Kobold DAG-A3T User manual

Operating Instructions
for
Digital Indicating Unit for
Panel Mounting
Model: DAG-A3T
Thermocouple type K, B, S, N, E, T, R, L, J

DAG-A3T
page 2 DAG-A3T K07_0423
We don’t accept warranty and liability claims neither upon this publication nor in
case of improper treatment of the described products.
The document may contain technical inaccuracies and typographical errors. The
content will be revised on a regular basis. These changes will be implemented in
later versions. The described products can be improved and changed at any time
without prior notice.
© Copyright
All rights reserved.
1. Contents
1.Contents ........................................................................................................ 2
2.Note .............................................................................................................. 3
3.Instrument Inspection .................................................................................... 3
4.Regulation Use ............................................................................................. 3
5.Assembly ...................................................................................................... 4
6.Electrical connection ..................................................................................... 5
7.Function description and operation ............................................................... 6
8.Setting up the device ..................................................................................... 7
8.1Switching on ........................................................................................ 7
8.2Standard parameterization: .................................................................. 7
8.3Programming interlock RUN ................................................................ 8
8.4Extended parameterization .................................................................. 8
9.Reset to default values ................................................................................ 10
10.Functional principle of the switching points ................................................. 11
11.Technical Information .................................................................................. 12
12.Order Codes ............................................................................................... 12
13.Dimensions ................................................................................................. 12
14.Safety advice .............................................................................................. 13
15.Error elimination .......................................................................................... 14
16.Disposal ...................................................................................................... 15
17.EU Declaration of Conformance ................................................................. 16
18.UK Declaration of Conformity ...................................................................... 17
Manufactured and Sold by:
Kobold Messring GmbH
Nordring 22-24
D-65719 Hofheim
Tel.: [phone]
Fax: [phone]
E-Mail: [email protected]
Internet: www.kobold.com

DAG-A3T
DAG-A3T K07_0423 page 3
2. Note
Please read these operating instructions before unpacking and putting the unit into
operation. Follow the instructions precisely as described herein.
The instruction manuals on our website www.kobold.com are always for currently
manufactured version of our products. Due to technical changes, the instruction
manuals available online may not always correspond to the product version you
have purchased. If you need an instruction manual that corresponds to the
purchased product version, you can request it from us free of charge by email
([email protected]) in PDF format, specifying the relevant invoice number and
serial number. If you wish, the operating instructions can also be sent to you by
post in paper form against an applicable postage fee.
Operating instructions, data sheet, approvals and further information via the QR
code on the device or via www.kobold.com
The devices are only to be used, maintained and serviced by persons familiar with
these operating instructions and in accordance with local regulations applying to
Health & Safety and prevention of accidents.
When used in machines, the measuring unit should be used only when the
machines fulfil the EC-machine guidelines.
3. Instrument Inspection
Instruments are inspected before shipping and sent out in perfect condition.
Should damage to a device be visible, we recommend a thorough inspection of the
delivery packaging. In case of damage, please inform your parcel service /
forwarding agent immediately, since they are responsible for damages during
transit.
Scope of delivery:
The standard delivery includes:
 Digital Indicating Unit model: DAG-A3T
4. Regulation Use
Any use of the device, which exceeds the manufacturer’s specification, may
invalidate its warranty. Therefore, any resulting damage is not the responsibility of
the manufacturer. The user assumes all risk for such usage.

DAG-A3T
page 4 DAG-A3T K07_0423
5. Assembly
Please read the Safety advice on page 19 before installation and keep this user
manual for future reference
1. After removing the fixing elements, insert the device.
2. Check the seal to make sure it fits securely.
3. Click the fixing elements back into place and tighten the
clamping screws by hand. Then use a screwdriver to
tighten them another half a turn.
CAUTION! The torque should not exceed 0.1 Nm!

DAG-A3T
DAG-A3T K07_0423 page 5
6. Electrical connection
Advice:
The galvanic isolation in devices with temperature sensors that do not have a
galvanic connection to an extrinsic potential, can be cancelled by an bridge from
terminal 3 to 4 and thus stabilise the device against external failures.
Devices with a 230 VAC supply need a connection from terminal 3 to signal ground.

DAG-A3T
page 6 DAG-A3T K07_0423
7. Function description and operation
Operation
The operation is divided into two different levels.
Menu Level
Here it is possible to navigate between the individual menu items.
Parameterization level:
The parameters stored in the menu item can be parameterized here.
Functions that can be adjusted or changed are always indicated with a flashing of
the display. Adjustments made at the parameterization level should be always
confirmed by pressing the [P] key to save them.
However, the display automatically saves all adjustments and then switches to
operation mode if no further keys are pressed within 10 seconds.

DAG-A3T
DAG-A3T K07_0423 page 7
8. Setting up the device
8.1 Switching on
Once the installation is complete, you can start the device by applying the current
loop. Check beforehand once again that all the electrical connections are correct.
Starting sequence
For 1 second during the switching-on process, the segment test (8 8 8 8 8) is
displayed, followed by an indication of the software type and, after that, also for
1 second, the software version. After the start-up sequence, the device switches
to operation/display mode.
8.2 Standard parameterization:
To be able to parameterize the display, press the [P] key in operating mode for 1
second. The display then changes to the menu level with the first menu item TYPE.

DAG-A3T
page 8 DAG-A3T K07_0423
8.3 Programming interlock RUN
8.4 Extended parameterization
By pressing the [▲] & [▼] buttons during standard parameterization for one
second, the display switches to the extended parameterization mode. Operation is
the same as in standard parameterization.

DAG-A3T
DAG-A3T K07_0423 page 9

DAG-A3T
page 10 DAG-A3T K07_0423
9. Reset to default values
To return the unit to a defined basic state, a reset can be carried out to the default
values.
The following procedure should be used:
 Switch off the power supply
 Press button [P]
 Switch on voltage supply and press [P]-button until
„--- -“ is shown in the display.
With reset, the default values of the program table are loaded and used for
subsequent operation. This puts the unit back to the state in which it was supplied.
Caution! All application-related data are lost.

DAG-A3T
DAG-A3T K07_0423 page 11
10. Functional principle of the switching points
Limit value exceedance “HIGH”
The switching point S1-S2 is “off” below the threshold and “on” on reaching the
threshold.
Limit value undercut “LOW”
The switching point S1-S2 is “on” below the threshold and switched “off” on
reaching the threshold.

DAG-A3T
page 12 DAG-A3T K07_0423
Alarms / optical switching point display
An activated set point can be optically indicated by flashing of the 7-segment
display.
Functional principle of the alarms
Alarm Deactivated, display value
Threshold Threshold/limit value for switch over
Hysteresis Width of the window between the thresholds
Operating principle Limit value exceedance / limit value
undercut
11. Technical Information
Operating instructions, data sheet, approvals and further information via the QR
code on the device or via www.kobold.com
12. Order Codes
Operating instructions, data sheet, approvals and further information via the QR
code on the device or via www.kobold.com
13. Dimensions
Operating instructions, data sheet, approvals and further information via the QR
code on the device or via www.kobold.com

DAG-A3T
DAG-A3T K07_0423 page 13
14. Safety advice
Please read the following safety advice and the assembly chapter 5 before
installation and keep it for future reference.
Proper use
The DAG-A3T-device is designed for the evaluation and display of sensor signals.
Danger! Careless use or improper operation can result in
personal injury and/or damage to the equipment.
Control of the device
The panel meters are checked before dispatch and sent out in perfect condition.
Should there be any visible damage, we recommend close examination of the
packaging. Please inform the supplier immediately of any damage.
Installation
The DAG-A3T-device must be installed by a suitably qualified specialist (e.g. with
a qualification in industrial electronics).
Notes on installation
• There must be no magnetic or electric fields in the vicinity of the device,
e.g. due to transformers, mobile phones or electrostatic discharge.
• The fuse rating of the supply voltage should not exceed a value of 6A N.B. fuse.
• Do not install inductive consumers (relays, solenoid valves etc.) near the
device and suppress any interference with the aid of RC spark
extinguishing combinations or free- wheeling diodes.
• Keep input, output and supply lines separate from each other and do not lay
them parallel with each other. Position “go” and “return lines” next to one
another. Where possible use twisted
pair. So, the best measuring results
can be received.
• Screen off and twist sensor lines. Do not lay current-carrying lines in the
vicinity. Connect the screening on one side on a suitable potential
equaliser (normally signal ground).
• The device is not suitable for installation in areas where there is a risk of
explosion.
• Any electrical connection deviating from the connection diagram can
endanger human life
and/or can destroy the equipment.
• The terminal area of the devices is part of the service. Here electrostatic
discharge needs to be avoided. Attention! High voltages can cause dangerous
body currents.

DAG-A3T
page 14 DAG-A3T K07_0423
• Galvanic insulated potentials within one complex need to be placed on an
appropriate point (normally earth or machines ground). So, a lower disturbance
sensibility against impacted energy can be reached and dangerous potentials,
that can occur on long lines or due to faulty wiring, can be avoided
15. Error elimination

DAG-A3T
DAG-A3T K07_0423 page 15
16. Disposal
Note!
 Avoid environmental damage caused by media-contaminated parts
 Dispose of the device and packaging in an environmentally friendly manner
 Comply with applicable national and international disposal regulations and
environmental regulations.
Batteries
Batteries containing pollutants are marked with a sign consisting of a crossed-out
garbage can and the chemical symbol (Cd, Hg, Li or Pb) of the heavy metal that
is decisive for the classification as containing pollutants:
Cd1 Hg2 Pb3 Li4
1. „Cd" stands for cadmium
2. „Hg" stands for mercury
3. „Pb" stands for lead
4. „Li" stands for lithium
Electrical and electronic equipment

DAG-A3T
page 16 DAG-A3T K07_0423
17. EU Declaration of Conformance
We, KOBOLD Messring GmbH, Hofheim-Ts, Germany, declare under our sole
responsibility that the product:
Digital Indicating Unit Model: DAG-A3T
to which this declaration relates is in conformity with the standards noted below:
EN 61010-1:2010+A1:2019+A1:2019/AC:2019
Safety requirements for electrical equipment for measurement, control and
laboratory use
EN 61326-1:2013
Electrical equipment for measurement, control and laboratory use - EMC
requirements - Part 1: General requirements
EN 63000:2018
Technical documentation for the assessment of electrical and electronic products
with respect to the restriction of hazardous substances
Also, the following EC guidelines are fulfilled:
2014/30/EU EMC Directive
2014/35/EU Low Voltage Directive
2011/65/EU RoHS (category 9)
2015/863/EU Delegated Directive (RoHS III)
Hofheim, 06 Okt. 2022
H. Volz M. Wenzel
General Manager Proxy Holder

DAG-A3T
DAG-A3T K07_0423 page 17
18. UK Declaration of Conformity
We, KOBOLD Messring GmbH, Hofheim-Ts, Germany, declare under our sole
responsibility that the product:
Digital Indicating Unit for Panel Mounting Model: DAG-A3T
to which this declaration relates is in conformity with the standards noted below:
BS EN 61010-1:2010+A1:2019
Safety requirements for electrical equipment for measurement, control, and
laboratory use. General requirements
BS EN 61326-1:2013
Electrical equipment for measurement, control and laboratory use. EMC
requirements. General requirements
BS EN IEC 63000:2018
Technical documentation for the assessment of electrical and electronic products
with respect to the restriction of hazardous substances.
Also, the following UK guidelines are fulfilled:
S.I. 2016/1091 Electromagnetic Compatibility Regulations 2016
S.I. 2016/1101 Electrical Equipment (Safety) Regulations 2016
S.I. 2012/3032 The Restriction of the Use of Certain Hazardous Substances
in Electrical and Electronic Equipment Regulations 2012
Hofheim, 28 April 2023
H. Volz M. Wenzel
General Manager Proxy Holder

