KitchenAid 9KHM92 User manual

9KHM92
9KHM9213

2
HAND MIXER INSTRUCTIONSHAND MIXER INSTRUCTIONS
HAND MIXER SAFETY .................................................................................................2
Important Safeguards.................................................................................................3
Electrical Requirements.............................................................................................3
PARTS AND FEATURES................................................................................................4
ACCESSORY GUIDE ......................................................................................................5
SETTING UP YOUR HAND MIXER
Attaching the accessories ..........................................................................................5
Removing the accessories..........................................................................................6
USING YOUR HAND MIXER
Operating the speed control .....................................................................................7
Speed control guide ..................................................................................................8
CARE AND CLEANING
Cleaning the Hand Mixer body..................................................................................9
Cleaning the accessories............................................................................................9
Cleaning the storage bag ...........................................................................................9
TROUBLESHOOTING .................................................................................................10
TABLE OF CONTENTS
HAND MIXER SAFETY

3
English
HAND MIXER SAFETYHAND MIXER INSTRUCTIONS HAND MIXER SAFETYHAND MIXER INSTRUCTIONS
IMPORTANT SAFEGUARDS
SAVE THESE INSTRUCTIONS
Electrical requirements
Volts: 100 A.C. only
Frequency: 50/60 Hz
Wattage: 100 W
HAND MIXER SAFETY
When using electrical appliances, basic safety precautions
should always be followed, including the following:
1. Read all instructions.
2. To protect against risk of electrical shock, do not put Hand
Mixer in water or other liquid.
3. Unplug Hand Mixer from the outlet when not in use, before
putting on or taking off parts, and before cleaning.
4. Avoid contacting moving parts. Keep hands, hair, clothing, as
well as spatulas and other utensils away from all accessories
during operation to reduce the risk of injury to persons and/
or damage to the Hand Mixer.
5. Do not operate the Hand Mixer with a damaged cord or
plug, or after the Hand Mixer malfunctions, or is dropped
or damaged in any manner. Return the Hand Mixer to the
nearest Authorized Service Center for examination, repair,
or electrical or mechanical adjustment.
6. The use of attachments not recommended or sold by
KitchenAid may cause re, electric shock, or injury.
7. Do not use the Hand Mixer outdoors.
8. Do not let cord hang over edge of table or counter.
9. Do not let cord contact hot surface, including the stove.
10. Remove any accessories from Hand Mixer before washing.
11. This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of
the appliance by a person responsible for their safety.
12. Children should be supervised to ensure that they do not
play with the appliance.
13. Switch off the appliance and disconnect from supply before
changing accessories or approaching parts that move in use.

4
HAND MIXER INSTRUCTIONSPARTS AND FEATURES
Hand Mixer parts and accessories
Swivel lock
power cord
Soft grip handle Oversized beater
ejector button
Digital speed control
Air
vents
Non-tip
heel rest
Cord strap
Liquid blender
rod accessory
Artisan BeaterTM
accessory
(Included with
KHM9213)
Turbo BeaterTM II
accessory
Dough hooks accessory 16-Tine pro whisk
accessory
Storage bag
* Included with
Model 9KHM92.
* Included with
Model 9KHM92.

5
English
HAND MIXER SAFETYHAND MIXER INSTRUCTIONS ACCESSORY GUIDE
SETTING UP YOUR HAND MIXER
Attaching the accessories
1Unplug the Hand Mixer from the
electrical outlet.
Injury Hazard
Unplug mixer before touching
beaters.
Failure to do so can result in
broken bones, cuts, or bruises.
IMPORTANT: Be sure to read and follow
the specific instructions in this manual for
proper use of the Hand Mixer.
Accessory Uses Included with Model
9KHM92 9KHM9213
Turbo Beater™II cookie dough
cake batter *
Artisan Beater™ cookie dough
cake batter *
Liquid blender rod smoothies, diet drink mixes, chocolate milk,
iced tea, milkshakes, soups, sauces *
Dough hooks yeast bread
doughs * *
16-Tine pro whisk whipped cream
whipped egg whites
sauces puddings * *
Storage bag† to store
accessories *
†Not sold as an accessory.

6
HAND MIXER INSTRUCTIONS
SETTING UP YOUR HAND MIXER
2Insert the accessory shaft with the collar
(D) into the larger opening (B) of the
Hand Mixer. Align the flanges on the
shaft with the slots in the opening. Push
to lock into place.
3Insert the accessory without a collar (C)
into the smaller opening (A). Align and
push to lock into place.
NOTE: An accessory shaft without a collar
may be used in either opening (A or B). Those
with a collar may only be used in the larger
opening (B).
CD
D
B
B
A
Paired accessories (beaters, optional dough
hooks) include one accessory with a collar
(D), and one without (C). Single accessories
come with a collar (D) (liquid blending rod)
or without (C) (whisk).
Removing the accessories
2Press the Ejector Button to release
the accessories from the Hand Mixer,
then remove them.
1If the Hand Mixer is running, stop
the Hand Mixer by sliding the Power
switch to the “O” (Off) position. Then,
unplug the Hand Mixer from the
electrical outlet.

7
English
HAND MIXER SAFETYHAND MIXER INSTRUCTIONS USING YOUR HAND MIXER
2Slide the Power switch to the “I” (ON)
position. The motor will automatically
start at Speed 1, and the “1” on the
Speed Indicator control will light up.
4When mixing job is finished, slide the
Power switch to the “O” (Off) position.
Unplug the Hand Mixer before removing
accessories.
3Touch the “UP (arrow)” button to
increase the mixing speed to the desired
setting. If necessary, touch the “DOWN
(arrow)” button to decrease the mixing
speed. See the “Speed Control Guide”
for more information.
NOTE: The Hand Mixer automatically
starts at Speed 1 every time it is turned on,
regardless of the Speed setting at the time
the Hand Mixer is shut off.
Operating the speed control
1Plug the Hand Mixer into an electrical
outlet.
Injury Hazard
Unplug mixer before touching
beaters.
Failure to do so can result in
broken bones, cuts, or bruises.
This KitchenAid Hand Mixer will beat faster and more thoroughly than most other electric
hand mixers. Therefore, the beating time in most recipes must be adjusted to avoid over
beating. Beating time is faster due to larger beater sizes.
To help determine the ideal beating time, observe the batter or dough and beat only until it
has the desired appearance described in your recipe, such as “smooth and creamy”.
To select the best beating speeds, use the “Speed control guide” section.

8
HAND MIXER INSTRUCTIONSUSING YOUR HAND MIXER
Speed control guide
NOTE: Beater accessories are not designed for mixing and kneading bread dough.
Special dough hook attachments are available. See “Accessories” section for details
and ordering information.
The 9-Speed Hand Mixer always starts on the lowest speed (Speed 1). Move
to higher speeds as needed, the speed setting indicator control will light up
with the corresponding number for each speed.
Speed Attachment Description
1For slow stirring, combining, and starting all
mixing procedures. Use this speed to stir
in nuts, chocolate chips, shredded cheese,
onions, olives, and other chunky ingredients.
2Mix flour and other dry ingredients with
liquids or other moist mixtures. Knead yeast
dough (bread, pizza dough) with the dough
hooks.
3Mix runny batters, such as pancake or
waffle batter.
4Combine heavy mixtures, such as cookie or
biscuit dough.
5Mix thick dough, such as muffin or cake batter.
Mash potatoes or squash.
6Blend butter and sugar. Mix frostings.
7Finish mixing cake and other batters.
8Whip cream and mousse mixtures.
9Beat egg white and meringue mixtures.

9
English
HAND MIXER SAFETYHAND MIXER INSTRUCTIONS CARE AND CLEANING
Electrical Shock Hazard
Do not put in water.
Doing so can result in death or
electrical shock.
Injury Hazard
Unplug mixer before touching
beaters.
Failure to do so can result in
broken bones, cuts, or bruises.
Cleaning the Hand Mixer body
Cleaning the accessories
Cleaning the storage bag
2Wipe Hand Mixer with a warm, soapy
cloth; then wipe clean with a damp
cloth. Dry with a soft cloth.
1Always unplug Hand Mixer before
cleaning. Wipe power cord and cord
strap with a warm, soapy cloth; then
wipe clean with a damp cloth. Dry with
a soft cloth.
Always remove beaters from Hand Mixer
before cleaning. Wash in dishwasher, or by hand
in warm, soapy water. Rinse and wipe dry.
Wipe storage bag with a warm, soapy cloth; then wipe clean with a damp cloth. Dry
with a soft cloth.
NOTE: Do not immerse Hand Mixer
in water.

10
HAND MIXER INSTRUCTIONS
TROUBLESHOOTING
First try the solutions suggested here and possibly avoid the cost of service.
1. Is the Hand Mixer plugged in?
2. Is the fuse in the circuit to the Hand
Mixer in working order? If you have
a circuit breaker box, make sure the
circuit is closed.
3. Try unplugging the Hand Mixer, then
plug it back in.
If the problem cannot be xed with the
steps provided in this section, then contact
KitchenAid or an Authorized Service Center.
If Hand Mixer malfunctions or fails to operate:
© 2013. All rights reserved.
