HOUSING AND CONTROL PARTS
1
For Models: KIRD802XSS3, KIRD862XSS3
30" AND 36"
RETRACTABLE DOWN DRAFT
VENT SYSTEM
10−96 Litho In U.S.A. (jcn) Part No. 4174507 Rev. A
HOUSING AND CONTROL PARTS
VENTILATION PARTS
2
For Models: KIRD802XSS3, KIRD862XSS3
4174507
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
1
Cover,
Controls (Top)
4360130
KIRD802
4360131
KIRD862
2
4360209
Button, Push
3
4360134
Housing, Switch
4
4360135
Switch, Fan
5
4360136
6
4360137
Knob
7
4360138
Panel, Control
8
4360139
End Cap (2)
9
4360140
Plate, Support
(Upper) (2)
10
Housing,
Non−Serviceable
11
Bracket, Support
4360141
Lower R.H.
4360170
Lower L.H.
12
4360142
Nut
13
4360143
Arm, Gear Motor
14
4360144
Arm, Cavity
15
4360145
Bolt
16
4360062
Strain Relief
17
4360006
Screw
18
4360146
Nut
19
4360147
Strain Relief
20
4360148
Screw
21
Cover, Housing
Non−Serviceable
22
4360149
Cover, Wiring Box
23
4360150
Nut
24
Guide, Housing
Non−Serviceable
25
4360152
Box, Wiring
26
4360153
Clamp
27
4360156
Nut
28
4360157
Spring
29
4360158
Washer
30
4360159
Bolt
31
4360160
Trim, R.H.
32
Cavity
Non−Serviceable
33
Filter, Grease
4360193
KIRD802
4360194
KIRD862
34
4360005
Washer
35
4360165
Terminal
36
4360196
Micro Switch (2)
37
4360166
Actuator,
Micro Switch (2)
38
4360167
Spring (2)
39
4360168
Cover, Switch (2)
40
4360169
Housing, Switch (2)
41
Support
4360171
L.H.
4360172
R.H.
42
4360173
Guide,
Housing (Back)
43
4360174
Spacer, Cavity (2)
44
4360044
Clamp, Cable
45
4360211
Connection, Wire
46
4360210
Switch
47
4360163
Bolt
48
4360164
Nut
49
4360229
Box, Microswitch
50
4360230
Cover, Box
51
4360155
Bracket, Motor
Following Parts Not Illustrated
Illus. Part
No. No. DESCRIPTION
End Cap (2)
4360198 Installation Kit
814380 Kit, Motor Mount
LITERATURE PARTS
LIT4360199
Installation
Instructions/
Use And Care Guide
1 4360192 Box, Blower
2 4360154 Motor, Gear
3 4360035 Micro Switch (3)
4 4360155 Bracket,
Motor Gear
5 4360059 Bracket, Capacitor
6 4360191 Cover, Blower Box
EXTERIOR VENTILATION PARTS
3
For Models: KIRD802XSS3, KIRD862XSS3
4174507
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
1
Power Unit
Complete
Model KPED890T
2
4173296
Roof Mounting Kit
(Dome cover
And Flashing)
5
4173414
Motor (Includes
Capacitor & Cap)
6
4173415
Blade, Fan
7
4173417
Cover, Motor
(Wall Mount)
8
4173416
Impeller
9
4173456
Plate, Adaptor
(With Damper)
10
Housing,
(Non−Serviceable)
11
Housing, Ring
(Non−Serviceable)
13
9" Elbow
(Not Included,
Purchase Locally)
OPTIONAL PARTS NOT INCLUDED
4360205
Trim Kit−White
(KIRD802)
4360207
Trim Kit−Black
(KIRD802)
4360206
Trim Kit−White
(KIRD862)
4360208
Trim Kit−Black
(KIRD862)
