COOKTOP PARTS
1
For Model: KECC567RSS05
(Stainless)
11−08 Litho in U.S.A. (amd) (eeb) Part No. W10240403 Rev. A
36" ELECTRIC
CERAN
COOKTOP
COOKTOP PARTS
2
For Model: KECC567RSS05
(Stainless)
W10240403
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
1 Literature Parts
Installation
Instructions
8286066 Cooktop
8304571 Undercounter Oven
8286430 Wiring Diagram
W10162162
Use & Care Guide
Safer Cooking Tips
9762761 English
W10065852
French
2 8286975 Cooktop, Glass
3 8285808 Bracket, Switch
4 4449868 Block, Terminal
5 9759094 Spring Locator(10)
6 246119 Screw (10)
7 Switch, Infinite
9763763 Single (3)
9763764 Dual
9763765 Triple
8 3183956 Seal, Switch Shaft
9 8286535 Bracket, Bottom
10
8286096BL
Knob, Control (5)
11 8286555 Box, Burner
12 9760762 Shield, Heat
13 8286578 Inside, Wall
14 3196537 Screw
15 8285242 Seal, Heat
16 8285439 Seal, Heat Shield
17 311865 Screw
18 4455917 Bracket, Mounting
19 3400093 Screw
20 9763517 Rail, Element
21 8286345 Rail, Element
22 8286056 Lamp, Hot
Surface Indicator
23
W10180229
Box, Control
24 Element, Surface
8285848 4300W (Bridge)
8286187 2500/1800/900W LF
8523698 1200W LR
8523697 1500W RR
25 3196163 Screw
26 112432 Nut
27 8285469 Seal, Switch
28
W10142239
Frame, Cooktop
29 3196160 Screw
30 8286582 Spring Clip,
Bridge (3)
31 8286600 Inside Wall,
Insulation
32 8286607 Gromment,
Flexible (2)
33 3192439 Seal, Limiter
OPTIONAL PARTS
3
For Model: KECC567RSS05
(Stainless)
W10240403
Illus. Part
No. No. DESCRIPTION
FOLLOWING PARTS
NOT ILLUSTRATED
Miscellaneous
8286642 Tape, Foam
WIRING HARNESS PARTS
8286468 Harness, Main
8286382 Clip, Harness
3196160 Screw, Ground
8286338 Conduit, Harness
8286238 Thermostat
