COOKTOP PARTS
1
For Models: KECC501BBL2, KECC501BWH2, KECC501BAL2
(Black) (White) (Almond)
5−96 Litho in U.S.A. (rmb) Part No. 885211
30" ELECTRIC
BUILT−IN
COOKTOP
COOKTOP PARTS
2
For Models: KECC501BBL2, KECC501BWH2, KECC501BAL2
(Black) (White) (Almond)
885211
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
NOTE: The screws and nuts
required to attach a part are
listed immediately following
that part.
1 Trim Ring, Cooktop
3187744 Black
3187745 White
3187746 Almond
2 Cooktop, Glass
3188255 Black
3188256 White
3188893 Almond
4 3188101 Bracket, Switch
Mounting
6 3189165 Spring Locator (8)
246119 Screw (8)
7 Switch, Infinite
4454541 Use W/2400W
Left Rear Burner
4454540 Use W/2100W
Right Rear Burner
4454539 Use W/1400W
Right Front Burner
4454539 Use W/1200 W
Left Front Burner
8 3183956 Seal, Switch Shaft
311865 Screw
9 4454437 Light, Indicator
10 Knob, Control (4)
9750372FF
Black
9750372FW
White
9750372FT
Almond
11 3188754 Box, Burner
13 3188533 Grommet
4159456 Screw
15 3182435 Seal, Switch (4)
16 Switch, Limiter
3190248 Use W/3196428
Element
3190253 Use W/3189894
Element
3190252 Use W/3189896
Element
3190251 Use W/3189897
Element
18 3188257 Plate, Backer
19 Seal, Silicone
3185589 Small (2)
3185590 Large (2)
20 3187753 Shield, Heat
4159456 Screw
21 3188852 Seal, Silicone
22 3189753 Lamp, Hot
Surface Indicator
4168863 Screw
23 3189152 Bracket, Stiffening
4159456 Screw
25 Element, Surface
(Includes # 16)
3196428 1200W Left Front
3189894 1400W Right Front
3189896 2100W Right Rear
3189897 2400W Left Rear
29 3188844 Shield, Heat
4159456 Screw
30 3189174 Bracket
31 3188102 Shield, Heat
32 3188158 Plate, Interior
4159456 Screw
33 3189159 Plate, End
4159456 Screw
34 3189036 Plate Louver
4159456 Screw
35 3189273 Cover, Conduit
WIRING HARNESS PARTS
3
For Models: KECC501BBL2, KECC501BWH2, KECC501BAL2
(Black) (White) (Almond)
885211
Illus. Part
No. No. DESCRIPTION
1 3189757 Wiring Harness
Surface Unit
2 3179589 Tie, Wire
4
MISCELLANEOUS PARTS
For Models: KECC501BBL2, KECC501BWH2, KECC501BAL2
(Black) (White) (Almond)
885211
Illus. Part
No. No. DESCRIPTION
FOLLOWING PARTS
NOT ILLUSTRATED
LITERATURE PARTS
LIT3189330
Installation
Instructions
3190372 Wiring Diagram
LIT4454475
Use & Care Guide
Miscellaneous
3172515 Hardware, Mounting
FOLLOWING PARTS
NOT ILLUSTRATED
SPLICING WIRES−−25FT.
LENGTH
242828 Wire, Black
12 Ga. 150 C
242820 Wire, Black
14 Ga. 150 C
242822 Wire, Blue
14 Ga. 150 C
242830 Wire, Brown
14 Ga. 200 C
242823 Wire, Green
14 Ga. 150 C
242824 Wire, Orange
14 Ga. 150 C
242829 Wire, Red
12 Ga. 150 C
242825 Wire, Red
14 Ga. 150 C
242831 Wire, Red
14 Ga. 200 C
242826 Wire, White
14 Ga. 150 C
242827 Wire, Yellow
14 Ga. 150 C
242832 Wire, Yellow
14 Ga. 200 C
ACCESSORY PARTS
3184477 Cleaner, Glass
3183488 Scraper, Glass
