COOKTOP PARTS
1
For Models: KDSS907SSS03
(Stainless)
5−08 Litho in U.S.A. (amd)(bay) Part No. W10206132 Rev. A
30" Slide−In
Dual Fuel
CONVECTION

COOKTOP PARTS
2
For Models: KDSS907SSS03
(Stainless)
W10206132
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10154991 Installation
Instructions
W10162199 Use & Care Guide
W10112147 Tech Sheet
9757680 Anti−Tip
Instructions
Safe Cooking Tips
9762761 English
W10065852 French
9763467 Guide Easy Set
2
W10153103 Burner Box
3 9761784 Bracket, Mounting
4
W10175861 Cooktop
5 3196537 Screw
6 9757807 Thermostat
7 3400843 Screw
8
W10108030 Bracket, Spark
Module
9 9763445 Bracket, Burner
10 8301084 Shield, Heat
11
W10110491 Module, Spark
12
9761555CB Grate, Burner (RH)
13
9761556CB Grate, Burner (LH)
14 3368921 Screw
15
W10129030 Screw
16 9759944 Thermostat
18
9761557CB Grate, Insert
19 Cap, Burner
9761563CB 12.5K (RR)
8284669 6K (RF, LR)
21 3196160 Screw
23 9761755 Cover, Cooktop
Rear
24 9763436 Cover, Top Rear
25 Head, Burner
8286182 Large (RR)
8286181 Small (LR,RF)
26
W10109920 Gasket

OVEN PARTS
3
For Models: KDSS907SSS03
(Stainless)
W10206132

OVEN PARTS
4
For Models: KDSS907SSS03
(Stainless)
W10206132
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Trim, Side
W10140548 Right
W10140547 Left
2 3400832 Screw
3 Hinge Receiver
4455606 Right
4455605 Left
4
W10105790 Bumper, Door (2)
5 3196537 Screw
6 3196160 Screw
7 8303099 Top Chassis
8 4449809 Screw
9 4452158 Tube, Vent
10
W10067870 Lens, Light (2)
11
W10009930 Oven Light,
Assembly (2)
12 4452166 Bulb, Light (2)
13 4449154 Screw
14
W10130368 Frame, Front
15
W10074200 Gasket, Door
16 4448444 Grommet, Mounting
Rail
17 4452152 Bracket, Mounting
18 9757685 Guide, Side Panel
19 4451478 Support, Insulation
20 Body, Side
9760723PB Black
21 9757461 Bracket,Side Panel
22 9760888 Latch, Motorized
23 9759242 Thermostat
24 9757811 Brace, Side Panel
25 4455641 Side, Chassis
26 9759761 Back, Chassis
27 Liner, Oven
(Not Serviceable)
28 9759890 Clip, Side Panel
29 4455636 Sensor
30 9759884 Insulation
31 3196176 Screw
32 9757829 Bracket,
Transformer
33 9759713 Base, Chassis
34 4448933 Retainer, Gasket
35 9758583 Cover, Back
36
W10160347 Vent, Bottom Upper
37
W10140546 Vent, Bottom Lower
38 4449743 Screw
39 9759722 Insulation, Side
Trim
40 9760481 Washer, Insulation
Body Side
41
W10111628 Control,
Transformer
43 3400080 Screw
44
W10165135 Box, Terminal
45 9757405 Cover, Terminal
Box
46 9759721 Insulator,
Terminal Box
47 9761958 Block, Terminal
48 9756454 Bracket, Appliance
Manager
49
W10083460 Slide, GOC
50
W10181438 Appliance Manager
51 9759320 Blower
52 9756821 Support, Wiring
53 3196537 Screw
54 9759945 Stand Off−Rear
55 3400805 Screw
56 9759885 Insulation, Pad
T.B.B
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
9756817 Insulation, Wrap
9756470 Insulation, Back

DOOR PARTS
5
For Models: KDSS907SSS03
(Stainless)
W10206132

DOOR PARTS
6
For Models: KDSS907SSS03
(Stainless)
W10206132
Illus. Part
No. No. DESCRIPTION
1 W10140551 Panel, Door
2 9757706 Glass, Inner
3 4451722 Insulation, Door
4 4457132 Retainer, Glass
5 Hinge, Oven Door
9760579 Right
9760580 Left
6 9759225 Glass, Inner
7 4457114 Shield, Heat
Bottom
8 9759229 Bracket, Glass
Side
9 4457103 Shield, Heat Top
10 9759225 Glass, Inner Door
11 9759230 Bracket, Central
12 Bracket, Handle
9763497 Right
9763496 Left
13 8522415 Seal, Window
14
W10155557 Assembly, Door
Kit
15
8303774SS Handle, Door
16 3196184 Screw
17 4448520 Bumper, Door (3)
18
8304603SS Badge

DRAWER PARTS
7
For Models: KDSS907SSS03
(Stainless)
W10206132
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Support, Drawer
Rail
9757687 Right
9757686 Left
2
9763501BL Support, Front
& Rear
3 Brace, Drawer
4453720 Right
4453721 Left
5 Side, Base
9759953 Right
9759954 Left
6
W10058460 Foot
8 3196037 Foot Assembly
10
W10144430 Drawer
11 Guide, Roller
Includes Roller
W10019810 Right
W10019800 Left
12
W10144431 Panel, Drawer
13
W10140545 Front, Drawer
14
9761573SS Handle, Drawer
15
W10162092 Screw
16 8274149 Thermistor
17 9760775 Element, Warming
18 4449809 Screw
19 9758676 Support, Element
20
W10171411 Bracket, Regulator
21
W10108850 Regulator
22
W10153100 Cover, Terminal
23 9761796 Enclosure, Warming
Drawer
24
W10153099 Cover, Access
25
W10162096 Screw

TOP VENTING PARTS
8
For Models: KDSS907SSS03
(Stainless)
W10206132
Illus. Part
No. No. DESCRIPTION
1 4451759 Vent, Exhaust
2 4455178 Elbow, Vent Top
4 4451758 Block, Foam
5 4455177 Elbow, Vent Bottom
6
W10143041 Bracket, Terminal
Box
7 4449809 Screw
10 4449040 Screw
11 4455352 Bracket, Blower

INTERNAL OVEN PARTS
9
For Models: KDSS907SSS03
(Stainless)
W10206132
Illus. Part
No. No. DESCRIPTION
1 9760774 Element, Broil
2 4448717 Rack, Oven
3 9760768 Element, Bake
4 4455037 Tray, Bake Hidden
5 9756690 Cover, Fan
6 4449154 Screw
8 4449809 Screw
9 9760769 Element,
Convection
10
W10116351 Blade, Fan
11
W10116349 Nut
12
W10116228 Motor, Convection
13 9755543 Jack, Meat Probe
14 9755542 Probe, Meat
15 9755547 Lock Washer
16 9755546 Hex Nut
17 4450039 Cover, Bake Tray

COOKTOP BURNER PARTS
10
For Models: KDSS907SSS03
(Stainless)
W10206132
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Burner Base
Includes Orifice
W10128455 RR
W10128446 RF, LR
2 9761069 Tubing, Burner(RF)
3 9761070 Tubing, Burner(RR)
4 9761068 Tubing, Burner(LR)
5 4456816 Valve, Burner
Small (2)
6 4456817 Valve, Burner
Large
7 9756824 Spark Switch &
Harness Assembly
8 9761752 Tube, Manifold
9 Manifold
9761641 TCB
9761642 Cooktop
11 3196537 Screw
12 8523704 Bolt, Valve (4)
13
W10108840 Tubing
DF to Regulator
14
W10110378 Igniter, Orfice
Holder
15 Orifice
9762938 RR
9762937 LR, RF
16 8273062 Screw

TRIPLE CROWN BURNER
11
For Models: KDSS907SSS03
(Stainless)
W10206132
Illus. Part
No. No. DESCRIPTION
1 9761639 Burner Assembly
Triple Crown
Burner
2 8285250 Plate, Closure
3 8285255 Internal Head,
Triple Crown
Burner
4 8285256 External Head,
Triple Crown
Burner
5 8285258 Cap, Burner
External
6
9758829CB Cap, Burner
Internal
7 3400702 Screw
8 3400843 Screw
9 9760519 Valve, TCB
10 Tube, TCB Gas
9761072 Outer
9761071 Inner
11 9763494 Igniter
12 Orifice
9762443 Internal
9762442 External

CONTROL PANEL PARTS
12
For Models: KDSS907SSS03
(Stainless)
W10206132
Illus. Part
No. No. DESCRIPTION
1 W10156274 Control Panel
2 9761566 Switch, Membrane
3
W10181439 Control, Interface
4
W10105370 Shield, Console
5 3196537 Screw
6 9761745 Bracket,
Touchsensor
7
W10156262 Knob (LF)
8
W10156265 Knob (LR, RF, RR)
9 9780271 Screw
10
W10116195 Gasket, Vent
Shield

OPTIONAL PARTS (NOT INCLUDED)
13
For Models: KDSS907SSS03
(Stainless)
W10206132
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
72017 White
261869 Cord Brown
72032 Black
PAINT, SPRAY
350930 White
261900 Citrine White
830864 Black
ADHESIVE
591014 Adhesive
Loctite (1/3 oz.)
482338 Sealer, Silastic
(3 oz.)
SPLICING WIRES−−25FT.
LENGTH
242828 Wire (12 Ga.
150 c Black)
242820 Wire (14 Ga.
150 c Black)
242821 Wire (14 Ga.
150 c Blue)
242822 Wire (14 Ga.
150 c Brown)
242830 Wire (14 Ga.
200 c Brown)
242823 Wire (14 Ga.
150 c Green)
242824 Wire (14 Ga.
150 c Orange)
242825 Wire (14 Ga.
150 c Red)
242831 Wire (14 Ga.
200 c Red)
242827 Wire (14 Ga.
150 c Yellow)
WIRING HARNESS PARTS
W10141504 Harness, Main
W10157935 Harness, Switch
Electric
9756921 Harness, TCB
9762921 Harness,
Communication
9763481 Harness, Ground
Strap
W10155291 Connector, Flex
313660 Clip, Ground Wire
W10177363 Grommet, Flex 60mm
4449809 Screw
9757778 Bushing, Snap
Splilt 1"
Block
4452222 Spacer, Harness
3400015 Screw, Ground
Miscellaneous
4455352 Bracket, Blower
(60mm)
9757426 Orifice Kit
9782676 Anti−Tip
Assembly
9757427 Kit, Orifice
