COOKTOP PARTS
1
For Models: KECC562GBL1, KECC562GWH1, KECC562GBT1
(Black) (White) (Biscuit)
36" ELECTRIC
BUILT−IN
COOKTOP
11−99 Litho in U.S.A. (RS)Part No. 8177481

COOKTOP PARTS
2
For Models: KECC562GBL1, KECC562GWH1, KECC562GBT1
(Black) (White) (Biscuit)
8177481
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
LIT3191771 Installation
Instructions
LIT3191796 Wiring Diagram
LIT3191524 Use & Care Guide
LIT3191638 Brochure,
Tips−Safe Cooking
2 Cooktop, Glass
4455307 Black
4455308 White
4455306 Biscuit
3 246119 Screw
4 4455420 Bracket, Switch
3183956 Seal, Switch
Bracket
Mounting
6 3191791 Spring Locator(10)
246119 Screw (8)
7 Switch, Infinite
3191049 LR −CR −RF
3188516 RR −LF
8 3192439 Seal, Switch Shaft
311865 Screw
9 3191945 Light, Indicator
10 Knob, Control (5)
9750372FF Black
9750372FW White
9750372FC Biscuit
11 4455423 Box, Burner
13 3192477 Bumper, Rubber
14 3196537 Screw
15 3182435 Seal, Switch (5)
17 311865 Screw
20 3191515 Rail, Element (2)
21 3192269 Rail, Element (1)
22 3192222 Lamp, Hot
Surface Indicator
24 Element, Surface
(Includes # 16)
8272563 1000/2400W −LF
8272567 1200W −RF
8272564 1500W −LR & CR
4452741 1000/1800W −RR

MISCELLANEOUS PARTS
3
For Models: KECC562GBL1, KECC562GWH1, KECC562GBT1
(Black) (White) (Biscuit)
8177481
Illus. Part
No. No. DESCRIPTION
FOLLOWING PARTS
NOT ILLUSTRATED
Miscellaneous
3172515 Mtg. Hardware Kit
3191948 Seal, Burner Box
SPLICING WIRES−−25FT.
LENGTH
242828 Wire, Black
12 Ga. 150 C
242820 Wire, Black
14 Ga. 150 C
242822 Wire, Blue
14 Ga. 150 C
242830 Wire, Brown
14 Ga. 200 C
242823 Wire, Green
14 Ga. 150 C
242824 Wire, Orange
14 Ga. 150 C
242829 Wire, Red
12 Ga. 150 C
242825 Wire, Red
14 Ga. 150 C
242831 Wire, Red
14 Ga. 200 C
242826 Wire, White
14 Ga. 150 C
242827 Wire, Yellow
14 Ga. 150 C
242832 Wire, Yellow
14 Ga. 200 C
CLEANER, COOKTOP
3191048 Cleaner, Glass
WIRING HARNESS PARTS
4455274 Harness, Main
313438 Clip, Harness
3400015 Screw, Ground
3192221 Conduit
