Preceded by a safety alert symbol and one of two signal words:
WARNING, or CUATION.
These signal words mean:
Physical harm may result from failure to adhere to the instructions that are described within the
WARNING labels.
Safety Headings: such as Important Safety Reminders or Important Safety Precautions,
Safety Section: such as Buggy Safety.
Instruction: how to use this BUGGY correctly and safety.

Owner`sManual Owner`sManual Owner`sManual Owner`sManual
7
This entire manual is filled with important safety information—please read it carefully.
Your BUGGY will provide you with many years of service and pleasure providing you take responsibility
for your own safety and understand the challenges you can meet while driving. There is much that you can
do to protect yourself when you drive. You'll find many helpful recommendations throughout this manual.
The following are a few that we consider most important.
Follow the Age Recommendation
It is strongly recommended that no one under the age of 16 be permitted to drive this BUGGY without
adult supervision.
Always Wear a Helmet
It's a proven fact: helmets significantly reduce the number and severity of head injuries. Always wear an
approved motorcycle helmet. We also recommend that you wear eye protection, sturdy boots, gloves, and
other protective gear.

Owner`sManual Owner`sManual Owner`sManual Owner`sManual
8
Drive Off-Road Only
Your BUGGY is designed and manufactured for off-road use only. The tires are not made for pavement,
and the BUGGY does not have turn signals and other features required for use on public roads. If you need
to cross a paved or public road, get off and walk your BUGGY across.
Take Time to Learn & Practice
Even if you have driven other BUGGY, take time to become familiar with how this BUGGY works and
handles. Practice in a safe area until you build your skills and get accustomed to this Buggy’s size and
weight. Because many accidents involve inexperienced or untrained drives, we urge all drivers to take a
training course approved by the BUGGY Safety Institute. Check with your dealer for more information on
training courses.
Be Alert for Off-Road Hazards
The terrain can present a variety of challenges when you drive off-road. Continually "read" the terrain for
unexpected turns, drop-offs, rocks, ruts, and other hazards. Always keep your speed low enough to allow
time to see and react to hazards.

Owner`sManual Owner`sManual Owner`sManual Owner`sManual
9
Drive within Your Limits
Pushing limits is another major cause of BUGGY accidents. Never drive beyond your personal abilities or
faster than conditions warrant. Remember that alcohol, drugs, fatigue, and inattention can significantly
reduce your ability to make good judgments and drive safely.
Don't Drink and Drive
Alcohol and driving don't mix. Even one drink can reduce your ability to respond to changing conditions,
and your reaction time gets worse with every additional drink. So don't drink and drive, and don't let your
friends drink and drive either.
Do not operate this BUGGY at night.
Dark vision can greatly reduce a driver's visibility and judgment. So driving at night is dangerous and can
increase possibility for accident.
Never run your BUGGY indoors.
The exhaust from the engine contains a tasteless, odorless and poisonous gas called carbon monoxide.

Owner`sManual Owner`sManual Owner`sManual Owner`sManual
10
Keep away from moving parts of the BUGGY
The operator of the BUGGY should never place their hands or other parts of their body near any
moving part of the BUGGY. Failure to adhere to this warning will cause physical harm to your body.
Skidding or Sliding
The terrain surface can be a major factor affecting turns. Skidding a turn is more likely to occur on slippery
surfaces such as snow, ice, mud and loose gravel. If you skid on ice, you may lose all directional control.
To avoid skidding on slippery terrain, keep your speed low and drive carefully.
This section presents some of the most important information and recommendations to help you drive your
BUGGY safely. Please take a few moments to read these pages.

Owner`sManual Owner`sManual Owner`sManual Owner`sManual
11
The labels should be considered permanent partsofthe
BUGGY. If a label comes off or becomes hard to read,
contact your dealer for warning labels replacements.
Before each drive you need to make sure you and your
BUGGY are both ready to drive. To helpgetyouprepared,
this section discusses how to evaluate your driving
readiness, what items you should check on your BUGGY,
and adjustments to make for your comfort, convenience, or
safety.
Before you drive your BUGGY for the first time, we urge you to:
• Read this owner's manual and the labels on your BUGGY carefully
• Make sure you understand all the safety messages.
• Know how to operate all the controls.

Owner`sManual Owner`sManual Owner`sManual Owner`sManual
12
• Have adult present if under 16 years old.
Before each drive, be sure:
• You feel well and are in good physical and mental condition.
• You are wearing an approved motorcycle helmet (with chin strap tightened securely), eye protection,
and other protective clothing.
• You don't have any alcohol or drugs in your body system.
Protective Apparel
For your safety, we strongly recommend that you always wear an approved motorcycle helmet, eye
protection, boots, gloves, long pants, and long-sleeved shirt or jacket whenever you drive.
Although complete protection is not possible, wearing proper gears can reduce the chance of injury when
you drive.
The following suggestions will help you choose the proper driving gears.
Helmets and Eyes Protection
Your helmet is your most important piece of driving gear because it offers the best protection against head

Owner`sManual Owner`sManual Owner`sManual Owner`sManual
13
injuries. A helmet should fit your head comfortably and securely.
An open-face helmet offers some protection, but a full-face helmet offers more.
Regardless of the style, look for a DOT (Department of Transportation) sticker in any helmet you buy.
Always wear a face shield or goggles to protect your eyes and help your vision.
Additional Driving Gears
In addition to a helmet and eye protection, we also recommend:
• Sturdy off-road motorcycle boots to help protect your feet, ankles, and lower legs.
• Off-road motorcycle gloves to help protect your hands.
• Driving pants with knee and hip pads, a driving jersey with padded elbows, and a chest and shoulder

Owner`sManual Owner`sManual Owner`sManual Owner`sManual
14
protector.
Driver Training
Developing your driving skills is an on-going process. Even if you have driven other Buggies, take time to
become familiar with how this BUGGY works and handles. Practice driving the BUGGY in a safe area to
build your skills. Do not drive in rough terrain until you get accustomed to the BUGGY's controls, and feel
comfortable with its size and weight.
Age Recommendation
It is strongly recommended that no one under the age of 16 be permitted to operate this BUGGY without
adult supervision.

Owner`sManual Owner`sManual Owner`sManual Owner`sManual
15
No Alcohol or Drugs
Alcohol, drugs and Buggies don't mix. Even a small amount of alcohol can impair your ability to operate a
BUGGY safely. Likewise, drugs---even if prescribed by a physician---can be dangerous while operating a
BUGGY. Consult your doctor to be sure it is safe to operate a vehicle after taking medication.

Owner`sManual Owner`sManual Owner`sManual Owner`sManual
16
Before each drive, it is important to inspect your BUGGY and make sure any problems you find are
corrected. A pre-drive inspection is a must, not only for safety, but because having a breakdown, or even a
flat tire, can be a major inconvenience.
If your BUGGY has overturned or has been involved in a collision, do not drive it until your BUGGY has
Pre-drive Inspection
Check the following items before you get on the BUGGY:
●Engine Oil: Check the level and add oil if needed. Check for leaks.
●Fuel: Check the level and add fuel if needed. Also make sure the fuel filling cap is securely fastened.
Check for leaks.

Owner`sManual Owner`sManual Owner`sManual Owner`sManual
17
●Tires: Use a gauge to check the air pressure. Adjust if needed. Also look for signs of damages or
excessive wear.
●Nuts & Bolts: Check the wheels to see that the axle nuts are tightened. Use a wrench to make sure all
accessible nuts, bolts, and fasteners are tight.
●Underbody & Exhaust System: Check for and remove any dirt, vegetation or other debris that could be
fire hazard or interfere with the proper operation of the BUGGY.
●Air Cleaner Housing Drain Tube: Check for carbon deposits in the drain tube. If necessary, clean the
tube and check the air cleaner housing.
●Leaks, Loose Parts: Walk around your BUGGY and look for anything that appears unusual, such as a
leak or loose cable.
●Lights: Make sure the headlight, brake light and taillight are working properly.
●Throttle: Check the free play and adjust if needed. Press the throttle to make sure it moves smoothly
without sticking, and snaps back automatically when it is released.
●Brakes: Press the rear brake pedal several times, check for proper brake pedal free play. Make sure
there is no brake fluid leakage.
●Engine Stop Button: When engine is running, press and hold the Engine Stop Button for two seconds.
Make sure the engine stops.

Owner`sManual Owner`sManual Owner`sManual Owner`sManual
18
●Steering Wheel: Check that the wheels turn properly as you turn the steering wheel.
● Cable: Check the cable housing for wear. Check the fittings for looseness. Replace or tighten as
needed.
Off-Road Use Only
Your BUGGY and its tires are designed and manufactured for off-road use only, not for pavement. Driving
on pavement can affect handling and control. You should not drive your BUGGY on pavement.

Owner`sManual Owner`sManual Owner`sManual Owner`sManual
19
When driving off-road, also remember to always obey local off-road driving laws and regulations. Obtain
permission to drive on private property. Avoid posted areas and obey "no trespassing" signs.
You should never drive your BUGGY on public streets, roads or highways, even if they are not paved.
Drivers of street vehicles may have difficulty seeing and avoiding you, which could lead to a collision. In
many states it is illegal to operate Buggies on public streets, roads and highways.
Keep Hands and Feet on Controls
Always keep both hands on the steering wheel and both feet on the foot controls when driving your
BUGGY. It is important to maintain your balance and to control the BUGGY. Removing hands or foot
away from the controls can reduce your ability to react control of the BUGGY.

Owner`sManual Owner`sManual Owner`sManual Owner`sManual
20
Control Speed
Driving at excessive speed increases the chance of an accident. In choosing a proper speed, you need to
consider the capability of your BUGGY, the terrain, visibility and other operating conditions, plus your
