ALL-PURPOSE 8"
TWO-WAY COMPACT
LOUDSPEAKER
SYSTEM
The Klipsch CA-8T compact full range
system is perfect for higher power pro-
fessional applications where flexible
mounting and extended range are
required, including everything needed
for fast and easy distributed sound
installations. Equally at home indoors
or out, in foreground or background,
higher SPLapplications, the CA-8T’s
appearance and Klipsch fidelity fit into
residential, business or recreational
environments equally well.
The UV- and weather-resistantABS
enclosure includes an internal multi-
tap transformer with switchable direct
8 ohm bypass, simplifying hookup to
any type of sound system. The C-
bracket assembly attaches to the enclo-
sure’s integral stainless steel threaded
studs with oversized knobs, ensuring
a positive position-lock and rapid "no-
pain" installation. External attachment
to the built-in security retainer pro-
vides an extra measure of safety,
protecting against unexpected
damage or removal.
The CA-8T includes a high power 8"
extended range low-frequency driver
and a 1" titanium diaphragm compres-
sion driver on a molded Tractrix Horn.
The 90º x 60º horn and driver assem-
bly allows repositioning by 90º for
selectable pattern control.
The compact dual port bass reflex
loudspeaker system can handle 100
watts continuous power for anAES
sensitivity of 96dB and a maximum
output of 113dB SPL.
Paintable and available in black or
white finishes, the ABS enclosure
features corrosion- and rust-resistant
stainless steel hardware and a remov-
able aluminum powder-coated grille,
ensuring maintenance-free service in
any environment or application.
Whether indoors or out, the Klipsch
CA-8T is the good looking, great
sounding full-range solution for
installed high-fidelity sound.
C A - 8 T
● Compact UV and weather-resistant ABS enclosure
● Adjustable pattern 90º x 60º Tractrix®Horn
● Internal 60W multi-tap transformer with direct 8 ohm bypass
● Continuous high power handling of 100 watts
● White or black enclosure paintable to match decor
● 96dB sensitivity, 113dB maximum output (1 meter)
● 11.125" x 16.375" x 11.75" and 17 lbs.
FREQUENCYRESPONSE1
POWER HANDLING
2
MAXIMUM CONTINUOUS OUTPUT
3
SENSITIVITY(2.83 V/1M)
4
TRANSFORMER TAPS
HORIZONTALCOVERAGE
VERTICALCOVERAGE
DIRECTIVITY
NOMINALIMPEDANCE
CROSSOVER FREQUENCY
COMPONENTS
INPUT CONNECTORS
ENCLOSURE MATERIAL
HEIGHT
WIDTH
DEPTH
WEIGHT
SHIPPING WEIGHT
FINISHES
ACCESSORIES
64Hz -19kHz±4dB
100 W (21V)
113dB
96dB
70V: 60W, 30W, 15W
100V: 60W, 30W
Thru Position: 8 ohms
60º±40 2500Hz-20kHz
80º±40 1300Hz-20kHz
8±2dB 1300Hz-20kHz
8 ohms nominal (4.2 min @ 175 Hz)
2kHz
One K-1111-A8" low frequency driver
One K-118-A1" titanium diaphragm compression driver
5-way binding posts
All-weather ABS plastic
11.125" (28.26cm)
16.375" (41.59cm)
11.75" (29.85cm)
17 lbs. (7.72kg)
44 lbs. (19.98kg)
White or Black
C-Bracket (included), CASecurity Kit
13M, Half-space anechoic
2AES Standard, continuous pink noise 50Hz-10kHz, 6dB peaks
3Calculated at 1M at power handling power input
4SPLat 1M, half-space anechoic with 2.83V input
Specifications

CA-8T COMPACT 8"TWO-WAY SPEAKER SYSTEM
HorizontalOff-AxisTransferFunction
HorizontalCoverage(-6dB) VerticalCoverage(-6dB)
Impedance
DirectivityIndex
FrequencyResponse
VerticalOff-AxisTransferFunctionUP VerticalOff-AxisFunctionDOWN

Horizontal 1 /3Octave Polars
Vertical 1 /3Octave Polars

3502 Woodview Trace, Suite 200 • Indianapolis, IN 46268
137 County Road 278 • Hope, AR USA71801
1-888-600-5776 • www.klipsch.com
Architectural Specifications
The CA-8T all-purpose two-way compact loudspeaker
system shall include a 8" (20.32cm) K-1111-A weather-
resistant low frequency driver and a 1" (2.54cm) K-118-
Atitanium diaphragm high frequency compression
driver mounted on a molded Tractrix Horn. Signal shall
be provided to the transducers via a passive internal
frequency dividing network, with a 2kHz crossover
frequency. The enclosure tuning shall be dual port
bass reflex.
Frequency response shall be 64Hz to 19kHz, ±4dB, with
the -10dB down point at 45Hz, measured at 1 meter,
half space anechoic. The dispersion angle shall be 90º x
60º nominal (refer to graph). Sensitivity shall be 96dB
SPL, measured at 1 meter, half space anechoic, with a
2.83V input. Power handling shall be 100 watts (21V),
to AES standards, continuous pink noise, 50Hz to
10kHz, 6dB peaks. Calculated maximum continuous
output at 1 meter shall be 113dB SPL. Nominal
impedance shall be 8 ohms, with a 4.2 ohm minimum
at 175Hz. Full-range connections shall be made via
5-way binding posts.
A removable powder-coated aluminum grille shall be
provided for protection of the transducers from
tampering or damage. The enclosure shall be of UV-
and weather-resistant ABS plastic, available in black
or white, with dimensions of 11.125" (28.26cm) high
by 16.375" (41.59cm) wide by 11.75" (29.85cm) deep.
Net weight shall be 17 lbs. (7.72kg). Mounting shall
be via protruding stainless steel threaded studs on
the side enclosure panels, mating to large external
knobs for positive attachment to the C-shaped
mounting bracket (included).
The system shall be a Klipsch CA-8T loudspeaker.
1M0901
195064
©2001 Klipsch Audio Technologies. All rights reserved.
Specifications subject to engineering changes.
Back View Back View With Out Bracket 1/4-20 UNC Stud
1/4-20 UNC Stud
Thread Hole
Left Side View
Front View
1/4-20 UNC Stud 1/4-20 UNC Stud
1/4-20 UNC Stud
Top View
Right Side View
Safety Point 6.559
3.486
11.125 Ref
Bottom View
6.559
