KitchenAid 5KHMB732C User manual

7 Speed Cordless Hand Mixer
5KHMB732C

2
PARTS AND FEATURES
1Upright Stance
2Motor Body
3Beaters
4Eject Button
5Battery Status Indicator
6Charging Port
7Speed Controller
8 Handle
9Charger Adapter
10 Charger Adapter Pin
3
6
5
7
8
2
4
9
1
10

ENGLISH
3
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be
followed, including the following:
1. Read all instructions. Misuse of appliance may result in personal injury.
2. To protect against risk of electrical shock, do not put the Motor Body of Cordless
Hand Mixer, Charger Adapter, cord, or electrical plug in water or other liquid.
3. This appliance is not intended for use by persons (including children) with reduced
physical, sensory, or mental capabilities, or lack of experience and knowledge,
unless they are closely supervised and instructed concerning use of the appliance
by a person responsible for their safety.
4. Close supervision is necessary when any appliance is used by or near children.
5. Children should be supervised to ensure that they do not play with the appliance.
6. Turn the appliance OFF when not in use, before assembling or disassembling
parts and before cleaning. To unplug the charger, grasp the plug and pull from the
outlet. Never pull from the power cord.
7. Do not use an extension cord. Plug charger directly into an electric outlet.
8. WARNING: For the purposes of recharging the battery, only use the detachable
supply unit provided with this appliance. Do not attempt to use this charger
(Charger Model - ZD12D140080CN) with any other product. Likewise, do not
attempt to charge this appliance with any other charger.
9. This appliance contains batteries that are non-replaceable and an adapter
ZD12D140080CN.
10.Do not incinerate this appliance even if it is severely damaged. The batteries can
explode in a re.
11.Avoid contacting moving parts. Keep hands, hair clothing, as well as spatulas
and other utensils away from Beaters and accessories during operation to reduce
the risk of injury to persons or damage to the Cordless Hand Mixer.
PRODUCT SAFETY

4
12.Do not operate any appliance with a damaged cord or plug, or after the appliance
malfunctions, or is dropped or damaged in any manner. Return appliance to
the nearest Authorised Service Facility for examination, repair, or electrical or
mechanical adjustment.
13.The use of attachments not recommended or sold by KitchenAid may cause re,
electric shock, or injury.
14.Do not use the appliance outdoors.
15.Do not let cord hang over edge of table or counter.
16.Never leave the appliance unattended while it is in operation.
17.Do not let cord contact hot surface, including the stove.
18.Remove Beaters or accessories from the Cordless Hand Mixer before washing.
19.Switch off the appliance and disconnect from supply before changing accessories
or approaching parts that move in use.
20.Refer to the “Care and Cleaning” section for instructions on cleaning the surfaces
in contact with food.
21.This appliance is intended to be used in household and similar applications such
as:
- staff kitchen areas in shops, ofces and other working environments;
- farm houses;
- by clients in hotels, motels and other residential type environments;
- bed and breakfast type environments.
SAVE THESE INSTRUCTIONS
PRODUCT SAFETY
LITHIUM-ION BATTERY OPERATED PRODUCT DISPOSAL
Always dispose the battery operated products according to federal, state, and local
regulations. Contact a recycling agency in your area for recycling locations.
ELECTRICAL REQUIREMENTS
Charger Adapter:
Input: 100-240 VAC 50/60 Hz
Cordless Hand Mixer:
Voltage: 12 Volts
NOTE: If the plug does not fit fully in the outlet, contact a qualified electrician.
Do not modify the plug in any way.

ENGLISH
5
GETTING STARTED
1. Charge the battery until the Battery Status Indicator turns solid green.
2. Clean all the parts. (see "Care and Cleaning" section).
3. Remove all packaging materials, if present.
Battery
Status % Battery Status Full Charge* Quick Charge**
Green 30 % to 100 %
200 cookies 1 cake batter
Yellow 15 % - 30 % (Consider Charging)
Red Lower than 15 % (Need to charge soon)
BEFORE FIRST USE
*Full Charge:
The Cordless Hand Mixer will be fully charged in 2 hours. The Battery Status Indicator pulses
when it charges and turns to solid green with a full charge.
The Cordless Hand Mixer will prepare approximately 200 cookies, based on 4 batches of
chocolate chip cookies when following the recommended battery maintenance.
**Quick Charge:
In 10 minutes the Cordless Hand Mixer will quick charge. The Cordless Hand Mixer will stir
up a cake batter recipe with one quick charge when following the recommended battery
maintenance.
NOTE: Make sure to charge the battery, when the Battery Status Indicator is yellow.
NOTE: It is best to store the Cordless Hand Mixer at room temperature.
BATTERY STATUS
BATTERY CHARGING
First, slide the Speed Controller to "O"
position and insert the Charger Adapter
pin into the Charging Port.
Plug the Charger Adapter into an earthed
electrical outlet.
2
1

6
BATTERY CHARGING
IMPORTANT: Make sure that the Speed
Controller is at "O" position before
attaching and removing Beaters.
1
3
The Battery Status Indicator pulses when it
charges. It will be fully charged in 2 hours
and the Battery Status Indicator turns solid
green.
PRODUCT ASSEMBLY
There are two Beaters. One is without a
collar (A) and another with a collar (B).
2
B
A
Insert the Beaters without a collar (A) into
the smaller opening (C) and Beaters with a
collar (B) into the larger opening (D). Align
and push to lock into place. Both the
Beaters will click in.
D
C
B
A
3

ENGLISH
7
1
Always start mixing at the lowest speed,
and by sliding the Speed Controller,
increase the speed according to the
recipes.
When finished, slide the Speed controller
to "O" position.
3
PRODUCT USAGE
To increase the speed, slide the Speed
Controller forward ( ). To decrease
the speed, slide the Speed Controller
backward ( ).
2
NOTE: Make sure the Cordless Hand Mixer is charged before use. Do not operate
continuously for more than 1 minute.
CARE AND CLEANING
IMPORTANT: Make sure the Speed Controller is at "O" before attaching or removing
Beaters.
Press the Eject Button to release the
Beaters from the Cordless Hand Mixer.
1
Always remove the Beaters from the
Cordless Hand Mixer before cleaning.
Wash in dishwasher, or by hand in warm,
soapy water. Rinse and wipe dry.
2
When finished, slide the Speed Controller
to "O" position.

8
Wipe the Cordless Hand Mixer with a
damp cloth. Dry with a soft cloth.
3
NOTE: To avoid damage to the Cordless Hand Mixer, do not immerse in water.
TROUBLESHOOTING GUIDE
Problem Solution
If the Cordless Hand Mixer fails
to start:
Check if the product is charged.
Charge the battery when the Battery Status Indicator is
red or when the Battery is completely drained.
If the Cordless Hand Mixer is not
getting charged:
If you have a Circuit Breaker Box, make sure that the
circuit is closed.
If the problem cannot be
corrected:
See the “Warranty and Service" sections. Do not return
the Cordless Hand Mixer to the retailer. Retailers do not
provide service.
CARE AND CLEANING
©2021 All rights reserved.

9
简体中文
零部件与功能
1直立底座
2电机本体
3搅拌器
4弹出按钮
5电池状态指示灯
6充电口
7速度控制器
8
手柄
9充电器适配器
10 充电器适配器接头
3
6
5
7
8
2
4
9
1
10

10
警告
危险 如果不立即遵守说明，可能导致 死亡 或
重伤。
如果不遵守说明，可能导致死亡或重伤。
我们已在本手册以及您的家电上提供了许多重要的安全信息。请务必阅读并遵循
所有安全消息。
这是安全警示符号。
此符号警示您可能导致您和他人伤亡的潜在危险。
所有安全信息都有安全警示符号和警示语“危险”或“警告”。这
些词的含义是：
所有安全信息都将指出潜在危险是什么，如何降低受伤的几率，以及不遵守说明
将会发生什么。
您的安全和其他人的安全非常重要。
重要保护措施
使用电器时，应始终遵循基本的安全预防措施，包括：
1. 阅读所有说明。电器使用不当可能导致人身伤害。
2. 为避免触电风险，请勿将无线手持混合器的电机本体、充电适配器、电源线或电插
头放入水中或其他液体中。
3. 本电器不适合以下人群（包括儿童）使用：行动不便者、知觉或智商缺陷者、
缺少经验和常识者，除非其在密切监督和指导下使用，以确保安全。
4. 儿童使用或在儿童附近使用电器时，需要密切监督。
5. 儿童需有成人看护，以确保其不会将本电器当做玩具。
6. 不使用时、组装或拆卸零部件前以及清洁前，请先将电器转向 OFF（关闭）。
拔出充电器时，抓牢插头并将其从插座中拔出。切勿拉扯电源线。
7. 请勿使用加长电源线。将充电器直接插入电源插座。
8. 警告：为电池充电时，只能使用本电器附带的可拆卸供电单元。请勿尝试使用本充
电器（充电器型号：ZD12D140080CN）为任何其他产品充电。同样，请勿尝试使
用任何其他充电器为本电器充电。
9. 本电器包含不可更换电池和适配器 ZD12D140080CN。
10. 即使电器损坏严重，也请勿将其烧毁。燃烧时电池会爆炸。
11. 避免接触运动部件。操作期间，手、头发、衣物、刮刀以及其他餐具需远离搅拌器和配件，
以降低人员受伤或无线手持混合器损坏风险。
12. 若电源线或插头受损，或电器发生故障、跌落或任何形式的损坏，请勿操作电器。
请将电器退回至最近的授权服务中心进行检查、修理或进行电气或机械调整。
13. 使用非 KitchenAid 推荐或出售的配件可能引起火灾、触电或受伤。
14. 请勿在室外使用本电器。
15. 请勿将电源线挂在桌子或橱柜边缘。
16. 切勿在无人看管的情况下运行本电器。
17. 请勿让电源线接触热烫表面，包括炉子。
产品安全性
