Stratos MS A405
Conductivity Measurement
Latest Product Information: www.knick.de
User Manual
English

3
Table of Contents
About This Manual.....................................................................................................5
Documents Supplied ................................................................................................6
Introduction........................................................................................ 7
Overview of the Stratos MS ............................................................... 8
Package Contents.......................................................................................................8
Mounting Accessories ..............................................................................................9
Pipe Mounting, Protective Hood .......................................................................10
Panel Mounting .......................................................................................................11
Terminal Assignments, Rating Plates..............................................12
Power Supply............................................................................................................13
Start-Up.............................................................................................14
Calibration and Maintenance in the Lab ........................................................14
Memosens Cable .....................................................................................................15
Wiring Example SE 670 / SE 680......................................................................... 16
Measuring Mode............................................................................... 17
The Keys and Their Functions ..........................................................18
The Display........................................................................................19
Display in Measuring Mode.................................................................................20
Selecting the Mode / Entering Values .............................................21
Operating Modes ....................................................................................................22
HOLD Mode...............................................................................................................23
Operating Modes / Functions............................................................................. 24
Connecting a Memosens Sensor .....................................................26
Replacing a Sensor.................................................................................................. 27
Conguration: Overview..................................................................29
Device Type: Cond / CondI...................................................................................32
Sensor Verication (TAG, GROUP) .....................................................................34
Output Current: Range, Current Start/End.....................................................36
Output Current: Curve........................................................................................... 38
Output Current: Logarithmic Curve.................................................................. 40
Output Current: Time Averaging Filter ............................................................42

4Table of Contents
Output Current: Error and HOLD .......................................................................44
Alarm Delay, Sensocheck, Tempcheck............................................................. 46
Temperature Compensation ...............................................................................48
Relay Contacts: Function Assignment, Limit Values ...................................50
Relay Contacts: Limit Function, Hysteresis.....................................................52
Relay Contacts: Alarm............................................................................................ 54
Relay Contacts: Controlling a Rinsing Probe .................................................56
Protective Wiring of Relay Contacts.................................................................. 58
Time and Date, Measuring Point (TAG/GROUP)...........................................60
Calibration ........................................................................................63
Calibration with Calibration Solution ..............................................................64
Product Calibration................................................................................................. 66
Temp Probe Adjustment....................................................................................... 68
Calibrating Toroidal Sensors................................................................................69
Calibration by Input of Cell Factor .................................................................... 70
Zero Calibration .......................................................................................................71
Measurement.................................................................................... 72
Diagnostics .......................................................................................73
Service ...............................................................................................78
Error Messages..................................................................................81
Sensocheck and Sensoface..............................................................83
Operating States...............................................................................84
Product Range ..................................................................................85
Specications....................................................................................86
Calibration Solutions .......................................................................91
Concentration Measurement...........................................................93
Concentration Curves.......................................................................94
Index................................................................................................100

5
About This Manual
Subject to change without notice
Return of Products Under Warranty
Please contact our Service Team before returning a defective device.
Ship the cleaned device to the address you have been given.
If the device has been in contact with process uids, it must be decontaminated/
disinfected before shipment. In that case, please attach a corresponding certicate,
for the health and safety of our service personnel.
Disposal
Please observe the applicable local or national regulations concerning the
disposal of “waste electrical and electronic equipment”.
About This Manual:
This manual is intended as a reference guide to your device –
You don’t have to read the book from front to back.
Take a look at the Table of Contents or the Index to nd the function you are
interested in. Each topic is explained on a double-page spread with step-by-step
instructions on how to congure the desired function. Clearly legible page numbers
and headlines help you to quickly nd the information:
58 59
Use of relays
Select process variable
Limit 1
switching characteristics (function)
Limit 1
contact type
Limit 1
setpoint
Limit 1
hysteresis
Limit 1
delay
Relay Contacts: Function Assignment, LimitValues
(Example: device type pH)
1 Press menu key.
2 Select CONF using  keys, press enter.
3 Select RELAY1 menu using  keys,
press enter.
Specify relay contact function: LIMIT.
4 All items of this menu group are indicated by the“LM1:“
code.
Press enter to select menu,
edit using arrow keys (see next page).
Confirm (and proceed) by pressing enter.
5 Exit: Press meas key until the [meas] mode indicator is
displayed.
4
Conguration: Relay Contacts
Menu item Action Choices
Use of relays Select in the text line using 
keys:
• Limit function (LIMITS)
• Error message (ALARM)
• Rinse contact (WASH)
Press enter to confirm.
Note: The following submenu
depends on the selected setting.
Select process variable Select desired process variable
using  keys.
Press enter to confirm.
Limit 1 function Select desired function using
arrow keys.
LoLevel: active if value falls
below setpoint
LoLevel: active if value exceeds
setpoint
Press enter to confirm.
Limit 1 icon:
Limit 1 contact response N/O: normally open contact
N/C: normally closed contact
Select using keys.
Press enter to confirm.
Limit 1 setpoint Enter setpoint using  
keys.
Press enter to confirm.
Conguration: Relay Contacts
Left page:
How do I get to the
function
Right page:
Which settings are pro-
vided for this function
Parameter concerned

6Documents Supplied
Ex Devices:
Control Drawings
EU Declarations of Conformity
Up-to date documentation available on our website:
www.knick.de
Safety Instructions
In ocial EU languages and others
Quickstart Guides
Installation and rst steps:
• Operation
• Menu structure
• Calibration
• Error messages and recommended actions
Specic Test Report
Electronic Documentation
Manuals + Software

7
Introduction
Stratos MS is a 4-wire analyzer for use with Memosens sensors. The Model A405B
allows applications in hazardous-area Zone 2. Current is provided through a
universal power supply 80...230VAC, 45...65Hz / 24...60VDC.
The analyzer provides two 0 (4) .... 20mA current outputs for transmission of
measured value and temperature, for example.
Two oating relay contacts are available for free conguration.
You can select one of the following measuring functions:
• pH
• ORP
• Dissolved oxygen
• Conductivity measurement (conductive/inductive)
Enclosure and mounting possibilities
• The sturdy molded enclosure is rated IP 67/NEMA 4X outdoor.
Material of front unit: PBT, rear unit: PC.
Dimensions: H 148 mm, W 148 mm, D 117 mm.
It is provided with knockouts to allow:
• panel mounting (138 mm x 138 mm cutout to DIN 43700)
• wall mounting (with sealing plugs to seal the enclosure)
• post/pipe mounting (dia. 40 … 60 mm, 30 … 45 mm)
Protective hood (accessory)
The protective hood provides additional protection against direct weather exposure
and mechanical damage (available as accessory).
Connection of sensors, cable glands
For connecting the cables, the enclosure provides
• 3 knockouts for cable glands M20x1.5
• 2 knockouts for NPT 1/2” or rigid metallic conduit
Memosens sensors and connecting cables
Please visit our website for more information on our product range: www.knick.de.

8
Package Contents
Check the shipment for transport damage and completeness.
The package should contain:
Front unit, rear unit, bag containing small parts
Specic test report
Documentation
11
10
9
8
76 54
1
2
3
Fig.: Assembling the enclosure
1) Jumper (3 x)
2) Washer (1 x), for conduit mounting:
Place washer between enclosure and
nut
3) Cable tie (3 x)
4) Hinge pin (1 x), insertable from either
side
5) Enclosure screw (4 x)
6) Sealing insert (1 x)
7) Rubber reducer (1 x)
8) Cable gland, M20x1.5 (3 x)
9) Filler plug (3 x)
10)Hexagon nut (5 x)
11)Sealing plug (2 x), for sealing in case
of wall mounting
Overview of the Stratos MS

9
Overview of the Stratos MS
Mounting Plan, Dimensions
1) Cable gland (3 x)
2) Knockouts for cable gland or
½“conduit, dia. 21.5 mm
(2 knockouts).
Conduit couplings not included!
3) Knockout for pipe mounting
(4x)
4) Knockout for wall mounting
(2x)
6.2
Mounting Accessories
Pipe-mount kit, accessory ZU 0274
Protective hood for wall and pipe mounting, accessory ZU 0737
Panel-mount kit, accessory ZU 0738
All dimensions in mm

10
Pipe Mounting, Protective Hood
Fig.: Protective hood for wall and pipe mounting, accessory ZU 0737
Fig.: Pipe-mount kit, accessory ZU 0274
1) Hose clamp with worm gear drive to
DIN 3017 (2 x)
2) Pipe-mount plate (1 x)
3) For vertical or horizontal posts or
pipes
4) Self-tapping screw (4 x)
1
2
3
4
ø40...ø60
Overview of the Stratos MS

11
Panel Mounting
Fig.: Panel-mount kit, accessory ZU 0738
1) Circumferential sealing (1 x)
2) Screw (4 x)
3) Position of control panel
4) Span piece (4 x)
5) Threaded sleeve (4 x)
Cutout
138 x 138 mm (DIN43700)
Overview of the Stratos MS
All dimensions in mm

12 Overview of the Stratos MS
Overview of the Stratos MS
8
14
15
16
1
2
3
4
21
22
9
10
11
12
Output 1
HOLD
input
Output 2
Power
RS 485
Memosens
Terminal Assignments, Rating Plates
The terminals are suitable for single or stranded wires up to 2.5 mm2(AWG 14).
Application in Hazardous Locations
When using the device in a hazardous location, observe the
specications of the Control Drawing.

13
Power Supply
Connect the power supply for Stratos MS to terminals 21 and 22
(80 ... 230 V AC, 45 ... 65 Hz / 24 ... 60 V DC)
Terminal assignments
Memosens connection
Brown
Green
Yellow
White /
Transp.
Current outputs OUT1, OUT2
Relay contacts REL1, REL2
Power supply
Areas for placing the
screwdriver to pull out
the terminals
1 22
Overview of the Stratos MS
Figure:
Terminals, device opened,
back of front unit
Connection of Memosens sensor
Brown
Green
Yellow
White/Transp.

14 Memosens Sensors
Start-Up
When a Memosens sensor is connected, the appropriate measuring function
(device type) is automatically loaded.
Changing the Measuring Function
In the “Service”menu you can select another measuring function at any time.
Calibration and Maintenance in the Lab
The “MemoSuite” software allows calibrating Memosens sensors under reproducible
conditions at a PC in the lab. The sensor parameters are registered in a database.
Documenting and archiving meet the demands of FDA CFR 21 Part 11. Detailed
reports can be output as csv export for Excel. MemoSuite is available as accessory
and comes in the versions“Basic” and “Advanced”: www.knick.de.
Function selection:
The selected func-
tion is highlighted.
Connected sensor:
sensor type, manu-
facturer, order code
and serial number,
measuring point and
tag number
Last adjustment
Conductivity
1.010 mS/cm
Measured values
Conductivity
Resistance
Temperature
1.010 mS/cm
1.00 kΩ
25 °C
Sensor data
Sensor type:
Manufacturer:
Order code:
Serial number:
Conductivity
Knick
SE630-MS
11003
Adjustment data
Date:
Cell constant:
4/27/2015 20:09:12
1.01 1/cm
StartCenter Calibration Table View History Statistics pH Buers
Sensor type:
Manufacturer:
Conductivity
Knick
Order code:
Serial number:
SE630-MS
11003
Measuring point:
Tag number: 7 Change
Change
Show
Connected sensor: sensor type, manufacturer,
order code and serial number
Settings and
specications
You can magnify a measured-
value display at a click of the
mouse.

15
Memosens Cable
Brown
Green
Yellow
White
Transparent
Memosens Cable CA/MS-...
Specications
Material TPE
Cable diameter 6.3 mm
Length up to 100 m
Process temperature –20°C…+135°C / –4…+275 °F
Ingress protection IP 68
Order Codes
Cable type Cable length Order number
Memosens
Ferrules 3 m
5 m
10 m
20 m
M12 plug, 8-pin 3 m
5 m
Memosens Ex*
Ferrules 3 m
5 m
10 m
20 m
M12 plug, 8-pin 3 m
5m
Other cable lengths or cable types are available on request.
*Ex-certied ATEX II 1G Ex ia IIC T3/T4/T6 Ga

16
Sensor, M12 connector
Wiring Example SE 670 / SE 680
White Brown Yellow
Transparent
Green
Cable Device
Connect the SE 670 / SE 680 sensor to the RS-485 interface of the device. When
SE670/ SE 680K is selected as sensor in the Conguration menu, the default values
are taken as calibration data. They can then be modied by calibration.
All calibration data of the SE 680M sensor with Memosens protocol are stored in the
sensor.
Cable types:
M12/ferrules
5 m
10 m
20 m

17
Operation
Measuring Mode
After the operating voltage has been connected, the analyzer automatically goes to
“Measuring“ mode. To call the measuring mode from another operating mode (e.g.,
Diagnostics, Service): Hold meas key depressed (> 2 s).
Depending on the conguration, you can set various displays as standard display for
the measuring mode (see page20).
Note: By pressing the meas key in measuring mode you can view the displays for
approx. 60 sec.
Sensoface indicator
(sensor status)
Time
Mode indicator
(measuring)
Hold meas key
depressed
for calling the measuring
mode
(hitting the key once more
switches the display)
Display indicates
OUT1:
e.g., measured
value
Display indicates
OUT2:
e.g.,
temperature
enter key
NOTICE:
You must congure the analyzer for the respective measurement task.

18 The Keys and Their Functions
meas
• Return to last
menu level
• Directly to
measuring mode
(press > 2 s)
• Measuring mode:
other display
(temporarily for
approx.60s)
info
• Retrieve
information
• Show error
messages
menu
• Measuring mode:
Call menu
Up / Down
arrows
• Menu:
Increase/decrease a
numeral
• Menu: Selection
Left / Right
arrows
• Menu:
Previous/next menu
group
• Number entry:
Move between digits
enter
• Conguration:
Conrm entries,
next conguration step
• Calibration:
Continue program ow

19
MEMO SENS
Signal Colors (Display Backlighting)
Red
Red blinking
Alarm (in case of fault: display values blink)
Input error: illegal value or wrong passcode
1 Temperature
2 Sensocheck
3 Interval/response time
4 Sensor data
5 Wear
6 Limit message:
Limit 1 or Limit 2
7 Alarm
8 Service
9 Not used
10 Calibration
11 Memosens sensor
12 Waiting time running
13 Info available
14 HOLD mode active
15 Primary process value
16 Secondary display
17 Proceed using enter
18 Not used
19 Diagnostics
20 Conguration mode
21 Calibration mode
22 Measuring mode
23 Sensoface
24 Unit symbols
The Display

20
enter key
meas key
approx. 2 s
By pressing meas briey you can step through
further displays such as primary value or tag
number (TAG).
After 60 sec they switch back to the main
display.
Press enter to select a display as
MAINDISPLAY (displayed permanently in
measuring mode).
The secondary display shows
“MAINDISPLAY – NO”.
Use the UP / DOWN arrows to select
“MAINDISPLAY – YES”
and conrm by pressing enter.
This display is now shown in measuring
mode.
The MAIN DISPLAY is the display which is
shown in measuring mode. To call the mea-
suring mode from any other mode, hold the
meas key depressed for at least 2 sec.
Display in Measuring Mode
