COOKTOP PARTS
1
For Models: KECC567BBL2, KECC567BWH2, KECC567BAL2, KECC567BBS2
(Black) (White) (Almond) (Black−Stainless)
2−97 Litho in U.S.A. (dmz) Part No. 885215 Rev. A
36" ELECTRIC
BUILT−IN
COOKTOP
COOKTOP PARTS
2
For Models: KECC567BBL2, KECC567BWH2, KECC567BAL2, KECC567BBS2
(Black) (White) (Almond) (Black−Stainless)
885215
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
NOTE: The screws and nuts
required to attach a part are
listed immediately following
that part.
1 Trim Ring, Cooktop
3190937 Black
3190938 White
3190939 Almond
3191105 Stainless
2 Cooktop, Glass
3187818 Black & Stainless
3187819 White
3188896 Almond
4 3188308 Bracket, Switch
Mounting
6 3189165 Spring Locator(10)
246119 Screw (8)
7 Switch, Infinite
3188755 Use W/2400/1000W
Left Rear Burner
3188755 Use W/2200/1000W
Right Rear Burner
4454543 Use W/1500W
Right Front Burner
4454543 Use W/1200 W
Left Front Burner
4454543 Use W/1400W
Center Rear Burner
8 3183956 Seal, Switch Shaft
311865 Screw
10 Knob, Control (4)
9750372FF
Black & Stainless
4211909 White
9750372FT
Almond
11 3188103 Box, Burner
13 3188533 Grommet
4159456 Screw
15 3182435 Seal, Switch (5)
16 Switch, Limiter
3189667 Use W/3189655
Element
3189668 Use W/3189656
Element
3190253 Use W/3189894
Element
3190247 Use W/3189901
Element
3190441 Use W/4454592
Element
18 3189843 Plate, Backer
19 Seal, Silicone
3185589 Small (2)
3188854 Large (2)
20 3187753 Shield, Heat
4159456 Screw
21 Seal, Silicone
3188852 8 In.
3188853 11 In.
22 3190951 Lamp, Hot
Surface Indicator
4168863 Screw
23 3189152 Bracket, Stiffening
4159456 Screw
24 Element, Surface
(Includes # 16)
3189655 1200W Left Front
3189656 1500 W Right Front
3189894 1400W Center Rear
3189901 2200W/1000W
Right Rear
4454592 2400W/1000W
Left Rear
29 3188876 Shield, Heat
4159456 Screw
30 3189175 Bracket, L
4159456 Screw
31 3188309 Shield, Heat
32 3188158 Plate, Interior
4159456 Screw
33 3189159 Plate, End
4159456 Screw
34 3189036 Plate Louver
4159456 Screw
35 3189273 Cover, Conduit
37 3188760 Housing, Backlight
311865 Screw
38 3188761 Lens, Backlight
39 3188786 Insulator
4159456 Screw
MISCELLANEOUS PARTS
3
For Models: KECC567BBL2, KECC567BWH2, KECC567BAL2, KECC567BBS2
(Black) (White) (Almond) (Black−Stainless)
885215
Illus. Part
No. No. DESCRIPTION
FOLLOWING PARTS
NOT ILLUSTRATED
LITERATURE PARTS
LIT3189330
Installation
Instructions
LIT3190374
Wiring Diagram
LIT4454475
Use & Care Guide
Miscellaneous
3172515 Mtg. Hardware Kit
MISCELLANEOUS PARTS
SPLICING WIRES−−25FT.
LENGTH
242828 Wire, Black
12 Ga. 150 C
242820 Wire, Black
14 Ga. 150 C
242822 Wire, Blue
14 Ga. 150 C
242830 Wire, Brown
14 Ga. 200 C
242823 Wire, Green
14 Ga. 150 C
242824 Wire, Orange
14 Ga. 150 C
242829 Wire, Red
12 Ga. 150 C
242825 Wire, Red
14 Ga. 150 C
242831 Wire, Red
14 Ga. 200 C
242826 Wire, White
14 Ga. 150 C
242827 Wire, Yellow
14 Ga. 150 C
242832 Wire, Yellow
14 Ga. 200 C
ACCESSORY PARTS
3191048 Cleaner, Glass
WIRING HARNESS PARTS
3189759 Harness, Main
3179589 Tie, Wire
3189130 Conduit Assembly
