Kobold DAG-M3T User manual

Operating Instructions
for
Digital Indicator and Controller
for Panel Mounting
Model: DAG-M3T

DAG-M3T
page 2 DAG-M3T K06/0623
We don’t accept warranty and liability claims neither upon this publication nor in
case of improper treatment of the described products.
The document may contain technical inaccuracies and typographical errors. The
content will be revised on a regular basis. These changes will be implemented in
later versions. The described products can be improved and changed at any time
without prior notice.
© Copyright
All rights reserved.
1. Contents
1.Contents ........................................................................................................ 2
2.Note .............................................................................................................. 4
3.Instrument Inspection .................................................................................... 4
4.Regulation Use ............................................................................................. 5
5.Brief description ............................................................................................. 5
6.Assembly ...................................................................................................... 6
7.Electrical connection ..................................................................................... 7
8.Function description and operation ............................................................... 8
9.Setting up the device ................................................................................... 10
9.1Switching on ...................................................................................... 10
9.2Standard parameterization (Flat operation level) ............................... 10
9.3Programming interlock RUN .............................................................. 12
9.4Extended parameterization (Professional operation level) ................. 13
10.Reset to default values ................................................................................ 24
11.Alarms / Relays ........................................................................................... 24
12.Interfaces .................................................................................................... 26
13.Technical Information .................................................................................. 27
14.Order Codes ............................................................................................... 27
15.Dimensions ................................................................................................. 27
16.Safety advices ............................................................................................. 28
17.Error elimination .......................................................................................... 30
18.Disposal ...................................................................................................... 31
19.EU Declaration of Conformance ................................................................. 32
20.UK Declaration of Conformity ...................................................................... 33
21.Appendix MODBUS Device Interface .......................................................... 34

DAG-M3T
DAG-M3T K06/0623 page 3
Manufactured and sold by:
Kobold Messring GmbH
Nordring 22-24
D-65719 Hofheim
Tel.: [phone]
Fax: [phone]
E-Mail: [email protected]
Internet: www.kobold.com

DAG-M3T
page 4 DAG-M3T K06/0623
2. Note
Please read these operating instructions before unpacking and putting the unit into
operation. Follow the instructions precisely as described herein.
The instruction manuals on our website www.kobold.com are always for currently
manufactured version of our products. Due to technical changes, the instruction
manuals available online may not always correspond to the product version you
have purchased. If you need an instruction manual that corresponds to the
purchased product version, you can request it from us free of charge by email
([email protected]) in PDF format, specifying the relevant invoice number and
serial number. If you wish, the operating instructions can also be sent to you by
post in paper form against an applicable postage fee.
Operating instructions, data sheet, approvals and further information via the QR
code on the device or via www.kobold.com
The devices are only to be used, maintained and serviced by persons familiar with
these operating instructions and in accordance with local regulations applying to
Health & Safety and prevention of accidents.
When used in machines, the measuring unit should be used only when the
machines fulfil the EC machinery directive.
3. Instrument Inspection
Instruments are inspected before shipping and sent out in perfect condition.
Should damage to a device be visible, we recommend a thorough inspection of the
delivery packaging. In case of damage, please inform your parcel service /
forwarding agent immediately, since they are responsible for damages during
transit.
Scope of delivery:
The standard delivery includes:
 Digital Indicator and Controller model: DAG-M3T

DAG-M3T
DAG-M3T K06/0623 page 5
4. Regulation Use
Any use of the device, which exceeds the manufacturer’s specification, may
invalidate its warranty. Therefore, any resulting damage is not the responsibility of
the manufacturer. The user assumes all risk for such usage.
5. Brief description
The panel meter instrument DAG-M3T is a 5-digit device for Thermocouple and a
visual threshold value monitoring via the display. The configuration happens via
four keys at the front. The integrated programming interlock prevents unrequested
changes of parameters and can be unlocked again with an individual code.
Optional available is one analogue output for further evaluating in the unit. With
help of the two galvanic isolated setpoints (optional), free adjustable limit values
can be controlled and reported to a superior master display. The electrical
connection is done via plug-in terminals on the back side. Selectable functions like
e.g. the recall of the min/max-value, a direct threshold value regulation during
operation mode, complete the modern device concept.

DAG-M3T
page 6 DAG-M3T K06/0623
6. Assembly
Please read the Safety advices on page 28 before installation and keep this user
manual for future reference.
1. After removing the fixing elements, insert the device.
2. Check the seal to make sure it fits securely.
3. Click the fixing elements back into place and tighten the clamping screws by
hand. Then use a screwdriver to tighten them another half a turn.
CAUTION! The torque should not exceed 0.1 Nm!
The dimension symbols can be exchanged before installation via a channel
on the side!

DAG-M3T
DAG-M3T K06/0623 page 7
7. Electrical connection
Type DAG-M3T8000R supply 100-240 VAC 50/60 Hz, DC ±10%
Type DAG-M3T7000R supply 10-40 VDC galv. isolated, 18-30 VAC 50/60 Hz

DAG-M3T
page 8 DAG-M3T K06/0623
8. Function description and operation
Operation
The operation is divided into three different levels.
Menu level (delivery status)
This level is for the standard settings of the device. Only menu items which are
sufficient to set the device into operation are displayed. To get into the professional
level, run through the menu level and parameterize “prof” under menu item RUN.
Menu group level (complete function volume)
Suited for complex applications as e.g. linkage of alarms, setpoint treatment,
totalizer function etc. In this level function groups which allow an extended
parameterization of the standard settings are available. To leave the menu group
level, run through this level and parameterize “uloc” under menu item RUN.
Parameterization level
Parameter deposited in the menu item can here be parameterized. Functions, that
can be changed or adjusted, are always signalized by a flashing of the display.
Settings that are made in the parameterization level are confirmed with [P] and
thus saved. By pressing the [0]-key it leads to a break-off of the value input and to
a change into the menu level. All adjustments are saved automatically by the
device and changes into operating mode, if no further key operation is done within
the next 10 seconds.

DAG-M3T
DAG-M3T K06/0623 page 9
Function chart:

DAG-M3T
page 10 DAG-M3T K06/0623
9. Setting up the device
9.1 Switching on
Once the installation is complete, you can start the device by applying the voltage
supply. Before, check once again that all electrical connections are correct.
Starting sequence
For 1 second during the switching-on process, the segment test (8 8 8 8 8) is
displayed followed by an indication of the software type and, after that, also for 1
second the software version. After the starting sequence, the device switches to
operation / display mode.
9.2 Standard parameterization (Flat operation level)
To parameterize the display, press the [P] key in operating mode for 1 second.
The display then changes to the menu level with the first menu item TYPE.

DAG-M3T
DAG-M3T K06/0623 page 11

DAG-M3T
page 12 DAG-M3T K06/0623
9.3 Programming interlock RUN

DAG-M3T
DAG-M3T K06/0623 page 13
9.4 Extended parameterization (Professional operation level)
9.4.1 Signal input parameters

DAG-M3T
page 14 DAG-M3T K06/0623

DAG-M3T
DAG-M3T K06/0623 page 15
9.4.2 General device parameters

DAG-M3T
page 16 DAG-M3T K06/0623

DAG-M3T
DAG-M3T K06/0623 page 17
9.4.3 Safety parameters

DAG-M3T
page 18 DAG-M3T K06/0623
9.4.4 Serial parameters

DAG-M3T
DAG-M3T K06/0623 page 19
9.4.5 Analogue output parameters

DAG-M3T
page 20 DAG-M3T K06/0623
