Knape&Vogt Smart Slide Full Fit Power User manual

Note: Use a minimum of three screws per bracket.
Cabinet Internal Width (CIW)
min. 7(9/32”)
min. 18 (23/32”)
max.16 (5/8”)
* 40 (1-18/32”)
X = 10 - 13mm
X = (13/32”) - (1/2”)
min.35 (1-3/8”)
11 (7/16”)
7 (9/32”)
X
Ø6x10mm
bore for hook
X + 11 (7/16”) X=10 - 13
(13/32”) - (1/2”)
21 (13/16”)
CIW - 42 ±0.5 (1-21/32”)
Minimum Inside Drawer Width = 220 (8 - 21/32”)
Minimum Inside Cabinet Width = 262 (10 - 10/32”)
8
(5/16”)
18 (23/32”)
21 (13/16”)
17.5
(11/16”)
32
(1-1/4”)
1.5
(1/16”)

Compatible with metal rear mounting brackets.
Slide Length
(NL)
Max Min A B
229 (9") 310 (12-7/32") 270 (10-5/8") 261 (10-9/32") 133 (5-7/32") 229 (9")
305 (12") 368 (14-1/2") 328 (12-29/32") 319 (12-9/16") 165 (6-1/2") 261 (10-9/32")
381 (15") 444 (17-1/2") 404 (15-29/32") 395 (15-9/16") 165 (6-1/2") 357 (14-1/16")
457 (18") 520 (20-1/2") 480 (18-29/32") 471 (18-17/32") 261 (10-9/32") 453 (17-27/32")
533 (21") 597 (23-1/2") 557 (21-15/16") 548 (21-9/16") 261 (10-9/32") 517 (20-3/8")
Inside cabinet depth with rear
attachment
Screw locations for frameless
cabinets
Drawer Length
10 (13/32")
4.5 (3/16") (Setback)
16 (5/8”) (Sub-Front
Thickness)
37 (1-15/32")
32 (1-1/4")
A
B
NL
9 (11/32")
9 (11/32")
Inside Cabinet Depth
Cabinet Front Side
17.5 (11/16") 20.5 (13/16") 23.5 (15/16")
20.5 (13/16") 23.5 (15/16") 26.5 (1-1/32")
23.5 (15/16") 26.5 (1-1/32") 29.5 (1-5/32")
Drawer Front Thickness
Setback
Runner Setback (Inset Drawer)
Sub-Front
Thickness
13 (1/2")
16 (5/8")
19 (3/4")
16 (5/8") 19 (3/4") 22 (7/8")
Setback
Runner Setback (Standard Drawer)
Sub-Front
Thickness
1.5 (1/16”)
4.5 (3/16”)
7.5 (5/16”)
13 (1/2”)
16 (5/8”)
19 (3/4”)
Block-Out
Drawer Sub-Front
Drawer Front
Frame
Trial Recommended
Runner Setback for Inset Drawer
(See Inset Drawer Table)
Drawer Sub-Front
Drawer Front
Trial Recommended
Runner Setback for Standard Drawer
(See Standard Drawer Table)
Frame
Setback Table for Standard & Inset Drawer Application

± 1.5 (± 1/16”) ±2(± 3/32”)
A
A B
B
x4 pcs
Position the locks to
the corners.
Position the locks to
the corners.

X mm
32 (1-1/4")
A
B
NL
9 (11/32")
9 (11/32")
Inside Cabinet Depth
Cabinet Front Side
Slide Length
(NL)
A B
229 (9") 270 (10-5/8") 261 (10-9/32") 133 (5-7/32") 229 (9")
305 (12") 328 (12-29/32") 319 (12-9/16") 165 (6-1/2") 261 (10-9/32")
381 (15") 404 (15-29/32") 395 (15-9/16") 165 (6-1/2") 357 (14-1/16")
457 (18") 480 (18-29/32") 471 (18-17/32") 261 (10-9/32") 453 (17-27/32")
533 (21") 557 (21-15/16") 548 (21-9/16") 261 (10-9/32") 517 (20-3/8")
Minimum Inside
Cabinet Depth
Screw locations for frameless
cabinets
Drawer
Length
Slide Mounting Specifications
Cabinet Internal Width (CIW)
min. 7
min. 18 (23/32”)
max.16 (5/8”)
* 42 (1-21/32”)
X=10 - 13
(13/32”) - (1/2”)
21 (13/16”)
CIW - 42 ±0.5 (1-21/32”)
Minimum Inside Drawer Width = 220
Minimum Inside Cabinet Width = 262 (10 - 10/32”)
50 (1-31/32") 53 (2-3/32") 56 (2-7/32")
53 (2-3/32") 56 (2-7/32") 59 (2-10/32")
56 (2-7/32") 59 (2-10/32") 62 (2-14/32”)
Drawer Front Thickness
X (Drilling Position)
Inset Drawer
Sub-Front
Thickness
13 (1/2")
16 (5/8")
19 (3/4")
16 (5/8") 19 (3/4") 22 (7/8")
X (Drilling Position)
Standard Drawer
Sub-Front
Thickness
34 (1-11/32”)
37 (1-15/32”)
40 (1-18/32”)
13 (1/2”)
16 (5/8”)
19 (3/4”)
Drawer Sub-Front
Drawer Front
Trial Recommended
Runner Setback for Inset Drawer
(See Inset Drawer Table)
Drawer Sub-Front
Drawer Front
Trial Recommended
Runner Setback for Standard Drawer
(See Standard Drawer Table)

± 1.5 (± 1/16”) ±2(± 3/32”)
A
A B
B
Position the locks to
the corners.
Position the locks to
the corners.
Ø3,15x16
Recommended Screw
