Klipsch ROOMGROOVE User manual

Important Safety Information
A
The exclamation point, within an equilateral triangle, is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the product.
The lightning flash with arrowhead symbol within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated "dangerous voltage" within
the product's enclosure that may be of sufficient
magnitude to constitute a risk of electrical shock to
persons.
WARNING: Do Not Open! Risk of Electrical Shock. Voltages in this
equipment are hazardous to life. No user-serviceable parts inside.
Refer all servicing to qualified service personnel.
A
WARNING: Batteries (battery pack or batteries installed) shall not be
exposed to excessive heat such as sunshine, fire or the like.
WARNING: To reduce the risk of fire or electrical shock, do not expose
this apparatus to rain or moisture.
WARNING: No naked flame sources - such as candles - should be
placed on the product.
WARNING: This product is intended to be operated ONLY from the
AC Voltages listed on the back panel or included power supply of the
product. Operation from voltages other than those indicated may cause
irreversible damage to the product and void the products warranty. The
use of AC Plug Adapters is cautioned because it can allow the product
to be plugged into voltages in which the product was not designed to
operate. If the product is equipped with a detachable power cord, use
only the type provided with your product or by your local distributor
and/or retailer. If you are unsure of the correct operational voltage,
please contact your local distributor and/or retailer.
CAUTION: Place the equipment near a main power supply outlet and
make sure that you can easily access the power breaker switch.
Adaptor I/P: 100-240VAC, 50-60Hz
Unit I/P: 15VDC, 3A
Ambient Temperature: 35° C
For Your Safety: The AC power plug is polarized
(one blade is wider than the other) and only fits
into an AC power outlet one way. If the plug won't
go into the outlet completely, turn the piug over
and try to insert it the other way. If it still won't fit,
contact a qualified electrician to change the outlet,
or use a different one. Do not attempt to bypass
this safety feature.
9.
8.
1.
2.
3.
4.
5.
6.
7.
READ these instructions.
KEEP these instructions.
HEED all warnings.
FOLLOW all instructions.
DO NOT use this apparatus near water.
CLEAN ONLY with dry cloth.
DO NOT block any ventilation openings. Install in
accordance with the manufacturer's instructions.
DO NOT install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
DO NOT defeat the safety purpose of the polarized or
grounding type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wider blade or the
third prong is provided for your safety. If the provided
plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. PROTECT the power cord from being walked on or
pinched, particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus. A
11. ONLY USE attachments/accessories specified by the
manufacturer.
12. USE only with a cart, stand, tripod, bracket, 8
or table specified by the manufacturer, or sold
with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. UNPLUG this apparatus during lightning storms
or when unused for long periods of time.
14. REFER all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled, objects have fallen
into the apparatus, the apparatus has been exposed to rain
or moisture, does not operate normally, or has been
dropped.
15. DO NOT expose this apparatus to dripping or splashing and
ensure that no objects filled with liquids, such as vases,
are placed on the apparatus.
16. To completely disconnect this apparatus from the AC
Mains, disconnect the power supply cord plug from the AC
receptacle.
17. The mains plug of the power supply cord shall remain readily
operable.
1

Thank You
Congratulations on your purchase of the Klipsch RoomGroove music
center. The RoomGroove is a wireless transceiver utilizing Wireless
KlipschCasFM Technology to transmit and receive CD-quality audio
signals to and from other KlipschCast components. The RoomGroove
features an iPod® dock and auxiliary input for connecting your
favorite components and enjoying them locally or transmitting them
throughout your home.
The RoomGroove is a true two-way, stereo sound system incorporating
two long-throw woofers and two Micro Tractrix™ Horn-loaded tweeters
in a ported enclosure. This system provides the accuracy, detail and
output that will bring your music to life as only Klipsch can.
Unpack the Box
Unpack the entire contents of the shipping box and make sure you
have the following items.
DD
--
~
[J
~
Ge)
GG
C)
G
~ .... T1
-j
~~
-
RoomGroove
Remote
Control
DD
------
~~
,,'~:_- :-:~
~ ..
. ', . -~;/-.,:
Power Supply
Universal Well Inserts
Place the RoomGroove on a sturdy surface. Plug the power cord into
the rear of the RoomGroove and then into a standard wall outlet. The
RoomGroove is now ready to listen to any source being transmitted
with wireless KlipschCast Technology.
Docking and Listening to an iPod
The RoomGroove is intelligently designed to easily accommodate
all iPods. Touching the Klipsch logo on the front of the RoomGroove
will reveal the retractable iPod dock. The RoomGroove must be
powered on for the drawer to open and close. When the dock is
extended, touching the dock again will cause it to retract. The dock
will not move when an iPod is docked. The dock will automatically
retract when no iPod is present and the RoomGroove is in standby
mode (the power LED will be red).
2
The RoomGroove is designed to work with Apple universal well
inserts. Several inserts are supplied with your RoomGroove
system. If your iPod came with an insert, it can also be used in the
RoomGroove. To configure the RoomGroove for your specific iPod,
select the appropriate well insert and place it in the universal well
as shown in the diagram. Now you are ready to dock your iPod.
While your iPod is docked, its battery is charging (until it is fully
charged).
To listen to the docked iPod, press the "Listen" button on the
RoomGroove or the remote until the "Listen" light becomes blue
and you hear the iPod. The iPod can be directly accessed by
pressing the "iPod" button on the RoomGroove's remote control.
Connecting an Auxiliary Source
The RoomGroove offers a 3.5mm stereo auxiliary input on the
rear of the device, To connect an auxiliary device, simply plug the
audio output of the device into the "Aux Input" on the rear of the
RoomGroove. You must use a 3.5mm stereo cable,
To listen to the auxiliary source, press the "Listen" button on
the RoomGroove or the remote until the "Listen" light becomes
blue and you hear the auxiliary device. This can also be done by
pressing the "Aux" button on the RoomGroove's remote control.
Note: The "Listen" light will be blue when listening to either a
local iPod or a device connected to the local auxiliary input. If
both inputs are in use, the "Listen" button will go from the Aux
to the iPod in that order.

Transmitting Audio from the RoomGroove
The RoomGroove is designed to allow you to transmit the iPod
or the auxiliary source so that it can be received and played by
other KlipschCast components. To transmit from the RoomGroove,
simply select the source you wish to transmit by pressing the
"Listen" button, or the desired source on the remote (iPod or Aux),
and then press the "Transmit" button. The selected source is now
being transmitted throughout your home and is available to other
KlipschCast-enabled products.
Note: If a RoomGroove is transmitting and a second Room-
Groove is told to transmit, the second RoomGroove will bump
the first RoomGroove and occupy that wireless channel. If you
wish to configure your wireless multi-room system to allow two
RoomGrooves to simultaneously transmit, see the "Transmitting
Audio from Two RoomGrooves" section of this manual.
Listening to Other KlipschCast Devices with Your
RoomGroove
The RoomGroove is designed to allow you to listen to sources
connected to, or integrated into, other KlipschCast components
such as another RoomGroove or the CS-700 DVD Entertainment
System.
To listen to a source being transmitted by another KlipschCast
device, simply press the "Listen" button to access the transmitted
source. The "Listen" light becomes red (or purple for a second
wireless source) when a wireless source is received and played. A
flashing color indicates no source is available on that channel.
Sources and Colors of the "Listen" Light
Blue always indicates a local source. Red and purple indicate
wireless channels. If the color is flashing, the source or wireless
channel is not available.
For systems transmitting from a CS·700 system
and RoomGroove
Local source (iPod or Aux) = blue
Transmitted Cinema System source = red
Transmitted RoomGroove source = purple
For systems transmitting from two RoomGrooves
Local source (iPod or Aux) = blue
1 st Transmitted RoomGroove source = red
2nd Transmitted RoomGroove source = purple
Transmitting Audio from the CS·700
In a multi-room system incorporating a CS-700 cinema system
(sold separately), the RoomGroove remote can be used to directly
select sources from the CS-700 once the CS-700 has been
selected by the RoomGroove's "Listen" button. The CS-700
will default to transmit its local source (the source selected for
listening/viewing on the CS-700 system) until another source is
selected. See the "Remote Control" section of this manual for
details on the remote's functionality.
Transmitting Audio from Two RoomGrooves
In systems not incorporating a CS-700 system (or if the cinema
system in not intended to be part of the wireless multi-room
system), two RoomGrooves can transmit simultaneously. To enable
this feature, all components of the wireless multi-room system
must be assigned to a home code from 5 to 9. Selecting a home
code from 5 to 9 will allow a second RoomGroove to occupy the
wireless channel which was previously assigned to the CS-700.
(See "Setting the Home Code" for more detailed information.)
If two RoomGrooves are transmitting and you wish to transmit
from a third and control which wireless channel will be used for the
new transmission, you must first select the broadcast you wish to
terminate by pressing the "Listen" button until that source is heard.
Then press transmit and the new source will occupy that wireless
channel and stop the transmission of the other source. You should
now hear the new source in all the locations in which the previous
source was playing. The new source should now be available to all
active listeners.
Note: All devices in the wireless multi-room system must be set
to the same home code in order for transmissions to take place.
Setting the Home Code
The home code dial on the rear of your RoomGroove allows you
to select a code specific to all of your KlipschCast components
to avoid interference from neighboring systems. The home code
numbers range from 0 to 9 with 0 set as the default. All of your
KlipschCast components will initially be set to 0 and allow one
wireless channel to broadcast audio from a cinema system and
the second wireless channel to broadcast wireless audio from a
RoomGroove. The home code number should only be changed for
one of two reasons:
1) There is interference from a neighboring system -If a
neighboring system in interfering with your wireless system,
simply change all KlipschCast components to another home code.
KlipschCast components will only transmit and receive audio from
components on the same home code. Home codes 0 through 4
can be used for systems transmitting audio from a cinema system
and a RoomGroove (home codes 5 through 9 are reserved for
systems transmitting from two separate RoomGrooves and no
cinema system).
2) You wish to transmit audio from two RoomGrooves (not a
cinema system) -If you wish to transmit audio from two separate
RoomGrooves and not a cinema system, simply choose a home
code from 5 to 9 and change all KlipschCast components to that
home code. KlipschCast components will only transmit and receive
audio from components on the same home code.
Once the home code has been changed, you must disconnect and
reconnect the power cord from the wall outlet for the change to be
made. This will change the home code and allow the component to
talk to other KlipschCast components set to the same home code.
Note: All devices in the wireless multi-room system must be set
3 to the same home code in order for transmissions to take place.

Remote Control
The wireless remote control allows interaction with the RoomGroove and iPod as well as other transmitting devices such as other RoomGrooves
and Klipsch cinema systems such as the CS-700.
Buttons
RoomGroove
888
Cinema Syslem Sources
888
88
Power
RoomGroove
iPod
Aux
Listen
Press to turn the RoomGroove "On". Press again to put the RoornGroove
into "Standby" mode.
Selects the iPod docked in the local RoomGroove.
Selects the audio device connected to the local RoomGroove (the audio
device must be playing to be heard).
Toggles through available sources both local and wireless.
ffi
88
8
@8
~
Note: This remote must be pointed at
the RoomGroove for proper interaction.
Cinema System Sources
CD/DVD Accesses the CD/DVD drive of the cinema system connected to the
KlipschCast network.
AM/FM Accesses the AM/FM tuner of the cinema system connected to the
KlipschCast network.
Cab/Sat Accesses audio from the device connected to the cinema system's
Cab/Sat input connected to the KlipschCast network. The device must be
delivering audio to the cinema system to be heard on the RoomGroove.
Aux 1 Accesses audio from the device connected to the cinema system's Aux 1
input connected to the KlipschCast network. The device must be
delivering audio to the cinema system to be heard on the RoomGroove.
Aux 2 Accesses audio from the device connected to the cinema system's Aux 2
input connected to the KlipschCast network. The device must be
delivering audio to the cinema system to be heard on the RoomGroove.
Track Selection ( ~ and »l ) These buttons enable control of several different sources:
• When controlling the local iPod, press ~ and »l to move to the previous or next track;
press and hold to reverse or fast-forward through the current track.
• When controlling a transmitted iPod docked in another RoomGroove, press ~ and »l
to move to the previous or next track.
• When controlling the CD/DVD cinema system source, press ~ and »l to move to the
previous or next track/chapter.
• When controlling the AM/FM cinema system source, press ~ and »l to move to the
previous or next preset station (if no stations have been preset, these buttons will not
function).
• When controlling the Cab/Sat cinema system source, press ~ and »l to move to the
previous or next chan nel.
• These buttons are non-functional when listening to the transmitted Aux 1 or Aux 2
sources of a cinema system.
Play/Pause
,';II
'J
Volume
r.:p, ,0;
\ .... j\..--1
Mute
4
Press once to "Pause" play; press again to resume play.
Press + or - to increase or decrease the RoomGroove volume level
(local RoomGroove only).
Decreases the volume of the local RoomGroove to a zero level
(no sound).

Changing the Remote Control Battery
The remote control battery will need to be changed when it stops
working or when its performance is noticeably reduced. To remove
the battery, simply pull the battery housing tab from the remote
control (as shown in the diagram) and remove the battery. Replace
only with a 3-volt CR2025 lithium battery.
Note: Lighting and other room conditions can reduce remote
performance.
Cable Management System and Mounting the
Power Supply
The RoomGroove's power supply has an integrated cable
management system. Excess cable length can be wrapped around
the power supply and secured with the rubber straps as shown in
the diagram.
J
The RoomGroove's power supply can be convieniently mounted
on the rear of the RoomGroove To mount the power supply simply
position the hooks on the side of the power supply into the slots on
the rear of the RoomGroove as show in the diagram.
Slots
Optional Wall Mount Bracket
Your RoomGroove can be wall mounted with the optional wall
mount bracket available at Klipsch.com. Visit Klipsch.com or call
1.800.KLlPSCH (554.7724) for more details.
5

Warranty - U.S. and Canada
The Warranty below is valid only for sales to consumers in the United
States or Canada. KLiPSCH, L.L.C. ("KLIPSCH") warrants this product
to be free from defects in materials and workmanship (subject to the
terms set forth' below) for a period of one (1) year from the date of
purchase. During the Warranty period, KLiPSCH will repair or replace
(at KLiPSCH's option) this product or any defective parts.
Proof of purchase in the form of a bill of sale or receipted invoice,
which is evidence that this product is within the Warranty period,
must be presented or included to obtain Warranty service.
This Warranty is invalid if (a) the factory-applied serial number has
been altered or removed from this product or (b) this product was not
purchased from a KLiPSCH authorized dealer. You may call 1-800-
KLiPSCH to confirm that you have an unaltered serial number and/or
you purchased from a KLiPSCH authorized dealer.
This Warranty is only valid for the original purchaser and will
automatically terminate prior to expiration if this product is sold or
otherwise transferred to another party.
This Warranty does not cover cosmetic damage or damage due
to misuse, abuse, negligence, acts of God, accident, commercial
use or modification of, or to any part of, the product. This Warranty
does not cover damage due to improper operation, maintenance or
installation, or attempted repair by anyone other than KLiPSCH or a
KLiPSCH dealer which is authorized to do KLiPSCH warranty work.
Any unauthorized repairs will void this Warranty. This Warranty does
not cover product sold AS IS or WITH ALL FAULTS.
REPAIRS OR REPLACEMENTS AS PROVIDED UNDER THIS
WARRANTY ARE THE EXCLUSIVE REMEDY OF THE CONSUMER.
KLiPSCH SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES FOR BREACH OF ANY EXPRESS
OR IMPLIED WARRANTY ON THIS PRODUCT. EXCEPT TO THE
EXTENT PROHIBITED BY LAW, THIS WARRANTY IS EXCLUSIVE
AND IN LIEU OF ALL OTHER EXPRESS AND IMPLIED WARRANTIES
WHATSOEVER, INCLUDING BUT NOT LIMITED TO, THE WARRANTY
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
.In accordance with FCC requirements, changes or modifications
not expressly approved by Klipsch could void the user's authority to
operate this product.
This device generates and uses radio frequency (RF) energy, and if
not installed and used properly, this equipment may cause interfer-
ence to radio and television reception.
If this equipment does cause interference to radio or television
reception (which you can determine by unplugging the unit), try to
correct the interference by one or more of the following measures:
• Re-orient the receiving antenna (that is, the antenna for the
radio or television that is "receiving" the interference).
• Move the unit away from the equipment that is receiving
interference.
• Plug the unit into a different wall outlet so that the unit and
the equipment receiving interference are on different branch
circuits.
If these measures do not eliminate the interference, please consult
your dealer or an experienced radio/television technician for ad-
ditional suggestions.
Also, the Federal Communications Commission has prepared a
helpfUl booklet, "How To Identify and Resolve Radio TV Interference
Problems." This booklet is available from the U.S. Government
Printing Office, Washington, DC 20402. Please specify stock number
004-000-00345-4 when ordering copies.
This product complies with DHHS Rules 21 CFR Subchapter J. Ap-
plicable at the date of manufacture.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numerique de la classe Best conforme a la norme
NMB-003 du Canada.
FCC Declaration Of Conformity
These devices were tested and found to comply with Part 15 of
the FCC Rules. Operation is subject to the following conditions: The
devices may not cause harmful interference, and the devices must
accept any interference received, including interference that may
cause undesired operation.
Some states do not allow the exclusion or limitation of incidental
or consequential damages or implied warranties so the above
exclusions may not apply to you. This Warranty gives you specific
legal rights, and you may have other rights, which vary from state
to state.
Warranty Outside the United States and Canada
The Warranty on this product if it is sold to a consumer outside of the
United States or Canada shall comply with applicable law. To obtain
any applicable warranty service, please contact the dealer from
which you purchased this product, or the distributor that supplied
this product.
FCC Information
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two: (1) This device may not cause harmful
interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Trade Name:
Product Name:
Model Number:
Responsible Party
Manufacturer:
Address:
Telephone:
Date:
KtlPSCI! ,\['010
n:CII~OJ.()(;I~~~
Klipsch Audio Technologies
Audio Speaker System
RoomGroove
Klipsch Audio Technologies
3502 Woodview Trace, Suite 200
Indianapolis, IN 46268
317 -860-8100
1/15/2006
RoomGroove
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and radiates radio frequency energy and, if not
installed and used in accordance with the instruction, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation
6
~
Tc~lcd To (')Dlply
~ \Vitil FCC Slandanls
FOR HOME OR OFFICE USE

II
I
II
For over 60 years, we've made speakers for people who are as passionate about
great sound as we are. That's why every Klipsch speaker is horn-loaded to create
a remarkably accurate listening experience for your music and movies. From our
smallest satellites to our acclaimed professional theater installations, our speakers
deliver sound that's so lifelike, you have to feel it to believe it.
THE ULTIMATE SOUND EXPERIENCE™
1006605

wo:npsd!l)l. H8Sdll)l-OOS- ~
S9l9v NI 's!lodeue!pUI
OOl 81!ns '8:
JeJl
M8!t\pooM lOSE:
I!BW pUB edBl 4l!M IBes '6J64 PIO:::l
BUSINESS REPLY MAIL
FIRST-CLASS MAIL PERMIT NO 201 INDIANAPOLIS IN
POSTAGE WILL BE PAID BY ADDRESSEE
KLIPSCH AUDIO TECHNOLOGIES
3502 WOODVIEW TRCE STE 200
INDIANAPOLIS
IN 46209-8631
1.1 •• 1.11'11.1.11111.1.1 •• 1111 •• 11111111"1111 ••• 111
NO POSTAGE
NECESSARY
IF MAILED
INTHE
UNITED STATES

_-----'K~L .. I ..... P___'S C_.JH P R~O .... D U_.:C_......T~R E .... G_.JI ...S T __ R__.. ........ rI __ O .... N~.-C .... A....-...JR .. D -----I __
Make sure you return your product registration card or register at www.klipsch.com so that we may keep you up-to-date on
new Klipsch products and promotions. As always, if you have any questions, contact your local authorized Klipsch dealer.
For multiple speaker purchases, please fill out only one registration card.
Name:
Street Address:
City/State/Zip:
Home Phone:
Work Phone:
E-mail Address:
Would you like to receive the latest Klipsch news, product updates and specials offers via e-mail? 0 Yes 0 No
PRODUCT PURCHASE
Model and serial number must be included to honor your product registration card. For multiple speaker purchases, please fill out only one registration card.
Model
Model
Model
Model
Model
Model
What store did you purchase your Klipsch products from?
Store Name:
Serial Number
Serial Number
Serial Number
Serial Number
Serial Number
Serial Number
State:
How did you hear about Klipsch? 0 AudiolHome Theater Magazine 0 Other Magazine 0 TV 0 Radio 0 Newspaper 0 Trade Show 0 Friend
o Retail Dealer 0 Direct Mail 0 Website 0 Web Forum
Have you purchased Klipsch products before? 0 Yes 0 No
If yes, what products?
Product Name(s):
When do you hope to purchase additional loudspeakers? 0 6 mos. -1 yr. 01-2 yrs.
How likely are you to consider Klipsch products for your upcoming purchases? 0 Very likely 0 Somewhat likely 0 Doubtful
If doubtful, why? 0 Don't carry product I'm looking for 0 Too expensive 0 Klipsch dealer too far away 0 Other
PLEASE TELL US ABOUT YOU!
o Married 0 Single 0 Student 0 Male 0 Female
Age: 0 15-17 0 18-24 025-35 0 36-45 046-55 055-64 065+
Annual Household Income: 0 Under $25,000 0 $25-35,000 0 $35-50,000 0 $75-100,000 0 $100,000+
PLEASE FOLD AND SEAL THIS POSTAGE PAID PRODUCT REGISTRATION CARD BEFORE MAILING.

Please allow our product specialists to care for your needs.
If you have any questions during set up or about the use of your new Klipsch system, please contact the
Klipsch Connect hotline toll-free at 866-428-2124.
If
you experience a problem, please do not return this product to the store where it was purchased. Our
Klipsch Connect team will instruct you on proper handling. The hotline is staffed Monday through Friday
8:00 a.m. to 8:00 p.m. EST
" 1l.i
.~~ !J';'
