KIRLOSKAR Non-Clog Submersible Series Programming manual

1
This is a proprietary document of Kirloskar Brothers Limited,
YAMUNA’ Sur ey No. 98/ 3 to 7, Baner, Pune
–
411045, India.
NS IOM MANUAL
1
Sept
2018
Instructions on Installation,
Operation and Maintenance
Manual for Kirloskar Non-Clog
Submersible series (IE2

2
This is a proprietary document of Kirloskar Brothers Limited,
YAMUNA’ Sur ey No. 98/ 3 to 7, Baner, Pune
–
411045, India.
NS IOM MANUAL
1
Sept
2018
WARRANTY
We warrant that the pump supplied by us is free from defective
material and faulty workmanship. This warranty holds good for a
period of 12 months from the date of commissioning the equipment
or 18 months from the date of dispatch from our factory, whichever
is earlier. Our liability in respect of any complaint is limited to
replacing part/parts free of charge ex-works or repairs of the
defective part/parts only to the extent that such replacement/repairs
are attributable to or arise solely from faulty workmanship or
defective material.
This warranty holds good only for the products manufactured by us.
– KIRLOSKAR BROTHERS LIMITED –

3
This is a proprietary document of Kirloskar Brothers Limited,
YAMUNA’ Sur ey No. 98/ 3 to 7, Baner, Pune
–
411045, India.
NS IOM MANUAL
1
Sept
2018
CAUTION
1. DO NOT LOWER OR LIFT THE PUMP WITH THE HELP OF
CABLES.
2. DO NOT FILL ANY LIQUID INSIDE THE MOTOR.
3. DO NOT MEGGER CONTROL PANEL CONTROL CIRCUIT
TERMINALS.
4. DO NOT RUN THE PUMP DRY OR IN REVERSE DIRECTION.
5. DO NOT RUN THE PUMP WITHOUT CONTROL PANEL.
6. DO NOT RUN THE PUMP WITH CONTROL UNIT IN BYPASSED
CONDITION.
7. DO NOT MEGGER CONTROL CABLE OF THE PUMP WITHOUT
DISCONNECTING FROM THE CONTROL PANEL.

4
This is a proprietary document of Kirloskar Brothers Limited,
YAMUNA’ Sur ey No. 98/ 3 to 7, Baner, Pune
–
411045, India.
NS IOM MANUAL
1
Sept
2018
INDEX
SR.
NO. CONTENTS PAGE NO.
1 GENERAL 4
2 SAFETY INSTRUCTIONS 7
3 INSTALLATION 8
4 OPERATION 10
5 MAINTENANCE 11
6 SHUT DOWN / STORAGE / PRESERVATION 13
7 TECHNICAL DATA 14
8 OVERHAULING 18
9 CROSS SECTIONAL DRAWING AND PARTLIST 18
10 OUTLINE DRAWING AND DIMENSIONS SHEET 23
11 GENERAL ARRANGEMENT DRAWING AND DIMENSIONS
SHEET 28
12 ANNEXURE: CONTROL PANEL / PMU SPECIFICATIONS 35
13 SPARE PARTS 36
14 ENVIRONMENTAL ASPECT AND PRODUCT RECYCLE
PROGRAM 36
NOTE:
•Please ensure these instructions are read fully before installation and
operation of the pump.
•Please furnish complete nameplate details, name of parts, part nos. and
material of construction while ordering spare parts for the pump

5
This is a proprietary document of Kirloskar Brothers Limited,
YAMUNA’ Sur ey No. 98/ 3 to 7, Baner, Pune
–
411045, India.
NS IOM MANUAL
1
Sept
2018
1. GENERAL :
1.1 KIRLOSKAR submersible sewage pumps type “NS” is available in the following types.
1. iNS series (1HS Series Code)
Unit kW Ratings in 2Pole kW Ratings in 4Pole kW Ratings in 6Pole
iNS unit - 1 0.75-1.1 0.55-0.75 -
iNS unit - 2 1.5-2.2 1.1-1.5 -
iNS unit - 3 3.7 2.2 -
iNS unit - 4 5.5-7.5 3.7-7.5 2.2-5.5
iNS unit - 5 9.3-18.5 9.3-15 -
iNS unit - 6 22 18.5-22 -
2. NS Series (192 Series Code)
Unit kW Ratings in 4Pole kW Ratings in 6Pole
NS unit - 1 - 7.5 -11
NS unit - 2 - 15
NS unit - 3 30 18.5-22
NS unit - 4 37-45
30
NS unit - 5 55 37
NS unit - 6 75 45
NS unit - 7 90 55
NS unit - 8 110-132
75-110
NS unit - 9 160-200
132-180
NS unit - 10 225
-
The following charts can be referred to know the pumps available in type of impellers ratings.
A. Refer below chart for 2 pole Models: (iNS)
*-design
developed. #-yet to develop.
How to read – NS20/13QT 1.1/2 i (i-stands for iNS)
Sr.
No.
IMPELLER kW RATING IN 2 POLE
PUMP QT 0.75 1.1 1.5 2.2 3.7 5.5 7.5 9.3 11 15 18.5 22
1 20/13
*
*
*
*
*
2 20/16
*
#
*
*
*
3 20/20
*
*
*
*
*
*
*
4 32/13
*
*
*
*
5 32/16
*
*
*
*
6 40/13
*
*
*
*
7 40/16
*
*
*
*
8 40/20
*
*
*
*
9 50/13
*
*
*
*
10 50/16
*
*
*
*
*
*
*
11 50/20
*
*
*
*
*
*
12 65/13
*
*
*
*
*
*
13 65/16
* * * * * *

6
This is a proprietary document of Kirloskar Brothers Limited,
YAMUNA’ Sur ey No. 98/ 3 to 7, Baner, Pune
–
411045, India.
NS IOM MANUAL
1
Sept
2018
B. Refer below chart for 4 pole Models: (iNS)
Sr.
No.
IMPELLER T PE kW Rating in 4 pole
PUMP N QM Q QT NB QMB NM QMM 2.2 3.7 5.5 7.5 9.3 11 15 18.5 22
1 40/20
*
*
*
2 40/32
*
*
*
*
3 50/20
*
*
*
*
4 50/26
*
*
*
*
*
*
*
*
*
*
5 50/32
*
*
*
*
*
*
*
*
*
6 50/36
*
*
*
*
*
7 65/32
*
*
*
*
*
*
*
*
*
*
*
*
8 80/26
*
*
*
*
*
*
*
*
*
*
9 100/26
*
*
*
*
*
*
*
*
*
*
10 100/32
*
*
*
*
*
*
*
*
11 150/26
*
*
*
*
*
*
*
*
*
*
*
*
12 150/32
*
*
*
*
*
*
13 80/40
*
*
*
*
*
*
*
*
C. Refer below chart for 6 pole Models: (iNS)
Sr.
No.
IMPELLER TYPE kW Rating in 6 po e
PUMP N QM Q QT NB QMB NM QMM 2.2 3.7 5.5
1 40/32
* *
2 50/26
* * * * * * * * *
3 50/32
* * * * * *
4 50/36
* * *
5 65/32
* * * * * * * * *
6 80/26
* * * * * *
7 100/26
* * * * * *
8 150/26
* * * * * * * * * *
D. Refer below chart for 4 pole Models: (NS).
Sr.
No.
IMPELLER TYPE kW RATING IN 4 POLE
PUMP N QM Q QT NB QMB NM QMM X 30 37 45 55 75 90 110 132 160 180 200 225
1 150/26
*
*
*
*
*
*
*
*
*
*
2 100/32
*
*
*
*
*
*
*
3 150/32
*
*
*
*
*
*
*
*
4 200/32
*
*
*
*
*
*
*
*
*
5 80/40
*
*
*
*
*
*
*
*
*
*
6 100/40
*
*
*
*
*
*
*
*
*
7 150/40
*
*
*
*
*
*
*
*
*
*
8 200/40
*
*
*
*
*
*
*
*
*
*
9 250/40
*
*
*
*
*
*
*
*
10 150/50
*
*
*
*
*
*
*
*
*
11 250/34
*
*
*
*
*
*
How to read – NS150/26Q 30/4

7
This is a proprietary document of Kirloskar Brothers Limited,
YAMUNA’ Sur ey No. 98/ 3 to 7, Baner, Pune
–
411045, India.
NS IOM MANUAL
1
Sept
2018
E. Refer below chart for 6 pole Models: (NS)
1.2 The pump comprises of three units:
I. Pump unit – It comprises of a delivery casing having wide volute opening and non-clog
type of impeller. The casing is attached with connector unit or stand as per order.
II. Stuffing box unit – It comprises double mechanical seal and mechanical seal housing
filled with oil for lubricating the seals. The seal behind the impeller is having seat ring of
silicon carbide V/s silicon carbide and second seal comprises of carbon ring V/s stainless
steel ring.
III. Electrical motor unit – These pumps are provided with submersible three phase squirrel
cage induction motors in watertight housing. The entire motor unit is air tested to ensure
the leak tightness of the joints. Moisture sensor is provided in the mechanical seal housing
to give the indication to control panel which in turn trips the motor, when the seal near
impeller fails. The pump is provided with high and low liquid level controllers which avoids
dry running of pump .
1.3 The NS pump can be supplied in portable or with fixed arrangement. When the pump is supplied
with portable type, hose, connection should be provided to avoid weight of pipe line on the pump
casing. The casing is provided with stand for support. For stationary application, the pump is
mounted on the support bracket and is connected to the delivery bend through a rubber diaphragm
and connector unit. The pump slides over the guide pipes without disconnecting/disturbing the
delivery pipe line .
1.4 NS pump is supplied with wall mounted control panel. These control panels are supplied either with
DIRECT ON LINE, STAR DELTA, SOFT STARTER or ATS type starters. These panels are
designed for smooth running of pump-set. The pump gets switched off automatically and is
protected against the following.
a. Contamination of oil with pumped liquid.
b. Dry running of pump.
c. Single phasing/reverse phasing.
d. Over load.
e. Overheating of winding [against order].
The coding of leads of the cables is clearly marked on each lead and the connections to the control
panel should be made as per connections diagram of control panel and s per below shown Figure
(1) & (2).
IMPELLER TYPE kW RATING IN 6 POLE
PUMP N QM Q QT NB QMB NM QMM X 7.5 9.3 11 15 18.5 22 30 37 45 55 75 90 110 132 160 180
50/32 * * * *
50/36 * *
65/32 * * * * * * *
80/40 * * * * * * * * * *
100/26 * * * * *
100/32 * * * * * * * * *
100/40 * * * * * * * * *
150/26 * * * * * * * * * *
150/32 * * * * * * * *
150/40 * * * * * * * * * *
150/50 * * * * * * * * *
200/32 * * * * * * * *
200/40 * * * * * * * * * *
250/34 * * * * *
250/40 * * * *
250/50 * * * * * * * *
300/55 * * * * *
350/40 * * * * * *
350/47 * * * * *

8
This is a proprietary document of Kirloskar Brothers Limited,
YAMUNA’ Sur ey No. 98/ 3 to 7, Baner, Pune
–
411045, India.
NS IOM MANUAL
1
Sept
2018
CONTROL CABLE LEADS
M1 & M2 : FOR MOISTURE SENSOR
T1 & T2 : FOR THERMISTER
M1
CABLES FROM PUMP
M2
T1 T2 A1
B1
C1
ELECTRICAL CONNECTION DIAGRAM
( STAR DELTA STARTING )
A2
B2
C2
POWER
CABLE
LEADS
EARTHING
E
CONTROL CABLE LEADS
M1 & M2 : FOR MOISTURE SENSOR
T1 & T2 : FOR THERMISTER
M1
POWER
CABLE
LEADS
CABLE FROM PUMP
M2
T1 T2 A
B
C
ELECTRICAL CONNECTION DIAGRAM
( DOL STARTING )
E
EARTHING
Fig (1) SDS CONNECTION Fig (2) DOL CONNECTION
1.5 As a standard scope of supply, NS pumps are supplied with 5 or 10 m long cable. This cable
consists of power cable having 4 and 3 core for Star Delta starting (for rating from 11kW to 22kW)
and 4 core cables for DOL (for rating upto 9.3kW) starting suitably designed for the voltage and
current. The control cable of 4 cores 1.5 sq.mm is used for thermistor and moisture sensor 2 wires
each.
2. Safety Instructions:
2.1: General Information
Before performing any actions detailed within this instruction, the Site Health and Safety
instructions shall be read and fully understood. The instructions in this document shall also be read
and fully understood.
Whenever the equipment is operated, maintained or used in any way, the procedures detailed
within the Health and Safety Dossier (DHS) and any procedures detailed within these instructions
shall be followed. The pump supplied by Kirloskar Brothers Limited (KBL) has been designed with
safety in mind; where hazards cannot be eliminated, the risk has been minimized using guards and
other design features. Some hazards cannot be guarded against and the instructions below MUST
BE COMPLIED WITH for safe operation. These instructions cannot cover all circumstances. It is
the responsibility of the user of the equipment for maintaining safe working practices always. The
pumps are supplied with stickers for hazard, caution and safety wherever these are applicable.
2.1.1 Within the manual, safety instructions are marked with safety symbols.
Hazard.
a. This symbol refers to general
mechanical aspects of safety.
c. This symbol refers to electrical
safety.
d. b. This symbol is used to
introduce safety instructions
whose non- Observance may
lead to damage to the machine and its functions.
e. This symbol refers to
magnetic field safety.

9
This is a proprietary document of Kirloskar Brothers Limited,
YAMUNA’ Sur ey No. 98/ 3 to 7, Baner, Pune
–
411045, India.
NS IOM MANUAL
1
Sept
2018
f. This symbol refers to restrict person having heart pacemaker to avoid contact
with magnetic components while pump is in running condition or while
carrying out maintenance work of pump.
2.1.2 KBL products are designed for installation in designated areas, which are to be kept clean and free
of obstructions that may restrict safe access to the controls and maintenance access points.
Pump nameplate is fitted to each unit and must not be removed. Loss of this plate
could make identification impossible. This in turn could affect safety and cause
difficulty in obtaining spare parts. Should accidental loss or damage occur, contact
KBL immediately.
2.1.3 Access to the equipment should be restricted to the personnel responsible for installation, operation
and maintenance and they must be trained, adequately qualified and supplied with the appropriate
tools for their respective tasks.
2.1.4 KBL firmly insists that all personnel responsible for installation, operation and maintenance of the
equipment must read the manual before any work is done.
2.1.5 Ear defenders should be worn where the specified equipment noise level exceeds locally defined
safe levels. Safety glasses or goggles should be worn where working with pressurized systems
and hazardous substances. Other personal protection equipment must be worn where local rules
apply.
2.2 DO NOT wear loose or frayed clothing or jewellery, which could catch on the
controls or becomes trapped in the equipment.
2.3 Operation of the equipment for the application other than for which it is supplied can increase the
risk from hazards. Please consult KBL before making such change in the application of the
equipment.
2.4 Improper installation, operation and maintenance of the product supplied by KBL could result in
injury or death.
2.5
2.6 In case of NS pumps which are handling fluid at high temperature, the operator
should avoid touching the pump in running condition. Use safety equipments like hand gloves and
safety shoes while operating NS pumps in such applications.
3. INSTALLATION:
3.1 The NS pumps of stationary arrangement are supplied with pump connector unit and this
connector unit is connected to pump support bracket with guide shoe & rubber diaphragm
to make it leak proof joint.

10
This is a proprietary document of Kirloskar Brothers Limited,
YAMUNA’ Sur ey No. 98/ 3 to 7, Baner, Pune
–
411045, India.
NS IOM MANUAL
1
Sept
2018
CABLE
CABLE PRO T ECTION
TUBE
CABLE G LAND
MOTO R E N D
COVER
HOLDER
GUIDE
PIPE
RUB BER
DIAPHRAG M
GUIDE
SH O E
DUC K F OOT
BEND
GUIDE
PIPE
AD A PTE R
EYE
BOLTS
MOTO R E N D
COVER
CABLE
BR A CKET
STU FF ING
BOX BUSH
CASIN G
STA ND
SUPPORT
BRACKET
ST A TO R
HOUSIN G
Single guide pipe arrangement (iNS) Double guide pipe arrangement
Stationary Installation view.
3.1.1 Installation of support bracket & bend –
Before installing the pump, ensure that sump bottom is flat and leveled. The support bracket &
bend should be attached and fixed to the sump bottom with foundation bolts, so that the guide pipe
shall be exactly vertical.
Ensure that support bracket and bend are located correctly relative to descending pump vertical
guide pipe and discharge pipe.
3.1.2 Lowering the pump - Attach the guide shoe & guide pipe adapter to the pump. The unsupported
length of guide pipe should not exceed 6 m.
3.1.3 Fix the guide pipe in the support bracket and locate the vertical position of guide pipe holder at the
top of the pit. Now grout the guide pipe holder.
3.1.4 Insert the above assembly in the guide pipe by dismantling the guide pipe holder & refit the holder
in the guide pipe.
3.1.5 Check- Lower the pump with the help of chain. While sliding over the guide pipe into the sump,
check that the cable is not slagging and is not under tension.
3.1.6 Ensure that the pump position is exactly vertical on the support bracket. Check by giving a jerk.
3.1.7 Before taking the pumping station into use, check that there are no loose solid pieces or other
material on bottom of sump that would damage the pump.
3.1.8 DO NOT LIFT THE PUMP WITH THE HELP OF CABLES.
3.2 The NS pumps supplied for portable installation requires no foundation. Only ensure that the
delivery pipe line is well supported and its weight is not acting on pump casing directly.
3.3 Use chain with intermediate hooks for holding to lower or lift the pump. This type of chain is specially
designed to avoid the tendency of the operator to lift the pump with the help of cable causing
damage & replacement of the cable unit. While selecting size of the chain, refer weight of the pump
given in 7.6. and chain capacity as per chart in 3.4. We recommend use of non-return valve in
delivery pipe line located before sluice valve.

11
This is a proprietary document of Kirloskar Brothers Limited,
YAMUNA’ Sur ey No. 98/ 3 to 7, Baner, Pune
–
411045, India.
NS IOM MANUAL
1
Sept
2018
3.4 As per IS: 2429 the following sizes of chains can be used upto the weight as mentioned in the
below chart.
4. OPERATION:
4.1 Prior to commissioning of the pump, check the following.
FILL THE OIL INSIDE THE MECHANICAL SEAL HOUSING WITH PROPER GRADE REFER CHART IN
7.5 OF CLEAN OIL FREE FROM MOISTURE. ENSURE THE MECHANICAL SEAL HOUSING OF THE
PUMP IS DULY FILLED AS PER CHART IN 7.6. CHECK THE OIL PLUG OF THE MECHANICAL SEAL
HOUSING IS INTACT.
4.1.1 Check the insulation resistance of winding by using 500 V megger. The insulation resistance of
winding should not be less than 10 mega-ohms for motor rating upto 45kW and 50 mega-ohms
beyond 45kW at phase to phase and phase to Earth. This test should be carried out at free end of
the cable. If the insulation resistance is found less than mentioned above then please consult our
service personnel.
For continuity test, connect the two wires of megger between the two ends of the same phase of
motor. It should show zero resistance. This test should be carried out for the phases.
The resistance across two moisture sensing wires M1 and M2 should be above 5 MΩ. Make sure
to remove control cable connections from terminal board [M1 and M2] before testing this. If the
resistance found less, please consult our service department. The megger test for phase to phase
and phase to Earth should be conducted serially. The megger test should show insulation
resistance above 10 MΩfor motor rating upto 45kW and 50 MΩbeyond 45kW .
4.1.2 The control panel is provided with auto/manual switch. When the switch is on "Manual" position the
pumpset can be started manually by the start push button provided the liquid level is above the low
level electrode. If the switch is on "Auto" position it will start automatically if liquid level in the sump,
is above the high-level electrode. The pump set gets switched off automatically for any position of
Auto Manual switch if liquid level goes down just below the low-level electrode. This is indicated by
glowing of red lamp on control panel.
When the pumped liquid gets mixed up with the oil in the casing cover, it is indicated by glowing of
red lamp under name plate contamination. After rectification of the fault, resetting switch is to be
pressed first and then the pump set will get started by pressing "Starting switch" if it is operated on
"Manual position" or automatically if control panel is operating on "Auto position".
Before change over from star to delta connection, time delay should be sufficient to allow the motor
to attain its normal running speed. The same depends upon the load of the motor and it is generally
around 10 second.
4.1.3 LIQUID LEVEL CONTROLLERS ARE INCORPORATED IN THE PANEL TO PROTECT THE
PUMP FROM DRY RUNNING. THE LOW-LEVEL ELECTRODE SHOULD BE POSITIONED IN
SUCH A MANNER THAT LOWEST END OF ELECTRODE REMAINS ABOVE MOTOR BODY. IF
LOW LEVEL ELECTRODE IS NOT INSTALLED PROPERLY THE MOTOR BODY IS LIKELY TO
BE HEATED UP AS COOLING OF MOTOR IS DONE BY LIQUID IN THE SUMP AROUND THE
STATOR HOUSING. HENCE SUBMERGENCE UPTO FULL CORE LENGTH OF MOTOR IS
REQUIRED.
4.1.4 Before starting the pump, check the direction of rotation is as outlined below.
Nom. Chain Size (mm)
Lifting capacity (Tonnes)
6
0.44
8
0.8
10
1.25
12
1.8
14
2.4
16
3.2

12
This is a proprietary document of Kirloskar Brothers Limited,
YAMUNA’ Sur ey No. 98/ 3 to 7, Baner, Pune
–
411045, India.
NS IOM MANUAL
1
Sept
2018
4.1.5 Hoist up the pump and momentarily switch on the power. If the connections are correctly made the
pump should jerk in anticlockwise direction when viewed from top. If the pump jerks in opposite
direction, change two phases of the incoming leads to the control panel. In no case the direction of
rotation should be changed by changing the leads of motor terminals. Do not run the pump dry.
Just check in which direction the pump jerks.
4.2 While putting the pump in operation, follow the procedure outlined below.
4.2.1 Start the pump. Let the motor pick-up its full speed.
4.2.2 Open the discharge valve slowly.
4.3 Check during running that –
4.3.1 The pump is running smooth.
4.3.2 Power consumption is within limit.
4.3.3 Head and capacity developed by the pump is as specified.
4.3.4 Stop the pump immediately if any defects are detected and must not be started unless they
are rectified. Report immediately to the supplier if it is not possible to rectify the defect.
4.4 STOPPING THE PUMP:
4.4.1 Pump should be switched off only after closing the delivery sluice valve.
5. MAINTENANCE:
Preventive maintenance schedule is the periodical checks and precautions by which possibilities
of failure and break-downs are minimized.
5.1 Daily checks –
5.1.1 An hourly record of the delivery pressure and power input to the pump should be maintained.
5.1.2 Noise and vibrations is the first sign of impending troubles like bearing failure, choking of impeller
or casing and such other operating troubles. The pump performance should be checked for noise
and vibration.
5.2 Periodical checks –
5.2.1 The lubrication of mechanical seals should be checked. The lubricant might get contaminated with
foreign material or get blackened due to overheating. In such cases, oil chamber should be flushed
and filled with fresh oil. Before filling, heat the oil [Servo system 317] to 140°C. This is required to
remove moisture present in the oil.
5.2.2 THE ELECTRODES/FLOAT SWITCHES SHOULD BE CLEANED WHENEVER POSSIBLE BUT
NOT LATER THAN 15 DAYS FOR SMOOTH WORKING OF PUMP.
5.2.3 Clean the sump if there are chances of deposition of the contents of liquid handled.
5.2.4 Replace the Oil from pump periodically after 2000 hrs.
5.3 Annual checks [after one year minimum] –
5.3.1 The pump portion of the motor pump set should be overhauled completely to check the clearance
and to replace the worn-out parts. Clearance between impeller and casing ring and casing cover
are very important.
5.3.2 The effect of liquid handled on pump components should be checked. If abnormal corrosion,
erosion is observed then the components should be replaced with that of suitable material.

13
This is a proprietary document of Kirloskar Brothers Limited,
YAMUNA’ Sur ey No. 98/ 3 to 7, Baner, Pune
–
411045, India.
NS IOM MANUAL
1
Sept
2018
6 SHUT DOWN / STORAGE / PRESERVATION
If operation is not required for some time after delivery, we recommend the following steps for storage
of the pump:
6.1 Storage of new pumps up to 3 months (Short storage)
i) Spray oil inside the pump housing, paying special attention to the area around the impeller
wear ring. Spray oil through inlet and outlet flanges of pump. It is then recommended to cover
the flanges with plastic caps or similar.
ii) Store the pump in an upright position in a dry place. Support all electrical cables at cable entry
points to avoid permanent distortion.
iii) Electric connecting cables are capped securely for protection purposes prior to delivery. This
protection must not be removed.
iv) Use weather-proof coverings such as flame-resistant sheeting or tarpaulins.
v) Tie coverings down to protect the pump from wind damage.
vi) Place the unit on skids, pallets or shoring higher than 5 inches from the ground for good air
circulation.
vii) Maintain an even temperature of 15 degree Celsius or higher above the dew point.
6.2 Pump long term storage requirements (Above 3 months)
Submersible units require proper preparation for storage and regular maintenance during storage.
The unit is considered in storage when it has been delivered to the job site and is awaiting
installation.
6.2.1 Storage preparation
i) Although this is a submersible pump, storage in a clean, dry area will help preserve the paint
and prevent corrosion. Hand rotation of the shaft every fifteen days is recommended to keep
the seals free and the bearings lubricated.
ii) Spray oil inside the pump housing, paying special attention to the area around the impeller
wear ring. Spray oil through inlet and outlet flanges of pump. It is then recommended to cover
the flanges with plastic caps or similar.
iii) Take care of all indoor storage requirements.
iv) Use weather-proof coverings such as flame-resistant sheeting or tarpaulins.
v) Tie coverings down to protect the pump from wind damage.
vi) Place the unit on skids, pallets or shoring higher than 5 inches from the ground for good air
circulation.
vii) Maintain an even temperature of 15 degree Celsius or higher above the dew point.
6.3 Site condition before installation of pump:
Pit in which pump is to be installed should be clean, free from hard particles such as nails, cement/
sand particles etc. Submersible pumps are designed only to handle the soft particles such as
clothes, plastic bags, etc.
6.4 Measures for prolonged shut down periods
i) The pump remains installed ready for operation when required.
ii) To maintain pump availability, the pump should be started for 10 second, once in every week.
iii) Always keep cable ends out of the sump to avoid leakage through cable ends to pump.
6.5 The pump is dismantled and stored
i) Prior to storage the pump should be checked and maintained in accordance operator must
ensure that all maintenance, inspection and repair work is carried out by qualified, authorized
staff who are familiar with the equipment and who have read the operating instructions.
ii) O-ring need to change after dismantling the pump. Do not use old O-rings for reassembly of
the pumps.
6.6 Rubber components storage ideal conditions
If the pumps are stored in below conditions, rubber components shelf life should be of 5 years
otherwise all rubber components need to be replaced after 1 year.
Condition:
a. store in cool, dry place with temperature below 15 degree Celsius.

14
This is a proprietary document of Kirloskar Brothers Limited,
YAMUNA’ Sur ey No. 98/ 3 to 7, Baner, Pune
–
411045, India.
NS IOM MANUAL
1
Sept
2018
b. keep away from direct heat or open flame.
c. store without stretch or tension including hanging.
d. keep product wrapped or sealed to minimize the absorption of moisture.
e. store in relaxed condition free from tension, compression or other deformation.
6. TECHNICAL DATA
7.1 Non-Clog Submersible pumps are supplied at maximum speed 1450 rpm having 4 pole motors.
However, the same pump can be offered at 980 rpm having 6 pole motor if fits in duty points. The
direction of rotation is clockwise when viewed from the motor top. We have newly introduced pump
series in iNS at 2950rpm having 2Pole.
7.2 SPECIFICATIONS OF BEARINGS:
The shaft is supplied with antifriction ball bearings at both ends. The bearing specifications are
given below. The designations of bearings are as per SKF catalogue. However, equivalent bearing
in type, capacity and dimensions are also can be used.
LUBRICATION:
Bearings of NS pumps are grease sealed for life. Re-lubrication of these bearings is not required.
Sr. No. Motor rating in kW Lower bearing Qty. Upper bearing Qty.
1
i-NS unit - 1 6305-2RS1 1 6303 2RSH 1
2
i-NS unit - 2 6305-2RS1 1 6303 2RSH 1
3
i-NS unit - 3 6307 2RS1 1 6305 2RS1 1
4
i-NS unit - 4 6307 2RS1 1 6305 2RS1 1
5
i-NS unit - 5 6307 2RS1 1 6306 2RS1 1
6
i-NS unit - 6 6307-2RS1 1 6306 2RS1 1
7
NS unit - 1 6309-2RS1 1 6306-2RS1 1
8
NS unit - 2 6309-2RS1 1 6306-2RS1 1
9
NS unit - 3 7312 BG Back to Back 2 6309-2RS1 1
10
NS unit - 4 7312 BG Back to Back 2 6309-2RS1 1
11
NS unit - 5 7315 BG Back to Back 2 6311-2RS1 1
12
NS unit - 6 7318 BG Back to Back 2 6313-2RS1 1
13
NS unit - 7 7318 BG Back to Back 2 6313-2RS1 1
14
15
NS unit - 8 7318 BG Back to Back 2 6313-2RS1 1
15
``
NS unit - 9 7320 BG Back to Back 2 6318-2RS1 1
7.3 EBXL CABLE CURRENT CARRYING CAPACITY
Cable size (sq.mm) Approx. Current carrying
capacity (amp) Cable size (sq.mm) Approx. Current carrying capacity (amp)
8C X 1.5 20 4C X 4 + 4C X 1.5 53/22
8C X 2.5 39 4C X 10 + 4C X 1.5 96/22
4C X 25 174 4C X 16 + 4C X 1.5 133/22
4C X 35 191 4C X 25 + 4C X 1.5 174/22
4C X 50 239 4C X 35 + 4C X 1.5 191/22
3C X 4 53 4C X 50 + 4C X 1.5 239/22
3C X 10 96 4C X 70 + 4C X 1.5 295/22
3C X 16 133 4C X 120 + 4C X 1.5 414/22
3C X 25 174 4C X 95 + 4C X 1.5 355/22
3C X 35 191
3C X 50 239
3C X 70 295/22
3C X 95 355/22
3C X 120 414/22

15
This is a proprietary document of Kirloskar Brothers Limited,
YAMUNA’ Sur ey No. 98/ 3 to 7, Baner, Pune
–
411045, India.
NS IOM MANUAL
1
Sept
2018
Note: These values are for reference only.
Consider factor of safety as 0.87 if ambient temperature is 45 degree Celcius.
7.4 MECHANICAL SEALS :
Sr.
No.
Motor ratings in kW Seal size in
mm
Mechanical seal type
Inboard
Outboard
1
iNS all 2 Pole ratings 22
SiC Vs SiC Carbon Vs St. Steel
2
iNS 4 Pole ratings upto 7.5kW 22
3
iNS 4 Pole ratings above 7.5kW 40 SiC Vs SiC Carbon Vs Ceramic
4
UNIT-I & II 40
SiC Vs SiC Carbon Vs St. Steel
5
UNIT-III 55
6
UNIT – IV 65
7
UNIT – V & VI 80
8
UNIT – VII, VIII & IX 90
7.5 LUBRICATION FOR MECHANICAL SEALS:
The upper mechanical seal faces are lubricated by oil provided in casing cover. The lubricating oil
should conform to the following grades of oil available in the market.
Note: The oil used should be highly refined straight mineral product of high demulsibility free from running and acid forming
tendencies. Detergent Oil may cause foaming and should not be used.
NAME OIL SPECIFICATION NAME OIL SPECIFICATION
ELF
ACANTIS HM 68 VEEDOL ATLINE 68
IOC
SERVOSYSTEM 57/68/317 PENNZOIL PENNZBELL AW 68
HPCL
ENKLO 57 BPCL HYDRO 68
CASTROL
HYSPIN EP 68 ESSO AW68
GULF
HARMONY 68 MOBIL AW68
SHELL
TELLUS 68
7.6 WEIGHTS OF PUMPS AND OIL QUANTITY:
Model
kW
Pole
Oil Qty
(approx)
Pump & onne tor
Wt. (kg) (approx)
Model
kW
Pole
Oil Qty
(approx)
Pump & onne tor
Wt (kg) (approx)
NS100/26N
7.5
4
3 Litre
240
120
NS150/26NM
15
4
3 Litre
340
155
NS100/26N
9.3
4
3 Litre
265
120
NS150/26NM
18.5
4
3 Litre
345
155
NS100/26N
11
4
3 Litre
268
120
NS150/26NM
22
4
3 Litre
355
155
NS100/26N
15
4
3 Litre
315
120
NS150/26Q
11
4
3 Litre
335
155
NS100/26N
18.5
4
3 Litre
320
120
NS150/26Q
15
4
3 Litre
340
155
NS100/
26N
22
4
3 Litre
330
120
NS150/26Q
18.5
4
3 Litre
345
155
NS100/26Q
7.5
4
3 Litre
240
120
NS150/26Q
22
4
3 Litre
355
155
NS100/26Q
9.3
4
3 Litre
307
120
NS150/26QMB
11
4
3 Litre
335
155
NS100/26Q
11
4
3 Litre
310
120
NS150/26QMB
15
4
3 Litre
340
155
NS100/26Q
15
4
3 Litre
315
120
NS150/26QMB
18.5
4
3 Litre
345
155
NS100/26Q
18.5
4
3 Litre
320
120
NS150/26QMB
22
4
3 Litre
355
155
NS100/26Q
22
4
3 Litre
330
120
NS150/26QM
11
4
3 Litre
335
155
NS100/26QM
7.5
4
3 Litre
240
120
NS150/26QM
15
4
3 L
itre
340
155
NS100/26QM
9.3
4
3 Litre
265
120
NS150/26QM
18.5
4
3 Litre
345
155
NS100/26QM
11
4
3 Litre
268
120
NS150/26QM
22
4
3 Litre
355
155
NS100/26QM
15
4
3 Litre
315
120
NS150/26QNM
11
4
3 Litre
335
155
NS100/26QM
18.5
4
3 Litre
320
120
NS150
/26QNM
15
4
3 Litre
340
155
NS100/26QM
22
4
3 Litre
330
120
NS150/26QNM
18.5
4
3 Litre
345
155
NS100/26QT
7.5
4
3 Litre
240
120
NS150/26QNM
22
4
3 Litre
355
155
NS100/26QT
9.3
4
3 Litre
307
120
NS150/26QT
11
4
3 Litre
335
155
NS100/26QT
11
4
3 Litre
310
120
NS150/26QT
15
4
3 Litre
340
155
NS100/26QT
15
4
3 Litre
315
120
NS150/26QT
18.5
4
3 Litre
345
155
NS100/26QT
18.5
4
3 Litre
320
120
NS150/26QT
22
4
3 Litre
355
155
NS100/26QT
22
4
3 Litre
330
120
NS150/32N
18.5
4
4 Litre
350
155

16
This is a proprietary document of Kirloskar Brothers Limited,
YAMUNA’ Sur ey No. 98/ 3 to 7, Baner, Pune
–
411045, India.
NS IOM MANUAL
1
Sept
2018
Model
kW
P
ole
Oil Qty
(approx)
Pump & onne tor
Wt. (kg) (approx)
Model
kW
Pole
Oil Qty
(approx)
Pump & onne tor
Wt (kg) (approx)
NS100/32N
11
4
4 Litre
330
120
NS150/32N
22
4
4 Litre
360
155
NS100/32N
15
4
4 Litre
335
120
NS150/32Q
18.5
4
4 Litre
350
155
NS1
00/32N
18.5
4
4 Litre
340
120
NS150/32Q
22
4
4 Litre
360
155
NS100/32N
22
4
4 Litre
350
120
NS150/32QM
18.5
4
4 Litre
350
155
NS100/32Q
11
4
4 Litre
330
120
NS150/32QM
22
4
4 Litre
360
155
NS100/32Q
15
4
4 Litre
335
120
NS150/32QT
18.5
4
4 Litre
350
155
NS100/32Q
18.5
4
4 Litre
340
120
NS150/32QT
22
4
4 Litre
360
155
NS100/32Q
22
4
4 Litre
350
120
NS40/20QT
2.2
4
1.7 Litre
145
55
NS100/32QM
11
4
4 Litre
330
120
NS40/20QT
3.7
4
1.7 Litre
155
55
NS100/32QM
15
4
4 Litre
335
120
NS40/20QT
1.5
4
1
.7 Litre
143
55
NS100/32QM
18.5
4
4 Litre
340
120
NS40/32QT
2.2
4
4 Litre
147
55
NS100/32QM
22
4
4 Litre
350
120
NS40/32QT
3.7
4
4 Litre
150
55
NS100/32QT
11
4
4 Litre
330
120
NS40/32QT
5.5
4
4 Litre
165
55
NS100/32QT
15
4
4 Litre
335
120
NS40/32QT
7.5
4
4 Litre
165
55
NS100/32QT
18.5
4
4 Litre
340
120
NS50/20QT
2.2
4
1.7 Litre
150
65
NS100/32QT
22
4
4 Litre
350
120
NS50/20QT
3.7
4
1.7 Litre
170
65
NS150/26NB
11
4
3 Litre
335
155
NS50/20QT
5.5
4
1.7 Litre
165
65
NS150/26NB
15
4
3 Litre
340
15
5
NS50/26NB
9.3
4
3 Litre
225
65
NS150/26NB
18.5
4
3 Litre
345
155
NS50/26NB
3.7
4
3 Litre
185
65
NS150/26NB
22
4
3 Litre
355
155
NS50/26NB
5.5
4
3 Litre
180
65
NS150/26N
11
4
3 Litre
335
120
NS50/26NB
7.5
4
3 Litre
180
65
NS150/26N
15
4
3 Litre
34
0
155
NS50/26N
9.3
4
3 Litre
225
65
NS150/26N
18.5
4
3 Litre
345
155
NS50/26N
3.7
4
3 Litre
180
65
NS150/26N
22
4
3 Litre
355
155
NS50/26N
5.5
4
3 Litre
180
65
NS150/26NM
11
4
3 Litre
335
155
NS50/26N
7.5
4
3 Litre
180
65
NS50/26Q
9.3
4
3 Litre
225
65
NS65/32Q
11
4
4 Litre
280
75
NS50/26Q
3.7
4
3 Litre
185
65
NS65/32Q
15
4
4 Litre
285
75
NS50/26Q
5.5
4
3 Litre
180
65
NS65/32Q
18.5
4
4 Litre
290
75
NS50/26Q
7.5
4
3 Litre
180
65
NS65/32Q
22
4
4 Litre
300
75
NS50/26QMB
9.3
4
3 Litre
225
65
NS6
5/32Q
7.5
4
4 Litre
230
75
NS50/26QMB
3.7
4
3 Litre
175
65
NS65/32QMB
9.3
4
4 Litre
275
75
NS50/26QMB
5.5
4
3 Litre
180
65
NS65/32QMB
11
4
4 Litre
280
75
NS50/26QMB
7.5
4
3 Litre
180
65
NS65/32QMB
15
4
4 Litre
285
75
NS50/26QM
9.3
4
3 Litre
225
65
NS65/32QMB
18.5
4
4 Litre
290
75
NS50/26QM
3.7
4
3 Litre
185
65
NS65/32QMB
22
4
4 Litre
300
75
NS50/26QM
5.5
4
3 Litre
180
65
NS65/32QMB
7.5
4
4 Litre
230
75
NS50/26QM
7.5
4
3 Litre
180
65
NS65/32QM
9.3
4
4 Litre
275
75
NS50/26QT
9.3
4
3 Litre
225
6
5
NS65/32QM
11
4
4 Litre
280
75
NS50/26QT
3.7
4
3 Litre
185
65
NS65/32QM
15
4
4 Litre
285
75
NS50/26QT
5.5
4
3 Litre
180
65
NS65/32QM
18.5
4
4 Litre
290
75
NS50/26QT
7.5
4
3 Litre
180
65
NS65/32QM
22
4
4 Litre
300
75
NS50/32N
9.3
4
4 Litre
275
65
NS65/32QM
7.5
4
4 Litre
230
75
NS50/32N
11
4
4 Litre
280
65
NS65/32QT
9.3
4
4 Litre
275
75
NS50/32N
15
4
4 Litre
285
65
NS65/32QT
11
4
4 Litre
280
75
NS50/32N
18.5
4
4 Litre
290
65
NS65/32QT
15
4
4 Litre
285
75
NS50/32N
22
4
4 Litre
300
65
NS65/32Q
T
18.5
4
4 Litre
290
75
NS50/32N
7.5
4
4 Litre
220
65
NS65/32QT
22
4
4 Litre
300
75
NS50/32QM
9.3
4
4 Litre
275
65
NS65/32QT
7.5
4
4 Litre
230
75
NS50/32QM
11
4
4 Litre
280
65
NS80/26N
9.3
4
3 Litre
250
85
NS50/32QM
15
4
4 Litre
285
65
NS80/26N
11
4
3 Litre
253
85
NS50/32QM
18.5
4
4 Litre
290
65
NS80/26N
15
4
3 Litre
290
85
NS50/32QM
22
4
4 Litre
300
65
NS80/26N
18.5
4
3 Litre
295
85
NS50/32QM
7.5
4
4 Litre
220
65
NS80/26N
22
4
3 Litre
305
85
NS50/32QT
9.3
4
4 Litre
275
65
NS80/26N
7.5
4
3 L
itre
220
85
NS50/32QT
11
4
4 Litre
280
65
NS80/26N
5.5
4
3 Litre
220
85
NS50/32QT
15
4
4 Litre
285
65
NS80/26Q
9.3
4
3 Litre
250
85
NS50/32QT
18.5
4
4 Litre
290
65
NS80/26Q
11
4
3 Litre
253
85
NS50/32QT
22
4
4 Litre
300
65
NS80/26Q
15
4
3 Litre
290
85
NS50/32QT
7.5
4
4 Litre
220
65
NS80/26Q
18.5
4
3 Litre
295
85
NS50/36QM
11
4
4 Litre
270
65
NS80/26Q
22
4
3 Litre
305
85
NS50/36QM
15
4
4 Litre
275
65
NS80/26Q
7.5
4
3 Litre
220
85
NS50/36QM
18.5
4
4 Litre
280
65
NS80/26Q
5.5
4
3 Litre
220
85
NS50/36QM
22
4
4 Litre
290
65
NS80/26QM
9.3
4
3 Litre
250
85
NS65/32NB
9.3
4
4 Litre
275
75
NS80/26QM
11
4
3 Litre
253
85

17
This is a proprietary document of Kirloskar Brothers Limited,
YAMUNA’ Sur ey No. 98/ 3 to 7, Baner, Pune
–
411045, India.
NS IOM MANUAL
1
Sept
2018
Model
kW
Pole
Oil Qty
(approx)
Pump & onne tor
Wt. (kg) (approx)
Model
kW
Pole
Oil Qty
(approx)
Pump & onne tor
Wt (kg) (approx)
NS65/32NB
11
4
4 Litre
280
75
NS80/26QM
15
4
3 Litre
290
85
NS65/32NB
15
4
4 Litre
285
75
NS80/26QM
18.5
4
3 Litre
295
85
NS65/32NB
18.5
4
4 Litre
290
75
NS80/26QM
22
4
3 Litre
305
85
NS65/32NB
22
4
4 Litre
300
75
NS80/26QM
7.5
4
3
Litre
220
85
NS65/32NB
7.5
4
4 Litre
230
75
NS80/26QM
5.5
4
3 Litre
220
85
NS65/32N
9.3
4
4 Litre
275
75
NS80/26QT
9.3
4
3 Litre
250
85
NS65/32N
11
4
4 Litre
280
75
NS80/26QT
11
4
3 Litre
253
85
NS65/32N
15
4
4 Litre
285
75
NS80/26QT
15
4
3 Litre
2
90
85
NS65/32N
18.5
4
4 Litre
290
75
NS80/26QT
18.5
4
3 Litre
295
85
NS65/32N
22
4
4 Litre
300
75
NS80/26QT
22
4
3 Litre
305
85
NS65/32N
7.5
4
4 Litre
230
75
NS80/26QT
7.5
4
3 Litre
220
85
NS65/32Q
9.3
4
4 Litre
275
75
NS80/40NM
18.5
4
8 Litre
287
85
NS50/26QM
3.7
6
3 Litre
180
65
NS80/40NM
22
4
8 Litre
297
85
NS50/26QM
5.5
6
3 Litre
180
65
NS80/40Q
22
4
8 Litre
287
85
NS50/26QM
2.2
6
3 Litre
185
65
NS80/40Q
18.5
4
8 Litre
297
85
NS50/26QT
2.2
6
3 Litre
185
65
NS80/40QM
18.5
4
8 Litre
287
85
NS50/26QT
3.7
6
3 Litre
180
65
NS80/40QM
22
4
8 Litre
297
85
NS50/26QT
5.5
6
3 Litre
180
65
NS80/40QNM
18.5
4
8 Litre
287
85
NS50/32N
2.2
6
4 Litre
225
65
NS80/40QNM
22
4
8 Litre
297
85
NS50/32N
3.7
6
4 Litre
220
65
NS80/40QT
18.5
4
8 Litre
287
85
NS50/32N
5.5
6
4 Litre
220
65
NS80/40QT
22
4
8 Litre
297
85
NS50/32QM
2.2
6
4 Litre
225
65
NS100/26N
3.7
6
3 Litre
240
120
NS50/32QM
3.7
6
4 Litre
220
65
NS100/26N
5.5
6
3 Litre
240
120
NS50/32QM
5.5
6
4 Litre
220
65
NS100/26Q
3.7
6
3 Litre
240
12
0
NS50/32QT
2.2
6
4 Litre
225
65
NS100/26Q
5.5
6
3 Litre
240
120
NS50/32QT
3.7
6
4 Litre
220
65
NS100/26QM
3.7
6
3 Litre
240
120
NS50/32QT
5.5
6
4 Litre
220
65
NS100/26QM
5.5
6
3 Litre
240
120
NS50/36QM
3.7
6
4 Litre
220
65
NS100/26QT
3.7
6
3 Litre
240
120
NS50/36QM
5.5
6
4 Litre
220
65
NS100/26QT
5.5
6
3 Litre
240
120
NS65/32NB
2.2
6
4 Litre
235
75
NS150/26NB
3.7
6
3 Litre
310
155
NS65/32NB
3.7
6
4 Litre
230
75
NS150/26NB
5.5
6
3 Litre
310
155
NS65/32NB
5.5
6
4 Litre
230
75
NS150/26N
3.7
6
3 Litre
310
155
NS65/32N
2.2
6
4 Litre
235
75
NS150/26N
5.5
6
3 Litre
310
155
NS65/32N
3.7
6
4 Litre
230
75
NS150/26NM
3.7
6
3 Litre
310
155
NS65/32N
5.5
6
4 Litre
230
75
NS150/26NM
5.5
6
3 Litre
310
155
NS65/32Q
2.2
6
4 Litre
235
75
NS150/26Q
3.7
6
3 Litre
310
155
NS65/32Q
3.7
6
4 Litre
230
75
NS150/26Q
5.5
6
3 Litre
310
155
NS65/32Q
5.5
6
4 Litre
230
75
NS150/26QMB
3.7
6
3 Litre
310
155
NS65/32QMB
2.2
6
4 Litre
235
75
NS150/26QMB
5.5
6
3 Litre
310
155
NS65/32QMB
3.7
6
4 Litre
230
75
NS150/
26QM
3.7
6
3 Litre
310
155
NS65/32QMB
5.5
6
4 Litre
230
75
NS150/26QM
5.5
6
3 Litre
310
155
NS65/32QM
2.2
6
4 Litre
235
75
NS150/26QNB
3.7
6
3 Litre
310
155
NS65/32QM
3.7
6
4 Litre
230
75
NS150/26QNM
5.5
6
3 Litre
310
155
NS65/32QM
5.5
6
4 Litre
230
75
NS150/26QT
3.7
6
3 Litre
310
155
NS65/32QT
2.2
6
4 Litre
235
75
NS150/26QT
5.5
6
3 Litre
310
155
NS65/32QT
3.7
6
4 Litre
230
75
NS40/32QT
2.2
6
4 Litre
170
55
NS65/32QT
5.5
6
4 Litre
230
75
NS50/26NB
3.7
6
3 Litre
180
65
NS80/26N
3.7
6
3 Litre
220
85
NS50/26NB
5.5
6
3 Litre
180
65
NS80/26N
5.5
6
3 Litre
220
85
NS50/26NB
2.2
6
3 Litre
180
65
NS80/26Q
3.7
6
3 Litre
220
85
NS50/26N
3.7
6
3 Litre
180
65
NS80/26Q
5.5
6
3 Litre
220
85
NS50/26N
5.5
6
3 Litre
180
65
NS80/26QM
3.7
6
3 Litre
220
8
5
NS50/26N
2.2
6
3 Litre
180
65
NS80/26QM
5.5
6
3 Litre
220
85
NS50/26Q
3.7
6
3 Litre
180
65
NS80/26QT
3.7
6
3 Litre
220
85
NS50/26Q
5.5
6
3 Litre
180
65
NS80/26QT
5.5
6
3 Litre
220
85
NS50/26Q
2.2
6
3 Litre
185
65
NS80/26QT
5.5
6
3 Litre
220
85
N
S50/26QMB
3.7
6
3 Litre
180
65
NS80/40N
18.5
4
8 Litre
287
85
NS50/26QMB
5.5
6
3 Litre
180
65
NS80/40N
22
4
8 Litre
297
85
NS50/26QMB
2.2
6
3 Litre
185
65
NOTE: change oil after every 5000 hrs of pump operation.

18
This is a proprietary document of Kirloskar Brothers Limited,
YAMUNA’ Sur ey No. 98/ 3 to 7, Baner, Pune
–
411045, India.
NS IOM MANUAL
1
Sept
2018
8 OVERHAULING:
Overhauling of the pump or any part of it, at site, is not permitted. In case of doubt, please consult
our service division.
Do not handle the pump with the use of cable.
9 CROSS SECTIONAL DRAWING
9.1 (UNIT 1,2,3,4,5,6- iNS Connector Unit)
New modified Duck Foot Bend integrated with
Support Bracket is supplied for stationary
Arrangement.
9.2 (UNIT 1- iNS with QT Type Impeller and DOL type of starting)
18900
91100
16401
26002
51100
52305
93200
27100
23200
35000
15300
10700
46500
34100
38300
13001
91401
22501
97802
91301
91500
84504
84501
25700
91200
90902
52306
26001
OIL
52301
52304
33000
23000
44400
50900
62100
48600
32000
52302
52302
SUC.
28300
91800
94100
91900
P U M P CO N N EC T O R U NIT
92800

19
This is a proprietary document of Kirloskar Brothers Limited,
YAMUNA’ Sur ey No. 98/ 3 to 7, Baner, Pune
–
411045, India.
NS IOM MANUAL
1
Sept
2018
9.3(UNIT 2,3,4,5,6- iNS with QT Type Impeller and DOL type of starting)
9.4(UNIT 2,3,4,5,6- iNS with Q Type Impeller and SDS type of starting)
18900 91100 16400
26002 51100
91302
52305
97803
91402
84505 84502
93200 27100
23200
35000
15300
10700
13001
91401 22501 97802 91301 91500 84504 84501
25700
91200
90902 52302
26001
OIL
52302
52301 52304 66900 23000 44400 50900
22502 48600
32000 46000
UNIT 2,3,4,5,6- iNS with Q Type Impeller and SDS type of starting
18900 91100 16401
26002
51100
52305
93200 27100
23200
35000
15300
10700
46500 34100 38300
13001
91401 22501 97802 91301 91500 84504 84501
25700
91200
90902 52302
26001
52302
52301 52304 33000 23000 44400 50900
62100
48600
32000
OIL
UNIT 2,3,4,5,6- iNS with QT Type Impeller and DOL type of starting

20
This is a proprietary document of Kirloskar Brothers Limited,
YAMUNA’ Sur ey No. 98/ 3 to 7, Baner, Pune
–
411045, India.
NS IOM MANUAL
1
Sept
2018
9.5 (UNIT 2,3,4,5,6- iNS with N Type Impeller and SDS type of starting)
9.5 CROSS SECTIONAL VIEW OF NS PUMP
CROSS SECTIONAL VIEW OF NS PUMP QT TYPE IMPELLER UNIT I (DOL)
26002 51100
91302
52305
97803
91402
84505 84502
93200 27100
23200
35000
15100
10700
13001
91401 22501 97802 91301 91500 84504 84501
25700
91200
90902 52302
26001
OIL
52302
52301
66900
23000 44400
50900
22502 48600
32000 19000
18900
6.5 (UNIT 2,3,4,5,6- iNS with N Type Impeller and SDS type of starting)
91100 16400
