klover DIVA SLIM Quick start guide

ENGLISH
DIVA SLIM AIR
pellet stove
INSTALLATION, USE,
MAINTENANCE AND HELPFUL
TIPS

1
CONTENTS
CONTENTS ........................................................................................................................................................................1
INTRODUCTION................................................................................................................................................................. 3
IMPORTANT SAFETY INSTRUCTIONS................................................................................................................................... 3
THE MACHINE AND THE PELLETS ................................................................................................................................. 4
COMPONENTS OF THE APPLIANCE ..................................................................................................................................... 4
OVERALL DIMENSIONS ...................................................................................................................................................... 7
CONNECTIONS DATA SHEET .............................................................................................................................................. 8
PELLET PROPERTIES ........................................................................................................................................................ 9
REQUIREMENTS OF THE PLACE OF INSTALLATION................................................................................................. 10
POSITIONING.................................................................................................................................................................. 10
SPACES AROUND AND ABOVE THE APPLIANCE.................................................................................................................. 11
EXTERNAL AIR INTAKE .................................................................................................................................................... 11
THE FLUE AND CONNECTION TO THE SAME....................................................................................................................... 12
CHIMNEY ....................................................................................................................................................................... 13
ELECTRICAL CONNECTION .......................................................................................................................................... 14
CONNECTION TO THE ROOM THERMOSTAT OR TO A ROOM PROBE..................................................................................... 15
DESCRIPTION OF COMPONENTS................................................................................................................................. 16
REMOTE CONTROL ......................................................................................................................................................... 16
SUPPORT PANEL ............................................................................................................................................................ 17
DISPLAY ........................................................................................................................................................................ 18
THE MENU ....................................................................................................................................................................... 19
INITIAL SETTINGS........................................................................................................................................................... 26
CONNECTING THE REMOTE CONTROL .............................................................................................................................. 26
CONNECTION TO THE WI-FI NETWORK............................................................................................................................. 26
START-UP........................................................................................................................................................................ 29
INITIAL START-UP............................................................................................................................................................ 29
IGNITION CYCLE.............................................................................................................................................................. 29
WORKING MODE............................................................................................................................................................. 30
SWITCH-OFF CYCLE........................................................................................................................................................ 30
MODIFYING THE MAIN ROOM TEMPERATURE SET-POINT.................................................................................................... 30
MODIFYING THE POWER SET-POINT ................................................................................................................................. 31
MODIFYING THE DUCTED AIR SPEED SET-POINT ............................................................................................................... 31
MODIFYING THE TEMPERATURE SET-POINTS OF THE DUCTED ROOMS ............................................................................... 31
PROBLEMS, ALARMS, USEFUL TIPS ........................................................................................................................... 32
USEFUL INFO….............................................................................................................................................................. 32
WHAT HAPPENS IF…...................................................................................................................................................... 32
ALARM SIGNALS ............................................................................................................................................................. 33
PRECAUTIONS BEFORE CLEANING ................................................................................................................................... 34
ROUTINE CLEANING........................................................................................................................................................ 34
NON-ROUTINE CLEANING ................................................................................................................................................ 36
CLEANING THE VERMICULITE COMPONENTS..................................................................................................................... 38
CLEANING THE CERAMIC GLASS ...................................................................................................................................... 38
CLEANING THE FLUE....................................................................................................................................................... 38
MAINTENANCE ............................................................................................................................................................... 39
PCB PARAMETERS ........................................................................................................................................................ 40

DIVA SLIM AIR PELLET STOVE
2
EN - Rev. 1.0
PARAMETER TABLES DIVA SLIM AIR ............................................................................................................................. 40
PARAMETER TABLES DIVA SLIM MULTI-AIR.................................................................................................................. 42
WIRING DIAGRAM........................................................................................................................................................... 44
STANDARD WARRANTY CONDITIONS......................................................................................................................... 45
Dear client,
First of all we would like to thank you for choosing a “KLOVER” product and we hope you will be satisfied with this
product.
Carefully read the warranty certificate on the last page of this User guide.
The manual contains a detailed description of the appliance and its operation, instructions for proper installation, basic
maintenance and control points, which must be periodically performed; furthermore, it contains practical advice which
helps to obtain maximum performance from the appliance with minimum fuel consumption.
Stay warm with KLOVER!
Copyright
All rights reserved. The reproduction of any part of this manual, in any form, without the explicit written permission of
KLOVER Srl is forbidden. The content of this manual may be modified without notice. Although the documentation
contained in this manual has been carefully compiled and checked, KLOVER Srl cannot be held liable for any damages
arising from the use of the same.
Copyright © 2018 KLOVER Srl

DIVA SLIM AIR PELLET STOVE
3
EN - Rev. 1.0
INTRODUCTION
Important safety instructions
Please read these instructions before installing and using the product.
-The appliance’s installation and initial start-up must be performed by skilled personnel trained in the relevant safety
standards, who are responsible for the definitive installation of the appliance and its efficient operation. KLOVER Srl
shall not be held liable if these precautions are not observed.
-During the installation and use of the appliance, all local regulations - including those referring to national and
European Standards - must be observed.
-Connect the flue gas outlet to a flue with the specifications described in the “Flue and its connection” section of this
User guide.
-The appliance is not suitable for installation on a shared flue system.
-If the flue should catch fire, use appropriate fire extinguishing equipment or call the fire brigade.
-Connect the product to an earthed power socket. Avoid using sockets controlled by switches or automatic timers.
-Do not use the power supply cable if damaged or worn.
-If a multiple socket is used, make sure that the total voltage of the connected devices does not exceed the rated
voltage for the socket. Also make sure that the total voltage of all the devices connected to the socket does not
exceed the maximum permitted level.
-The plug on the appliance’s power cable should be connected only once the assembly and installation of the
appliance is complete. It should remain accessible after installation if the appliance is not fitted with a suitable and
accessible two-pole switch.
-Do not use flammable substances to clean the appliance or its parts.
-Do not leave flammable containers and substances in the place where the appliance is installed.
-The appliance works exclusively with wood pellets and only with the hearth door shut.
-NEVER open the door of the appliance during normal operation.
-The use of poor quality pellets or any other material can damage the appliance operation, voiding the warranty and
exempting the manufacturer from all liability.
-Do not use the appliance as an incinerator or for any use other than that for which it was designed.
-Do not use fuels other than those recommended.
-Do not use liquid fuels.
-The appliance, and its outer surfaces in particular, become very hot to the touch during operation; handle with
caution in order to avoid burns.
-Keep fuel and flammable materials at a safe distance.
-Only use original spare parts recommended by the manufacturer.
-Do not make any unauthorised modifications to the appliance.
-Do not touch the hot components of the product (ceramic glass, flue pipe) during normal operation.
-Never touch the appliance if you are barefoot and/or if you have wet or damp parts of the body.
-Use the appropriate button to switch off the electrical panel. Do not disconnect the power supply cable while the
appliance is operating.
-During the ignition phase and normal operation of the appliance, maintain the necessary safety distance and do not
remain standing in front of it.
-Keep children away from the appliance when it is running since they could get burned by touching its hot
components.
-Do not leave the packaging elements within reach of children or unassisted disabled persons.
-Children and inexperienced people must not be allowed to use the appliance.
-The appliance may be used by children no younger than 8 years of age and people with reduced physical, sensory or
mental capabilities, or those without experience of the appliance, as long as they are supervised or have received
instructions on how to use the appliance safely and understand the hazards inherent to the appliance.
-Children should not play with the appliance.
-User maintenance and cleaning operations should not be carried out by unsupervised children.
-Do not use the appliance in ways other than those indicated in this user guide.
-The appliance is designed for indoor use only.
-This user guide constitutes an integral part of the appliance. If the product is sold to another user, this manual must
be passed on to the new owner.

DIVA SLIM AIR PELLET STOVE
4
EN - Rev. 1.0
KLOVER S.R.L. DECLINES ALL LIABILITY IN CASE OF ACCIDENTS DUE TO FAILURE TO COMPLY WITH THE
SPECIFICATIONS OF THIS MANUAL.
KLOVER S.R.L. DECLINES ALL LIABILITY DUE TO INCORRECT USE OF THE PRODUCT BY THE USER,
UNAUTHORISED MODIFICATION AND/OR REPAIRS, AND USE OF NON-ORIGINAL SPARE PARTS OR SPARE
PARTS NOT SPECIFICALLY DESIGNED FOR USE ON THIS PRODUCT MODEL.
KLOVER S.R.L. SHALL NOT BE HELD LIABLE FOR THE STOVE'S INSTALLATION. THE INSTALLER IS THE
SOLE PARTY RESPONSIBLE FOR THIS OPERATION AND IS ALSO ENTRUSTED WITH CHECKING THE FLUE,
EXTERNAL AIR VENT AND THE CORRECTNESS OF THE PROPOSED INSTALLATION SOLUTIONS. ALL THE
SAFETY REGULATIONS SET OUT IN THE SPECIFIC LAWS IN FORCE IN THE COUNTRY WHERE THE MACHINE
IS INSTALLED MUST BE OBSERVED.
NON-ROUTINE MAINTENANCE MUST ONLY BE PERFORMED BY AUTHORISED AND QUALIFIED STAFF.
To ensure the validity of the warranty, the user must comply with the instructions contained in this guide and, in
particular, must:
-Use the appliance within its operating limits;
-Regularly perform all maintenance activities;
-Authorise expert and competent people to use the appliance.
Failure to comply with the instructions contained in this guide shall automatically void the warranty.
THE MACHINE AND THE PELLETS
Components of the appliance
The appliance is supplied with the following material:
-1 User, installation and maintenance manual;
-1 Power supply cable;
-1 Cleaning hook for the front heat exchanger;
-1 Remote control.
The images below show certain details of the appliance:
Hook for cleaning the
front heat exchanger.

DIVA SLIM AIR PELLET STOVE
5
EN - Rev. 1.0
Anti-interference filter.
Main switch, connection for
power supply cable with 2
built-in fuses (4A 250V).
Support panel.
Wi-Fi information
(MAC address and
registration code).
Safety thermostat with
manual reset.
R.T. terminal for room
main thermostat
connection.
FRONT VIEW
Serial Connector
to connect to the
Technical Assistance
Centre.
R.T. Terminal/Probe for
ducted room thermostat
connection / ducted room
probe connection.
Inspection Port
lower flue gas
passage.
Inspection Port
flue gas extractor
passage.
CE label
with technical data,
serial number and
model.
Flue gas extractor.
Flue pressure
switch.
Control unit.
Rod for cleaning the
front heat exchanger.

DIVA SLIM AIR PELLET STOVE
6
EN - Rev. 1.0
Flue gas
outlet.
Intake pipe.
REAR VIEW
TOP VIEW
Pre-configuration
for ducted air outlet.
Bracket
for fixing on wall.
Bracket
for fixing on wall.
Inspection Port
right side flue gas
passage.
Inspection Port
left side flue gas
passage.
Opening
for power supply
cable.

DIVA SLIM AIR PELLET STOVE
7
EN - Rev. 1.0
Overall dimensions

DIVA SLIM AIR PELLET STOVE
8
EN - Rev. 1.0
Connections data sheet
Description of connections
A = Intake pipe
50 mm
Cn1u = Upper ducted air outlet (only on configured models)
80 mm M
Cn1b = Rear ducted air outlet (only on configured models)
80 mm M
Sb = Rear flue gas outlet
80 mm M
Su = Upper flue gas outlet
80 mm F
E =Electricity connection
REAR
VIEW
E

DIVA SLIM AIR PELLET STOVE
9
EN - Rev. 1.0
Pellet properties
The appliance has been tested with all types of pellets available on the market. The pellets must have the following
properties:
-Diameter 6 mm.
-Maximum length 35 mm.
-Maximum humidity content 8 –9 %.
-100% wood. Totally additive-free.
-Maximum ash residue 1.1 %.
To obtain good performance from the appliance, we recommend using good quality pellets. Pellets should be poured
into the tank using a shovel, and not directly from the bag.
Good quality pellets should have the following properties:
-Constant diameter cylinders with a smooth, shiny surface;
-There should not be a lot of sawdust inside the packaging;
-After grabbing a bunch of pellets and placing them into a container filled with water, good-quality pellets will sink and
poor-quality ones will tend to float;
-The quality certification data, in particular conformity to international standards such as EN14961-2, DIN 51731 and
O-NORM M7135, should be indicated on the packaging;
-The packages should be intact since pellets tend to absorb humidity. Humidity not only reduces the calorific value
and increases the amount of flue gases expelled, but also causes swelling of the product which may create problems
with the appliance.
The production of pellets must be compliant with some international standards (such as EN14961-2, DIN 51731 and O-
NORM M7135) which establish minimum values for quality checks on pellets. To facilitate the right choice of the
combustible material you can find below one of the most common certification marks identifying the quality of the pellets:
The use of poor quality pellets or any other material can damage the appliance operation, voiding the warranty
and exempting the manufacturer from all liability.
In order to guarantee trouble-free combustion, the pellets must be stored in a dry place.
Indication of the standard,
base reference for the quality
classes ENplus
Indication of the quality
class of the certified pellet
(preferable A1)
IT xxx
Code of the certified company
consisting of two elements:
-Symbol of the country of
production (example “IT”)
-Progressive number assigned at
the acquisition of the
certification (example "xxx")

DIVA SLIM AIR PELLET STOVE
10
EN - Rev. 1.0
REQUIREMENTS OF THE PLACE OF INSTALLATION
Positioning
The initial phase for best installation of the appliance is to determine its optimum location; the following elements need to
be considered:
-The possibility of creating an external air vent;
-The possibility of creating a straight flue, preferably coaxial to the outlet of the appliance;
-Ease of access for cleaning the appliance, the flue gas exhaust pipes and the flue.
The unit must be installed on a floor with a suitable load capacity. If the existing building does not fulfil this requirement
appropriate measures (e.g. load distribution plate) must be taken.
The minimum safety distance from flammable materials must be at least 200 mm from the sides and 800 mm
from the front of the appliance.
Relocating the appliance should not be done by forcing on the handle, glass or majolica elements.
The installation must guarantee easy access for cleaning the appliance, the flue gas exhaust pipes and the flue, and any
subsequent maintenance operation by the Authorised technical assistance centre.
Once you have found the best location for the appliance, position it following the instructions given below.
The appliance must not be installed in small rooms, bedrooms, bathrooms or in areas with an explosive atmosphere.
We recommend you fix the appliance to the wall for improved stability. Therefore, proceed as follows:
1. Make two 8 mm diameter holes on the rear wall, at a height and distance according to the bracket (figure 1).
Insert suitable wall plugs in the wall with a diameter of 8 mm.
2. Remove the bracket fixed to the appliance by undoing the two screws indicated in the image (figure 2).
3. Fix the bracket to the wall. Use suitable washers if needed.
4. Position the appliance against the wall making sure that the bracket matches its original position on the
appliance.
5. Tighten the two screws on the bracket and appliance (figure 2), while keeping the appliance at the chosen
distance from the wall.
1
2

DIVA SLIM AIR PELLET STOVE
11
EN - Rev. 1.0
Spaces around and above the appliance
The figure below shows the minimum distances from walls or other not-easily-removable furniture, that need to be taken
into consideration when positioning the appliance.
Any shelves or false ceilings mounted above the appliance must be at least 75 cm away from the top part of it.
Furniture and movable objects made from flammable materials must be positioned at least 50 cm from the side surfaces
of the appliance; these objects must be moved when performing maintenance on the appliance.
Protect all structures that can catch fire against the radiated heat of the fire.
External air intake
During operation, the appliance takes in air from the environment in which it is installed; It is therefore essential that this
air is replaced through an external air vent. The absence of the air vent may affect the flue draught and therefore the
combustion and the safety of the appliance.
Therefore it is mandatory to install an external air vent with a minimum completely free passage of at least 80 cm2
(round hole with minimum diameter of 15 cm protected with a special fixed large mesh grid).
If the wall behind the appliance is on the outside, we recommend you make the hole near it at about 20 cm above the
ground (see example in Fig. A).
If it is not possible to put an air vent in the wall behind the appliance, make a hole in a perimeter wall in the room where it
is installed. If it not possible to put the external air vent in the same room as where the appliance is installed, this hole
can be made in an adjoining room as long as this room communicates permanently, by means of a transit hole (15 cm
minimum diameter).
The hole must be protected externally with a fixed grille. The protective grille must be checked periodically to ensure that
it is not obstructed, thereby impeding the passage of air. Therefore keep the air vents clear of obstructions.
The UNI 10683 Standard FORBIDS the drawing of combustion air from garages, warehouses storing combustible
materials, or from business premises with a fire hazard.
If there are other heating or extraction devices inside the room, the air vents must guarantee a sufficient amount of air for
properly operating all the devices.
Only sealed appliances (e.g. C type gas appliances, according to the UNI 7129 Standard) or appliances that do not
cause a lower pressure compared with the external environment can pre-exist or be installed in the place where the
appliance is installed.
Extractor fans can cause malfunctions to the appliance if used in the same room.
REAR WALL
SIDE WALL
SIDE WALL

DIVA SLIM AIR PELLET STOVE
12
EN - Rev. 1.0
The flue and connection to the same
The flue is an essential element for the efficient operation of the appliance. The flue must have the minimum cross-
sectional dimensions stated in the appliance’s technical specifications (80 mm). Each product must be equipped with its
own flue, without other adjoining elements (boilers, chimneys, stoves, etc.). The flue dimensions are closely related to its
height, which must be measured from the appliance flue gas outlet to the base of the stack. In order to guarantee
adequate draught, the surface of the chimney flue outlet must be double the flue cross-section. The discharge pipe for
combustion products generated by the forced draught device, must comply with the following requirements:
-It must seal off the combustion gases, as well as being waterproof and suitably isolated and insulated in relation to
the conditions of use (refer to UNI 9615);
-It must be made of suitable materials capable of withstanding normal mechanical stress, heat, and the effects of
combustion gases and condensate, if any;
-It must go upwards after the vertical section, for the entire remaining part, with a minimum gradient of 5%. The sub-
horizontal section must not have a length greater than ¼ of the effective height H of the flue or chimney, and must
not be longer than 2,000 mm;
-It must preferably have a round internal cross-section: square or rectangular cross-sections must have rounded
corners with radius not inferior to 20 mm;
-It must have a constant, free and independent internal cross section;
-Rectangular cross-sections must have a maximum ratio of 1.5 between the sides;
-If the flue is installed externally, it must be insulated in order to prevent the flue gases from cooling and forming
condensation;
-Parts made from non-combustible materials - capable of withstanding combustion gases and potential condensation
- must be used for mounting the flue gas pipes (for the section from the appliance to the flue inlet); it is strictly
forbidden to use flue pipes made of aluminium;
-It is forbidden to use fibre cement pipes to connect the appliance to the flue;
-Flue gas conduits must not pass through rooms in which the installation of combustion devices is prohibited;
-The flue gas conduits must be assembled in such a way as to guarantee adequate sealing of flue gases during low
pressure operation of the appliance;
-The installation of horizontal sections is prohibited;
-It is prohibited to use counter sloping elements;
-The flue gas pipe must allow for the recovery of soot or be cleanable, and must have a constant cross-section;
-It is forbidden to allow other air intake conduits and system pipes to transit inside the flue gas pipes, even if they are
over-sized.
FURTHER SPECIFICATIONS TO BE CONSIDERED
-The appliance works with the combustion chamber in depression and the flue pipe in pressure; it is essential that
the flue gas outlet is hermetically sealed.
-The flue pipes inside the installation room must be made of a suitable material (see applicable regulations) and
equipped with sealing gaskets with a minimum diameter of 80 mm.
-The pipes must have a double wall (thermally insulated) or be suitably insulated with rock wool. The maximum
temperature of the flue pipe inside the room must not exceed 70°C.
-IT IS MANDATORY TO HAVE AN INITIAL VERTICAL SECTION OF AT LEAST 1.5 M IN ORDER TO GUARANTEE
CORRECT FLUE GAS DISCHARGE.
-Every direction change must be carried out with a T-shaped fitting and inspection cap. The pipes must be smoke-
tight thanks to special seals capable of withstanding temperatures of up to 250°C. Secure the pipes to the wall with
special collars to prevent any vibration.
-IT IS STRICTLY FORBIDDEN TO INSTALL DRAUGHT REGULATION VALVES (BUTTERFLY VALVES).

DIVA SLIM AIR PELLET STOVE
13
EN - Rev. 1.0
If the flue is old or too large (internal diameter greater than 15 cm), it must be ducted using a stainless steel pipe that is
suitably insulated (with rock wool or vermiculite) and sized according to the route. The connection to the flue must be
appropriately sealed.
When assembling the flue, there must be no more than 4 direction changes, including the initial T-shaped
fitting.
Chimney
The chimney is a device crowning the flue, used to ease dispersion of combustion products.
It must satisfy the following requirements:
-It must have a usable outlet cross-section which cannot be smaller than double that of the flue onto which it is
inserted;
-It must be shaped in such a way as to prevent rainwater or snow from entering the flue;
-It must be built in such a way as to ensure the discharge of combustion by-products even in the event of winds from
every direction and inclination.
The outlet height (where height refers to the top of the flue, regardless of any chimney stacks) must be outside of the so-
called reflux zone, in order to prevent the formation of counter-pressures preventing the free discharge of combustion
by-products into the atmosphere.
It is therefore necessary that the minimum heights - indicated in the following diagrams - are observed:
Ø 80 mm
Ø 80 mm
INSPECTION
MINIMUM 0.5 m
80 mm
INSPECTION

DIVA SLIM AIR PELLET STOVE
14
EN - Rev. 1.0
ELECTRICAL CONNECTION
The electric connection must only be performed by qualified staff, in compliance with all general and local safety
standards.
Check that the power supply voltage and frequency correspond to 220V –50 Hz.
The appliance's safety is ensured when it is properly connected to an efficient earthing system.
When making the electric connection to the mains power supply, include a 6 A –Id 30 mA magnetothermic residual-
current device with suitable breaking load. The electric connections, including the earth connection, must be made after
shutting off the electrical system.
When completing the system, bear in mind that the cables must be laid in an unmovable manner and far from parts
subject to high temperatures. During the final wiring of the circuit, only use components with a suitable electrical
protection rating. Do not pass electric cables in the immediate vicinity of the flue gas pipe, unless they are insulated with
suitable materials.
KLOVER Srl declines all responsibility for injury to persons and animals or damage to objects due to failure to
connect the appliance to earth or to comply with IEC specifications.
Distance > 5 m
Distance < 5m
Distance >1.85 m
Distance < 1.85 m
0.5 m
Technical
volume
0.5 m
1 m minimum
Reflux
zone
15°

DIVA SLIM AIR PELLET STOVE
15
EN - Rev. 1.0
Connection to the room thermostat or to a room probe
One or more terminal blocks are located behind the appliance to connect any room thermostats or probes (refer to
“Components of the appliance”).
The table below describes the operation of the terminal blocks found on the rear panel of the appliance.
Terminal
block
Description
Type of management
Action
1
Main room
Only with room thermostat *
With the contact CLOSED, the appliance continues to work at the set power,
regardless of the SET ROOM (button 1) value and the status of any other room
thermostats or probes connected.
With the contact OPEN, the appliance enters the modulation mode, provided
that the room temperature set in SET ROOM (button 1) is fulfilled and that any
other room thermostats or probes connected are fulfilled.
2
Ducted room 1
(only on configured
model)
With room thermostat *
(it must be enabled in Pr56
with value T1)
With the contact CLOSED, the appliance continues to work at the set power,
regardless of the SET ROOM (button 1) value and the status of any other
thermostats connected.
With the contact OPEN, the appliance enters the modulation mode, provided
that the room temperature set in SET ROOM (button 1) is fulfilled and that any
other thermostats connected.
The ducted room 1 fan modulates nonetheless.
With room probe **
(it must be enabled in Pr56
with value S1)
When the temperature set in SET ROOM 1 (Menu 12-SET ROOM DUCT.) is
reached, the appliance enters the modulation mode, provided that the room
temperature set in SET ROOM (button 1) is fulfilled and that any other room
thermostats or probes connected are fulfilled.
The ducted room 1 fan modulates nonetheless.
* Connect a non-powered room thermostat to manage a simple dry contact and, preferably, with a settable hysteresis
value.
** Connect a room probe type “NTC 10K ± 1%”.

DIVA SLIM AIR PELLET STOVE
16
EN - Rev. 1.0
DESCRIPTION OF COMPONENTS
Remote control
The remote control must be powered by 3 x 1.5 V AAA batteries (model LR03 / MN2400); the battery life depends on
how frequently the remote control is used.
The table describes the operation of the buttons on the remote control.
Button
Description
Mode
Action
1
INCREASE
When pressed the first time...
Allows for modifying the “SET ROOM” room temperature.
Programming mode..
Changes/increases the value of the selected menu item.
Increases the room temperature/working power value.
2
DECREASE
When pressed the first time...
Allows for modifying the “SET OUTPUT” working power.
Programming mode..
Changes/decreases the value of the selected menu item.
Decreases the room temperature/working power value.
In “SET DUCTING”, it modifies the value of ducting 1.
3
ON/OFF
When pressed the first time...
It switches on the display.
Working..
Switches the appliance off when pressed for 2 seconds.
In off mode...
Switches the appliance on when pressed for 2 seconds.
In alarm block..
Releases the alarm.
Menu/programming mode..
Goes to the previous menu level, without saving the changes made.
4
SET
When pressed the first time...
Accesses the user menu.
Menu mode..
Goes to the next menu, saving the changes made.
Programming mode..
Goes to the next sub-menu item, saving the changes made.
5
ESC
When pressed the first time...
Allows for modifying the speed of the ducted fans “SET DUCTING”.
Menu mode..
Goes to the previous menu, saving the changes made.
Programming mode..
Goes to the previous sub-menu item, storing the changes made.
Button 1 –INCREASE
Button 5 –ESC
Button 3 –ON/OFF
Button 2 –DECREASE
Button 4 –SET
Display

DIVA SLIM AIR PELLET STOVE
17
EN - Rev. 1.0
Support panel
The underlying table describes the operation of the buttons on the remote control.
Button
Description
Mode
Action
1
ON/OFF
Working..
Switches the appliance off when pressed for 2 seconds.
In off mode...
Switches the appliance on when pressed for 2 seconds.
In alarm block..
Releases the alarm.
2
POWER
Whenever pressed...
Allows for modifying the “SET OUTPUT” working power, by selecting among 3
available power levels (1, 3 or 5).
The underlying table describes the operation of the LEDs present on the support panel.
LED
Description
Status
Action
1
ON/OFF
Off
The appliance is off.
Flashing
The appliance is switching off.
Lit
The appliance is on.
2 and
3
POWER STATUS
LED 2 Lit, LED 3 Off
Power setting on 1
LED 2 Lit, LED 3 Lit
Power setting on 3
LED 2 Off, LED 3 Lit
Power setting on 5
4
RECEPTION
Lit
Switches on when the PCB receives a signal from the remote control.
5
ALARM
Lit
The appliance is in alarm mode.
6
WI-FI
Off
The appliance is not connected to a Wi-Fi network.
Lit
The appliance is connected to a Wi-Fi network.
Button 1 –ON/OFF
Button 2 –POWER
LED 6 –WI-FI
LED 4 –RECEPTION
LED 5 –ALARM
LED 3 –POWER STATUS
LED 2 –POWER STATUS
LED 1 –ON/OFF
Serial connection for remote
control

DIVA SLIM AIR PELLET STOVE
18
EN - Rev. 1.0
The support panel allows for managing the basic functions concerning the appliance’s operation when there is no remote
control.
The following operations can therefore be carried out:
-SWITCHING ON/OFF: by pressing and holding button 1 (On/Off) for 2 seconds
-WORKING POWER CHANGE: whenever button 2 (Power) is pressed, the working power can be varied by selecting
one of the three available power levels (1, 3 or 5). With the help of LEDs 2 and 3 (Power status), it is possible to
verify which power level was chosen (see LED table).
Display
The remote control display shows information on the appliance’s operating status.
The display can be switched on by pressing button 3 (On/Off).
The underlying figure shows the display during normal operating conditions.
By accessing the menu through button 4 (Set), it is possible to obtain various types of display modes and perform
settings according to the selected menu.
The figure below shows the display when the menus are being browsed.
Room temperature
Clock
Operating status
Power set in
SET OUTPUT
