KneeRover GO User manual

KneeRover® GO
Knee Scooter User Manual
Congratulations on your purchase of the KneeRover®GO
–The Most Compact & Portable Knee Scooter!
The KneeRover®GO is designed for the person on the go that
won’t let an ankle, foot or leg injury slow them down. Whether you
are a commuter, traveler, or just need a compact and portable
mobility device to go about your busy life–the KneeRover®GO will
give you the freedom you deserve during your recovery.
Operating Instructions:
This medical device is designed to maximize mobility during your
recovery from foot/ankle surgery or injury.
Place the knee of your injured leg on the knee platform and stand as
straight as possible. Adjust the handlebar to waist height so the arms and
hands are in a comfortable position. Adjust the knee platform so that
your injured leg is supported at a 90 degree angle when standing.
Ensure that the hand brake is fully engaged before mounting the
KneeRover®scooter. To move the scooter, simply push forwards or
backwards with your good foot. Allow the scooter to glide, and as it slows
down, push again.
Safety First:
The KneeRover®scooter is designed for easy steering and stopping and
should be used to carefully move about at slow, controlled speeds. When
turning the scooter, you should have the brake applied and be moving at a
slow, safe, controlled speed. It is easy to tip the scooter if you are making
a turn with too much speed. Use caution and balance and operate at your
own risk.
With routine use, nuts and bolts on steering column and brake
mechanism can and likely will become loose. Periodically check nuts and
bolts after use and re-tighten as appropriate.

KneeRover®GO
Set Up Instructions:
Please follow the step by step instructions on the following pages to
properly assemble your KneeRover®scooter. The diagram below
identifies the key components of the scooter to aid with assembly.
Visit kneerover.com for assembly videos.
Setup Instructions:
Step 1: Install Steering Column
Please carefully complete all steps before operating your new
KneeRover®scooter. Remove all packing materials and then unhook the
Transport Bungee hook from steering column (shown in left photo
below). Next, raise the steering column until it is vertical, and lift the
hinge lever completely so it is also vertical. Then slide the black latch to
the LEFT to secure the hinge lever in place (see right photo below).
Step 2: Rotate Front Wheels & Set Guide Pin
Pull down the guide pin ring (as shown below left), and turn the
handlebars counterclockwise so that the front wheels and brake handle
are facing forward. Release the guide pin so it sits between the guide
stops (see photo on right). Be sure that the brake cable is not twisted.
The front of the scooter should look similar to the picture on the previous
page.
Hand Brake Lever
7.5” Non Marking
Wheels
Steering Column
Steering
Column Quick
Release Clamp
Brake Cable
Weight Capacity = 300 pounds
Steering Column
Guide Pin
Center Frame
Hinge
Steering Height
Adjustment Lever
Adjustable Knee
Platform
Rear Brake
Mechanism
Transport
Bungee Hook
Steering Hinge
Lever
Pull Guide Pin
Ring Down
Steering
Guide Pin
Steering
Guide Stops
Move Black
Latch to Left

Step 3: Secure Center Frame Hinge
Connect the front (green) and rear (white) frame sections by
closing the center frame hinge. The hinge pin will lock into place
(see left photo). Next, ensure the frame is securely locked into place
by sliding the frame lever into the slot (center photo). Rotate the
lever clockwise to tighten and then press the lever firmly down
until it is locked in place (see left photo).
Step 4: Install Knee Platform and Set Handlebar Height
The knee platform is designed to be used with either the right or left
leg. Insert the knee platform post into the receptacle tube and set the
knee platform at your desired height for use by inserting the locking
pin through the aligned holes. Finally, tighten the clamp lever to secure
the knee platform in place. (see left photo below)
Open the steering height lever, and pull up on the handlebars to set at
the desired height - typically waist height. Next, turn the ribbed knob
clockwise to tighten the clamp and firmly push the steering height
lever to closed and locked position (see bottom right photos).
Setup Continued & Maintenance:
Step 5: Brake Operation
To engage the hand brake, squeeze the brake lever on handle bar.
The KneeRover®scooter comes equipped with a brake lock /
parking brake. Simply squeeze brake handle firmly and press the
button to engage the lock. To release the lock, squeeze the brake
handle again.
Ongoing Maintenance
With routine use, nuts and bolts on the steering column and brake
assembly can become loose. To ensure safe operation of this
KneeRover®scooter it is important to periodically inspect the knee
walker for loose nuts and bolts and re-tighten as appropriate.
The KneeRover®GO is designed to quickly
breakdown for compact portability and easy
transport. To learn how to breakdown the
KneeRover®GO, and for additional support in
maintaining your knee scooter, please visit:
kneerover.com/pages/kneerover-maintenance-videos
Hinge Pin
Press Lever Down
Firmly
Slide Lever into Slot
Frame Lever
Ribbed Knob
Close Steering
Height Lever
Clamp
Lever
Locking Pin
Brake Lock

Your Satisfaction is Our Top Priority:
Thank you for your business –we appreciate having you as a customer!
We are committed to providing innovative and affordable mobility
solutions to get you moving as soon as possible after injury or surgery
and for the duration of your recovery –free to go about your busy,
active life –and have a little fun doing it.
We hope that you are completely satisfied with your purchase. If you
have any issues, please contact us and we will do everything possible
to help you. Reviews have a significant impact on our small business.
If you purchased this product on Amazon or eBay, we would greatly
appreciate a review once you’ve had a chance to use your new
KneeRover® scooter. We hope we’ve earned a 4 or 5 star review – if
not, please give us the opportunity to help you before leaving a review.
Thank you for your support. We appreciate you!
Need Help –Contact Us:
Phone: [phone]
Email: [email protected]
Web: www.kneerover.com
Assembly Support: kneerover.com/pages/assembly-video
EU AUTHORIZED REPRESENTATIVE
Murray's Medical Equipment Ltd
Airton Park, Airton Road, Tallaght,
Dublin 24 (Eircode D24 DY09), Ireland
T: 00 353 1 855 5696
www.murrays.ie
Limited Lifetime Warranty
This warranty applies only to the original purchaser.
This device was built to exacting standards and carefully inspected
prior to shipment. Your KneeRover®brand product is warranted
to be free of defects in materials and workmanship for a period of
one year from the date of purchase. The side frames and cross
braces are warranted for the lifetime of the KneeRover®scooter.
This warranty does not cover device failure due to owner misuse,
negligence, or normal wear and tear. The warranty does not
extend to non-durable components, which are subject to normal
wear and need periodic replacement. These components include,
but are not limited to tires, grips, brake pads and upholstery.
The warranty shall not apply for damages or defects caused by
unauthorized parts, attachments or repairs, negligence, accident,
or any circumstances beyond the control of KneeRover®, such as
improper operation, maintenance or storage.
If you have any questions regarding your KneeRover®product or
this warranty, please contact our Customer Care Team. We are
available, for your convenience, toll free at 1-877-737-9877,
Monday –Friday from 9 am to 5 pm Eastern.
Need Parts or Accessories?
Add an accessory like a deluxe backpack, knee pad cover, cup holder
or headlight to enhance your experience on your new KneeRover®
scooter. Keep your scooter operating in top shape with original
manufacturer parts. Visit kneerover.com, to explore our full range
of parts and accessories.
KneeRover®is a registered trademark of Rover Mobility, LLC.
