KNX JUNG 23066REGHE User manual

Multi station
Multi station
Art. No. : 23066REGHE
Operating instructions
1 Safety instructions
Electrical devices may only be mounted and connected by electrically skilled
persons.
Serious injuries, fire or property damage possible. Please read and follow manual fully.
Danger of electric shock. Device is not suitable for disconnection from supply voltage.
For parallel connection of several motors to an output it is essential to observe the
corresponding instructions of the manufacturers, and to use a cut-off relay if necessary.
The motors may be destroyed.
Use only venetian blind motors with mechanical or electronic limit switches. Check the
limit switches for correct adjustment. Observe the specifications of the motor
manufacturers. Device can be damaged.
Danger of electric shock on the SELV/PELV installation. Do not connect loads for mains
voltage and SELV/PELV together on a single switch actuator.
These instructions are an integral part of the product, and must remain with the end
customer.
2 Device components
Figure 1
(1) Keypad for local control
(2) Programming button and LEDs
(3) Bus connection
(4) Input terminals
(5) Status LED
(6) Output terminals
1/7
82596803
j0082596803 26.01.2017

3 Function
System information
This device is a product of the KNX system and complies with the KNX directives. Detailed
technical knowledge obtained in KNX training courses is a prerequisite to proper understanding.
The function of this device depends upon the software. Detailed information on loadable
software and attainable functionality as well as the software itself can be obtained from the
manufacturer´s product database. Planning, installation and commissioning of the device are
carried out with the aid of KNX-certified software. The latest versions of product database and
the technical descriptions are available on our website.
Intended use
- Switching of electrical loads with potential-free contacts
- Switching of electrically-driven Venetian blinds, roller shutters, awnings and similar
hangings
- Switching of electrothermal actuators
- Polling of conventional switching or push-button contacts, window contacts etc. in KNX
systems, for reporting of states, meter levels, operation of loads, etc.
- Polling of external temperature sensors for heating control
- Logic functions to control building functions
- Mounting on DIN rail according to EN 60715 in distribution boxes
Product characteristics
- Actuator functions Switching, Venetian blind, electrothermal drives
- Actuator function switchable in pairs
- Integrated push-button interface with 6 inputs
- 2 inputs for temperature sensors
- Outputs can be operated manually
- Feedback in manual mode and in bus mode
- Scene function
- Disabling of individual outputs manually or by bus
Switching function
- Max. 6 switching outputs
- Operation as NO or NC contacts
- Logic and restraint function
- Feedback function
- Central switching function with collective feedback
- Time functions: switch-on delay, switch-off delay, staircase lighting timer with run-on time
Blind function
- Max. 3 Venetian blind outputs
- Suitable for 230 V AC motors
- Blind/shutter position directly controllable
- Slat position directly controllable
- Feedback of movement status, blind/shutter position and slat position
- Forced position through higher-level controller
- Safety function: 3 independent wind alarms, rain alarm, frost alarm
- Sun protection function
Actuator function
- Max. 2 outputs for electrothermal drives
- Switching operation or PWM operation
- Actuators with characteristics opened or closed without power controllable
- Emergency operation in case of bus voltage failure for summer and winter
- Protection against seized valves
- Forced position
- Cyclical monitoring of the input signals can be parameterized
iPWM operation: electrothermal actuators only have the positions Open and Closed. In
PWM operation, switch-on and switch-off during the drive's cycle time achieves an almost
constant behaviour. Cycle times < 15 minutes shorten the lifespan of the relay outputs
2/7
82596803
j0082596803 26.01.2017
Multi station

Heating controller
- 2 internal controllers to control two independent rooms
Control for heating or cooling operation, optionally with additional level
- Two-point, PWM or PI control
- Predefined heating types (hot water heating, blower convector, etc.) or individual
parameters possible
Inputs
- 6 inputs for push-buttons
- Input functions switching, dimming, shutter control, light scene extension unit, brightness or
temperature value transmitter
- 2 inputs for external temperature sensors
Logic functions
- Up to 10 logic operations with up to 8 inputs each, e.g. for AND, OR and exclusive OR
operations
- Conversion of data point types, e.g. 1-bit to 8-bit
- Comparison operations, e.g. <, >, ≤, ≥
- Arithmetic functions, e.g. +, –, *, :
4 Operation
Continuous manual mode
oActivate: Press the c
button for approx. 5 s.
LED c lights up, LED A1 flashes.
oDeactivate: Press the c button for approx. 5 s.
Short-time manual operation
oActivate: Press the c button briefly.
Automatic return to bus operation 5 s after last operation
Operating an output in manual mode
oKeep pressing the c button until the LED (5) of the selected output flashes.
oPress the ON/n or OFF/o button.
Short: Switch on / switch off, adjust slats or stop.
Long: Move hanging upwards/downwards.
LED ON/n on: Output on
LED OFF/o on: Output off
Switch off all
oActivate permanent manual operation.
oPress the ALL OFF button.
Block/enable individual outputs
oActivate permanent manual operation.
oKeep pressing the c button until the LED (5) of the selected output flashes.
oPress the ON/n and the OFF/o button simultaneously for at least 5 s.
The status LED A1... of the blocked output flashes quickly.
5 Information for electrically skilled persons
Mortal danger of electric shock.
Disconnect device. Cover up live parts.
3/7
82596803
j0082596803 26.01.2017
Multi station

Fitting the device
Observe the temperature range. Ensure adequate cooling.
oMount the device on DIN rail. Output terminals must be at the top.
Connecting the device
Figure 2
oConnect bus line with connecting terminal.
oAttach the cover cap to the bus cable connection as protection against hazardous voltages.
oFor switched loads, configure the outputs as a switching output.
oFor Venetian blind operation, configure the outputs as a Venetian blind output. Two
adjacent relay outputs form a Venetian blind output. In each case, the left-hand relay
output A1, A3, A5 is intended for the up direction n, and the right-hand load output A2,
A4, A6 for the down direction o.
oConnect electrothermal drives to relay outputs A1, A2 .
iDelivery state: The outputs can be operated using a keypad. Outputs are set as venetion
blind outputs.
Switching inputs
DANGER!
When the mains voltage is connected to the input terminals (4), the bus voltage
is connected to the mains potential.
People at remote devices may also receive an electric shock. Connected bus
devices are destroyed.
Never connect to the inputs to the mains voltage of FELV circuits.
4/7
82596803
j0082596803 26.01.2017
Multi station

Figure 3
Do not route input cables parallel to mains cables. Otherwise, EMC interference may occur.
For cable lengths > 3 m , use a shielded two-wire cable.
oConnect window contacts, NO or NC push-buttons to the terminals C and 1...6 .
oConnect the temperature sensor to the terminals TC and T1 or T2 .
Venetian blind outputs: Measuring the hanging and slat travel time
The blind/shutter travelling time is important for position and scene runs. For slatted Venetian
blinds the slat adjusting time is by design part of the overall blind/shutter travelling time. The
opening angle of the slats is therefore set as the operation time between the positions "Open"
and "Closed".
The upwards travel generally lasts longer than the downwards travel, and is taken into account
as the operation time extension in %.
oMeasure upwards and downwards operation time of the hanging.
oMeasure slat adjusting time between "Open" and "Closed".
oEnter the measured values in the parameter setting – Downwards travel in
minutes/seconds and operation time extension in percent.
Load the address and the application software
oSwitch on the bus voltage.
oPress the programming button.
The programming LED lights up.
oAssign physical address.
The programming LED goes out.
oWrite the physical address on the device label.
oLoad the application software into the device.
6 Technical data
KNX
KNX medium TP 256
Commissioning mode S-mode
Rated voltage KNX DC 21 ... 32VSELV
Current consumption KNX max. 20mA
Current consumption KNX min. 4mA
Connection type for bus device connection terminal
Power loss max. 6W
Ambient conditions
Ambient temperature -5 ... +45°C
Storage/transport temperature -25 ... +70°C
Relay outputs
Contact type µ contact, potential-free NO contact
Switching voltage AC 250V ~
Minimum switching current AC 100mA
5/7
82596803
j0082596803 26.01.2017
Multi station

Switching current AC1 16A
Switching current AC3 6A
Fluorescent lamps 16AX
Switch-on current 200 µs max. 800A
Switch-on current 20 ms max. 165A
Switching voltage DC DC 12 ... 24V
Switching current DC 24 V 6A
Connected load 230 V
Ohmic load 3000W
Blind, fan motors 1380VA
Lamp loads 230 V
Incandescent lamps 3000W
HV halogen lamps 2500W
HV-LED lamps max. 400W
Electronic transformers 1500W
Inductive transformers 1200VA
Fluorescent lamps T5/T8
uncompensated 1000W
parallel compensated 1160W (140 µF)
twin-lamp circuit 2300W (140 µF)
Compact fluorescent lamps
uncompensated 1000W
parallel compensated 1160W (140 µF)
Mercury vapour lamps
uncompensated 1000W
parallel compensated 1160W (140 µF)
Electrothermal actuators
Cycle time min. 15min
Load connections
Connection mode Screw terminal
single stranded 0.5 ... 4mm²
Finely stranded without conductor sleeve 0.5 ... 4mm²
Finely stranded with conductor sleeve 0.5 ... 2.5mm²
Inputs
Rated voltage DC 3.3VSELV
Signal duration min. 100ms
NO contacts max. 50
NC contacts max. 50
Cable length max. 30m
Input connections
single stranded 0.08 ... 1.5mm²
Finely stranded without conductor sleeve 0.08 ... 1.0mm²
Finely stranded with conductor sleeve 0.14 ... 0.5mm²
Fitting width 72mm / 4modules
Weight approx. 290g
