Start Building
To begin your model, find step number and
follow the numbers. Each piece has its own shape
and color. Look at the pictures, find the pieces that
match what you see, and connect them together.
It helps to face your model in the same direction
as the instructions while you build. The arrows
show you where the parts connect, but not all
connection points have arrows. The faded color
parts are the ones you have already put together.
1
Connectors
You can slide these special connectors together.
Push tightly until you hear a “click”. Pay close
attention to the instructions and position them
horizontally or vertically exactly as shown.
Driver
Assembly
Parts List
Before you start building, be sure to compare the parts in your set with the parts listed here.
If anything is missing, call or write to us using the information on the back cover. We’re here to help!
