REX Regulator (KM47/77)

KIRBY MORGAN DIVE SYSTEMS INCORPORATED
MAINTENANCE AND REPAIR
TECHNICIAN TRAINING
Only selected Dive Lab trained Tec nicians are aut orized to teac t e Tec nicians Course.
Only Dive Lab aut orized Tec nicians may teac t e KMDSI Operator/User Course.
Course curriculum must be presented wit in t e guidelines set-up in t e repair tec nician’s
guide and slide s ow.
Kirby Morgan, SuperLite, Band Mask, KMB Band Mask, EXO, SuperMask, SuperFlow, and Rex are all registered
trademarks of Kirby Morgan Dive Systems, Inc. Use of t ese terms to describe products t at are not
manufactured by KMDSI is not permitted wit out written permission from KMDSI.
© Copyrig t 1970-2009 Kirby Morgan Dive Systems, Inc. All rig ts reserved. T is manual is made available for t e
express use of owner of t is Kirby Morgan product. No part of t is manual may be reproduced, stored in any
retrieval system, or transmitted, or used in any form or by any means, w et er grap ic, electronic, mec anical,
p otocopy, or ot erwise by tec nology known or unknown, wit out t e prior written permission of Kirby Morgan
Dive Systems, Inc.
THIS SLIDE SHOW IS FOR THE USE OF KIRBY MORGAN CUSTOMERS AND USERS OF KIRBY MORGAN DIVING EQUIPMENT
ONLY. IT IS FREE OF CHARGE FROM OUR WEB SITES FOR THAT USE ONLY UNTIL FURTHER NOTICE. T is material
may not be reproduced for resale or given to unaut orized organizations or persons. THIS MATERIAL MAY NOT
BE CHANGED OR MODIFIED WITHOUT WRITTEN PERMISSION.
Prepared by Dive Lab®, Inc. 1415 Moylan Road, Panama City Beach, L 32407 USA
Telephone: [phone] Web Site: www.divelab.com E-Mail: divelab@aol..com
Document #TechTrnG 03101

REX Regulator (KM47/77)
•T e breat ing system on all Kirby Morgan
elmets and masks is simple and ig ly reliable
•T e fact t at t ey can continue to operate w en
t e components are not in a well-maintained
condition can cause divers to become complacent
about maintenance
•Your life depends on the correct function of this
equipment!

REX Regulator (KM47/77)
•T e REX regulator is simple to maintain, like any
type of life support equipment, it requires regular
periodic maintenance to function properly
•All parts disassembled s ould be t oroug ly
cleaned
•Components t at require t e use of lubricants,
sealing and t read locking compounds s ould
also be serviced

REX Regulator (KM47/77)
Disassembly for Cleaning
•Remove tie wraps from w isker wings
•Remove w isker valve assembly from eac side of
ex aust body, inspect
•During regular cleaning and inspection, t e w isker
valves do not need to be removed from plastic
ex aust valve seats
•Remove regulator cover ring, cover, was er, and
diap ragm

REX Regulator (KM47/77)
Disassembly

REX Regulator (KM47/77)
Disassembly

REX Regulator (KM47/77)
Disassembly
•Remove eac plastic valve cage
wit t e silicone valve still
installed
•Clean and inspect valve
assemblies
•Silicone valves s ould be smoot
and flat, w en lifted away from
seat, it s ould snap firmly into
place
•T e seats s ould be smoot and
straig t

REX Regulator (KM47/77)
Set-up/Adjustment
•Screw t e regulator adjustment knob in clockwise
all t e way, t en rotate it out counter clockwise
t ree turns
•Slowly rotate t e inlet nipple in clockwise until a
slig t movement is noticed at t e roller lever
t en stop
•Lig tly tig ten t e jam nut to prevent movement
of t e nipple tube

REX Regulator (KM47/77)
Set-up/Adjustment
•Install diap ragm, t rust was er, flexible cover
and cover ring to t e regulator assembly using
t e special spanner wrenc

REX Regulator (KM47/77)
Set-up/Adjustment
•Adjustment of t e demand regulator s ould be done
using a supply pressure of between 135-140 p.s.i.g.
•Re-c eck adjustment knob position by completely
turning it in, t en backing it out 3 full turns
•Attac a air source to eit er umbilical adapter at t e
one way valve, or EGS valve
•Slowly pressurize elmet, t en open t e supply fully

REX Regulator (KM47/77)
Set-up/Adjustment
•T e cover s ould travel inward 1/4 - 5/16 of an inc
before gas flow is eard
•Once desired travel is ac ieved, tig ten lock nut against
regulator body using two 13/16” wrenc es
•Make certain bent tube fitting is snug against t e ex
on nipple tube by again using two 13/16” wrenc es
•Re-c eck purge adjustment, re-adjust if needed

REX Regulat r (KM47/77)
Set-up/Adjustment
Low pressure air source must
be adjustable over a range
from 135-140 p.s.i.
With the air supply connected,
turn the adjustment knob all
the way out and back in 3
turns

REX Regulator
•Regulator is adjusted
and ready for use

Summary
•Inspection
•Adjustments
Always refer to Operations & maintenance manual
for adjustment procedures

????
