KodaCloud OAP30 User manual

OAP30 Dual Band
Installation Guide
Access Point
Installation Guide

Package Contents

Step 1 - Connect the Access Point
A Connect one end of the Ethernet cable to the LAN1 Port (PoE of the access point and
the other end to the LAN + PoE (Power-over-Ethernet .
B Screw on the antennas (supplied separately as shown in the following illustration.
C Connect the ground wire to the access point.
Note: The access point supports both IEEE 802.3at PoE (Power-over-Ethernet) supplie by a
switch, or using a PoE Injector. You may use either one as the power source. DO NOT
use both at the same time.

Step 2 – Mount the Access Point
Wall Mounting
A Determine where the AP is to be placed and mark location on the surface for the four
mounting holes. You may adjust the position with a level.
B Use the appropriate drill bit to drill four 8 mm diameter and 37 mm depth holes in the
markings and hammer the bolts into the openings.

C Place the lock and flat washer on the round head screws and drive the screws to attach
mounting base to the back of the access point.

D Attach the device onto the wall by tightening the bolt’s flat washers and nuts to secure
the mounting base to the mounting surface. Connect the ground wire (not shown to a
grounding point.

Pole Mounting
A Place the lock and flat washer on the round head screws and drive the screws to attach
the mounting base to the back of the access point.

B Determine which placement to be assembled. Drive the four round head screws to attach
the pole mount bracket to the mounting base.

C Thread the open end of the pole strap through the two tabs on the pole mount bracket.

D Determine where the AP is to be fastened. Lock and tighten pole strap to secure pole
mount bracket to the pole. Connect the ground wire (not shown to a grounding point.

Step 3 - Verif connectivit
Verify that the OAP30 access point is connected to your network with either the KodaCloud
website or the KodaCloud mobile device app.
Check the Power LED to determine whether the access point is operating correctly. The
access point is properly installed and connected to the KodaCloud management services when
the LED turns solid green after a few minutes.
When the access point is powered on, the Power LED should display the following sequence:
# Power LED Description
1
Power LED
Solid
Orange and a
ll other
LEDs on
(for less than 10 secon s)
Unit has just received power and has
started booting
2
Power LED Solid
Orange and a
ll other
LEDs off
(for less than a few minutes)
Unit is starting up.
3
Blinking Green
(for less than a minute)
A
ccess point
is negotiating a connection
with KodaCloud management services in
the cloud.
4
Solid Green
A
ccess point
is successfully
setup to be
managed by KodaCloud management
services in the cloud.
Note 1: The very first time the Access Point is connecte , it will self-up ate so it will go
through this sequence twice
LED
LED Description
5 GHz
Green: 5 GHz radio
is active (off otherwise
2.4 GHz
Green: 2.4 GHz radio is active (off otherwise
LAN 2
Green: Ethernet Link on LAN2 Port (off otherwise
LAN 1
Green: Ethernet Link on LAN1 Port (off otherwise

Note 2: See the Tips an Troubleshooting section if the access point oes not reach Soli
Green. For a full escription of LED Description visit the Support website
(http://Ko aClou .com/support).
Step 4 - Configure the Access Point
Use your mobile device or the KodaCloud website.
Website
Sign into your account at http://KodaCloud.com and follow the instructions in the KodaCloud
website to complete the process.
Mobile Device
Information about the mobile app is available at http://KodaCloud.com. The mobile device
app includes instructions for completing the process.
If you have any trouble, please contact [e-mail] and we’ll be happy to help!

Tips and Troubleshooting
If our access point Power LED light is flashing orange and all other LEDs are off for over
10 minutes
The access point cannot connect to the KodaCloud management services. This usually occurs
when the unit cannot get an IP address from your network using DHCP and has switched to
Local Network Configuration mode.
While in this mode, the access point does not pass data through the LAN1 port and broadcasts
an SSID that contains a portion of the access point’s MAC address. You can use any Wi-Fi
enabled device to connect to this SSID and configure the network settings for this access point
using a web browser.
To connect to the access point using the Local Network Configuration interface:
1. Connect your Wi-Fi enabled device to the SSID in the form of “AP-XX:XX:XX” (where
X is a placeholder . You are successfully connected when the Power LED on the
access point becomes solid red.
2. Use your web browser to navigate to http://192.168.100.1 (login using user: admin,
password: admin .
3. Follow the on-screen instructions
See the Support section (http://kodacloud.com/support for information about Local Network
Configuration.
Note: Local Configuration mo e only activates if the access point is in factory efault
con ition an has never connecte to the Ko aClou management services in the clou .
Learning More, Service, and Support
Online Resources
Our support website (http://kodacloud.com/support contains links to online resources
available to help you get the most out of your access point.
Cop right and Trademark
Copyright © 2016 KodaCloud, Inc. All rights reserved. The contents of this Installation Guide
are the copyrighted and proprietary property of KodaCloud, Inc. Reproduction, distribution
or modification without the express, written permission of KodaCloud, Inc. is not permitted.
“Art2Wave” and “KodaCloud” are trademarks of KodaCloud, Inc. All other trademarks are the
property of their respective owners.

Open Source Code
Certain KodaCloud products include open source software code subject to the GNU General
Public License (GPL and other Open Source Licenses. For more information, see:
http://KodaCloud.com/opensource
Legal Notice
EXCEPT FOR ANY WRITTEN EXPRESS WARRANTY WE MAY SEPARATELY OFFER TO YOU, AND TO
THE EXTENT PERMITTED BY LAW, THIS PRODUCT IS PROVIDED “AS IS” AND WE SPECIFICALLY
DISCLAIM ALL EXPRESS, STATUTORY AND IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED
TO, WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, NON-
INFRINGEMENT AND AGAINST HIDDEN OR LATENT DEFECTS. IF WE CANNOT LAWFULLY
DISCLAIM STATUTORY OR IMPLIED WARRANTIES, THEN TO THE EXTENT PERMITTED BY LAW,
ALL SUCH WARRANTIES SHALL BE LIMITED IN DURATION TO THE DURATION OF ANY WRITTEN
EXPRESS WARRANTY WE MAY SEPARATELY OFFER TO YOU, AS APPLICABLE, AND TO REPAIR OR
REPLACEMENT SERVICE. SOME JURISDICTIONS DO NOT ALLOW LIMITATIONS ON HOW LONG A
STATUTORY OR IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO
YOU. WE ARE NOT RESPONSIBLE FOR DIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL
DAMAGES RESULTING FROM ANY BREACH OF WARRANTY OR UNDER ANY OTHER LEGAL THEORY.
IN SOME JURISDICTIONS THE FOREGOING LIMITATION DOES NOT APPLY TO DEATH OR
PERSONAL INJURY CLAIMS, OR ANY STATUTORY LIABILITY FOR INTENTIONAL AND GROSS
NEGLIGENT ACTS AND/OR OMISSIONS, SO THE ABOVE EXCLUSION OR LIMITATION MAY NOT
APPLY TO YOU. SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF
DIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE EXCLUSION OR LIMITATION
MAY NOT APPLY TO YOU.

OAP30 Specifications and Safet Guidelines
Specifications:
Frequency Bands: Programmable for different country regulations
Radio 1 – 2.400 to 2.484 GHz
Radio 2 - 5.150 – 5.250 GHz, 5.725 – 5.850 GHz
Standards: Radio 1 2.4G IEEE 802.11 b/g/n, Radio 2 5G IEEE 802.11 a/n/ac
Input voltage and current: 54VDC @ 1.2A
Interfaces:
RJ-45 for 10/100/1000 Gigabit Ethernet
2
nd
RJ45 port support 802.3af (15.4W PSE
6 N-Type connector
Environmental Specifications:
Operating Temperature: -40℃ to 60℃
Storage Temperature: -40℃ to 70℃ (-40°F to 158°F)
Humidify: 5% ∼ 90% typical (non-condensing
Antenna Specifications:
Antenna: N-type Dipole
Peak Gain: 4.5 dBi @ 2.4 GHz / 6 dBi @ 5 GHz
Caution:
Safety caution: The unit should be connected to PoE networks only, without routing to the
outside plant.
