KitchenAid 5KHB1231G Installation instructions

5KHB1231G
5KHB1231W
W11287567A.indb 1 7/27/2018 8:03:14 PM

2
TABLE OF CONTENTS
HAND BLENDER SAFETY...................................................................................... 3
Important safeguard........................................................................................ 3
Electrical requirements .................................................................................... 5
PARTS AND FEATURES.......................................................................................... 6
Parts and accessories....................................................................................... 6
Hand Blender features..................................................................................... 6
OPERATING YOUR HAND BLENDER ................................................................... 7
Assembling the Hand Blender......................................................................... 7
Using the blending arm ...................................................................................7
TIPS FOR GREAT RESULTS .................................................................................... 9
Blending tips.................................................................................................... 9
Operating tips ............................................................................................... 10
CARE AND CLEANING ........................................................................................ 11
Washing the motor body............................................................................... 11
Washing the accessories and attachments.................................................... 11
W11287567A.indb 2 7/27/2018 8:03:14 PM

HAND BLENDER SAFETY | 3
ENGLISH
ENGLISH
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety
precautions should always be followed, including
the following:
1. Read all instructions. Misuse of appliance may result
in personal injury.
2. To protect against risk of electrical shock do not
put motor body, cord, or electrical plug of this Hand
Blender in water or other liquid.
3. This appliance is not intended for use by persons
including children, with reduced physical, sensory,
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance in a safe
way and understand the hazards involved.
HAND BLENDER SAFETY
W11287567A.indb 3 7/27/2018 8:03:15 PM

4 | HAND BLENDER SAFETY
4. Children should be supervised to ensure they do
not play with the appliance. Do not allow children to
use the Hand Blender without supervision. Care should
be taken when used near children.
5. To protect against risk of electrical shock, do not put
appliance in water or other liquid.
6. Never leave the appliance unattended while it is in
operation.
7. Unplug from outlet when not in use, before putting on
or taking off parts, and before cleaning.
8. Avoid contacting moving parts. Keep hands, hair, and
clothing, as well as spatulas and other utensils away
from accessories during operation to reduce the risk of
injury to persons and/or damage to the appliance.
9. Do not operate any appliance with a damaged cord or
plug or after the appliance malfunctions or has been
damaged in any manner. Return appliance
to the nearest Authorised Service Centre for
examination, repair, or adjustment.
10. If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualied
persons in order to avoid a hazard.
11. The use of attachments not recommended or sold
by the manufacturer may cause re, electric shock,
or injury.
12. Do not use the Blender outdoors.
13. Do not let cord hang over edge of table or counter.
14. Do not let cord contact hot surfaces, including
the stove.
15. When mixing liquids, especially hot liquids, use a
tall container or make small quantities at a time to
reduce spillage.
16. Keep hands and utensils out of the container while
blending to prevent the possibility of severe injury
to persons or damage to the unit. A scraper may
be used, but must be used only when the unit is
not running.
HAND BLENDER SAFETY
W11287567A.indb 4 7/27/2018 8:03:15 PM

HAND BLENDER SAFETY | 5
ENGLISH
ENGLISH
17. The blades are sharp. Care should be taken when
handling the sharp cutting blades, and during cleaning.
18. Be careful if hot liquid is blended in the jar, as it can be
ejected out due to a sudden steaming.
19. “Refer to the “Operating Your Hand Blender” section
for maximum operating time and speed.
20. Refer to the “Care and Cleaning” section for
instructions on how to clean surfaces in contact with
food.
21. This appliance is intended to be used in household
and similar applications such as:
- staff kitchen areas in shops, ofces, or other
working environments
- farmhouses
- by clients in hotels, motels, and other residential
type environments
- bed and breakfast type environments.
SAVE THESE INSTRUCTIONS
HAND BLENDER SAFETY
Voltage: 220-240 Volts
Frequency: 50-60 Hertz
Wattage: 180 Watts
ELECTRICAL REQUIREMENTS
NOTE: If the plug does not fit in the outlet,
contact a qualified electrician.
Do not modify the plug in any way.
W11287567A.indb 5 7/27/2018 8:03:15 PM

6 | PARTS AND FEATURES
PARTS AND FEATURES
PARTS AND ACCESSORIES
Stainless steel
blending arm
Motor
body
One-touch
power button
Speed control dial
1.5 m
Power cord
700 mL blending
jar and lid
HAND BLENDER FEATURES
Speed control
Provides easy adjustment of speed.
One-touch power button
Activate the Hand Blender by pressing
and holding the POWER button during
blending. To stop blending, simply release
the power button.
Motor body
Designed for a comfortable, nonslip grip.
Powerful DC motor (not shown)
Provides a powerful blending action and
is designed for quiet, long-life operation.
1.5 m power cord
Long enough to take the Hand Blender
to the cooktop or work area, the power
cord is rounded with no grooves for easy
cleanup. A silicone cord strap is included
for convenient cord storage.
Twist-lock stainless steel
blending arm
Attaches onto the motor body with a
simple twist and rotates to lock into place.
The sharp stainless steel blade is covered
to help prevent splashing while blending.
Blending jar
700 mL BPA-free jar with lid.
W11287567A.indb 6 7/27/2018 8:03:15 PM

OPERATING YOUR HAND BLENDER | 7
ENGLISH
ENGLISH
OPERATING YOUR HAND BLENDER
ASSEMBLING THE HAND BLENDER
Before using the KitchenAid Hand Blender
for the first time, wipe the motor body and
attachment adapters with a clean, damp
cloth to remove any dirt or dust. Mild dish
soap may be used, but do not use abrasive
cleansers.
NOTE: Do not immerse the motor
body or the adapters in water.
Dry with a soft cloth. Wash all the other
attachments and accessories by hand
or in the top rack of the dishwasher.
Dry thoroughly.
NOTE: Always be sure to unplug the
power cord from the wall socket before
installing or removing attachments.
NOTE: Do not exceed 30 seconds
continuous operation at speed 2. Blending arm
attachment
Use the blending arm attachment for smoothies, milkshakes, soup, cooked
vegetables, frosting, or baby food.
1Insert blending arm into motor body
and twist to lock until it clicks.
USING THE BLENDING ARM
W11287567A.indb 7 7/27/2018 8:03:16 PM

8 | PARTS AND FEATURES
OPERATING YOUR HAND BLENDER
Electrical Shock Hazard
Plug into an earthed outlet.
Do not remove earth prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these
instructions can result in
death, fire, or electrical shock.
2
Plug the electrical cord into an
earthed outlet, then set The Hand
Blender on Speed 1. Adjust the speed
by turning the speed control dial on
top of the Hand Blender.
3Insert the Hand Blender
into the mixture. 4Press the Power button to activate the Hand Blender.
IMPORTANT: The Hand Blender should
only be immersed in liquids
the length of the attachment. Do
not submerge beyond the seam
of the blending attachment. Do
not immerse the motor body into
liquids or other mixtures.
5When blending is complete, release
the power button before removing
the Hand Blender from the mixture.
IMPORTANT: Unplug immediately after
use, and before removing or changing
attachments.
W11287567A.indb 8 7/27/2018 8:03:17 PM

TIPS FOR GREAT RESULTS | 9
ENGLISH
ENGLISH
BLENDING TIPS
TIPS FOR GREAT RESULTS
Blending: Insert the Hand Blender with
blending arm attached into the blending
jar containing ingredients at an angle.
Use your free hand to cover the top of
the blending jar for better stability and
avoid splattering. Remember to stop the
Hand Blender before removing it from
the jar to avoid splashing.
Drawing up: Rest the Hand Blender
on the bottom of the blending jar
momentarily then hold at an angle and
slowly draw it upwards against the side
of the jar. As the Hand Blender is drawn
up, you will notice the ingredients from
the bottom of the jar being drawn up.
When the ingredients are no longer
being drawn up from the bottom,
return the Hand Blender to the bottom
of the jar and repeat the process until
the ingredients are at the desired
consistency.
Wrist movement: Using a light circular
motion from your wrist, draw the Hand
Blender up slightly and let it fall again
into the ingredients. Allow your wrist
motion and the weight of the Hand
Blender to do the work.
W11287567A.indb 9 7/27/2018 8:03:17 PM

10 | TIPS FOR GREAT RESULTS
TIPS FOR GREAT RESULTS
OPERATING TIPS
• Cut solid foods into small pieces for
easier blending or chopping.
• The Hand Blender is equipped with
thermal protection from high operating
temperatures. Should the Hand Blender
suddenly stop during use, unplug it and
allow 10 minutes to automatically reset.
• To avoid splashing, insert the Hand
Blender into the mixture before
pressing the power button, and release
the power button before pulling the
Hand Blender out of the mixture.
• When blending in a saucepan on a
cooktop, remove the pan from the
heating element to protect the Hand
Blender from overheating.
• For best blending, hold the Hand
Blender at an angle and gently move up
and down within the container. Do not
pound down on the mixture with the
Hand Blender.
• To prevent overflow, allow room in the
container for the mixture to rise when
using the Hand Blender.
• Be sure the extra-long cord of the
Hand Blender is not extending
over a hot heating element.
• Do not let the Hand Blender sit in a hot
pan on the cooktop while not in use.
• Remove hard items, such as fruit pits
or bones, from the mixture before
blending or chopping to help prevent
damage to the blades.
• Do not use your Hand Blender to
process coffee beans or hard spices such
as nutmeg. Processing these foods could
damage the blades of the Hand Blender.
• Do not use the jar in the microwave
oven.
W11287567A.indb 10 7/27/2018 8:03:18 PM
