KitchenAid KGCK306 User manual

GAS COOKTOP
Use & Care Guide
For questions about features, operation/performance, parts, accessories, or service, call: 1-800-422-1230 or visit our website at
www.kitchenaid.com
In Canada, call: 1-800-807-6777 or visit our website at www.KitchenAid.ca
TABLE DE CUISSON À GAZ
Guide d’utilisation et d’entretien
Au Canada, pour assistance, installation ou service composez le 1-800-807-6777, ou visitez notre site web à www.KitchenAid.ca
Table of Contents/Table des matières.............................................................................2
Model/Modèles KGCV566 KGCC506 KGCC566 KGCK306 KGCK366 KGCC706 KGCC766
W10169072A

2
TABLE OF CONTENTS
COOKTOP SAFETY........................................................................3
PARTS AND FEATURES................................................................5
COOKTOP USE ..............................................................................9
Cooktop Controls.........................................................................9
Sealed Surface Burners ...............................................................9
Surface Grates with Locator Pin................................................10
Ceramic Glass Surface ..............................................................10
Home Canning ...........................................................................11
Cookware ...................................................................................11
COOKTOP CARE..........................................................................11
General Cleaning........................................................................11
TROUBLESHOOTING ..................................................................13
ASSISTANCE OR SERVICE.........................................................14
In the U.S.A. ...............................................................................14
Accessories................................................................................14
In Canada ...................................................................................14
WARRANTY ..................................................................................15
TABLE DES MATIÈRES
SÉCURITÉ DE LA TABLE DE CUISSON ....................................16
PIÈCES ET CARACTÉRISTIQUES ..............................................18
UTILISATION DE LA TABLE DE CUISSON................................22
Commandes de la table de cuisson ..........................................22
Brûleurs de surface scellés........................................................23
Grilles de surface avec tige de positionnement.........................23
Surface en vitrocéramique .........................................................24
Préparation de conserves à la maison.......................................24
Ustensiles de cuisson ................................................................24
ENTRETIEN DE LA TABLE DE CUISSON ..................................25
Nettoyage général ......................................................................25
DÉPANNAGE.................................................................................26
ASSISTANCE OU SERVICE.........................................................27
GARANTIE.....................................................................................27

3
COOKTOP SAFETY
You can be killed or seriously injured if you don't immediately
You can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING
WARNING: If the information in this manual is not followed exactly, a fire or explosion
may result causing property damage, personal injury or death.
–Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this
or any other appliance.
–WHAT TO DO IF YOU SMELL GAS:
•Do not try to light any appliance.
•Do not touch any electrical switch.
•Do not use any phone in your building.
•Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's
instructions.
•If you cannot reach your gas supplier, call the fire department.
–Installation and service must be performed by a qualified installer, service agency or
the gas supplier.

4
SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
WARNING: To reduce the risk of fire, electrical shock,
injury to persons, or damage when using the cooktop, follow
basic precautions, including the following:
■ WARNING: NEVER use this appliance as a space
heater to heat or warm the room. Doing so may result in
carbon monoxide poisoning and overheating of the cooktop.
■ CAUTION: Do not store items of interest to children in
cabinets above the cooktop – children climbing on the
cooktop to reach items could be seriously injured.
■ Proper Installation – The cooktop, when installed, must be
electrically grounded in accordance with local codes or, in
the absence of local codes, with the
National Electrical
Code, ANSI/NFPA70 or the Canadian Electrical Code,
Part 1
. Be sure the cooktop is properly installed and
grounded by a qualified technician.
■ This cooktop is equipped with a three-prong grounding
plug for your protection against shock hazard and should
be plugged directly into a properly grounded receptacle. Do
not cut or remove the grounding prong from this plug.
■ Disconnect the electrical supply before servicing the
cooktop.
■ Injuries may result from the misuse of the cooktop such as
stepping, leaning, or sitting on the top surface.
■ Maintenance – Keep cooktop area clear and free from
combustible materials, gasoline, and other flammable
vapors and liquids.
■ Storage on the cooktop – Flammable materials should not
be stored on or near surface units.
■ Top burner flame size should be adjusted so it does not
extend beyond the edge of the cooking utensil.
The California Safe Drinking Water and Toxic Enforcement Act requires the Governor of California to publish a list of substances
known to the State of California to cause cancer, birth defects, or other reproductive harm, and requires businesses to warn of
potential exposure to such substances.
WARNING: This product contains a chemical known to the State of California to cause cancer, birth defects, or other
reproductive harm.
This appliance can cause low-level exposure to some of the substances listed, including benzene, formaldehyde, carbon
monoxide, toluene, and soot.

5
PARTS AND FEATURES
This manual covers several different models, and not all models are shown. The cooktop you have purchased may have some or all of
the items listed. The locations and appearances of the features shown here may not match those of your model. All Btu/h ratings shown
are for Natural gas unless otherwise noted.
Model KGCV566 (36" [91.4 cm] shown)
Control Panel
Cooktop
A. Left front burner control knob
B. Control knob off position
C. Left rear burner control knob
D. Center rear burner control knob
E. Right rear burner control knob
F. Right front burner control knob
A. 17,000 Btu/h burner
B. Surface burner cap
C. Left surface burner grate
D. 6,000 Btu/h burner
E. Model and serial number plate
(under cooktop)
F. 9,100 Btu/h burner
G. Center grate
H. 6,000 Btu/h burner
I. Right surface burner grate
J. 17,000 Btu/h burner
K. Control panel
OFF
Hi
Med Lo
Lt
OFF
Hi
Med Lo
Lt
OFF
Hi
Med Lo
Lt
OFF
Hi
Med Lo
Lt
OFF
Hi
Med
Lo
Lt
A
B
C
D
E
F
A
B
C
D
E
FG
H
I
J
K

6
Model KGCC566 (36" [91.4 cm] shown)
Model KGCC506 (30" [76.2 cm] not shown)
Control Panel
Cooktop
A. Left front burner control knob
B. Control knob off position
C. Left rear burner control knob
D. Center rear burner control knob
(on 36" [91.4 cm] models only)
E. Right rear burner control knob
F. Right front burner control knob
A. 17,000 Btu/h burner
B. Surface burner cap
C. Left surface burner grate
D. 6,000 Btu/h burner (9,100 Btu/h burner
on 30" [76.2 cm] models)
E. Model and serial number plate
(under cooktop)
F. 9,100 Btu/h burner
(on 36" [91.4 cm] models only)
G. Center grate
H. 12,500 Btu/h burner
I. Right surface burner grate
J. 6,000 Btu/h burner
K. Control panel
OFF
Hi
Med Lo
Lite
A
B
C
D
E
F
OFF
Hi
Med Lo
Lite
OFF
Hi
Med Lo
Lite
OFF
Hi
Med Lo
Lite
OFF
Hi
Med Lo
Lite
A
B
C
D
E
FG
H
I
J
K

7
Model KGCK366 (36" [91.4 cm] shown)
Model KGCK306 (30" [76.2 cm] not shown)
Control Panel
Cooktop
A. Left front burner control knob
B. Control knob off position
C. Left rear burner control knob
D. Center rear burner control knob
(on 36" [91.4 cm] models only)
E. Right rear burner control knob
F. Right front burner control knob
A. 17,000 Btu/h burner
B. Surface burner cap
C. Left surface burner grate
D. 6,000 Btu/h burner (9,100 Btu/h burner
on 30" [72.6 cm] models)
E. Model and serial number plate
(under cooktop)
F. 9,100 Btu/h burner
(on 36" [91.4 cm] models only)
G. Center grate
H. 12,500 Btu/h burner
I. Right surface burner grate
J. 6,000 Btu/h burner
K. Control panel
OFF
Hi
Med Lo
Lite
A
B
C
D
E
F
OFF
Hi
Med Lo
Lite
OFF
Hi
Med Lo
Lite
OFF
Hi
Med Lo
Lite
OFF
Hi
Med Lo
Lite
A
B
C
D
E
FG
H
I
J
K

8
Model KGCC766 (36" [91.4 cm] shown)
Model KGCC706 (30" [76.2 cm] not shown)
Control Panel
Cooktop
A. Left front burner control knob
B. Control knob off position
C. Left rear burner control knob
D. Center rear burner control knob
(on 36" [91.4 cm] models only)
E. Right rear burner control knob
F. Right front burner control knob
A. 17,000 Btu/h burner
B. Surface burner cap
C. Left surface burner grate
D. 6,000 Btu/h burner (9,100 BTU burner
on 30" [72.6 cm] models)
E. Model and serial number plate
(under cooktop)
F. 9,100 Btu/h burner
(on 36" [91.4 cm] models only)
G. Center grate
H. 12,500 v burner
I. Right surface burner grate
J. 6,000 Btu/h burner
K. Control panel
OFF
Hi
Med Lo
Lite
A
B
C
D
E
F
OFF
Hi
Med Lo
Lite
OFF
Hi
Med Lo
Lite
OFF
Hi
Med Lo
Lite
OFF
Hi
Med Lo
Lite
A
B
C
D
E
FG
H
I
J
K

9
COOKTOP USE
Cooktop Controls
IMPORTANT: Your cooktop is factory-set for use with Natural
Gas. If you wish to use LP Gas, an LP Gas Conversion Kit is
included with your new cooktop. See the instructions included
with the LP Gas Conversion Kit for details on making this
conversion.
Electric igniters automatically light the surface burners when
control knobs are turned to LITE.
The large burners (17,000 Btu/h [British Thermal Units] and
12,500 Btu/h) provide the highest heat setting, and are ideal for
cooking large quantities of food or liquid, using large pots and
pans. The small burners (9,100 Btu/h and 6,000 Btu/h) allow
more accurate simmer control at the lowest setting, and are ideal
for cooking smaller quantities of food, using smaller pots and
pans.
Before setting a control knob, place filled cookware on the grate.
Do not operate a burner while using empty cookware or without
any cookware on the grate.
NOTE: Visually check that the burner has lit. If the burner does
not ignite, listen for a clicking sound. If you do not hear the igniter
click, turn off the burner. Check for a tripped circuit breaker or
blown household fuse.
Check that the control knob is pressed completely down on the
valve shaft. If the spark igniter still does not operate, call a trained
repair specialist.
Proper grounding and polarity are necessary for correct operation
of the electric ignition system. If the wall receptacle does not
provide correct polarity, the igniters will become grounded and
occasionally click, even after the burner has ignited. Contact a
trained repair specialist to check the wall receptacle to see
whether it is wired with the correct polarity.
To Set:
1. Push in and turn knob counterclockwise to LITE.
All surface burners will click. Only the burner with the control
knob turned to LITE will produce a flame.
2. Turn knob to anywhere between HI and LO. Use the following
chart as a guide when setting heat levels.
Power failure
In case of prolonged power failure, the surface burners can be lit
manually. Hold a lit match near a burner and turn knob
counterclockwise to LITE. After burner lights, turn knob to
setting. Do not use a grill or griddle accessory during a power
failure, as the vent fan will not operate.
Sealed Surface Burners
IMPORTANT: Do not obstruct the flow of combustion and
ventilation air around the burner grate edges.
Burner cap: Always keep the burner cap in place when using a
surface burner. A clean burner cap will help avoid poor ignition
and uneven flames. Always clean the burner cap after a spillover
and routinely remove and clean the caps according to the
“General Cleaning” section.
WARNING
Fire Hazard
Do not let the burner flame extend beyond the edge of
the pan.
Turn off all controls when not cooking.
Failure to follow these instructions can result in death
or fire.
SETTING RECOMMENDED USE
Lite ■Light the burner.
Hi ■Start food cooking.
■Bring liquid to a boil.
Medium High
Between Med & Hi
■Hold a rapid boil.
■Quickly brown or sear food.
Med
Medium
■Fry or sauté foods.
■Maintain a slow boil.
■Cook soups, sauces and gravies.
Medium Low
Between Med & Lo
■Stew or steam foods.
■Simmer.
Lo ■Keep food warm.
A. Burner cap
B. Alignment pins
C. Igniter
D. Burner base
E. Gas tube opening
REMEMBER: When cooktop is in use, the entire cooktop
area may become hot.
A
B
C
D
E

10
Gas tube opening: Gas must flow freely throughout the gas tube
opening for the burner to light properly. Keep this area free of soil
and do not allow spills, food, cleaning agents or any other
material to enter the gas tube opening. Keep spillovers out of the
gas tube opening by always using a burner cap.
Burner ports: Check burner flames occasionally for proper size
and shape as shown above. A good flame is blue in color, not
yellow. Keep this area free of soil and do not allow spills, food,
cleaning agents or any other material to enter the burner ports.
To Clean:
IMPORTANT: Before cleaning, make sure all controls are off and
the cooktop is cool. Do not use oven cleaners, bleach or rust
removers.
1. Remove the burner cap from the burner base and clean
according to “General Cleaning” section.
2. Clean the gas tube opening with a damp cloth.
3. Clean clogged burner ports with a straight pin as shown. Do
not enlarge or distort the port. Do not use a wooden
toothpick. If the burner needs to be adjusted, contact a
trained repair specialist.
4. Replace the burner cap, making sure the alignment pins on
the cap are properly aligned with the burner base.
5. Turn on the burner. If the burner does not light, check cap
alignment. If the burner still does not light, do not service the
sealed burner yourself. Contact a trained repair specialist.
Surface Grates with Locator Pin
Surface Grates
The grates located on the left and right side of the cooktop
contain grooves. These grooves must always face inward toward
the control knob panel to hold the grates in place. On some
models, the middle grate must be placed in position first,
followed by the left and right grates.
Locator Pin
On all models except for model KGCV566, the locator pin on the
grate must be positioned in the burner cap hole to hold the grate
in place.
Ceramic Glass Surface
Wiping off the cooktop before and after each use will help keep it
free from stains. For more information, see “General Cleaning”
section.
■Do not store jars or cans above the cooktop. Dropping a
heavy or hard object onto the cooktop could crack the
ceramic glass.
■For foods containing sugar in any form, clean up all spills and
soils as soon as possible. Allow the cooktop to cool down
slightly. Then, while wearing oven mitts, remove the spills
while the surface is still warm. If sugary spills are allowed to
cool down, they can adhere to the cooktop and can cause
pitting and permanent marks.
■Do not allow objects that could melt, such as plastic or
aluminum foil, to touch any part of the entire cooktop.
■Make sure the bottoms of pots and pans are clean and dry
before using them. Residue and water can leave deposits
when heated.
A. 1-1¹⁄₂" (25-38 mm)
B. Burner ports
A. Incorrect
B. Correct
B
A
A
B
A. Left grate
B. Middle grate
C. Groove
A. Locator pin
B. Burner cap
A
B
C
A
B
