KitchenAid KBFU271 Product information sheet

FREESTANDING AND BUILT-IN
OUTDOOR REFRESHMENT CENTER
Installation Instructions and Use & Care Guide
For questions about features, operation/performance, parts, accessories or service, call: 1-800-422-1230
or visit our website at www.kitchenaid.com
In Canada, for assistance, installation and service, call: 1-800-807-6777
or visit our website at www.KitchenAid.ca
COMPTOIR POUR RAFRAÎCHISSEMENTS
D'EXTÉRIEUR - AUTOPORTANT ET ENCASTRÉ
Instructions d’installation et Guide d’utilisation et d’entretien
Au Canada, pour assistance, installation ou service composez le 1-800-807-6777 ou visitez notre site web
www.KitchenAid.ca
Table of Contents/Table des matières.............................................................................2
Models/Modèles KFFU271 KBFU271
W10110733B

2
TABLE OF CONTENTS
OUTDOOR REFRESHMENT CENTER SAFETY ..........................2
INSTALLATION REQUIREMENTS................................................3
Tools and Parts ............................................................................3
Location Requirements................................................................3
Cabinet Cutout Dimensions.........................................................4
INSTALLATION INSTRUCTIONS..................................................6
Built-In Refreshment Center ........................................................6
Freestanding Refreshment Center...............................................7
REFRESHMENT CENTER CARE ..................................................8
General Cleaning..........................................................................8
Cabinet Door Alignment...............................................................9
Cabinet Door Removal.................................................................9
Attach Condiment Shelf.............................................................10
ASSISTANCE OR SERVICE.........................................................11
In the U.S.A. ...............................................................................11
Accessories................................................................................11
In Canada ...................................................................................11
WARRANTY ..................................................................................11
TABLE DES MATIÈRES
SÉCURITÉ DU COMPTOIR POUR
RAFRAÎCHISSEMENTS D'EXTÉRIEUR......................................13
EXIGENCES D'INSTALLATION...................................................14
Outillage et pièces......................................................................14
Exigences d'emplacement.........................................................14
Dimensions de l'ouverture à découper dans le placard............15
INSTRUCTIONS D'INSTALLATION.............................................17
Comptoir pour rafraîchissements encastré ...............................17
Comptoir pour rafraîchissements autoportant ..........................18
ENTRETIEN DU COMPTOIR POUR
RAFRAÎCHISSEMENTS ...............................................................20
Nettoyage général ......................................................................20
Alignement de la porte du placard.............................................21
Dépose de la porte du placard ..................................................21
Fixation de l'étagère à condiments............................................22
ASSISTANCE OU SERVICE.........................................................23
Accessoires ................................................................................23
Au Canada..................................................................................23
GARANTIE.....................................................................................23
OUTDOOR REFRESHMENT CENTER SAFETY
You can be killed or seriously injured if you don't immediately
You can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING

3
INSTALLATION REQUIREMENTS
Tools and Parts
Gather the required tools and parts before starting installation.
Read and follow the instructions provided with any tools listed
here.
Tools needed
■Level
■Phillips screwdriver
■Short Phillips screwdriver or a 90° screwdriver with a Phillips
screw bit
■Tape measure
■Slip-joint pliers
■Pipe wrench
■Adjustable wrench
Parts supplied
■Faucet
■Cutting board
■Ice bin covers
■4 - Condiment bins with lids
■Bottle cap container
■Bottle container
■Rear mounting flange and mounting screws (on built-in model
only)
Parts needed
■NSF or UPC listed water connection lines or hose
■All weather clear silicone
Location Requirements
IMPORTANT: Observe all governing codes and ordinances.
Product Dimensions
Freestanding Models
The freestanding model must have suitable drain systems in
accordance with local codes for the ice bin and sink drains.
Built-In Models
Cabinet Dimensions (for built-in model)
Provide suitable drain systems in accordance with local codes for
ice bin and sink drains. The drains and filter must be accessible.
A. 17¹⁄₄" (43.8 cm)
B. 30" (76.2 cm)
C. 36⁷⁄₈" (93.7 cm)
D. 26³⁄₈" (67.0 cm)
A
A
C
D
B
A. 26³⁄₈" (67.0 cm)
B. 30" (76.2 cm)
C. 10" (25.4 cm)
D. 22³⁄₄" (57.8 cm)
A
C
D
B

4
Cabinet Cutout Dimensions
The dimension chart and illustration below include cutout dimensions and minimum spacing requirements for all built-in outdoor
products. The illustration is for reference. The design of your cabinet layout can be personalized, but the dimensions for the cutouts and
minimum spacing must be followed.
Installation must conform to local codes.
C
E
D
HA
G
K
KF
K
B
J
D
E
20⁵⁄₈" (52.4 cm)
1¹⁄₂"
(3.8 cm) min.
3" (7.6 cm) min.
to open hood
2¹⁄₂" (6.4 cm) min.
12" (30.5 cm) min.
to any accessory
12" min.
to any
accessory
20⁷⁄₈" (53.0 cm)
9¹⁄₈"
(23.2 cm)
5"
(12.7 cm) min.
C
M
L
K
K
Grills or
Refreshment Centers
Side,
Sear
or
Power™
Burners
Warming
Drawer Access Doors
Refrigerator
or
Ice Maker
Utility
or
Trash
Drawer
Minimum Spacing Requirement Between Cutouts - Dimension K
Between 2 or more sets of Access Doors adjacent to each other:
K = 14" (35.6 cm) when 2 adjacent doors are opened to 90 degrees
K = 8" (20.3 cm) when 1 of the adjacent doors is opened to 90 degrees
Between a set of Access Doors and a Trash Drawer, Utility Drawer, Warming Drawer, Refrigerator, or Ice Maker:
K = 8" (20.3 cm) when 1 of the adjacent doors is opened to 90 degrees
Between a Trash Drawer, Utility Drawer, or Warming Drawer:
K = 3" (7.6 cm)
Cabinet Height and Depth Dimensions
Dimension A Minimum Dimension B Minimum
With outdoor refrigerator 37" (94.0 cm) 26" (66.0 cm)
Grill with insulated jacket 36½" (92.7 cm) 27" (68.6 cm)
Grill without insulated jacket 35½" (90.2 cm) 26" (66.0 cm)

5
*Dimension L is the minimum mounting surface area around the opening for mounting the optional door or drawers.
Cutout Dimensions - Built-in Grill
Grill Size Dimension C Dimension D Dimension E
27" (68.6 cm) 29⁵⁄₈" (75.2 cm) 10¾" (27.3 cm) 22⁷⁄₈" (58.1 cm)
36" (91.4 cm) 38⁵⁄₈" (98.1 cm) 10¾" (27.3 cm) 22⁷⁄₈" (58.1 cm)
48" (121.9 cm) 50⁵⁄₈" (128.6 cm) 10¾" (27.3 cm) 22⁷⁄₈" (58.1 cm)
Cutout Dimensions - Built-in Grill with Insulated Jacket
Grill Size Dimension C Dimension D Dimension E
27" (68.6 cm) 33" (83.8 cm) 11¾" (29.8 cm) 24" (61.0 cm)
36" (91.4 cm) 42" (106.7 cm) 11¾" (29.8 cm) 24" (61.0 cm)
48" (121.9 cm) 54" (137.2 cm) 11¾" (29.8 cm) 24" (61.0 cm)
Cutout Dimensions - Built-in Power Burner
Dimension C Dimension D Dimension E
19³⁄₈" (49.2 cm) 10¾" (27.3 cm) 19¾" (50.2 cm)
Cutout Dimensions - Built-in Side Burner
Burner Position Dimension C Dimension D Dimension E
Front to Back 13½" (34.3 cm) 10¾" (27.3 cm) 22⁵⁄₈" (57.5 cm)
Side by Side 24½" (62.2 cm) 10¾" (27.3 cm) 16⁷⁄₈" (42.9 cm)
Cutout Dimensions - Built-in Sear Burner
Dimension C Dimension D Dimension E
13½" (34.3 cm) 10⁵⁄₈" (27.0 cm) 22¹¹⁄₁₆" (57.6 cm)
Cutout Dimensions - Built-in Refreshment Center
Dimension C Dimension D Dimension E
30½" (77.5 cm) 10¾" (27.3 cm) 23" (58.4 cm)
Cutout Dimensions - Built-in Access Doors
Door Size Dimension F Dimension L*
18" (45.7 cm) 16³⁄₁₆" (41.1 cm) 1½" (3.8 cm)
27" (68.6 cm) 25¹⁄₈" (63.8 cm) 1½" (3.8 cm)
30" (76.2 cm) 28¹⁄₈" (71.4 cm) 1½" (3.8 cm)
36" (91.4 cm) 34¹⁄₈" (86.7 cm) 1½" (3.8 cm)
48" (121.9 cm) 46¹⁄₈" (117.2 cm) 1½" (3.8 cm)
Cutout Dimensions - Outdoor Refrigerator
Dimension G Dimension H
24" (61.0 cm) 35¼" (89.5 cm)
Cutout Dimensions - Outdoor Ice Maker
Dimension G Dimension H
18" (45.7 cm) 34" (86.4 cm) min. to 34½" (87.6 cm) max.

6
*Dimension L is the minimum mounting surface area around the opening for mounting the optional door or drawers.
INSTALLATION INSTRUCTIONS
Built-In Refreshment Center
Use a certified plumber to connect and install potable water
supply and drain system to outdoor refreshment center
according to local code requirements.
1. Using two or more people, set the refreshment center on a
covered surface.
2. Install rear flange to back of built-in refreshment center using
4 mounting screws provided.
3. Check that you have the drain connections, in accordance
with local codes, under the refreshment center.
4. Remove the faucet from the ice bin.
5. Install the faucet and fasten securely.
6. Install water inlet connector in a convenient location under
the cutout. Position the water inlet connector so that the
plastic tubing easily reaches the filter inlet connection.
7. Connect ice bin drain and sink drain fittings to drain system in
accordance with local code requirements.
Cutout Dimensions - Built-in Warming Drawer
Warming Drawer Size Dimension J
24" (61.0 cm) 22½" (57.2 cm)
Cutout Dimensions - Built-in Utility Drawer and Built-in Trash Drawer
Dimension M Dimension L*
12¼" (31.1 cm) 1½" (3.8 cm)
A. Rear flange
WARNING
Excessive Weight Hazard
Use two or more people to move and install
refreshment center.
Failure to do so can result in back or other injury.
A
A. Faucet
B. Brass escutcheon with “O” ring
C. Sink
D. Plastic washer
E. Locking nut
A. Plastic tubing from water filter
(inlet)
B. Hose connector
C. Hose connector nut
D. Brass locking nut
E. Inlet connector (¾" MHT x ½"
MIP hose adapter)
F. Exterior side of mounting panel
A
B
C
D
E
A
BC
E
D
F

7
8. Apply a bead of all weather clear silicone on the underside of
the two sides of mounting trim.
9. Using two or more people, place the refreshment center into
the cutout. Immediately remove any excess silicone.
10. Connect the plastic tubing from the water filter to the faucet
connection and securely tighten.
11. Attach the plastic tubing from the water inlet connection to
the inlet side of the filter. Use NSF or UPC listed water
connection line for water supply to inlet connector. Potable
water supply system must be connected to inlet connector
according to local code requirements.
12. Unwrap the sliding cover and place into frame on top of the
ice bin.
Freestanding Refreshment Center
Use a certified plumber to connect and install potable water
supply and drain system to outdoor refreshment center
according to local code requirements.
1. Check that you have adequate drain connections for the
refreshment center.
2. Remove the faucet from the ice bin.
3. Install the faucet and securely fasten.
4. Connect the plastic tubing from the water filter to the faucet
connection and securely tighten.
A. Underside of mounting trim
A. Plastic tube insert
B. Plastic ferrule
C. Compression nut
D. Plastic tubing from water filter (outlet)
E. Filter
A. Plastic tubing
B. Inlet connector
C. Filter
D. NSF or UPC listed water supply line or hose
A
D
E
A
B
C
A
B
CD
A. Faucet
B. Brass escutcheon with “O” ring
C. Sink
D. Plastic washer
E. Locking nut
A. Plastic tube insert
B. Plastic ferrule
C. Compression nut
D. Plastic tubing from water filter (outlet)
E. Filter
WARNING
Excessive Weight Hazard
Use two or more people to move and install
refreshment center.
Failure to do so can result in back or other injury.
A
B
C
D
E
D
E
A
B
C

8
5. Install water inlet connector through hole provided in cabinet
rear panel. 6. Attach the plastic tubing from the water inlet connection to the inlet side of the filter. Use NSF or UPC listed water
connection line for water supply to inlet connector. Potable
water supply system must be connected to inlet connector
according to local code requirements.
7. Unwrap the sliding cover and place into frame on top of the
ice bin.
8. Rotate the side shelves up into their locked position or leave
down as needed.
9. Lock the front locking caster wheels to keep refreshment
center from moving.
REFRESHMENT CENTER CARE
General Cleaning
IMPORTANT: Always follow label instructions on cleaning
products.
Soap, water and a soft cloth or sponge are suggested first unless
otherwise noted.
To avoid weather damage use the accessory cover designed for
the Outdoor Refreshment Center.
STAINLESS STEEL
Cleaning Method:
Rub in direction of grain to avoid damaging stainless steel
surface.
■Food spills should be cleaned as soon as possible. Spills may
cause permanent discoloration. Use stainless steel cleaner
and polish to clean spills.
KitchenAid®Stainless Steel Cleaner and Polish Part Number
4396920 (not included) or KitchenAid®Stainless Steel Wipes
Part Number 8212510 (not included):
See “Assistance or Service” section to order.
■Liquid detergent or all-purpose cleaner:
Rinse with clean water and dry with soft, lint-free cloth.
■Vinegar for hard water spots
■Use a glass cleaner to remove fingerprints.
To avoid damage to stainless steel surfaces, do not use soap-
filled scouring pads, abrasive cleaners, cleaners containing
chlorine, Cooktop Polishing Creme, steel-wool pads, gritty
washcloths or some paper towels.
REFRESHMENT CENTER WATER FILTER
■Filter should be replaced every 6 to 12 months.
To remove filter, turn filter counterclockwise ¹⁄₄ turn and
remove.
To install filter, push in new cartridge and turn clockwise.
REFRESHMENT CENTER EXTERIOR
The quality of this material resists most stains and pitting,
providing that the surface is kept clean and covered.
Cleaning Method:
■Apply stainless steel polish to all areas before first use.
Apply after each cleaning to avoid damage refreshment
center exterior surface.
■Cleaning should always be followed by rinsing with clean,
warm water.
■Use a metal polish or stainless steel brightener to remove
fingerprints, water spots, oxidation, and food stains. Always
follow the manufacturer’s directions.
■Wipe the surface completely dry with a soft cloth.
Winterization of faucet and drain system
When temperatures are below 35°F (1.7°C) for an extended
period of time:
1. Turn off water source to sink.
2. Remove potable water supply system from inlet connection
and store it appropriately.
A. Plastic tubing from water filter
(inlet)
B. Hose connector
C. Hose connector nut
D. Brass locking nut
E. Inlet connector (¾" MHT x ½"
MIP hose adapter)
F. Exterior side of mounting panel
A
BC
E
D
F
A. Plastic tubing
B. Inlet connector
C. Filter
D. NSF or UPC listed water supply line or hose
A
B
CD

9
3. Remove filter from its connection and discard. (Follow the
instructions provided with your refreshment center water filter
to replace. See “Assistance or Service” section to order.)
4. Disconnect ice bin and sink drain and plastic tubing from the
filter connector and allow to drain.
5. Cover refreshment center with accessory cover or tarpaulin.
Cabinet Door Alignment
Style 2 Only
Your cabinet door(s) can be realigned if necessary.
1. Check door to determine alignment requirements.
2. Open the cabinet door.
3. Locate and loosen the 4 door hinge mounting screws ½ turn.
4. Adjust the top or bottom of the door in the direction
necessary to align the door.
5. Tighten the 4 door hinge mounting screws.
6. Close the door and check alignment.
7. Readjust the door using steps 2 through 6 if necessary.
8. Repeat steps 1 through 7 on the other door if necessary.
Cabinet Door Removal
The door(s) can be removed if necessary to gain access to the
inside of the cabinet area.
Style 1
To Remove the Door:
1. Open cabinet door.
2. Lift door to slide door hinge pins from hinge brackets on
cabinet.
3. Repeat steps 1 and 2 for the other door if necessary.
To Replace the Door:
1. Position hinge pins on the door with the hinge brackets on
the cabinet. Gently push down to slide the pins into place.
2. Repeat Step 1 for the other door if necessary.
A. Plastic tubing
A. Top screws (2 - underside of frame)
B. Bottom screws (2)
A
A
B
A. Door hinge pin
B. Hinge bracket
A. Door hinge pin
B. Hinge bracket
A
B
A
B

10
Style 2
To Remove the Door:
1. Open the door to the fully open position.
2. Locate and remove the 4 door hinge mounting screws.
3. Pull the door away from the center to slide the door hinges
out of the slots in the frame.
4. Repeat steps 1 through 3 for the other door if necessary.
To Replace the Door:
1. Slide the door hinges into the slots in the frame and push in
to seat hinges.
2. Locate the 4 hinge screw mounting holes through the top and
bottom of the frame and replace the 4 screws. Do not tighten.
3. Check and adjust door then tighten the screws. See “Cabinet
Door Alignment.”
4. Repeat steps 1 through 3 for the other door if necessary.
Attach Condiment Shelf
1. Open cabinet door.
2. Use a short Phillips screwdriver or a 90° screwdriver with a
Phillips screw bit to loosen the 2 mounting screws on the
inner door panel.
3. Position the condiment shelf so that the large ends of the
keyhole slots are over the 2 mounting screws.
4. Lower the condiment shelf until the 2 mounting screws are in
the narrow ends of the keyhole slots.
5. Tighten the screws.
A. Top screws (2 - underside of frame)
B. Bottom screws (2)
A
B
A. Mounting screws
A. Mounting screw in keyhole slot
B. Condiment shelf
A
B
A
