KiSS MC-670 User manual

1
PROFESSIONAL
CLIPPER
To ensure you achieve the best possible use of your clipper please read
the following instructions.
Ceramic blade
with acute angle
Cleaning brush Lubricating OilComb attachment
ON/OFF Switch
Working indicator
MC-670
Pet Clipper
Component Name
Accessories
Owner’s Guide
3mm 6mm 9mm 12mm

2 3
SPECIFICATIONS
SAFETY CAUTION
OPERATING INSTRUCTIONS
MAINTENANCE
Blade
Install the Blade
Removing and Cleaning the Blade
Comb Attachments
Operation
A
B
1. The cutting length is marked on the comb
attachments.
2. Select a suitable size and slide the blade into the
comb attachment. Hold both sides of the comb and
push until the comb is in position.
(Notes: The comb should not be loose or easy to fall
off after installation.)
1. Align the blade (B) with the hair
clipper’s slot (A).
2. Push the blade into the slot
until it snaps in position.
1. Remove the blade set from the blade housing by pressing the top cutting head
with your thumb.
Hair Clipper
Motor
Blade
Voltage
Cord Length
Operating voltage: 12V
Ceramic
Input: AC 100V – 240V 50/60Hz
2.8m
Keep the clipper away from moisture; do not submerge in water or liquid.
1. Use this appliance for its intended purpose. Use only on clean, dry hair.
2. Close supervision is necessary when this appliance is by or near children.
3. Use only with accessories included in the package, or those recommended by
the manufacturer.
4. Avoid contact with the eye area. Avoid use near or on open wounds, damaged or
sensitive skin.
5. Always unplug from the electrical socket after use.
6. Keep away from water and all liquids and any detergent agents.
7. Do not pull, twist or wrap the cord tightly. Pull on the plug (not the cord) to
remove from power receptacle.
8. Operation should be done in a safe environment (between 0 and 4℃); indoors in
a dry place.
9. Do not disassemble the product.
10. The product can only be cleaned by cloth with little water or mild soap solution.
11. It’s normal for the product to produce little heat during using.
12. Use or store the trimmer only at room temperature(between 0 and 40℃). Avoid
direct sunlight, moisture or heated surfaces and environments.
Should the following situations occur, unplug and switch off immediately, and send
for examination or repair.
1. The blade, main unit, power cord or attachment comb is damaged.
2. The clipper or the adapter is dropped into water.
3. The clipper is switched off, but the charging indicator does not light up when
plugged into the power source.
The clipper and accessories must be checked regularly to prevent damage and
ensure good performance.
If damage is detected, do not put the device into operation.
1. The blade must be lubricated before and after each use. This will maintain good
condition and will extend its service life.
2. Nonstop usage for hours may cause overheating of blades, reduce the cutting
performance and shorten blade service life. When blade gets overheated, switch the
unit off for a few minutes to cool it down; then lubricate the blades.
3. Hair must be clean and dry before cutting. Foreign matter hidden in the hair may
damage the blade edge.
4. Hair may gather inside the blade housing during use. Too much stored hair will
reduce the oscillating ability of the blades and cause malfunctioning. Always clean
residual hair in the blade.
5. Avoid impact of the blade with hard objects as this may cause damage to the
blade teeth.
You may adjust the cutting length from 3-12mm by attaching the comb attachment.
This trimmer can be operated by plugging it into the power source.
1. Ensure that the Switch is off.
2. Plug into the wall socket.
3. Check if the working indicator is lit.
4. Switch “On” to operate.
Always switch off before removing, replacing and cleaning the blade.
Set blade adjuster to 2.0mm to reassemble blade; otherwise the adjuster does not
work.
Feed tool
Post
Moving blade
Fixed blade

45
MAINTENANCE MOTOR LIFE
ENVIRONMENTAL DISPOSAL
BLADE LIFE
Lubricating the Blade
Remove the Blade
Cleaning the Main Body and Accessories
2. Brush off the collected residual hair from between the teeth and the blade housing.
3. Move the oscillating bracket with your thumb to separate stored hair from the
blades. Brush off the hair between the blades. Make sure that hair is not trapped
between the blades.
1. Before or after use, drop a small amount of
oil on the red-point places shown in the left
picture.
2. Drop oil and spread evenly. Slightly move the
oscillating part to spread the oil between the
blades.
1. Switch off and unplug the trimmer before cleaning.
2. Wipe with a soft damp cloth.
3. Allow it to completely air dry before use.
*The service life of the blade may be shortened in the following situations:
1. The blade has not been lubricated properly on a regular basis.
2. The blade cuts unclean hair or objects other than hair.
3. A foreign object damages the blade edge.
4. The blade is subjected to an impact.
If the cutting efficiency is reduced substantially despite proper maintenance, the
blade has exceeded its service life and should be sharpened or replaced.
*No maintenance is required for the motor.
*Professional DC motor.
*The service life of the motor may be shortened in the following situations:
1. The clipper is stored in humid surroundings for long periods.
2. The blade has not been lubricated properly.
3. Stored hair in the blade housing has not been cleaned properly.
4. An incorrect power source is used.
It is the owner’s responsibility to dispose of the clippers in a
reasonable manner after their useful life. Do not dispose of in
household waste.
The clipper can be returned to the place of purchase for recycling,
or taken to your local authority waste disposal site.
Please hold with the other hand to
avoid the blade falling off.
Press the moving part of the blade with
the thumb and then remove the blade.
Producer : Shanghai TOEX International Trading Co., Ltd.
Address : Floor 5, Building 6, No.675 Zhujin Road, Songjiang District, Shanghai,
201615, China
