c1992 KITCHENAID
30" ELECTRIC
BUILT−IN
COOKTOP
MODEL
BL−Black
WH−White
KECC500WBL2
Part No. 4174261
11−92 Litho in U.S.A.
COOKTOP PARTS
2
(Black) (White)
For Model: KECC500WBL2, KECC500WWH2
4174261
COOKTOP PARTS
3
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
NOTE: The screws and nuts
required to attach a part are
listed immediately following
that part.
OPTIONAL PARTS (NOT INCLUDED)
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
FOLLOWING PARTS
NOT ILLUSTRATED
LITERATURE PARTS
Miscellaneous
SPLICING WIRES−−25FT.
LENGTH
242828 Wire, Black
12 Ga. 150 C
242820 Wire, Black
14 Ga. 150 C
242822 Wire, Blue
14 Ga. 150 C
242830 Wire, Brown
14 Ga. 200 C
242823 Wire, Green
14 Ga. 150 C
242824 Wire, Orange
14 Ga. 150 C
242829 Wire, Red
12 Ga. 150 C
242825 Wire, Red
14 Ga. 150 C
242831 Wire, Red
14 Ga. 200 C
242826 Wire, White
14 Ga. 150 C
242827 Wire, Yellow
14 Ga. 150 C
242832 Wire, Yellow
14 Ga. 200 C
ACCESSORY PARTS
(Black) (White)
For Model: KECC500WBL2, KECC500WWH2
4174261
1 Trim Ring, Cooktop
3150305 Black
3150306 White
4168863 Screw (14)
2 Cooktop, Glass
3185578 Black
3185579 White
4 3150328 Bracket, Switch
Mounting
5 Element, Surface
3183584 1400W Left Rear
3183200 1700W Right Front
3183201 2100W Right Rear
3183632 2400W Left Front
6 3149191 Spring Locator (8)
246119 Screw (8)
7 Switch, Infinite
3148949 Use W/1400W Left
Rear & 1700W Right
Front Burner
3148950 Use W/2100W Right
Rear Burner
3148965 Use W/2400W Left
Front Burner
311865 Screw (8)
8 309839 Seal, Switch Shaft
9 3149978 Light, Indicator
10 Knob, Control (4)
3150100 Black
3150096 White
11 3150317 Cover, Bottom
3148107 Screw (6)
12 3150316 Element Support (2)
3148107 Screw (4)
13 3150318 Cover, Service
3148107 Screw (5)
15 3182435 Seal, Switch (4)
16 Switch, Limiter
3149129 Use W/3183584
Element
3183972 Use W/3183200
Element
3149123 Use W/3183201
Element
3149124 Use W/3183632
Element
17 Rail, Side
3150325 Right Hand
3150326 Left Hand
18 3183380 Rail, Front & Rear
19 Seal, Silicone
3185589 Small (3)
3185590 Large (2)
20 3185294 Insulation,Ceramic
21 3150321 Bracket, Hot
Surface Indicator
22 3150304 Lamp, Hot
Surface Indicator
3148107 Screw (2)
LIT3181199 Installation
Instructions
3183176 Wiring Diagram
LIT3181198 Use & Care Guide
LIT4174261 Repair Parts List
Mounting Screws
258644 10A X 2 (2)
3150320 Clamp (2)
3184477 Cleaner, Glass
4
Illus. Part
No. No. DESCRIPTION
WIRING HARNESS PARTS
(Black) (White)
For Model: KECC500WBL2, KECC500WWH2
4174261
1 3181503 Wiring Harness
Surface Unit
2 3181502 Wiring Harness
Infinite Switch
3148107 Screw (4)
6 3149964 Jumper, Infinite
Switch
