KitchenAid 5KEK1835A User manual

5KEK1835A
W10597348C_EN.indd 1 12/18/2018 4:36:26 PM

2| PARTS AND FEATURES
PARTS AND FEATURES
PARTS AND ACCESSORIES
Water filter
1.7 L (7 cup)
Electric
Kettle
Underside of base
with power cord wrap
Water gauge
window
Lid release button Water fill
location
Control panel
Base with power cord
W10597348C_EN.indd 2 12/18/2018 4:36:27 PM

ENGLISH
ELECTRIC KETTLE SAFETY | 3
ELECTRIC KETTLE SAFETY
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety
precautions should always be followed, including the
following:
1. Read all instructions. Misuse of appliance may result
in personal injury.
2. Do not touch hot surfaces. Use handles or knobs.
3. To protect against re, electric shock and injury to
persons do not immerse cord, plugs or appliance in
water or other liquid. Avoid spillage on the connector.
4. This appliance is not intended for use by persons
(including children) with reduced physical, sensory,
or mental capabilities, or lack of experience or
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
5. Children should be supervised to ensure that they do
not play with the appliance.
6. Close supervision is necessary when any appliance is
used by or near children.
W10597348C_EN.indd 3 12/18/2018 4:36:27 PM

4| ELECTRIC KETTLE SAFETY
ELECTRIC KETTLE SAFETY
7. If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualied
persons in order to avoid a hazard.
8. Unplug Electric Kettle from outlet when not in use and
before cleaning. Allow to cool before putting on or
taking off parts, and before cleaning the appliance.
9. Do not operate any appliance with a damaged cord
or plug or after the appliance malfunctions, or has
been damaged in any manner. Return appliance to the
nearest Authorised Service Centre for examination,
repair, or adjustment.
10. Use of replacement parts not recommended by
manufacturer may result in re, shock, or injury to
persons.
11. Do not use outdoors.
12. Do not let cord hang over edge of table or counter, or
touch hot surfaces.
13. To disconnect, turn any control to “OFF”, then remove
plug from wall outlet.
14. Do not place on or near a hot gas or electric burner, or
in a heated oven.
15. The Electric Kettle should only be used to heat water.
16. Do not use Electric Kettle with loose or weakened
handle.
17. Do not use the appliance for other than intended use.
18. Do not clean Electric Kettle with abrasive cleaners,
steel wool, or other abrasive materials.
19. The Electric Kettle is only to be used with the stand
provided.
20. Do not overll kettle. If the kettle is overlled, boiling
water may be ejected.
21. The heating element surface is subject to residual heat
after use. Do not touch hot surface. Use handles.
22. Scalding may occur if the lid is removed during the
brewing cycles.
W10597348C_EN.indd 4 12/18/2018 4:36:27 PM

ENGLISH
ELECTRIC KETTLE SAFETY | 5
23. Refer to the “Care and Cleaning” section for
instructions on cleaning the surfaces in contact with
food.
24. This appliance is intended to be used in household and
similar applications such as:
- staff kitchen areas in shops, ofces or other working
environments;
- farmhouses;
- by clients in hotels, motels and other residential type
environments;
- bed and breakfast type environments.
25. The temperature of accessible surfaces may be high
when the appliance is operating.
26. CAUTION: Do not operate the kettle on an inclined
plane. Do not operate the kettle unless the element
is fully immersed. Do not move while the kettle is
switched on.
27. Visit www.KitchenAid.com.au or www.KitchenAid.co.nz
website to download this instruction manual.
SAVE THESE INSTRUCTIONS
ELECTRIC KETTLE SAFETY
W10597348C_EN.indd 5 12/18/2018 4:36:27 PM

6| ELECTRIC KETTLE SAFETY
BATTERY ACTIVATION (OPTIONAL)
ELECTRIC KETTLE SAFETY
ELECTRICAL REQUIREMENTS
Electrical Shock Hazard
Plug into an earthed outlet.
Do not remove earth prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these
instructions can result in death,
re, or electrical shock.
Volts: 220-240 V
Hertz: 50-60 Hz
Wattage: 2400 W
NOTE: If the plug does not fit in the outlet,
contact a qualified electrician. Do not modify
the plug in any way.
Do not use an extension cord. If the power
supply cord is too short, have a qualified
electrician or service technician install an
outlet near the appliance.
A short power supply cord (or detachable
power supply cord) should be used to reduce
the risk resulting from becoming entangled in
or tripped over a longer cord.
NOTE: If batteries have been added and the Electric Kettle is off the base, the display
will show the current temperature of the water. Placing the Electric Kettle back on the
base will allow full functionality of the kettle to change the temperature, heat, and hold
temperature.
1
To provide power to the display when
the Electric Kettle is not on the base,
insert 2 AA batteries (not inlcuded) in
the battery housing on the underside of
the kettle.
W10597348C_EN.indd 6 12/18/2018 4:36:28 PM

ENGLISH
OPERATING THE ELECTRIC KETTLE | 7
BEFORE FIRST USEBEFORE FIRST USE
1
Open the lid of the Electric Kettle by
pressing the Lid Release Button.
2
Fill Electric Kettle. The water level is
displayed in .25 L increments. If there is
no water in the kettle, the water drop
icon will display and the alert tone will
sound for 6 seconds. Remove water if it
exceeds the “Max” line.
3
Push the lid down so it locks into the
closed position. You will hear a clicking
sound which indicates the lid is locked. 4
Place the Electric Kettle on the base.
OPERATING THE ELECTRIC KETTLE
Before first use, fill the Electric Kettle to the maximum level, then boil and discard the water.
The temperature can be displayed in Celsius (C) or Fahrenheit (F). To change setting, hold
the “-” and “+” buttons down at the same time.
NOTE: The Electric Kettle is designed for water only. Do not put any other liquids or
substances in the Electric Kettle.
FILLING THE ELECTRIC KETTLE WITH WATER
NOTE: There must be a minimum of .25 L of water for Electric Kettle to operate. Do
not exceed the “Max” fill line.
W10597348C_EN.indd 7 12/18/2018 4:36:30 PM

8| OPERATING THE ELECTRIC KETTLE
HEATING WATER
°C °F
50 122
55 131
60 140
65 149
70 158
75 167
80 176
85 185
90 194
95 203
100 212
1
Place the Electric Kettle on the base.
The display will show the default
temperature (100° C). Press the “+” or
“-” buttons to select your desired water
temperature. See the “Temperature
guide” for more information.
The Electric Kettle has eleven programmed
temperature settings.
OPERATING THE ELECTRIC KETTLE
4
Once the desired temperature has been
reached, three beeps will sound and the
word “Off” will show in the top corner
of the display.
If batteries have been added and the Electric
Kettle is off the base, push any button to
display the current temperature, and the
battery icon will display the battery charge
level.
NOTE: The temperature will blink 5 times and return to standby after 5 seconds. This
will continue until after the water temperature reduces below the desired temperature.
2
Press the start/cancel button to save
temperature and to begin heating the
water. “On” will be displayed on the
screen to indicate the Electric Kettle
is heating. The “Start/Cancel” button
does not function when the Electric
Kettle is off the base.
3
Once the water reaches 50° C, the
current temperature will show on the
main display, and continue heating until
the desired temperature is reached.
W10597348C_EN.indd 8 12/18/2018 4:36:32 PM

ENGLISH
OPERATING THE ELECTRIC KETTLE | 9
TEMPERATURE GUIDE
USING THE HOLD TEMP MODE
OPERATING THE ELECTRIC KETTLE
Use this guide for outstanding results from your KitchenAid Electric Kettle.
60° C 70° C 80° C 90° C 100° C
Delicate Tea Green Tea
Gyokuro
Sencha
Blooming Tea Black Tea
Earl Grey
English Breakfast
Boil Water
White Tea
Silver Needle
Chai
Green
White
Hot Chocolate Chai
Red
Green Tea
Bencha
Genmaicha
Oolong Tea Herbal Tea
Tisanes
Instant Soup
Oatmeal
Rooibos Tea
Yerba Maté
1
To activate the Hold Temp mode, leave
the Electric Kettle on the base after
reaching the selected temperature and
press the “Hold Temp” button. The
Electric Kettle will maintain the desired
temperature for up to 30 minutes.
2
The Hold Temp mode may be canceled
by pressing the Start/Cancel button.
NOTE: Hold Temp mode works for all temperatures. When using Hold Temp mode at
100° C, mode will activate at 92° C and 100° C depending on altitude.
W10597348C_EN.indd 9 12/18/2018 4:36:33 PM

10 | CARE AND CLEANING
TURNING OFF THE ELECTRIC KETTLE
CLEANING THE EXTERIOR
OPERATING THE ELECTRIC KETTLE
1
Press Start/Cancel while in heating
mode. Unplug cord when Electric Kettle
is not is use. 2
Press Start/Cancel while in Keep Warm
mode. Unplug cord when Electric Kettle
is not is use.
The Electric Kettle can be turned off in several ways:
IMPORTANT: Before cleaning, always disconnect the Electric Kettle from the electrical
outlet. Make sure the Electric Kettle has cooled completely.
1
The exterior of the Electric Kettle may
be cleaned with a damp cloth. Dry and
polish the Electric Kettle with a soft
cloth. Abrasives and scouring agents of
any kind are not recommended.
CARE AND CLEANING
W10597348C_EN.indd 10 12/18/2018 4:36:33 PM

ENGLISH
CARE AND CLEANING | 11
CLEANING THE FILTER
CARE AND CLEANING
1
To access filter: Open the lid; the filter
is located behind spout inside Electric
Kettle. Grasp the top of the filter to
remove.
2
Clean under hot water with a soft brush
or cloth to remove deposits, and replace
filter by sliding the filter into the slot
behind the spout.
The Electric Kettle features a removable mesh filter that traps scale deposits for cleaner water.
The filter will need to be cleaned periodically—more often if you have hard water.
NOTE: If calcium deposits remain on the filter, let it stand overnight in a solution of
water and white vinegar. Rinse the filter thoroughly and replace in the Electric Kettle.
REMOVING MINERAL DEPOSITS FROM THE INTERIOR
To get the best performance from your Electric Kettle, decalcification will be necessary. Calcium
deposits may form on the interior metal parts of the Electric Kettle. The cleaning interval will
depend on the hardness of the water you put in the Electric Kettle.
1
Fill the Electric Kettle with white vinegar
to the .25 L mark. Add water to the .75
L mark. Boil (100º C) and allow to stand
overnight.
2
Empty the solution from the Electric
Kettle.
W10597348C_EN.indd 11 12/18/2018 4:36:35 PM

12 | SERVICE
CUSTOMER SERVICE
In Australia:
For any questions, or to find the nearest Authorised KitchenAid Service Centre,
please find our contact details below.
NOTE: All service should be handled locally by an Authorised KitchenAid Service
Centre.
Toll free number: 1-800-990-990
Phone number: 02 49026500
Address Australia:
KitchenAid Australia Pty Ltd
6-8 Billbrooke Close
Cameron Park NSW 2285, Australia
Phone: [phone]
Mobile: [phone]
Email: [email protected]
In New Zealand:
Website: www.KitchenAid.co.nz
Email: [email protected]
Phone: [phone]
In other countries:
For all product related questions and after-sales matters, please contact your dealer to obtain
the name of the nearest Authorised KitchenAid Service/Customer Centre.
For more information, visit our website at:
www.KitchenAid.com.au
SERVICE
3
Fill the Electric Kettle with water, bring
to a boil and drain out the water. Repeat
this step twice. The Electric Kettle is
now ready to use.
CARE AND CLEANING
W10597348C_EN.indd 12 12/18/2018 4:36:35 PM

W10597348C_EN.indd 13 12/18/2018 4:36:35 PM

W10597348C_EN.indd 14 12/18/2018 4:36:35 PM

W10597348C_EN.indd 15 12/18/2018 4:36:35 PM

©2018 All rights reserved.
Specifications subject to change without notice.
W10597348C 12/18
W10597348C_EN.indd 16 12/18/2018 4:36:36 PM
