Knox Video SDI8x8 User manual

KNOX VIDEO
SDI8x8 Routing Switcher
Page 1 Page 2
WARNING!
Static Sensitive Connectors! During the installation process and whenever
changing cables to the Knox SDI8x8 inputs and outputs, use extreme caution to
avoid conducting static electricity to any inputs or outputs including video, audio,
and RS232.
DC Offset Warning! Connect standard video and audio inputs and outputs only.
Do not connect input or output signals with a positive or negative dc offset.
Chassis Ground is Earth Ground Do not connect video or audio cables with
induced or direct-connection potential on the shield.
SECTION 2. INSTALLATION
2.1 INTRODUCTION
This section provides the information required for installation of the SDI8x8
into its operating environment.
2.2 UNPACKINGANDINSPECTION
Unpack the SDI8x8 carefully and verify that the serial number matches the
number quoted on the packing list. Before installing it into a system, check the
outside of the unit carefully for signs of damage and check that none of the fasteners
have come loose.
Checkthat thepower moduleis alsopresent andmarked foruse withthe SDI8x8
product. The SDI8x8 uses a +5 volt supply with center pin positive.
DONOTUSEANYOTHERPOWER SUPPLYWITHTHESDI8x8.
Units are shipped with a memory-backed program microprocessor chip which
retains the routing crosspoint information when power is off.
2.3 INSTALLATION
The SDI8x8 is designed to be mounted in a standard 19” rack panel; it is 5.25
inches, or three standard units, high.
Choose a space in the rack which is convenient for all the cables and mount the
unit using standard rack bolts. Connect the output of the SDI8x8 power unit to the
power connector at the right rear (as viewed from the back of the panel) of the
SDI8x8 and plug the power unit into a grounded AC power outlet of the voltage and
frequency specified on the power unit. There is no power switch on the SDI8x8; it
isdesigned tobe ONat alltimes. (Ifit isdesirable tohave theSDI8x8 powereddown
regularly, connect the power module to a switchable AC power strip.)
2.4 VIDEOCONNECTIONS
Connect up to eight SDI video sources to the input BNC connectors marked
VIDEO INPUT. Inputs are automatically terminated in 75 ohms. An Input Carrier
DetectLED will lightfor eachvalid SDIinput.
Connect up to eight SDI destinations to the eight BNC connectors marked
OUTPUT. Be sure that all destination devices are terminated at 75 ohms. When a
valid input signal has been routed to an output, the CD LED and the Data Rate LED
for that output will light.
Do not connect a SOURCE of video to any of the video OUTPUT connectors.
KNOX VIDEO
SDI8x8 Routing Switcher

KNOX VIDEO
SDI8x8 Routing Switcher
KNOX VIDEO
SDI8x8 Routing Switcher
Page 3 Page 4
2.5 SETTINGTHEBAUDRATE
If the SDI8x8 is to be controlled through its RS232 port, it is important to set
the correct baud rate. One of four baud rates may be selected using positions 1 and
2 of the programming switch located on the rear panel of the SDI8x8. Set the
switches as follows:
Switches are ON when pushed up.
All baud rates are 8 bit, No Parity, One or Two stop bits.
The switches are read by the microprocessor only at power-up; for switch
configuration changes to take effect, cycle the power input to the SDI8x8.
2.6 ANSWERBACKMODES
The user may choose between two modes of answerback: verbose and non-
verbose. Select the mode using position 3 of the programming switch located on
therear panelof theSDI8x8. Position3 ONis verbose,while position3 OFFisnon-
verbose.
In the verbose mode, each time a routing command is sent, the entire current
routing map will be reported on the RS232 line.
In the non-verbose mode, only the word DONE will be reported.
In either mode, an incorrect or meaningless command will result in the word
ERRORbeing reported.
ALLOTHERSWITCHPOSITIONS(5-8) SHOULD BEOFF.
BAUDRATE
19200
1200
2400
9600
SWITCH1
ON
OFF
ON
OFF
SWITCH2
ON
ON
OFF
OFF
SECTION3.OPERATION
3.1 INTRODUCTION
Thissection explains indetail theoperation ofthe SDI8x8using eitherthe front
panel pushbutton switches or the RS232 port.
3.2 CONNECTIONS
Connect video sources as described in sections 2.4 and 2.5. There is no
requirement that all inputs or outputs be used or terminated.
If outputs are left over they may be used like a distribution amplifier to buffer
and distribute an input signal. To use extra outputs in this way simply route the
input you wish to distribute to as many available outputs as desired.
Do not route an output back to the same input.
3.3 ROUTINGVIATHEFRONTPANELSWITCHES
3.3.1 HOWTOROUTESDIVIDEO
Select the output you wish to route a signal to and push (and release) the front
panel button with that number; the row of LEDs to the right of the button you
pushed will flash. Then select the input audio and video you wish to have routed
to that output and push the front panel button with that input number.
The row of LEDs will stop flashing and the lamp corresponding to that
crosspoint will then glow steadily.
If you do not push an input button within ten seconds, the LEDs will stop
flashing and the crosspoint will remain where it was.

KNOX VIDEO
SDI8x8 Routing Switcher
KNOX VIDEO
SDI8x8 Routing Switcher
Page 5 Page 6
3.3.2 HOWTOSTOREANDRECALLCROSSPOINTPATTERNS
The SDI8x8 has 8 stored routing map configuration memory locations. These
stored configurations are non-volatile and are thus maintained during power
interruptions.
To RECALL and load one of the stored patterns from front panel, push and
hold input button #1; an R will appear on the LED display. Then push an output
button, 1 to 8, corresponding to the crosspoint pattern you wish to recall.
To STORE the currently loaded crosspoint pattern to one of the eight pattern
storage areas, push and hold input button #8; an S will appear on the LED display.
Then push an output button, 1 to 8, corresponding to the storage area you wish to
store the crosspoint pattern in.
3.4 ROUTINGVIATHERS232INPUT
3.4.1 ROUTINGSDIVIDEO
A simple protocol allows all crosspoints to be set through the RS232 port. The
RS232 port will accept inputs from a terminal, computer, or other software-driven
control device. No handshaking is required, but the SDI8x8 will answerback in one
of two modes to each command received (see section 3.5 for details).
TheSDI8x8 RS232port isconfigured asaDCE. The pin-outof thisport allows
connection to an IBM-PC or compatible 9 pin serial COM port with a 1:1 cable.
To route video, send a four-byte command in the form:
Vxy(ENTER),
where x is an output number and y is an input number. The leading letter may be a
Vor aB.
Each time a routing command is sent, the RS232 output line responds in
accordance with the verbose/non-verbose switch setting (see section 2.6).
3.4.2 TURNINGANOUTPUTOFF
Any output may be turned off by using a 0 (zero) as the input number. Thus the
command: B10(ENTER)
turns output 1, and its front-panel crosspoint LED, OFF.
All outputs may be turned off by sending the command:
C(ENTER)
All crosspoint LEDs will go off.
3.4.3 STORINGANDRECALLINGCROSSPOINTPATTERNS
To RECALL and load one of the eight crosspoint patterns in the backed-up
memory, send the three-byte command:
Rn(ENTER),
where n is a number from 1 to 8.
To STORE the currently loaded crosspoint pattern to one of the eight pattern
storage areas, send the three-byte command:
Sn(ENTER),
where n is a number from 1 to 8. The pattern stored in that memory area will be
overwritten by the new pattern.

KNOX VIDEO
SDI8x8 Routing Switcher
KNOX VIDEO
SDI8x8 Routing Switcher
Page 7 Page 8
3.5 ANSWERBACKMODES
The user may choose between two modes of answerback: verbose and non-
verbose. Select the mode using position 3 of the programming switch located on
therear panel of the SDI8x8.Position 3ON isverbose, whileposition 3OFF isnon-
verbose.
In the verbose mode, each time a routing command is sent, the current routing
map will be reported on the RS232 line.
In the non-verbose mode, only the word DONE will be reported.
In either mode, an incorrect or meaningless command will cause the word
ERRORto be reported.
3.6 READINGSYSTEMSTATUS
The crosspoint status can be read from the RS232 port at any time by sending
the two-byte command:
D(ENTER)
The status report does not disturb the existing crosspoint pattern.
3.7 LAMPTEST
The lamp test which occurs automatically on power-up or at RESET can be
initiated through the RS232 port by sending the two-byte command:
T(ENTER)
The lamp test does not disturb the existing crosspoint pattern.
3.8 SIGN-ONMESSAGE
The SDI8x8 will report its sign-on message out the RS232 port on receipt of
thecommand:
I(ENTER)
3.9 HELPSCREEN
TheSDI8x8 willdump alistof itscommands outthe RS232porton receiptof
thecommand:
H(ENTER)
Bxy ROUTEVIDEOOUTPUTXTOINPUTY
Vxy ROUTEVIDEOOUTPUTXTOINPUT Y
T RUNLAMPTEST
D DUMPEXISTINGCONFIGURATION
I DISPLAYSIGNONMESSAGE
C CLEARLEDARRAY
H DISPLAYTHISHELPMESSAGE
Figure 3.1 Typical Help screen

KNOX VIDEO
SDI8x8 Routing Switcher
Page 9
[12/00]
SECTION4. MAINTENANCE
Note: Maintenance of the SDI8x8 should be performed by qualified service
people only.
4.1 INTRODUCTION
The SDI8x8 does not require any routine maintenance.
4.2 SWITCHOPTIONS
An 8-position switch, accessible through the rear panel, is provided for
setting the baud rate and certain programming functions.
Switch positions 1 and 2 are used to set the baud rate for the RS232 control
port. One of four baud rates may be selected as follows:
4.3 SETTINGTHEANSWERBACKMODE
The user may choose between two modes of answerback: verbose and non-
verbose. Select the mode using position 3 of the programming switch located on
the rear panel of the SDI8x8. Position 3 ON is verbose, while position 3 OFF is
non-verbose.
In the verbose mode, each time arouting command is sent, the currentrouting
map will be reported on the RS232 line followed by the word DONE.
In the non-verbose mode only the work DONE will be reported.
In either mode an incorrect or meaningless command will cause the word
ERRORto be reported.
Switch positions 5 through 8 are reserved for programming options not
covered here. Switches 5 through 8 should always be OFF. Switches are ON
when pushed up.
BAUDRATE
19200
1200
2400
9600
SWITCH1
ON
OFF
ON
OFF
SWITCH2
ON
ON
OFF
OFF
