Kirchner und Tochter RA 65 User manual

VA Flow Meters
RA 65 / FA 65
Installation and Operating Instructions
Variable area flow meter
RA 65 / FA 65
A. Kirchner & Tochter GmbH Dieselstraße 17 · D-47228 Duisburg
Fon: [phone] · Fax: [phone] Internet: www.kt-web.de · e-mail: [email protected]
Version 1.1

VA Flow Meters
RA 65 / FA 65
2
Contents
1. Foreword..................................................................................................................................................................3
2. Safety.........................................................................................................................................................................3
2.1. Symbol and meaning................................................................................................................................3
2.2. General safety directions and exemption from liability............................................................ 3
2.3. Intended use ................................................................................................................................................3
2.4. Special safety instructions concerning glass devices.............................................................. 4
2.5. Operator and operating personnel ...................................................................................................4
2.6. Regulations and guidelines ...................................................................................................................4
2.7. Notice as required by the hazardous materials directive......................................................4
3. Transport and storage......................................................................................................................................4
4. Installation ............................................................................................................................................................... 5
4.1. Installation RA 65...................................................................................................................................... 6
4.2. Installation FA 65 ...................................................................................................................................... 6
5. Start-up..................................................................................................................................................................... 6
6. Readings in operation........................................................................................................................................ 6
7. Limit contacts MSK-1, MSK-12, MSK-W.................................................................................................7
7.1. Connection of limit contacts................................................................................................................. 7
7.2. Setting the limit contacts....................................................................................................................... 7
8. Maintenance and cleaning of the flow meter......................................................................................... 8
8.1. Dismantling and installation .................................................................................................................8
8.2. Replacement of measuring glass...................................................................................................... 8
9. Service ...................................................................................................................................................................... 9
9.1. Disposal.......................................................................................................................................................... 9
10. Technical data...............................................................................................................................................10
10.1. Materials ...............................................................................................................................................10
10.2. Dimensions...........................................................................................................................................11
10.3. Technical data of limit contacts..................................................................................................13
10.3.1. Low-Voltage Directive............................................................................................................13
A. Kirchner & Tochter GmbH Dieselstraße 17 · D-47228 Duisburg
Fon: [phone] · Fax: [phone] Internet: www.kt-web.de · e-mail: [email protected]
Version 1.1

VA Flow Meters
RA 65 / FA 65
3
1. Foreword
These Installation and Operating Instructions are applicable to devices of Series RA 65 and
FA 65. Please follow all instructions and information given for installation, operation,
inspection and maintenance. The Instructions form a component part of the device, and
should be kept in an appropriate place accessible to the personnel in the vicinity of the
location. Where various plant components are operated together, the operating instructions
pertaining to the other devices should also be observed.
2. Safety
2.1. Symbol and meaning
Safety notice
This symbol is placed against all directions/information relating to occupational health and
safety in these Installation and Operating Instructions, and draws attention to danger to life
and limb. Such notices should be strictly observed.
2.2. General safety directions and exemption from liability
This document contains basic instructions for the installation, operation, inspection and
maintenance of the variable-area flow meter. Failure to comply with these instructions can
lead to hazardous situations for Man and Beast and also to damage to property, for which
Kirchner und Tochter disclaims all liability.
The Operator is required to rule out potentially hazardous situations through voltage and
released media energy.
2.3. Intended use
The RA 65/FA 65 Series device is a variable-area flow meter for liquids and gases. It is
designed for installation in vertical pipe runs. Installation in the pipeline should be carried out
solely in accordance with these Instructions. The required version of the variable-area
flowmeter should be selected on the basis of the pipe diameter at the installation location of
the device. The limit values pertaining to the device are specified in Section 10 and must be
complied with. Any modifications or other alterations to the measuring device may be
carried out solely by Kirchner und Tochter. Installation in horizontal pipe runs is possible
using appropriate pipe bends. The direction of flow must always be from bottom to top.
Details of the process product together with the operating conditions are marked on the
measuring glass.
A. Kirchner & Tochter GmbH Dieselstraße 17 · D-47228 Duisburg
Fon: [phone] · Fax: [phone] Internet: www.kt-web.de · e-mail: [email protected]
Version 1.1

VA Flow Meters
RA 65 / FA 65
4
2.4. Special safety instructions concerning glass devices
For safety reasons, we recommend fitting a protective shield in front of the
measuring tube when starting up flow meters fitted with glass measuring tubes.
The devices should not be operated where there is a risk of pressure surges (water
hammer)!
To avoid glass breakage, all fitting work between measuring glass and heads inside the
glass should be carried out by twisting and simultaneously pressing after having wetted the
packing rings/gaskets.
2.5. Operator and operating personnel
Authorized installation, operating, inspection and maintenance personnel should be suitably
qualified for the jobs assigned to them, and should receive appropriate training and
instruction.
2.6. Regulations and guidelines
In addition to the directions given in these Installation and Operating Instructions, observe
t
he regulations, guidelines and standards, such as DIN EN, and, for specific applications,
t
he codes of practice issued by DVGW (gas and water) and VdS (underwriters), or the
equivalent national codes, and applicable national accident prevention regulations.
2.7. Notice as required by the hazardous materials directive
In accordance with the law concerning handling of waste (critical waste) and the hazardous
materials directive (general duty to protect), we would point out that all flow meters
returned to Kirchner und Tochter for repair are required to be free from any and all
hazardous substances (alkaline solutions, acids, solvents, etc.).
Make sure that devices are thoroughly rinsed out to neutralize hazardous
substances.
3. Transport and storage
Alwa
y
s use the ori
g
inal packin
g
for transport, handlin
g
and stora
g
e. Protect the device
against rough handling, impact, jolts, etc.
A. Kirchner & Tochter GmbH Dieselstraße 17 · D-47228 Duisburg
Fon: [phone] · Fax: [phone] Internet: www.kt-web.de · e-mail: [email protected]
Version 1.1

VA Flow Meters
RA 65 / FA 65
5
4. Installation
Variable-area flow meters are suitable only for vertical installation, with the direction of flow
being from bottom to top . For all other installation situations, appropriate pipe bends need
to be fitted in the existing pipeline in order to ensure upward vertical flow through the device.
Before installing, remove all protective caps, transport locks and any foreign bodies found.
Make sure the pipes are correctly spaced and in true alignment at the installation location of
the flow meter. For Type RA 65, additionally fit pipe unions to both open ends of the pipeline
before installing the flow meter.
Straight unimpeded pipe runs upstream and downstream of the meter’s installation location
should each have a length equal to 5 x DN (= meter size). Any control equipment, particularly
in the case of gaseous media, should always be located downstream of the flow meter.
The type FA 65 flow meter is sealed off from the pipeline by gaskets. After it has been
installed, the flow meter should not be turned any more. Avoid drawing the ends of the
pipelines together and do not tighten down the device excessively.
O-ring
Gaske
t
Device head with
external thread
Union nu
t
Insert with internal
thread
Device head with
flanged connection
Gaske
t
O
-
ring
RA 65 FA 65
A. Kirchner & Tochter GmbH Dieselstraße 17 · D-47228 Duisburg
Fon: [phone] · Fax: [phone] Internet: www.kt-web.de · e-mail: [email protected]
Version 1.1

VA Flow Meters
RA 65 / FA 65
6
4.1. Installation RA 65
•Dismantle the inserts and the union nuts from the device.
•Slip the union nuts over the ends of the pipeline at the installation point.
•Screw the inserts on to the pipe ends together with packing material.
•Slide the device with the gaskets (not included with the flow meter) at both ends into
the installation point.
•Screw the union nuts back on to the device heads and tighten them down such that
the device is seated in the pipeline without stresses.
4.2. Installation FA 65
•Slide the device together with the gaskets (not included with flow meter) at both ends
into the installation point.
•Check that the gaskets are in alignment and make sure they do not project into the
pipeline.
•Attach bolts and nuts loosely to the flanged connection.
•Tighten bolts on the flanged connection in diagonally opposed sequence so that the
device is fastened in the pipeline without stresses.
5. Start-up
The flow meter must have been properly installed before it is started up.
•Test all device connections.
•To set the flow: pressurize the pipelines by slowing opening the shut-off valves. On
liquid service: carefully evacuate the pipeline.
•Check that all components are leak-tight and, if necessary, tighten down threaded
joints and screw connections.
6. Readings in operation
The flow value is read off from the scale on the glass cone at the top edge of the float. The
measured-value readings are only correct when the operating condition at the measuring
point (flowing medium, operating pressure and temperature) corresponds to the values
marked on the measuring glass. If operating conditions should differ, the measured value
must be corrected with the aid of the general float equation, which you will find in our
technical documents.
You can also do the recalculation with the help of our conversion program given on our
home page: www.kt-web.de, Section “Physical Basics“.
A. Kirchner & Tochter GmbH Dieselstraße 17 · D-47228 Duisburg
Fon: [phone] · Fax: [phone] Internet: www.kt-web.de · e-mail: [email protected]
Version 1.1

VA Flow Meters
RA 65 / FA 65
7
7. Limit contacts MSK-1, MSK-12, MSK-W
The flow meter can be equipped with limit contacts to provide local indication with
monitoring function:
•MSK-1 normally closed contact
•MSK-12 normally open contact
•MSK-W change over contact
The limit contacts consist of a limit contact (reed switch) that is switched over by the
magnet integrated in the float. The limit contact is guided in a guide slot in the protective
case and can be adjusted over the full measuring range. The reed contacts have a bistable
characteristic.
Uncontrolled current and voltage peaks can occur in the case of inductive or capacitive
loads, e.g. from contactors or solenoid valves. Such peaks will also occur, depending on cable
geometry, where cables exceed a certain length.
We therefore recommend using an MSR contact protection relay, which is additionally
available. This will increase the contact rating and prevent occurrence of inductive and
capacitive peaks, thus ensuring long service life of the contacts.
Electrical data and limit values are specified in Section 10.2.
7.1. Connection of limit contacts
•Electrical connection of the device must be carried out in conformity with the relevant
VDE regulations (or equivalent national standards) and in accordance with the
regulations issued by the local power supply utility.
•Disconnect the plant from supply before connecting the limit contact.
•Provide a protective circuit for the contacts in keeping with their capacity.
•Connect line-side fuse elements matched to consumption.
•Connect the cable using the supplied right-angle plug. Assigned are terminals 1 and
2. Earth and terminal 3 are not assigned. The circuit diagram for limit contacts is
shown in the Technical Data, Section 10.1 on page 12.
7.2. Setting the limit contacts
•Loosen the lock nut M10 on the neck of the contact.
•Slide the contact to the flow value required to be monitored.
•Test the switching characteristic by moving the float over and beyond the switching
position.
•Retighten the lock nut.
A. Kirchner & Tochter GmbH Dieselstraße 17 · D-47228 Duisburg
Fon: [phone] · Fax: [phone] Internet: www.kt-web.de · e-mail: [email protected]
Version 1.1

VA Flow Meters
RA 65 / FA 65
8
8. Maintenance and cleaning of the flow meter
The device is maintenance-free. Should the glass cone become fouled, the device can be
removed from the pipeline as follows.
8.1. Dismantling and installation
Remove the flow meter out of the system by detaching the union nuts or, as the case may
be, the screw connections and/or pipe unions. After dismantling the upper head (detach the
radial retaining screw), remove the measuring glass from the device and clean the individual
parts. Reassemble in reverse order. Pay special attention to correct installation of the
appropriate gaskets and the float stops. Before installing, inspect all gaskets (see Figure on
page 5) for signs of damage, and replace if necessary.
8.2. Replacement of measuring glass
Refer to Figure on page 5.
1. Remove the device from the installation point. Detach the lateral retaining screws
and remove the device heads by simultaneously twisting and pulling them out of the
glass. On devices with a guide rod, leave the rod mounted on the upper head!
2. On devices with non-guided floats, remove the float stops and the float from the old
glass and insert them into the new glass. Carefully screw the float stops (helical
springs made of VA steel) using pliers into the ends of the glass (risk of glass
breakage!).
3. Fit the device heads with new O-rings and gaskets.
4. Wet the O-ring before assembling glass and head.
5. Carefully slide the lower device head into the bottom opening of the measuring glass,
twisting and pushing simultaneously (risk of glass breakage!).
6. Insert the glass with head into the case, making sure not to knock the glass against
the case.
7. Fasten the device head with the retaining screws to the case.
8. Align the glass cone so that the inscriptions can be read through the viewing window
on the case.
9. Slide the second head with wetted O-ring by twisting and pushing it simultaneously
into the upper opening of the measuring glass, or steel case, as the case may be.
Also lock the head in place on the case.
10. On devices with guide rod, check float mobility. If necessary, correct the position by
turning the guide rod (to do this, hold the plain end of the guide rod at the lower head
with a pair of engineer’s pliers, or similar, and slightly loosen the M5 screw at the
opposite end).
11. Reinstall the device in the installation point.
A. Kirchner & Tochter GmbH Dieselstraße 17 · D-47228 Duisburg
Fon: [phone] · Fax: [phone] Internet: www.kt-web.de · e-mail: [email protected]
Version 1.1

VA Flow Meters
RA 65 / FA 65
9
9. Service
All devices with defects or deficiencies should be sent direct to our repair department.
To enable our customer service facility to deal with complaints and repairs as quickly
as possible, you are kindly requested to coordinate the return of devices with our sales
department, Tel. [phone].
9.1. Disposal
Please help to protect our environment, and dispose of workpieces in conformit
y
with
current regulations or use them for some other purpose.
A. Kirchner & Tochter GmbH Dieselstraße 17 · D-47228 Duisburg
Fon: [phone] · Fax: [phone] Internet: www.kt-web.de · e-mail: [email protected]
Version 1.1

VA Flow Meters
RA 65 / FA 65
10
10. Technical data
Nominal pressure rating FA 65: PN 10 at 20 °C
RA 65: PN 10 at 20 °C
Max. operating pressure 10 bar at 20°C for diameter H from 25 up to 60 1)
8 bar at 20°C for diameter H = 70 and 90
Thermal endurance 80°C, optionally: 100°C
Ambient temperature 90°C
Turn-down ratio 1:10
Accuracy class 1.6 to VDI/VDE 3513
Connection RA 65 two-part pipe union: insert with cylindrical internal thread to ISO 7-
Connection FA 65 Flanges PN 10 to DIN 2501, others (ANSI, JIS, ...) on request
1) Diameter H according to Dimension Tables for FA65 and RA65
10.1. Materials
Heads RA 65 Grey cast iron, size 9.5 steel
Threaded joint Malleable cast iron, galvanized
Flanges FA 65 Grey cast iron, size 9.5 steel
Measuring glass Borosilicate glass (Duran)
splinter shield Plexiglas XT
Gaskets Standard: NBR; optionally: Viton, EPDM, silicone
Floats for liquids 1) Standard: 1.4571 (stainless steel); optionally: PVC, PP,
PVDF or PTFE with lead core
Floats for gases 1) Standard: aluminium; optionally: PVC, PP, PTFE, PVDF
or 1.4571 (stainless steel)
Limit contacts 1) 1.4571 (stainless steel) with magnetic core (liquids)
PVC with magnetic core (gases)
1) Floats up to size 19 are nonguided; size 30 and larger: with guided float. Optionally,
A. Kirchner & Tochter GmbH Dieselstraße 17 · D-47228 Duisburg
Fon: [phone] · Fax: [phone] Internet: www.kt-web.de · e-mail: [email protected]
Version 1.1

VA Flow Meters
RA 65 / FA 65
11
10.2. Dimensions
Size Pipe union S L d 1) H
9.5 Rp 1/4 28 308 12 25
Rp 3/8 32 310 16
Rp 1/2 39 312 20
19 Rp 1/2 39 413 20 45
Rp 3/4 48 420 25
Rp 1 55 424 32
30 Rp 1 55 424 32 60
Rp 1 1/4 67 428 40
Rp 1 1/2 74 430 50
36 Rp 1 1/4 67 428 40 70
Rp 1 1/2 74 430 50
Rp 2 90 445 63
43 Rp 1 1/2 74 430 50 90
Rp 2 90 445 63
Rp 2 1/2 111 446 75
Rp 3 131 450 90
RA 65
1) d for bondin
g
and weldin
g
sleeve
A. Kirchner & Tochter GmbH Dieselstraße 17 · D-47228 Duisburg
Fon: [phone] · Fax: [phone] Internet: www.kt-web.de · e-mail: [email protected]
Version 1.1

VA Flow Meters
RA 65 / FA 65
12
DN L H D d4 k
Qt
y
Thread d2
10 260 25 90 40 60 4 M 12 14
15 95 45 65 4 M 12 14
10 360 45 90 40 60 4 M 12 M 12
15 95 45 65 4 M 12 14
20 105 58 75 4 M 12 14
25 115 68 85 4 M 12 14
20 360 60 105 58 75 4 M 12 M 12
25 115 68 85 4 M 12 14
40 150 88 110 4 M 16 18
25 360 70 115 68 85 4 M 12 M 12
40 150 88 110 4 M 16 18
50 165 102 125 4 M 16 18
50 360 90 165 102 125 4 M 16 18
65 185 122 145 4 M 16 18
FA 65
Bolts
A. Kirchner & Tochter GmbH Dieselstraße 17 · D-47228 Duisburg
Fon: [phone] · Fax: [phone] Internet: www.kt-web.de · e-mail: [email protected]
Version 1.1

VA Flow Meters
RA 65 / FA 65
13
10.3. Technical data of limit contacts
Ausführung MSK-1 MSK-12
Voltage switched 50VAC/75VDC 50VAC/75VDC
Current switched 0,5A 0,5A
Contact rating 10W/VA 10W/VA
Dielectric strength 230VAC/400VDC 230VAC/400VDC
Temperature range -20 bis +90°C -20 bis +90°C
Switching function normally closed contact normally open contact
Ausführung MSK-W
Voltage switched 50VAC/75VDC
Current switched 0,5A
Contact rating 5W/VA
Dielectric strength 110VAC/200VDC
Temperature range -20 bis +90°C
Switching function change over contact
1) The deciding factor is the thermal endurance of the flow meter!
Connection via right angle plug (number of contacts 3 +PE) according to
DIN 46350 Form A and cable gland M16 (IP65)
10.3.1. Low-Voltage Directive
Above 50 V AC/75 V DC, contacts are subject to the EU Low
-
Voltage Directive.
The user is required to verify their use accordingly.
A. Kirchner & Tochter GmbH Dieselstraße 17 · D-47228 Duisburg
Fon: [phone] · Fax: [phone] Internet: www.kt-web.de · e-mail: [email protected]
Version 1.1

VA Flow Meters
RA 65 / FA 65
14
The equipment from Kirchner und Tochter
has been tested in compliance with the
applicable CE-regulations of the European
Community. The respective declaration of
conformity is available on request.
The Kirchner und Tochter QM-System will be
certified in accordance with DIN-EN-ISO
9001:2000. The quality is systematically
adapted to the increasing demands.
A. Kirchner & Tochter GmbH Dieselstraße 17 · D-47228 Duisburg
Fon: [phone] · Fax: [phone] Internet: www.kt-web.de · e-mail: [email protected]
Version 1.1
