Knape&Vogt LAZY SUSAN User manual

DOOR MOUNT POLYMER
LAZY SUSAN
Installation Instructions
KNAPE & VOGT MANUFACTURING COMPANY
P. O. Box 191, Muncie, IN 47308
0.899.6535 • 765.288.8730 • Fax [phone] • www.kv.com
RN-245EFS 04/03
Inspect all parts and read all instructions prior to beginning assembly and installation.
Parts Included
A. (2) Shelves F. (4) #10 x 1˝ Screws
B. Lower post G. (8) #8 x 1/2˝ Screws
C. Upper post H. (2) Bearing Hubs
D. Bottom Mounting I. (2) Bearing pins
Bracket
E. Clutch Mount
Assembly
Tools Required
•Phillips screwdriver with sharp #2 point
and 1/4˝ diameter shank. Note: a rounded
or broken point will make height
adjustment difficult or damage adjusting
screw.
•Drill with 1/8˝ and 1/16˝ diameter drill bits
• Pencil
Product Assemblies
PPN24 PPN28
Step 1 Hold Lower post (B) and locate height adjusting
screw in post raising assembly. To check that jack
base is properly located for future vertical
adjustment, loosen screw 1 turn. Leave the
screwdriver in the screw to use as a handle. Rotate
the jack base within the post to the right and to the
left. Stop the screw so that the jack base is in the
middle of the travel area and tighten 1 turn.
Step 2 Insert Bearing Hubs (H) into center area on the
underside of each of the Shelves (A). Note that the
key way on the side of the Bearing Hub must be
aligned with the key on the inside of the Shelf.
Step 3 Slide the Shelves onto the Lower post from the
bottom (post raising assembly end).
Step 4 Push one of the Bearing pins (I) into bottom slot in
pole and through the hole in post raising assembly,
then slide bottom shelf down over pin so that the
groove in the hub engages or captures the pin,
making sure the jack assembly remains inserted in
the lower post.
Step 5 Insert second Bearing pin (I) into one of the upper
holes in the Lower post to give desired shelf
separation. (Note: The second from the top pin hole
will give approximately 11 1/2˝ of clearance. This
should allow for enough room for items on Lower
Shelf). Slide Top Shelf down over the Bearing pin so
that the groove in the Bearing Hub engages or
captures the pin.
Step 6 Lay the cabinet door over a sawhorse or similar
workstand. Position shelves onto door as they
would be in the installed location. The bottom of
the face of lower shelf should be located 1-1/2˝
above the floor of the cabinet when the post raising
assembly is in the center of its range.
E
A
B
C
D
F
H
G
I
1
2
3
4 & 5

Check to see if the faceframe protrudes above the floor of the cabinet, then subtract any
protrusion and the desired door/frame reveal from 1-1/2˝ to get the location of the bottom of
the door relative to the bottom of the face of the shelf. Recheck the Shelves to make sure
the grooves in the Bearing Hub are engaging the Bearing pins and that they are pushed onto
the pins as far as they will go. Mark and drill 1/8˝ pilot holes, 1/4˝ deep using the existing
holes in the Bottom Shelf face as a template. Fasten the Bottom Shelf to door using (4) #10 x
1˝ Screws (F).
Step 7 Making sure the Top Shelf is pushed down onto the top Bearing pin as far as it will go, mark
and drill 1/8˝ pilot holes, 1/4˝ deep using the existing holes in the Top Shelf face as a
template. Fasten the Top Shelf to door using (4) #10 x 1˝ Screws (F).
Step 8 Use installation template to mark and drill 1/16˝ pilot holes in the bottom and top of cabinet
interior.
Step 9 Place Bottom mounting bracket (D) over drilled holes and fasten using (2) #8 x 1/2˝ Screws
(G). Install the Clutch Mount Assembly (E) in the same manner using 2 Screws (G).
Step 10 Using the lower post as a handle to keep shelves from sliding off Bearing pins, and making
sure that the upper post is inserted fully into the lower post, place the entire door-mounted
unit into the cabinet. Engage the bottom of the post raising assembly with the bottom
mounting bracket. Loosen the setscrew that holds the Upper post in the lower post and slide
up the upper post to engage the clutch mount assembly. Push the upper post into the clutch
mount assembly as far as it will go, then back out 3/32˝ to leave room for rotational
adjustment. Tighten the set screw securely with a screwdriver.
Step 11If cabinet door needs to be raised or lowered to center in the cabinet opening, loosen height
adjusting screw 1 turn (leaving screwdriver engaged in screw). Using the screwdriver as a
handle, rotate as needed to set the door to the proper height and tighten screw securely. If
the Upper post won't move far enough, the screw on the clamp of the Clutch Mount
Assembly can be loosened and the Upper post moved up or down 1/8˝ more.
Step 12 Loosen clamp screw on the Clutch Mount Assembly 1 turn. Gently turn the shelves
clockwise (push with left hand). When the shelves stop turning easily, return the shelves
back turning counterclockwise (push with right hand). Stop turning at the moment the door
is perfectly aligned in the opening. Turn the doors back into the cabinet clockwise (push
with left hand). Stop turning when you can easily reach the clamp screw on the Clutch
Mount Assembly. Retighten clamp screw.
Your installation is complete! Affix the enclosed “Care Instructions” to an inside wall of the
cabinet for future reference.
8 & 9
10
11
6
